PRECAUTIONS - 1991477A937/A
e
PRECAUTIONS 19
General safety instructions 19
Installation 22
Appliance purpose 23
This user manual 23
Manufacturer’s liability 23
Identification plate 23
Disposal 24
To save energy 24
How to read the user manual 24
DESCRIPTION 25
General description 25
USE 26
Basic functions 26
Preliminary operations 26
Safety features 27
Using the hob 27
Error notifications 28
CLEANING AND MAINTENANCE 29
Cleaning the glass ceramic hob 29
What to do if... 29
INSTALLATION 30
Electrical connection 30
Section cut from the countertop 31
Mounting 32
Fixing to the built-in cabinet 32
Fixing to the built-in cabinet 33
Testing 33
Instructions for the installer 33
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• Protect hands with heat resistant
gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• Be aware of how rapidly the
cooking zones heat up. Do not
place empty pans on the heat.
Danger of overheating.
• Activate the controls lock when
you have children or pets which
could reach the hob.

20 - PRECAUTIONS 91477A937/A
• Do not touch or clean the hob
surface during operation or
when the residual heat
indicator lights are still on.
• After use, switch off the plates.
Never rely solely on the
cookware detector.
• Supervise children carefully as
they cannot readily see the
residual heat indication. After
use the cooking zones remain
hot for a certain period of time
even if they have been turned
off. Keep children away from
the cooking zones.
• The cooking process must
always kept under control. A
short cooking process must be
continuously monitored.
• WARNING: Cooking foods
containing fat and/or oil
without monitoring them can be
dangerous and can cause a
fire.
• Fats and oils can catch fire if
they overheat. Do not leave the
appliance unattended while
preparing foods containing oils
or fats. If fats or oils catch fire,
never put water on them. Place
the lid on the pan and turn off
the relevant cooking zone.
• Do not use the Booster and/or
the Double Booster functions (if
present) to heat fats or oils. Fire
hazard.
• Do not place metal objects,
such as dishes or cutlery, on the
surface of the hob during
cooking as they may overheat.
• Do not cook foods in closed
tins or containers or plastic
containers.
• Do not use magnetic tins.
• Do not use trivets or other items
between the bottom of the pan
and the glass ceramic surface.
Danger of burns.
• Do not insert pointed metal
objects (cutlery or utensils) into
the slots in the appliance.
• Do not use or store flammable
materials near the appliance or
directly underneath the hob.
• Switch off the appliance
immediately after use.
• Do not pull the cable to unplug
the appliance (if present).
•DONOTUSEAEROSOLSIN
THE VICINITY OF THIS
APPLIANCE WHILST IT IS IN
USE.
• DO NOT MODIFY THIS
APPLIANCE.
• Always wear personal
protective equipment (PPE)
before carrying out any work
on the appliance (installation,
maintenance, positioning or
moving).
• Do not clean the appliance if it
is still hot or in operation.
• After use the cooking zones
remain hot for a certain period
of time after they have been
turned off. Do not touch the hob
surfaces.
• Before performing any work on

PRECAUTIONS - 2191477A937/A
e
the appliance, switch off the
power supply.
• Do not try to repair the
appliance yourself or without
the assistance of a qualified
technician.
• If the power cable becomes
damaged, contact technical
support immediately to arrange
for it to be replaced in order to
avoid possible hazards.
• If cracks or fissures form, or if
the glass ceramic cooking
surface breaks, turn off the
appliance immediately.
Disconnect the power supply
and call Technical Support.
• People who have pacemakers
or other similar devices fitted
must make sure that the
operation of these devices is
not affected by the induction
field, the frequency range of
which is between 20 and 50
kHz.
• In conformity with the provisions
regarding electromagnetic
compatibility, the
electromagnetic induction
cooking hob comes under
group 2 and class B (EN
55011).
Risk of damaging the appliance
• Do not use abrasive or
corrosive detergents (e.g.
scouring powders, stain
removers and metallic
sponges) on glass parts.
• Use wooden or plastic utensils.
• Do not sit on the appliance.
• Do not use the glass ceramic
cooking surface as a support
surface.
• Do not use the appliance as a
support surface.
• Do not obstruct ventilation
openings and heat dispersal
slots.
• Do not use the hob if the
pyrolytic cycle is taking place
inside any oven installed
below.
• Do not use steam jets to clean
the appliance.
• Never leave the appliance
unattended during cooking
operations where fats or oils
could be released, as these
could then heat up and catch
fire. Be very careful.
• Fire hazard: Never leave
objects on the cooking
surfaces.
• DO NOT FOR ANY REASON
USE THE APPLIANCE AS A
SPACE HEATER.
• Cooking vessels or griddle
plates should be placed inside
the perimeter of the hob.
• All pans must have smooth, flat
bottoms.
• If any liquid does boil over or
spill, remove the excess from
the hob.
• Take care not to spill acid
substances such as lemon juice
or vinegar on the hob.

