SMC Networks SMCBGLLCX1 User manual

11 TigerAccess Transceiver
SMCBGSSCX1
SMCBGLSCX1
SMCBGZSCX1
TigerAccess™ GBIC
1000BASE-X GBIC transceiver
SMCBGSSCX1
•PHY type: 1000BASE-SX
•Connector: SC
•Max. Range*: 220 m - 550 m
•Wavelength: 850 nm
•Fiber type: MMF
SMCBGLSCX1
•PHY type: 1000BASE-LX
•Connector: SC
•Max. Range*: 550 m - 10 km
•Wavelength: 1300 nm
•Fiber type: MMF/ SMF
SMCBGZSCX1
•PHY type: 1000BASE-ZX
•Connector: SC
•Max. Range*: 70 km - 100 km
•Wavelength: 1550 nm
•Fiber type: SMF
* Depending on various factors such as fiber quality, type, core size, modal bandwidth, number of splices, and connectors.
Please refer to the product datasheet for more details.
** STP Cat-5e cabling
SMCBGSLCX1
SMCBGLLCX1
SMCBGZLCX1
TigerAccess™ SFP
1000BASE-X SFP transceiver
SMCBGSLCX1
•PHY type: 1000BASE-SX
•Connector: LC
•Max. Range*: 220 m - 550 m
•Wavelength: 850 nm
•Fiber type: MMF
SMCBGLLCX1
•PHY type: 1000BASE-LX
•Connector: LC
•Max. Range*: 550 m - 10 km
•Wavelength: 1300 nm
•Fiber type: MMF/ SMF
SMCBGZLCX1
•PHY type: 1000BASE-ZX
•Connector: LC
•Max. Range*: 70 km
•Wavelength: 1550 nm
•Fiber type: SMF
SMC10GXFP-SR
SMC10GXFP-LR
SMC10GXFP-ER
TigerAccess™ XFP
10GBASE-X XFP transceiver
SMC10GXFP-SR
•PHY type: 10GBASE-SR
•Connector: LC
•Max. Range*: 300 m
•Wavelength: 850 nm
•Fiber type: MMF
SMC10GXFP-LR
•PHY type: 10GBASE-LR
•Connector: LC
•Max. Range*: 300 m - 10 km
•Wavelength: 1300 nm
•Fiber type: MMF/ SMF
SMC10GXFP-ER
•PHY type: 10GBASE-ER
•Connector: LC
•Max. Range*: 10 km - 40 km
•Wavelength: 1550 nm
•Fiber type: SMF
SMC10GXEN-T
SMC10GXEN-SR
SMC10GXEN-LR
SMC10GXEN-ER
TigerAccess™ XENPAK
10GBASE-X XENPAK transceiver
SMC10GXEN-T
•PHY type: 10GBASE-T
•Connector: RJ-45
•Max. Range*: 100 m**
•Wavelength: -
•Fiber type: Copper
SMC10GXEN-SR
•PHY type: 10GBASE-SR
•Connector: SC
•Max. Range*: 300 m
•Wavelength: 850 nm
•Fiber type: MMF
SMC10GXEN-LR
•PHY type: 10GBASE-LR
•Connector: SC
•Max. Range*: 300 m - 10 km
•Wavelength: 1310 nm
•Fiber type: MMF/ SMF
SMC10GXEN-ER
•PHY type: 10GBASE-ER
•Connector: SC
•Max. Range*: 10 km - 40 km
•Wavelength: 1550 nm
•Fiber type: SMF
SMCBGLSCX1 SMCBGSLCX1 SMC10GXEN-SR SMC10GXFP-LR
http://www.smc.com
