Smeg CS20 User manual

Contents
33
1. INSTRUCTIONS FOR SAFE AND PROPER USE _______________34
2. INSTALLATION OF THE APPLIANCE ________________________36
3. ADAPTATION TO DIFFERENT TYPES OF GAS ________________38
4. FINAL OPERATIONS______________________________________40
5. DESCRIPTION OF CONTROLS _____________________________42
6. USE OF THE COOKING HOB _______________________________47
7. USE OF THE OVENS _____________________________________48
8. AVAILABLE ACCESSORIES ________________________________49
9. COOKING HINTS_________________________________________50
10. CLEANING AND MAINTENANCE ____________________________57
11. EXTRAORDINARY MAINTENANCE __________________________60
THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE
IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified
technician who must carry out a suitable check of the gas system,
install the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.

Introduction
34
1. INSTRUCTIONS FOR SAFE AND PROPER USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND
THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE
PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE
READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE
USING THE COOKER. ALSO KEEP THE SERIES OF NOZZLES SUPPLIED.
INSTALLATION MUST BE CARRIED OUT BY QUALIFIED PERSONNEL IN
ACCORDANCE WITH THE REGULATIONS IN FORCE. THIS APPLIANCE IS
INTENDED FOR DOMESTIC USES AND CONFORMS TO CURRENT
REGULATIONS IN FORCE. THE APPLIANCE HAS BEEN BUILT TO CARRY
OUT THE FOLLOWING FUNCTIONS: COOKING AND HEATING-UP OF FOOD.
ALL OTHER USES ARE CONSIDERED IMPROPER.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR IMPROPER
USE.
DO NOT LEAVE THE PACKING IN THE HOME ENVIRONMENT. SEPARATE
THE VARIOUS WASTE MATERIALS AND TAKE THEM TO THE NEAREST
SPECIAL GARBAGE COLLECTION CENTRE.
IT IS OBLIGATORY FOR THE ELECTRICAL SYSTEM TO BE GROUNDED
ACCORDING TO THE METHODS REQUIRED BY SAFETY RULES.
THE PLUG TO BE CONNECTED TO THE POWER CABLE AND THE SOCKET
MUST BE THE SAME TYPE AND MUST CONFORM TO CURRENT
REGULATIONS.
THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE HAS BEEN
BUILT IN.
NEVER UNPLUG BY PULLING ON THE CABLE.
IMMEDIATELY AFTER INSTALLATION CARRY OUT A BRIEF INSPECTION
TEST OF THE APPLIANCE, FOLLOWING THE INSTRUCTIONS BELOW.
SHOULD THE APPLIANCE NOT FUNCTION, DISCONNECT IT FROM THE
SUPPLY AND CALL THE NEAREST TECHNICAL ASSISTANCE CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
ALWAYS CHECK THAT THE CONTROL KNOBS ARE IN THE POSITION
(OFF) WHEN YOU FINISH USING THE HOB.
NEVER PUT INFLAMMABLE OBJECTS INTO AN OVEN: IF THEY CATCH FIRE
THEY COULD CAUSE A FIRE IN THE HOME.

Introduction
35
THE I.D. PLATE WITH TECHNICAL DATA, REGISTRATION NUMBER AND
BRAND NAME IS POSITIONED VISIBLY IN THE STORAGE COMPARTMENT.
THE PLATE MUST NOT BE REMOVED.
DO NOT INSTALL THIS APPLIANCE ON A RAISED PLATFORM.
DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO
TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.
DO NOT PUT PANS WITHOUT PERFECTLY SMOOTH AND FLAT BOTTOMS
ON THE COOKING HOB GRIDS.
DO NOT USE CONTAINERS OR BROILERS THAT EXTEND BEYOND THE
OUTER PERIMETER OF THE HOB.
THE APPLIANCE IS DESIGNED FOR USE BY ADULTS. DO NOT ALLOW
CHILDREN TO GO NEAR OR PLAY WITH IT.
REPLACED APPLIANCES MUST BE TAKEN TO A SPECIAL GARBAGE
COLLECTION CENTRE.
The manufacturer declines all responsibility for damage to persons
or things caused by non-observance of the above prescriptions or by
interference with any part of the appliance or by the use of non-original
spares.

Instructions for the installer
36
2. INSTALLATION OFTHE APPLIANCE
It is the law that all gas appliances are installed by competent persons.
Corgi gas installers are approved to work to safe and satisfactory
standards. All gas installation, servicing and repair work must be in
accordance with the gas safety regulations 1984 (installation and use) as
amended 1990.
This unit is equipped with a type Y fire protection, and may be set
against walls that are higher than the hob.
2.1 Electrical connection
Make sure that the power line voltage matches the specifications
indicated on the rating plate located inside the storage compartment.
This rating plate must never be removed.
The plug at the end of the power cable and the wall socket must be the
same type (conforming to regulations in force). Check that the power line
is adequately grounded. Do not use reducers, adapters or shunts.
On the power line, install an omnipolar cut-off device with contact cut-off
distance greater than or equal to 3 mm, located in an easily accessible
position near the unit.
If the power cable is replaced, the wire
section on the new cable must not be
less than 2.5 mm2(3 x 2.5 cable),
keeping in mind that the end to be
connected to the hob must have the
ground wire (yellow-
g
reen) longer by
at least 20 mm. Use only the special
cables available at our Service
Centres.
The manufacturer declines all responsibility for damage to persons
or things caused by non-observance of the above prescriptions or by
interference with any part of the appliance.

