Network Adapters SMC-GT1255FTX-SC
EZ Card™ 10/100 Mbps Combo Adapter
www.smc.com
The EZ Card™ 10/100 Mbps Combo Adapter
(SMC-GT1255FTX-SC) is an auto-sensing adapter that is
designed to support today's popular Ethernet-based
applications as well as tomorrow's next generation power
applications. To ensure network reliability, the
EZ Card™ 10/100 Mbps Combo Adapter (SMC-
GT1255FTX-SC) is compliant with most PCI standards
and contains a RJ-45 and Fiber SC port. The SMC-
GT1255FTX-SC fiber media provides added versatility
and future-proof networking. Its ease of use and highly
integrated design results in improved quality, control and
reliability. The SMC-GT1255FTX-SC supports a single
RJ-45 port for 10Mbps and 100Mbps, SC fiber port, and
optional ST connector. This multi-functional design auto-
matically senses media type, defaulting to 100Base-FX.
The SMC-GT1255FTX-SC is also trade compliant making it
a terrific solution for government agencies looking for
network flexibility. Additional features include flow con-
trol, Wake-on-LAN functionality, 4-easy to read LEDs,
and a broad range of driver support.
FEATURES
Dual-port design
32-bit PCI bus-master architecture
Dual-speed 10/100 Mbps, full-duplex and
auto-negotiation support
Auto-configures on power-up
Diagnostic LEDs
Management
Fiber(SC) and RJ-45 connectors for network versatility. SC
to ST converter is also available.
Supports 32-bit data transfer; bus-mastering reduces CPU
utilization and improves throughput
Support for 10 Mbps and 100 Mbps data rates enable easy,
cost-effective additional bandwidth
Simple, quick and easy installation
Provides clear data on status of network and card
Wake-on-LAN for remote management. Optional BootROM
(PXE/RPL) for centralized or remote booting.
BENEFITS
OVERVIEW

TECHNICAL SPECIFICATIONS SMC-GT1255FTX-SC
FEATURES
• Full-Duplex/ Half-duplex operation
• Auto-negotiation
• Diagnostic LEDs
• Flow-control
• On-board socket of optional boot-ROM
• Wake-on-LAN
MANAGEMENT
• Management
• SNMP (coming soon)
• Support for up to 16 VLANs (coming soon)
LEDs
• Link, Activity, Speed, Duplex
BUS INTERFACE
• 32-bit PCI, v.2.2
CONNECTOR
• 10BASE-T/100BASE-TX (RJ-45)
• 100BASE-FX (SC)
DRIVERS
• Windows 9x, ME, NT, 2000, XP
• Dos (NDIS2, ODI, Packet)
• Novell Netware 3.12, 4.x, 5.x, 6.0
• Linux, SCO Unix 5, Unixware 7
• Mac OS
COMPATIBLE
• IEEE 802.3, IEEE 802.3u, IEEE 802.3x,
IEEE 802.1q, PCI bus v.2.2, ACPI
WARRANTY
• Limited Lifetime
DIMENSIONS (without bracket)
• 4.72 x 1.62 in
• 11.92 x 4.11 cm
WEIGHT
• 0.10 lbs
•45.3 g North America