22 - PRECAUTIONS 91477A937/A
• Do not spill sugar or sweet
mixtures on the hob during
cooking.
• Do not place materials or
substances that could melt or
catch fire (paper, plastic or
aluminium foil) on the
appliance while it is in use.
• Place the cookware directly on
the glass ceramic surface.
• Do not put empty pans or frying
pans on switched on cooking
zones.
• Do not use rough or abrasive
materials or sharp metal
scrapers.
• The glass ceramic surface is
highly resistant to impact.
However, prevent hard, solid
objects from falling on the
cooking surface as they may
cause it to break.
• Do not use cleaning products
containing chlorine, ammonia
or bleach on parts made of
steel or that have metallic
surface finishes (e.g. anodizing,
nickel- or chromium-plating).
• This appliance is not intended
to be operated by means of
external timer or separate
remote control system.
Installation
• THIS APPLIANCE MUST NOT
BE INSTALLED IN BOATS OR
CARAVANS.
• This appliance must not be
installed on a dishwasher.
• Position the appliance into the
cabinet cut-out with the help of
a second person.
• Check that the carcase has the
required openings.
• Check that the carcase material
is heat resistant.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• Have the electrical connection
performed by authorised
technical personnel.
• The appliance must be
connected to earth in
compliance with electrical
system safety standards.
• Use cables that can withstand
temperatures of at least 90°C.
• Run the power cable in the rear
part of the unit. Make sure that
it does not come into contact
with the lower part of the hob
or a built-in oven below it.
• Be careful when connecting
additional electrical
appliances. Connection cables
must not come into contact with
hot cooking zones.
• The tightening torque of the
screws of the terminal supply
wires must be 1.2 - 1.5 Nm.
• Do not attach the appliance
too tightly to the unit as this
could cause damage during
use or partially obstruct the heat
dispersal slots.
• The power cable must only be
installed or replaced by a

PRECAUTIONS - 2391477A937/A
e
qualified technician.
• If the power cable becomes
damaged, contact technical
support immediately to arrange
for it to be replaced in order to
avoid possible hazards.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Before performing any work on
the appliance, switch off the
power supply.
• Allow the appliance to be
disconnected after installation,
via an accessible plug or a
switch in the case of a fixed
connection.
• Fit the power line with an all-
pole circuit breaker with a
contact separation distance
sufficient to provide complete
disconnection in category III
overvoltage conditions,
pursuant to installation
regulations.
• If the electrical supply is
restricted, means of all-pole
disconnection must be
accessible and incorporated in
the fixed wiring in accordance
with the wiring rules.
• This appliance can be used up
to a maximum altitude of 2,000
metres above sea level.
Appliance purpose
This appliance is intended for
cooking food in the home
environment. Every other use is
considered inappropriate. It
cannot be used:
• in employee kitchens, shops,
offices and other working
environments.
• in farms/farmhouses.
• by guests in hotels, motels and
residential environments.
• In bed and breakfast
accommodation.
This user manual
• This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user's reach for the
whole working life of the appliance.
• Read this user manual carefully before using
the appliance.
• The explanations in this manual include
images, which describe all that regularly
appears on the display. However, it should
be kept in mind that the appliance may be
equipped with an updated version of the
system, and as such, all that appears on the
display may differ from those in the manual.
Manufacturer’s liability
The manufacturer declines all liability for
damage to persons or property caused by:
• use of the appliance other than that
specified;
• failure to comply with the instructions in the
user manual;
• tampering with any part of the appliance;
• use of non-original spare parts.
Identification plate
The identification plate bears the technical data,
serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.

