Smeg Oven Instruction manual

25
Contents
THESE INSTRUCTIONS ARE VALID ONLY FOR THE DESTINATION COUNTRIES
WHOSE IDENTIFYING SYMBOLS ARE INCLUDED ON THE COVER OF THIS
MANUAL.
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified
technician who must install the appliance, set it functioning and carry out
an inspection test.
1. INSTRUCTIONS FOR USE .............................................................. 26
2. SAFETY PRECAUTIONS ................................................................. 28
3. ENVIRONMENTAL RESPONSIBILITY............................................. 30
4. GET TO KNOW YOUR OVEN.......................................................... 31
5. USING THE OVEN ........................................................................... 33
6. CLEANING AND MAINTENANCE.................................................... 39
7. EXTRAORDINARY MAINTENANCE................................................ 42
8. OVEN INSTALLATION..................................................................... 44

General instructions
26
1. INSTRUCTIONS FOR USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS
ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF
THE APPLIANCE.
CAREFUL READING OF THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN
BEFORE USING THE APPLIANCE IS ESSENTIAL. INSTALLATION MUST BE CARRIED
OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN
FORCE. THIS APPLIANCE IS INTENDED FOR PROFESSIONAL USE AND
CONFORMS TO THE EEC DIRECTIVES CURRENTLY IN FORCE. THE APPLIANCE
HAS BEEN BUILT TO CARRY OUT THE FOLLOWING FUNCTIONS: COOKING FOOD;
ALL OTHER USES ARE CONSIDERED UNSUITABLE.
THE MANUFACTURER CANNOT BE HELD LIABLE FOR USE OTHER THAN AS
INDICATED.
IF THE APPLIANCE IS INSTALLED ON BOATS OR IN CARAVANS, DO NOT USE IT AS
A ROOM HEATER.
DO NOT USE THIS APPLIANCE FOR HEATING ROOMS.
THIS APPLIANCE IS MARKED ACCORDING TO EUROPEAN DIRECTIVE 2002/96/EC
ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
THIS DIRECTIVE DEFINES THE STANDARDS FOR THE COLLECTION AND
RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT APPLICABLE
THROUGHOUT THE EUROPEAN UNION.
NEVER OBSTRUCT THE OPENINGS AND SLITS PROVIDED FOR VENTILATION AND
HEAT DISPERSAL.
DO NOT REST ANY WEIGHT OR SIT ON THE OPEN DOOR OF THE APPLIANCE.
THE IDENTIFICATION PLATE WITH THE TECHNICAL DATA, SERIAL NUMBER AND
BRAND NAME HAS BEEN VISIBLY AFFIXED TO THE APPLIANCE.
DO NOT REMOVE THIS PLATE FOR ANY REASON.
BEFORE THE APPLIANCE IS PUT INTO OPERATION, ALL THE PROTECTIVE FILMS
APPLIED INSIDE OR OUTSIDE MUST BE REMOVED.
TAKE CARE THAT NO OBJECTS ARE STUCK IN THE DOOR OF THE OVEN.

General instructions
27
THE APPLIANCE BECOMES VERY HOT INSIDE DURING USE. SUITABLE HEAT-
PROOF GLOVES SHOULD BE WORN FOR ALL OPERATIONS.
TRAYS MUST BE WASHED BEFORE USE WITH A SUITABLE KITCHENWARE
DETERGENT (DO NOT USE ABRASIVE PRODUCTS).
THE OVEN IS DESIGNED FOR A MAXIMUM LOAD OF 3.5 KG.
DO NOT USE STEEL SPONGES AND SHARP SCRAPERS AS THEY WILL
DAMAGE THE SURFACE.
USE NORMAL NON-ABRASIVE PRODUCTS, INCLUDING WOODEN OR
PLASTIC UTENSILS IF NECESSARY. RINSE THOROUGHLY AND DRY
USING A SOFT CLOTH OR A MICROFIBRE CLOTH.
DO NOT ALLOW RESIDUES OF SUGARY FOODS (SUCH AS JAM) TO SET
INSIDE THE OVEN. IF THEY ARE ALLOWED TO SET FOR TOO LONG,
THEY COULD RUIN THE SURFACES.
DO NOT USE PLASTIC KITCHENWARE OR CONTAINERS. THE HIGH
TEMPERATURES INSIDE THE OVEN COULD MELT THE PLASTIC, DAMAGING THE
APPLIANCE.
DO NOT USE SEALED TINS OR CONTAINERS IN THE APPLIANCE.
OVERPRESSURE MAY OCCUR INSIDE THE CONTAINERS DURING COOKING,
CREATING A DANGER OF EXPLOSION.
DO NOT LEAVE THE APPLIANCE UNATTENDED DURING COOKING PROCESSES
WHERE FATS OR OILS COULD BE RELEASED.
FATS AND OILS MAY CATCH FIRE.
DO NOT COVER THE BOTTOM OF THE OVEN WITH ALUMINIUM OR TINFOIL
SHEETS DURING COOKING AND DO NOT PLACE PANS OR TRAYS ON IT TO AVOID
DAMAGE TO THE SURFACE.
ALL COOKING OPERATIONS MUST TAKE PLACE WITH THE DOOR CLOSED.