Instructions for the installer
37
2.2 Ventilation requirements
The room containing the appliance should have an air supply in
accordance with B.S. 5440 part 2 1989.
1. All rooms require an opening window or equivalent, and some
rooms will require a permanent vent as well.
2. For room volumes up to 5 m3an air vent of 100 cm2is required.
3. If the room has a door that opens directly to the outside, and the
room exceeds 1 m3no air vent is required.
4. For room volumes between 5 m3and 10 m3an air vent of 50 cm2is
required.
5. If there are other fuel burning appliances in the same room B.S.
5440 part 2 1989 should be consulted to determine the air vent
requirements.
6. This appliance must not be installed in a bed sitting room of less
than 20 m3or in a bathroom or shower room.
Windows and permanent vents should therefore not be blocked or
removed without first consulting a Corgi gas installer.
Failure to install appliances correctly is dangerous and could lead
to prosecution.
2.3 Connecting to natural and LPG gas
(Please see connection diagram)
Make the connection to the appliance using
flexible bayonet style hose in accordance to B.S.
669. The hose connection at the rear of the
appliance has a 1/2" BSP internal thread. Please
use seal Cbetween the flexible connection Land
the appliance supply tube B. When making the
connection, make sure that no stress of any kind
is applied to the cooker and that the hose does
not touch any sharp edges.
If connecting to LPG the bayonet hose must
have red bands on it.

Instructions for the installer
38
3. ADAPTATIONTO DIFFERENTTYPES OF GAS
Before performing any cleaning or maintenance work, detach the
appliance from the electrical socket.
The cooking hob of the cooker is inspection-tested for use with G 20
natural gas at a pressure of 20 mbars. If used with other types of gas,
you have to replace the nozzles and regulate the primary air to the
burners. Then regulate the minimum flame on the gas taps. For nozzle
replacement and burner adjustment you must raise the cooking hob as
described in the following paragraph.
3.1 Raising of cooking hob
Remove the grids, first the middle one then the ones at the sides; remove
all the burner caps, the flame cap crowns and the burners.
1. Remove the programmer buttons;
2. Remove the knobs;
3. Unscrew the front panel fixing screws and remove it after
disconnecting the thermostat tell-tale light faston;
4. Loosen the screws of the hinge on the back of the cooker;
5. Raise the surface from the front end;
6. Place the surface support brackets in the front groove of the side;
7. Proceed to replacement of the burner nozzles in accordance with the
appropriate gas table;
8. Adjust the primary air as described in paragraph “3.2 Regulation for
LPG”;
9. After adjustment, fully tighten the fixing screws.

Instructions for the installer
39
3.2 Regulation for LPG
Loosen screw Aand push air regulator
Bto the bottom.
With a 7 mm wrench, remove nozzle C
and replace it with the proper one
(follow the instructions on the
reference tables for the type of gas to
be used). The torque wrench setting of
the nozzle must not exceed 3 Nm.
Regulate the air by sliding regulator B
until reaching distance “X” shown in
the table in paragraph “3.4 Regulation
of primary air”. Lock regulator B by
tightening screw A.
Burner
Rated
heating
capacity
(kW)
LPG – G30/G31 28/37 mbar
Nozzle
diameter
1/100 mm
By-pass
mm
1/100
Reduced
flowrate
(W)
Flowrate
g/h G30
Flowrate
g/h G31
Auxiliary 1.05 48 30 380 76 75
Semi rapid 1.65 62 30 380 120 118
Rapid 2.55 76 45 800 185 182
Ultra rapid 3.25 85 75 1850 236 232
3.3 Regulation for natural gas
The cooking hob has been inspected for G 20 natural gas at a pressure
of 20 mbar. To allow the unit to work with this type of gas, perform the
same operations described in paragraph “3.2 Regulation for LPG”, but
choose the nozzles and regulate the primary air for natural gas, as shown
in the following table and in paragraph “3.4 Regulation of primary air”.
Burner
Rated
heating
capacity
(kW)
Natural gas – G20 20 mbar
Nozzle diameter
1/100 mm
Reduced flowrate
(W)
Auxiliary 1.05 73 380
Semi rapid 1.65 92 380
Rapid 2.55 115 700
Ultra rapid 3.25 130 1200