24 - PRECAUTIONS 91477A937/A
Disposal
This appliance conforms to the WEEE
European directive (2012/19/EU) and
must be disposed of separately from
other waste at the end of its service life.
The appliance does not contain substances in
quantities sufficient to be considered hazardous
to health and the environment, in accordance
with current European directives.
To dispose of the appliance:
• Cut the power cable and remove it.
• Deliver the appliance to the appropriate
recycling centre for electrical and electronic
equipment waste, or return it to the retailer
when purchasing an equivalent product, on
a one for one basis.
Our appliances are packaged in non-polluting
and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
To save energy
• The diameter of the base of the pan must not
extend beyond the lines printed on the glass
ceramic surface.
• Pans must not be placed outside the
perimeter of the hob or on the display.
• When buying a pan, check whether the
diameter indicated is that of the base or the
top of the pan, as the top is almost always
larger than the base.
• When preparing dishes with long cooking
times, you can save time and energy by
using a pressure cooker, which also helps to
retain vitamins contained in the food.
• Make sure that the pressure cooker contains
enough liquid as, if there is not enough and
it overheats, this may cause damage to both
the pressure cooker and the cooking zone.
• If possible, always cover pans with a
suitable lid.
• Choose a pan suitable for the quantity of
food to be cooked. A large, half-empty
saucepan leads to a waste of energy.
How to read the user manual
This user manual uses the following reading
conventions:
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part of it
unattended.
• Do not let children play with the plastic
bags.
Under certain circumstances, if the hob
and the oven are used at the same time,
the maximum power limit of the
electrical system might be exceeded.
Warning/Caution
Information/Advice

DESCRIPTION - 2591477A937/A
e
DESCRIPTION
General description
*Power levels are approximate and may vary according to the pan used or the settings made.
Cooking zones
// Frontleft
/ / Rear left
// Frontright
/ / Rear right
List of symbols:
Symbol 0: cooking zone off.
Symbol P: activates the booster function.
Symbol A: activates the accelerator function.
Advantages of induction cooking
• Energy saving thanks to the direct
transmission of energy to the pan (suitable
magnetisable cookware is required)
compared to traditional electric cooking.
• Improved safety as the energy is only
transmitted to the pan placed on the hob.
• High level of energy transmitted from the
induction cooking zone to the base of the
pan.
• Rapid heating speed.
• Reduced danger of burns as the cooking
surface is only heated under the base of the
pan; foods which overflow do not stick.
Zone Diameter/Dimensions H
x L (mm)
Pan mini-
mum Ø
(mm)
Power draw at lev. 9 (W)* Power draw in booster
function (W) *
1 - 3 160 x 160 110 1300 1400
2 - 4 210 x 210 120 2300 3000
The appliance is equipped with an
induction generator for each cooking
zone. Each generator located under the
glass ceramic cooking surface creates
an electromagnetic field which induces
a thermal current in the base of the pan.
This means the heat is no longer
transmitted from the hob to the pan but
created directly inside the pan by the
inductive current.

26 - USE 91477A937/A
Power control
The hob is fitted with a power control module
that optimises/limits consumption. If the overall
set power level exceeds the maximum limit
permitted, the electronic circuit board will
automatically manage the power supplied by
the hot plates. The module tries to maintain the
maximum deliverable power levels. Levels set by
the automatic control will appear on the display.
The flashing of a power level indicates that it will
be automatically limited to a new level selected
by the power control module.
USE
Basic functions
First power connection
When connected to the power supply for the
first time, or after power has been switched
back on after a power failure, an automatic
check is carried out that control turns on the
indicator lights and the displays for a few
seconds. Afterwards, the appliance can be
used normally.
Preliminary operations
• Remove any protective film from the outside
or inside of the appliance, including any
accessories (if present).
• Remove any labels (apart from the technical
data plate).
Cookware suitable for use in induction
cooking
Cookware used on the induction cooking
surface must be made of metal, with magnetic
properties and a sufficiently large base.
Suitable cookware:
• Enamelled steel cookware with thick bases.
• Cast iron cookware with an enamelled
base.
• Cookware in multilayer stainless steel, ferritic
stainless steel and aluminium with a special
base.
Unsuitable cookware:
• Copper, stainless steel, aluminium, fireproof
glass, wood, ceramic and terracotta
cookware.
Advice on energy-saving
To see whether the pan is suitable, bring a
magnet close to the bottom: if it is attracted, the
pan is suitable for induction cooking. If you do
not have a magnet, you can put a small amount
of water in the pan, place it on a cooking zone
and start the hot plate. If the symbol appears
on the display, it means the pan is not suitable.
Advice on energy-saving
The diameter of the base of the pan must
correspond to the diameter of the cooking zone.
• When buying a pot, check whether the
diameter indicated is that of the base or the
top,
as the top is almost always larger than the base.
• The base of the cookware must be thick and
completely flat. In addition, the hob should
be clean and dry as well.
• When preparing dishes with long cooking
Priority is given to the last zone set.
The power control module does not
affect the total power consumption of
the appliance.
See General safety instructions.