General instructions
28
2. SAFETY PRECAUTIONS
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS
FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS.
IN YOUR INTERESTS AND FOR YOUR SAFETY THE LAW REQUIRES THAT THE
INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS CARRIED
OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN
FORCE.
OUR APPROVED INSTALLERS GUARANTEE A SATISFACTORY JOB.
GAS OR ELECTRICAL APPLIANCES MUST ALWAYS BE DISCONNECTED BY
SUITABLY SKILLED PEOPLE.
BEFORE CONNECTING THE APPLIANCE TO THE POWER GRID, CHECK THE DATA
ON THE PLATE AGAINST THE DATA FOR THE GRID ITSELF.
BEFORE CARRYING OUT INSTALLATION/MAINTENANCE WORK, MAKE SURE THAT
THE APPLIANCE IS NOT CONNECTED TO THE POWER GRID.
THE PLUG TO BE CONNECTED TO THE POWER SUPPLY CABLE AND ITS SOCKET
MUST BE OF THE SAME TYPE AND CONFORM TO THE REGULATIONS IN FORCE.
THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE HAS BEEN BUILT IN.
NEVER DISCONNECT THE PLUG BY PULLING ON THE CABLE.
IF THE POWER SUPPLY CABLE IS DAMAGED, HAVE IT REPLACED IMMEDIATELY.
IT IS OBLIGATORY FOR ALL ELECTRICAL EQUIPMENT TO BE EARTHED
ACCORDING TO THE METHODS LAID DOWN BY SAFETY REGULATIONS.
IMMEDIATELY AFTER INSTALLATION, CARRY OUT A BRIEF INSPECTION TEST,
FOLLOWING THE INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT
FUNCTION, DISCONNECT IT FROM THE ELECTRICITY SUPPLY AND CALL THE
NEAREST TECHNICAL SUPPORT CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
NEVER PUT INFLAMMABLE OBJECTS IN THE OVEN: IF IT IS SWITCHED ON BY
ACCIDENT, IT MAY CAUSE A FIRE.
DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH
THE HEATING ELEMENTS INSIDE THE OVEN.
THE APPLIANCE IS DESIGNED FOR PROFESSIONAL USE BY TRAINED
PERSONS. DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN
OPERATION OR PLAY WITH IT AT ANY TIME.

General instructions
29
DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE
SLITS IN THE APPLIANCE.
DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE.
THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING
SHORT-CIRCUITS.
DO NOT MODIFY THIS APPLIANCE.
DO NOT SPRAY ANY SPRAY PRODUCTS NEAR THE ELECTRICAL APPLIANCE
WHILE IT IS IN OPERATION.
DO NOT USE SPRAY PRODUCTS WHILE THE PRODUCT IS STILL HOT.
The manufacturer cannot be held liable for damage to persons or things caused by
failure to observe the above instructions, by interference with any part of the
appliance or by the use of non-original spare parts.

Instructions for disposal
30
3. ENVIRONMENTAL RESPONSIBILITY
3.1 Our environmental responsibility
Pursuant to Directives 2002/95/EC, 2002/96/EC and 2003/108/EC relating to
the reduction of the use of hazardous substances in electrical and electronic
appliances, as well as to the disposal of refuse. The crossed out bin symbol on
the appliance indicates that the product, at the end of its useful life, must be
collected separately from other refuse. Therefore, the user must consign the
product that has reached the end of its working life to the appropriate selective
collection centres for electrical and electronic refuse, or deliver it back to the
retailer when purchasing an equivalent product, on a one for one basis.
Adequate differentiated collection for the subsequent forwarding of the
decommissioned product to recycling, processing and ecologically compatible
disposal contributes to avoiding possible negative effects on the environment
and on health, and promotes recycling of the appliances constituent materials.
The illicit disposal of the product by the user results in the application of
administrative sanctions.
The product does not contain substances in quantities sufficient to be
considered hazardous to health and the environment, in accordance with
current European directives.
3.2 Your environmental responsibility
Our product’s packing is made of non-polluting materials, which are therefore
compatible with the environment and recyclable. Please help by disposing of the
packaging correctly. You can obtain the addresses of collection, recycling and
disposal centres from your retailer or from the competent local organisations.
Do not discard the packaging or any part of it, or leave it unattended. It can
constitute a suffocation hazard for children, especially the plastic bags.
Your old appliance also needs to be disposed of correctly.
Important: hand over your appliance to the local agency authorised for the
collection of electrical appliances no longer in use. Correct disposal enables
intelligent recovery of valuable materials.
Before disposing of your appliance it is important to remove doors and leave
shelves in the same position as for use, to ensure that children cannot
accidentally become trapped inside during play. It is also necessary to cut the
connecting cable to the power grid, removing it along with the plug.

