Supports up to four switches with cables included
Thermal overload protection
Over-voltage protection for each output channel
Over-current protection
Short-circuit protection against output channels
Power Unit SMCRPU14
44PPoorrttRReedduunnddaannttPPoowweerrUUnniitt
www.smc.com
Redundant power units provide an easy to
install and use method of giving you the peace
of mind required when managing safety toler-
ant systems.
This Redundant Power Unit (SMCRPU14) can
supply 600 Watts of backup power to four
switches in the event of an AC loss or failure
of an internal power supply. It ships with four
DC Backup Power Cords included (IEC connec-
tors). Thermal overload protection prevents
the RPU from overheating if a thermal over-
load occurs. Over-voltage protection shuts
down an output channel if the voltage exceeds
a preset threshold whereas over-current pro-
tection shuts down the RPU if the output load
exceeds a preset threshold. Short-circuit pro-
tection prevents the RPU from being damaged
from a short circuit on any output channel.
Four status indicators for Link, Activity, Fan,
Thermal, and Power are located on the RPUs
front panel. While the AC supply and DC back-
up receptacles are located on the RPUs rear
panel. The SMCRPU14 can be mounted in a
standard 19-inch equipment rack(brackets
included) or on a flat surface.
FEATURES
OVERVIEW

TECHNICAL SPECIFICATIONS SMCRPU14
PORTS
4 RPU DC power outlets (IEC socket 216C743-07)
LEDS
Port: Link, Activity
System: Power, Fan, Thermal
WEIGHT
5.5 kg (12.1 lbs)
DIMENSIONS
44.0 x 32.3 x 4.3 cm (17.34 x 12.6 x 1.69 in.)
TEMPERATURE
Operating: 0 to 45 °C (32 to 110°F)
Storage: -40 to 70 °C (-40 to 158 °F)
HUMIDITY
Operating: 20% to 90%
AC Input
100 to 240 V, 50 to 60 Hz
EIA RATINGS
10 A @ 125 VAC
10 A @ 250 VAC
DC Power Cable Connector
14-pin P-Type connector
POWER SUPPLY
Internal, auto-ranging transformer:
100 to 240 VAC, 50 to 60 Hz
Output 11.5 VDC
POWER CONSUMPTION
644 W (Maximum)
161 W (Maximum per port)
MAXIMUM CURRENT
7.8 A @ 110 VAC
3.5 A @ 240 VAC
OVERLOAD PROTECTION
Ports are shutdown when output exceeds 150 W
POWER SUPPLY
+12 VDC
Initial accuracy: +/- 1%
Current: 2 A (minimum), 10 A (maximum)
Line regulation: +/- 1%
Load regulation: +/- 10%
Overshoot and undershoot: 5%
COMPLIANCES
CE Mark
Emissions
FCC Class B
Industry Canada Class B
CISPR Class B
VCCI Class B
AS/NZS 3548 (1995) Class B
IMMUNITY
EN 55024
Safety
CSA/ C US (CSA 60950-00 & UL60950)
CB: IEC 60950
EN 60950 (TÜV/GS)