USE - 2791477A937/A
e
times, you can save time and energy by
using a pressure cooker, which also makes it
possible to preserve the vitamins in the food.
• Make sure that the pressure cooker contains
enough liquid as, if there is not enough and
it overheats, this may cause damage to both
the pressure cooker and the cooking zone.
• If possible, always cover the pans with a
suitable lid.
• Choose a pan suitable for the quantity of
food to be cooked. A large, half-empty
saucepan leads to a waste of energy.
• Do not use cast-iron cookware or cookware
with a rough base.
Power level table
The power in the cooking zones can be
adjusted to various levels. In the table below
you will find instructions for the different types of
cooking.
Residual heat
If the cooking zone is still hot after being
switched off, the symbol will be displayed
on the display. The symbol clears once the
temperature drops below 60°C.
Safety features
Limiting the cooking duration
The appliance has an automatic device that
limits the duration of use.
If the cooking settings for a pan are not
changed, the maximum operation time for each
zone depends on the power level selected.
When the device for limiting the duration of use
is activated, pan heating is deactivated and
the symbol appears on the display.
Using the hob
Booster function
After switching on the hob and having selected
a zone, to activate the function:
1. Select the button .
2. The Booster function will be activated and
the symbol appears on the cooking
zone display.
To deactivate the Booster function, simply
decrease the power level of the cooking zone
or switch off the appliance.
If hob and oven are being used at the
same time, under certain conditions the
maximum power limit that can be used
by your electrical system might be
exceeded.
Power level Suitable for:
0 OFF setting
from 1 to 2 Cooking small amounts of food
(minimum power)
from 3 to 4 Cooking
from 5 to 6 Cooking large quantities of food,
roasting larger portions
from 7 to 8 Roasting, slow frying with flour
9 Roasting
P
Bring a large amount of water to
the boil (maximum power, see
"Booster function")
See General safety instructions.
Power level Maximum cooking dura-
tion in hours
16
26
35
45
54
6 - 7 - 8 - 9 1.5
• The Booster function remains active
for a maximum of 10 minutes, after
which the power is reduced
automatically to level 9.
• If the internal temperature is too high,
the Booster function will be
temporarily disabled.

28 - USE 91477A937/A
Heating accelerator
This function allows the selected power to be
achieved in the shortest amount of time.
1. Turn the knob anticlockwise to position A
and then release it. The display shows the
symbol.
2. Select the required heating power (1..8)
within 3 seconds. The selected power and
the symbol will flash alternately on the
display.
The power level can be increased at any
moment. The “maximum power” period will
automatically be modified. Once the
acceleration period is over the power level will
remain the same as the one previously selected.
Controls lock
To activate the controls Lock, carry out the
following procedure:
1. With all cooking zones switched off,
simultaneously turn the two cooking zone
control knobs anti-clockwise to the left
(position A).
2. Keep them turned until the symbols
appear on the display.
3. Release the knobs.
In order to remove the control lock repeat the
same operations described previously.
Error notifications
If the appliance malfunctions or operates
incorrectly, the associated error code appears
on the display.
The error codes always begin with the letter “E”
or “C” followed by a series of digits (e.g. “Er47-
30”).
Setting the power level of the appliance
1. Disconnect the appliance from the mains
power supply and wait 10 seconds before
turning the power back on.
2. Turn and hold the front left and front right
cooking zone control knobs anti-clockwise
(position “A”) at the same time.
The rear left and rear right cooking zone
displays will show “7.” and “4”.
3. Release the knobs.
4. Turn and hold both knobs anti-clockwise
again.
The rear left and rear right cooking zone
displays will indicate the power levels “4.”and
“5”.
5. Release the knobs.
6. Turn and hold both knobs anti-clockwise
again.
The rear left and rear right cooking zone
displays will indicate the power levels “3.”and
“8”.
7. Release the knobs.
8. Turn and hold both knobs anti-clockwise
again.
The rear left and rear right cooking zone
displays will indicate the power levels “3.”and
“0”.
9. Release the knobs.
10.Turn and hold both knobs anti-clockwise
again.
Turn and hold both knobs anti-clockwise again.
11. Release the knobs.
12.Turn and hold both knobs anti-clockwise
again.
The rear left and rear right cooking zone
displays will indicate the power levels “1.”and
“9”.
13. Release the knobs.
Each cooking zone is equipped with a
heating accelerator that allows the
maximum power to be delivered for a
time that is proportional to the selected
power.
If the power is reduced, by turning the
knob anti-clockwise, the heating
accelerator will automatically be
disabled.
The controls lock is a device that
protects the appliance from accidental
or inappropriate use.
If a knob is turned to position “A” for
more than 30 seconds, an error
message will appear on the
displays .
• The power level has to be set within
2 minutes from the power being
switched on.
• The appliance is factory set to a
maximum power of 7.4 kW, but can
be regulated to operate at 4.5, 3.8,
3.0, 2.6 and 1.9 kW.