Instructions for the user
31
4. GET TO KNOW YOUR OVEN
OVEN FAN
LAMP
RACK AND TRAY SUPPORT RUNNERS
CONTROL PANEL

Instructions for the user
32
4.1 DESCRIPTION OF CONTROLS
START BUTTON
This button lets you start cooking operations or perform a rapid
cooling cycle when they are finished.
STOP BUTTON
This button lets you stop cooking at any time.
DISPLAY
This lets you display the selected program and related cooking
parameters.
PROGRAM SELECTION KNOB
Allows you to set the cooking operation using one of the programs,
to select the temperature and duration of the cooking operation as
well as the operating power.

Instructions for the user
33
5. USING THE OVEN
THE OVEN IS DESIGNED FOR A MAXIMUM LOAD OF 3.5 KG.
5.1 Warnings and general advice
• When using the oven for the first
time, heat it up to its maximum
temperature for a duration long
enough to burn off any oily residues
from the manufacturing process.
• To access food during cooking,
always leave the door open as short
a time as possible to prevent the
temperature in the oven from falling
and ruining the food.
5.2 Choice of programs
This appliance allows you select 40 cooking programs including:
• 38 programs that can be edited and saved as the user wishes;
• 1 preheating program with delayed start “P39”;
• 1 manual program “P40”.

Instructions for the user
34
5.3 Editing / saving a program
The oven has 38 programs that can be modified by the user (from P01 to P38).
To set the operational parameters of a program:
1 Turn the knob to the or symbols to select the program you wish to
save / edit.
2 Keep the “PUSH” knob pressed for 3 seconds: the display will show the
cooking temperature.
3 Turn the knob to the or symbols to set the cooking temperature.
4 Press the “PUSH” knob: the display will show the cooking time.
5 Turn the knob to the or symbols to set the cooking time (from 1 to 99
min).
6Pressthe“PUSH” knob to exit from the data setting and saving phase. The
message “PEnd” will appear on the display and the parameters will be
saved.
7 After 3 seconds the display will show the parameters set in rotation.
8 To return to the “OFF” status keep the “STOP” button pressed for 4 seconds.
5.4 Running a program
From the “OFF” status proceed as follows:
1 Turn the knob to the or symbols to select one of the available
programs from P01 to P38. The display will show the parameters of the
selected program in rotation.
2 To start the program press the “START” button. The appliance will perform a
preheating cycle, showing the message “PrEh” on the display.
3 When preheating is finished, a series of beeps lasting 3 seconds indicate
that is possible to proceed with the cooking operation. The message “PrEh”
will flash on the display.
4 To start the cooking, keep the “START” button pressed for 2 seconds. The
display will show, in order, the set parameters, the time remaining until the
end of cooking and the program selected.
5 It is possible to start cooking early before the preheating temperature is
reached, by keeping the “START” button pressed for 3 seconds.
6 During the last minute of cooking, only the countdown of the remaining 60
seconds will be displayed. At the end, a beep and the text “End” flashing (for
20 minutes) will indicate that cooking has been completed.
7 To return to the “OFF” status keep the “STOP” button pressed for 4 seconds.

Instructions for the user
35
5.4.1 Extending a cooking operation
When a cooking operation finishes, it is possible to extend it manually:
1 While the display is showing the message “End”, press the “START” button;
the text “tP00” will appear on the display.
2 Turn the knob to the or symbols to set the additional minutes of
cooking; at most 20 extra minutes are allowed.
3 To start cooking with the extra time that has just been set, press the
“START” button for at least 2 seconds. A buzzer will sound to indicate the
restart of the cooking process.
4 At the end of cooking, the text “End” will continue to flash for the next 20
minutes and the oven light will remain on.
5.4.2 Modifying a program during cooking
The program can be modified during cooking:
1 Press the “PUSH” knob: the display will show the cooking temperature.
2 Modify the settings as described in points 3 - 8 of paragraph "5.3 Editing /
saving a program".
Settings modified during cooking are not stored.
3 3 seconds after the most recent change, the program exits its modification
status, saving the settings (the parameters modified as described in this
paragraph only remain stored until the end of cooking).

