SMC Networks TigerSwitch SMC6948L2 User manual

Benefits
SMC6948L2
Model Number::
Features
• High-port density with Gigabit
and Fiber options
• Priority Queuing
• VLAN with GVRP
• IGMP Snooping
• Port Trunking
• Port Mirroring
• Redundant power supply
• Switch provides 48 10/100 Mbps
ports;2 expansion slots for
optional uplink modules
Benefits
• Supports up to 48 10/100 Mbps,2
1000 Mbps ports or 4 100FX ports - the
ultimate in flexibility for future expansion
• Two levels of priority,with weighted fair
queuing,ensures smooth transmission of
vital data
• Supports VLANs based on frame tags or
ports, plus support for automatic GVRP
LAN registration for maximum security
and bandwidth efficiency
• IGMP Snooping allows Multicast traffic
transmission to registered users only
• Port trunking groups links between
switches;increases bandwidth for
dedicated link
• Port mirroring allows Sniffer tracking data
transmission for easy troubleshooting
Compatibility
• IEEE 802.3
• 802.3u
• 802.3z
• 802.1d
• 802.3x
• 802.1p
• 802.1q
Switches/Hubs
The TigerSwitch 10/100 is a 48-port 10/100 Mbps
standalone managed switch and offers the highest
port density available in its category. It is intended for
corporate workgroup applications where a high-
speed Gigabit Ethernet connection to the
corporate backbone is required. The switch
provides two optional Gigabit uplink modules,
integrated SNMP/RMON management, port-based
VLANs, Quality-of-Service (QOS), and port trunking.
Spanning Tree support, redundant management and
optional redundant power provide network flexibility
and serve to lower the cost of ownership. SNMP,
RMON and a full-featured Web-based
interface enable the user to monitor network
performance and status.
TigerSwitchTM 10/100
48-Port 10/100 Mbps Standalone Managed
Layer 2 Switch
6 H u g h e s
Irvine, CA 92618
1-800-SMC-4YOU
www.smc.com

SMC6948L2
Switches/Hubs
Ports
48 10/100 RJ-45 ports
2 slots for Expansion Modules
Built-in Network Management
NetworkInterface
10BASE-T:RJ-45 UTP Cat.3,4,5
100BASE-TX:RJ-45 UTP Cat.5
1000BASE-T:RJ-45 UTP Cat.5
100BASE-FX:VF-45/SC/ST connector
1000BASE-SX:SC connector
1000BASE-LX:SC connector
BufferArchitecture
128 Kbps per 10/100 Mbps ports
2 Mbps per 1000 Mbps port
AggregateBandwidth
13.6 Gbps
SwitchingDatabase
12,000 MAC address entries
LEDIndicators
System (power,RDP, Mgmt.)
Port:mode (flow control,full-duplex,
activity)
Link (speed,link,disable/partition)
Weight
18.07 lbs
Size
22.4 x 19 x 7.5 in
Temperature
Operating: 32° – 122° F
Storage:–4° - 158° F
Humidity
Operating 5% to 95% (non-condensing)
ACInput
100 to 240 V,50-60 Hz
PowerSupply
Internal,auto-ranging transformer:
100 - 240 VAC,50-60 Hz
Redundant DC input
PowerConsumption
100W
HeatDissipation
273 BTU/hr.
MaximumCurrent
0.80A RMS max.@110 VAC
0.50A RMS max.@240 VAC
MTBF
6 years
SwitchFeatures
SpanningTree Protocol
Forwarding Mode
Store-and-forward
FlowControl
Full-duplex:IEEE 802.3x
Half-duplex:back pressure
VLANSupport
Up to 256 groups,port-based or with
802.1Q VLAN tagging,GVRP for auto-
matic VLAN learning
Qualityof Service
Supports two levels of priority and
weighted Fair Queuing
Broadcast Storm Control
MultiLinkTrunking
Port Mirroring
ManagementFeatures
In-Band Management
Telnet,SLIP,Web-based HTTP or SNMP
Manager
Out-of-BandManagement
RS-232 DB-9 console port
SoftwareLoading
TFTP in-band or Xmodem out-of-band
MIBSupport
MIB II (RFC 1213), Bridge MIB (RFC 1493),
Ethernet-like MIB (RFC 1643),RMON MIB
(RFC 1757),SMC proprietary MIB
RMONSupport
Groups 1,2,3,9 (Statistics,History,Alarm,
Event)
Standards
IEEE 802.3 Ethernet
IEEE 803.3u Fast Ethernet
IEEE 802.1d Spanning Tree Protocol and
traffic priorities
IEEE 802.1p PriorityTags
IEEE 802.1q VLAN
IEEE 802.3ac VLAN Tagging
IEEE 802.3x Full-duplex flow control;ISO
IEC 8802-3
SNMP (RFC 1157),RMON (RFC 1757),ARP
(RFC 826),
IGMP (RFC 1112),MIB II (RFC 1213),
Ethernet-like MIB
(RFC 1643),Bridge MIB (RFC 1493)
Compliances
CE Mark
• Emissions
FCC Class A
Industry Canada Class A
EN55022 (CISPR 22) Class A
VCCI Class A
C-Tick – AS/NZS 3548 (1995) Class A
• Immunity
IEC 1000 – 4 – 2/3//4/6
• Safety
CSA/NRTL (CSA22.2.950 & UL 1950),
EN60950 (TUV/GS)
Warranty
Limited lifetime
Models
SMC6900FSC,SMC6900FST,
SMC6900FSSC
Ports
2 – 100Base-FX MMF or
1 – 100Base-FX SMF
Model
SMC6900GT
Ports
(1) 10/100/1000Base-T
1000Base-SX Extender Module
1000Base-LX Extender Module
Model
SMC6900G
SMC6900GLSC
Ports
(1) 1000Base-SX
(1) 1000Base-LX
Redundant Power Unit
Model
SMCRPU150W
Function
Redundant Power Unit with cables;
supports one device
TigerSwitchTM 10/100
48-Port 10/100 Mbps Standalone Managed
Layer 2 Switch
SMC6948L2 Tigerswitch 10/100 48-Port Managed Switch With Gigabit Uplinks
SMC6900G TigerSwitch 10/100 1-port 1000BASE-SX Expansion Module
SMC6900GLSC TigerSwitch 10/100 1-port 1000BASE-LX Expansion Module
SMC6900GT TigerSwitch 10/100 1-port 10/100/1000BASE-T Expansion Module
SMC6900FSC TigerSwitch 10/100 2-Port 100Base-FX MMF SC Fiber Module
SMC6900FSSC TigerSwitch 10/100 1-Port 100Base-FX SMF SC fiber Module
SMC6900FST TigerSwitch 10/100 100Base-FX MMF SC Fiber Module with SC-ST converters
SMCRPU150W Redundant Power Supply
