SMC Networks SMCGS50C-SMART - FICHE TECHNIQUE Operating and safety instructions

Key Features and Benefits
Product Overview
SMCGS50C-Smart
EZ Switch™ 10/100/1000 48 Ports Gigabit Web Smart
Switch including 2 100/1000BASE-X SFP slots
SMC Network’s EZ SwitchTM SMCGS50C-Smart is a new 50-port Gigabit Ethernet Smart Switch providing 48 Gigabit
ports and 2 100/1000BASE-X SFP slots. The switch supports a flexible web-based management interface as well as
SNMP for both IPv4 and IPv6. The new SMCGS50C-Smart provides a range of feature-rich functions, including VLANs,
Spanning Tree, link aggregation, multicasting, security, storm control, and QoS with 8 priority queues. Ideal for users
looking to migrate from unmanaged to managed networks, this Smart Switch is easy to install and perfect for SMB and
SOHO businesses.
Performance and Scalability
This entry-level managed switch provides 100Gbps
wire-speed switching performance across all 50 ports.
This enables the switch to fully support existing high-
performance PCs and laptops, which significantly
improves application response times and the speed of
large file transfers.
The two Gigabit Ethernet 100/1000BASE-X SFP slots
provide uplink flexibility, offering extended fiber
connections to the network backbone.
Feature-Rich Functionality
VLAN features support flexible network partition and
configuration, performance improvement, and cost
savings.
IGMP snooping prevents flooding of IP multicast traffic
and limits bandwidth-intensive video traffic to only the
subscribers.
Storm control monitors the amount of storm traffic that is
sent every single second on an interface. It allows the
administrator to specify how much storm traffic can be
sent as a percentage of the total bandwidth of an interface.
Continuous Availability
IEEE 802.1w Rapid Spanning Tree Protocol provides a
loop-free network and redundant links to the core network
with rapid convergence, ensuring faster recovery from
failed links, and enhancing overall network stability and
reliability.
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
increases bandwidth by automatically aggregating several
physical links together as a logical trunk and providing
load balancing and fault tolerance for uplink connections.
Comprehensive QoS
Support for eight egress queues per port enable
differentiated management of up to eight traffic types. Traffic
is prioritized according to 802.1p, DSCP, and TCP/UDP port
number, giving optimal performance to real-time
applications such as voice and video. Asymmetric
bidirectional rate-limiting, per port or per traffic class,
preserves network bandwidth and allows maximum control
of network resources.
Enhanced Security
Port Security limits the total number of devices that can
access a switch port based on MAC address, and protects
against MAC flooding attacks.
IEEE 802.1X port-based or MAC-based access control
ensures all users are authorized before being granted
access to the network. User authentication is carried out
using a standard-based RADIUS server, with support for
dynamic VLAN assignment.
Simple Management
An embedded user-friendly web interface helps users
quickly and simply configure switches. SNMP v1/v2 is
supported for management by a network management
station. The switch supports management functions over
both IPv4 and IPv6. Cable diagnostics identifies cable faults
(such as short, open, etc.) and feeds back a distance to the
fault. LLDP (Link Layer Discovery Protocol) enables
administrators to monitor devices attached to switch ports.

PHYSICAL PORTS
48 10/100/1000BASE-T RJ-45 ports
2 Gigabit Ethernet SFP slots
(SFP ports support dual speed 100/1000BASE-X)
PERFORMANCE
Switching Capability: 100Gbps
Packet Buffer Size: 512KB
MAC Address Table: 8K
Flash: 16MB
L2 FEATURES
Auto-negotiation for port speed and duplex mode
Flow Control:
IEEE 802.3x for full-duplex mode
Back-Pressure for half-duplex mode
Spanning Tree Protocol:
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
STP Auto Edge
VLANs:
Supports 4K IEEE 802.1Q VLANs
Port-based VLANs
Voice VLAN
Private VLAN
Link Aggregation:
Static Trunk
IEEE 802.3ad Link Aggregation Control Protocol
Trunk groups: 25 trunk links: Up to 8 ports
IGMP Snooping:
IGMP snooping v1/v2/v3
IGMP immediate leave
Supports jumbo frames up to 10 KB
QoS FEATURES
Priority Queues: 8 hardware queues per port
Traffic classification based on IEEE 802.1p CoS, DSCP,
Supports WRR, Strict scheduling, or hybrid mode
Rate Limiting
Ingress: Resolution 16 Kbps
Egress: Resolution 16 Kbps
SECURITY
Port security: static and dynamic
Supports IEEE 802.1X port based and MAC-based
EAPOL transparent
MAC authentication
Web authentication
HTTPS/SSL
SSH v1.5/v2.0
MAC Filter/IP Filter
DHCP Snooping
MANAGEMENT
Switch Management:
Web management
SNMP v1/v2/v3
Firmware and Configuration:
upgrade/downgrade via TFTP/HTTP
Supports DHCP Client
Supports LLDP (802.1ab) and LLDP-MED
RMON (groups 1, 2, 3, and 9)
Features
Contact
MANAGEMENT
Port mirroring: one to one and many to one
Event log: local flash, syslog, remote server (RFC3164) and SMTP
(RFC821)
SNTP (IPv4/IPv6)
Loop detection and prevention
UPnP
Cable diagnostics
IPv6 management:
IPv4/IPv6 dual protocol stack
IPv6 address types: unicast/multicast
IPv6 Ping/tracert
ICMPv6 and ICMPv6 redirect
IPv6 neighbor discovery
IPv6 stateless auto config/manual config
IPv6 Telnet/SNMP/HTTP/DHCP
MECHANICAL
Dimensions (W x D x H)
43 x 25 x 4.4 cm
Weight: TBD
LED Indicators: Port, Uplink, System, Diagnostic
POWER SUPPLY
AC Power
100 to 240 V, 50-60 Hz, 0.5A
Power Supply
Internal, auto-ranging transformer: 100 to 240 VAC, 47 to 63 Hz
Power Consumption
20 Watts for System Power
ELECTROMAGNETIC COMPATIBILITY
CE Mark
FCC Class A
EN 55022 (CISRP 22) Class A
EN 61000-3-2/3
ENVIRONMENTAL SPECIFICATIONS
Temperature:
-0°C to 50°C (standard operating)
-40°C to 70°C (non-operating)
Humidity: 10% to 90% (non-condensing)
Vibration: IEC 68-2-36, IEC 68-2-6
Shock: IEC 68-2-29
Drop: IEC 68-2-32
SAFETY
CSA (CSA 22.2 NO 60950-1 & UL 60950-1)
CB (IEC/EN60950-1)
WARRANTY
Please check www.smc.com for the warranty terms in your country.
Worldwide Corporate and Sales Headquarters
No. 1 Creation Road III,
Hsinchu Science Park,
30077, Taiwan, R.O.C.
Tel: [phone] Fax: [phone]
©2012 SMC Networks. EZ SwitchTM is a trademark of SMC
Networks. Other trademarks or registered trademarks are the
property of their respective owners. Information is subject to
change without notice.
All rights reserved.