Instructions for the user
36
5.5 Manual cooking
The manual program is “P40” and can be edited by the user, but does not save
the cooking parameters set in memory. To select this program proceed as
follows:
• Save the program temporarily, as described in chapter 5.3 Editing / saving a
program. Unlike saved programs, the cooking time can even be set to
infinite; the display will show the text “InF”.
• After saving it, do NOT return to the “OFF” condition. Press the “START”
button. The appliance will perform a pre-heating cycle, showing the text
“PrEh” on the display.
• When preheating is finished, a series of beeps lasting 3 seconds indicate
that is possible to proceed with the cooking operation. The text “PrEh” will
flash on the display.
• To start the cooking, keep the “START” button pressed for 2 seconds. The
display will show, in order, the set cooking parameters.
• It is possible to start cooking early before the preheating temperature is
reached, by keeping the “START” button pressed for 3 seconds.
• The operating parameters can be modified during cooking, as indicated in
paragraph 5.4.2 Modifying a program during cooking.
• During the last minute of cooking, only the countdown of the remaining 60
seconds will be displayed. At the end, a beep and the text “End” flashing (for
20 minutes) will indicate that cooking has been completed.
• At the end of the cooking operation, to perform the same program again
press the “START” button once more.
• To return to the “OFF” status keep the “STOP” button pressed for 4 seconds.
The parameters set for the program are deleted.

Instructions for the user
37
5.6 Preheating with delayed start
The program with delayed pre-heating is set as follows:
• Turn the knob to the or symbols to select the program “P39”.
• Press the “PUSH” button for at least 3 seconds; the display shows the
current hour flashing.
• Turn the knob to the or symbols to set the current hour.
• Press the “PUSH” button; the display will show the minutes
flashing.
• Turn the knob to the or symbols to set the minutes.
• Press the “PUSH” button; the display will show the temperature flashing.
• Turn the knob to the or symbols to set the temperature.
• Press the “PUSH” button; the display will show the cooking start hour
flashing.
• Turn the knob to the or symbols to set the preheating start hour.
• Press the “PUSH” button; the display will show the minutes
flashing.
• Turn the knob to the or symbols to set the minutes.
• Press the “PUSH” button to exit from the data setting and saving
phase. The text “PEnd” appears on the display and after 3 seconds it
will display P39, the temperature and the pre-heating start time in
succession.
• To start the program press the “START” button for at least 2 seconds.
The display will show the current time and “P39A” in succession until
the program is activated at the set time.
The oven will perform preheating at the set time; during this phase the
display shows “P39”, the text “InF” and the set temperature in succession;
this will continue until interrupted by the “STOP” button.
The program must be activated every day. To reactivate it set function P39
and press the “START” button for at least 2 seconds.

Instructions for the user
38
5.7 Rapid cooling
The oven is equipped with a special function that allows the oven interior to be
cooled rapidly.
To activate it, when the display shows the text “OFF”, open the door and
press the “START” button for at leasts 4 seconds.
This will activate the internal motor fan, the heating elements are switched off
and the display shows the text “ - - - - “.
To stop the function, press the “STOP” button.

Instructions for the user
39
6. CLEANING AND MAINTENANCE
Important:
do not aim jets of water directly against the oven; avoid the use of
pressure jets.
NEVER USE A STEAM JET FOR CLEANING THE APPLIANCE.
Before performing any operations, switch off the power supply to the
oven.
6.1 Cleaning stainless steel
To keep stainless steel in good condition it should be cleaned regularly at the
end of the day. Let it cool first.
To clean and preserve the stainless steel surfaces, always use only specific
products that do not contain abrasives or chlorine-based acids.
How to use: pour the product onto a damp cloth and wipe the surface, rinse
thoroughly and dry with a soft cloth or chamois leather.
Do not use metallic sponges or sharp scrapers as they will damage
the surface.
Use ordinary non-abrasive products for steel, with the aid of wooden
or plastic utensils if necessary.
Rinse thoroughly and dry with a soft cloth or chamois leather.

Instructions for the user
40
6.2 Cleaning the oven cavity
To keep the oven in good condition it should be cleaned regularly at the end of
the day. Let it cool first. Take out all removable parts.
Remove the side guides by lifting them in order to release the front hook from
the side pin, sliding them out of the holes on the base of the oven.
Removing the guide frames makes it easier to clean the side
parts of the oven.
To remove the guide frames, pull the frame towards the inside of
the oven to unhook it from its housing A, then slide it out of the
seats at the back B.
• When cleaning is complete, repeat the above procedures in
reverse order to put the guide frames back in.

Instructions for the user
41
6.3 Cleaning and removing the door glass
To facilitate cleaning, it is possible to remove the door (see 7.2 Removing the
door) and place it on a canvas, or open it and lock the hinges in order to extract
the glass panels.
The glass panels of the door can be completely removed by following the
instructions provided below.
Removing the internal glass panel:
• Remove the internal glass panel by
pulling it upwards, following the
movement indicated by the arrows.
Doing this detaches the 4 pins attached
to the glass from their slots in the oven
door.
Cleaning:
• It is now possible to clean the external
glass panel and the panels removed
previously. Use absorbent kitchen roll. In
the case of stubborn dirt, wash with a
damp sponge and neutral detergent.
Replacing the glass panels:
• Reposition the internal glass panel,
taking care to centre and insert the 4
pins attached to the glass into their slots
in the oven door by applying slight
pressure.
Warning: before removing the glass panels, make sure that the door hinges
have been locked in the open position as described in “7.2 Removing the door”.
This operation may have to be repeated during the glass removal process if the
door is accidentally freed.

Instructions for the user
42
7. EXTRAORDINARY MAINTENANCE
The oven may require extraordinary maintenance or replacement of parts
subject to wear, such as gaskets, bulbs, etc.
The following instructions describe how to carry out these minor maintenance
operations.
Before performing any operations, switch off the power supply to the
oven.
7.1 Replacing the light bulb
If a light bulb needs to be replaced because it
is worn or burnt out, remove the guide
frames; see “6.2 Cleaning the oven cavity”.
Then remove the bulb cover using a tool (e.g.
a screwdriver).
Remove the bulb by unscrewing it as shown.
Replace the bulb with one of the same type
(25W). Replace the cover correctly, so that
the moulded part of the glass is facing the
door.
Use oven bulbs only (T 300°C).

Instructions for the user
43
7.2 Removing the door
Open the door completely.
Insert two pins into the holes in the two
hinges, away from them, until they engage.
Grasp the door on both sides with both
hands, lift it forming an angle of around 30°
and remove it.
To reassemble the door, put the hinges in
the relevant slots in the oven, making sure
that grooved sections C are resting
completely in the slots. Lower the door and
once it is in place remove the pins from the
holes in the hinges.
7.3 Removing the door seal
To permit thorough cleaning of the oven, the
seal may be removed. Before removing the
seal, take off the door as described above.
Once the door has been taken off, lift the
tabs at the corners as shown in the figure.

Instructions for the installer
44
8. OVEN INSTALLATION
The oven must be installed on a free-standing horizontal work top. The distance
from the rear wall must allow easy access to the terminal board for connection
of the power supply cable. Installation must be carried out by a qualified
technician and in compliance with EC DIRECTIVES currently in force.
8.1 Electrical connection
Make sure the voltage and the cross-section of the power cord match the
specifications indicated on the identification plate positioned on the side of the
oven. Do not remove this plate for any reason.
The oven is fitted with an H07RN-F three-core cable for operation at 220-
240V∼and a power supply plug.
The standard cable is of the three-core 3 x 1.5 mm2 H07RN-F type.
The power supply cable must be replaced by the manufacturer or by an
authorised service centre to prevent any risks.
The plug and wall-mounted socket must be of the same type (in accordance
with current regulations). Make sure that the supply line is suitably earthed.
Avoid the use of adapters and shunts.
If the appliance is connected to the electrical mains supply in a permanent
manner, install a multipolar cut-out device on the line, with contact opening
distance equal to or greater than 3 mm located near the appliance and in an
easily reachable position.
WARNING: if the phase voltage drops below 190V∼, the performance of the
oven may suffer, not due to the product itself.
The terminal indicated by this symbol links up parts that are normally earthed.
Connect the appliances appropriately using this terminal in
order to make sure that they are equipotential.
8.1.1 Safety thermostat
The oven is equipped with a safety device that takes action in case of serious
malfunction. To re-arm the safety device you must contact the technical
assistance service.
The manufacturer cannot be held liable for damage to persons or things
caused by failure to observe the above instructions or deriving from tampering
with any part of the appliance.