Instructions for the installer
40
3.4 Regulation of primary air
Referred to distance “X” in mm.
BURNER G20
20 mbar
G30/G31
28/37 mbar
Auxiliary 2.5 2.5
Semi rapid 1 1.5
Rapid 1.5 2.5
Ultra rapid 1.5 2.5
4. FINAL OPERATIONS
Having carried out the above adjustments, reassemble the appliance
following, backwards, the instructions in paragraph “3.1 Raising of
cooking hob”.
After adjustment to a different kind of gas from the one for which the
cooker has been tested, replace the plate inside the storage
compartment with one corresponding to the new kind of gas. This plate
can be obtained from your nearest Authorised Assistance Centre.
4.1 Adjustment of minimum for natural gas
Light the burner and take it to the minimum .
Remove the gas tap knob and turn the
adjustment screw inside or at the side of the tap
shaft (depending on the model) until there is a
regular minimum flame. Replace the knob and
check burner flame stability: (rapidly turning the
knob from maximum to minimum position, the
flame should not go out). Repeat the operation on
all the gas taps.

Instructions for the installer
41
4.2 Regulation of minimum for LPG
To regulate the minimum for LPG, completely tighten (clockwise) the
screw inside or next to the gas tap pin (depending on the model).
The diameters of the by-passes for each burner are given in table “3.2
Regulation for LPG”.
4.3 Arrangement of burners on cooking hob
BURNERS
1 Auxiliary
2 Semi rapid
3 Rapid
4 Ultra rapid
4.4 Positioning and levelling of the appliance
Having carried out the electricity and gas hook-up, level the appliance
using the four adjustable legs.

Instructions for the user
42
5. DESCRIPTION OF CONTROLS
5.1 Front control panel
All the cooker controls and commands are on the front panel.
Before using the main oven check that the electronic programmer is
showing the symbol (see paragraph “5.2.1 Clock adjustment”).
DESCRIPTION OF SYMBOLS
BACK LEFT BURNER BACK RIGHT BURNER
FRONT LEFT BURNER FRONT RIGHT BURNER
FRONT CENTRAL
BURNER
BACK CENTRAL
BURNER
MAIN OVEN
THERMOSTAT
AUXILIARY OVEN
THERMOSTAT
MAIN OVEN
FUNCTIONS
AUXILIARY OVEN
FUNCTIONS
COOKING HOB BURNER COMMAND KNOB
The flame is lit by pressing the knob and turning it
anticlockwise to maximum flame . To adjust the
flame turn the knob between maximum ( ) and
minimum ( ). The burner goes out when the knob is
returned to the position .

Instructions for the user
43
THERMOSTAT KNOB (OVENS)
Selection of cooking temperature is carried out by
turning the knob clockwise to the required temperature,
between 50° and 250°C.
The tell-tale light comes on to indicate that the oven is
warming up. When it goes out it means that the
required temperature has been reached. Regular
flashing means that oven temperature is being
constantly maintained at the programmed level.
FUNCTION SWITCH KNOB (OVENS)
Turn the knob to select from the following functions:
MAIN OVEN AUXILIARY OVEN
NO FUNCTION SET
NO FUNCTION SET
OVEN LIGHT
OVEN LIGHT
UPPER AND LOWER
HEATING ELEMENT
UPPER AND LOWER
HEATING ELEMENT
GRILL ELEMENT UPPER HEATING ELEMENT
GRILL ELEMENT + VENTILATION
LOWER HEATING ELEMENT
LOWER HEATING ELEMENT +
VENTILATED HEATING ELEMENT
GRILL ELEMENT
VENTILATED HEATING ELEMENT +
VENTILATION
GRILL + SPIT ELEMENT

Instructions for the user
44
5.2 Electronic Programmer
The programmer user instructions are valid only for the main oven.
LIST OF FUNCTIONS
MINUTE-COUNTER KEY
COOKING TIME KEY
END-OF-COOKING KEY
DECREASE TIME KEY
INCREASE TIME KEY
5.2.1 Clock adjustment
When using the oven for the first time, or after a power failure, the display
flashes regularly and indicates . Press the keys and at
the same time the keys o : each single press changes the time by 1
minute either up or down.
Before setting the programmer activate the desired function and
temperature.

Instructions for the user
45
5.2.2 Semiautomatic cooking
Use this setting for automatic oven switch-off at the end of cooking time.
By pressing key , the display lights up, showing ; keep the key
pressed and at the same time, press keys o to set the cooking
time.
Release key to start the programmed cooking time count. The display
will now show the right time together with symbols Aand .
5.2.3 Automatic cooking
Use this setting to automatically start and stop the oven.
By pressing key , the display lights up showing ; keep the key
pressed and at the same time, press keys or to set the cooking
time.
By pressing key the sum of the right time + cooking time will appear;
keep the key pressed and at the same time, press keys o to
regulate the end of cooking time.
Release key to start the programmed count and the display will show
the right time together with symbols A and .
After set-up, to see the cooking time remaining, press the key ; to see
the end of cooking time press the key .
Set-up with incoherent values is logically prevented (e.g. the contrast
between a cooking time and a longer period will not be accepted by the
programmer).
5.2.4 End of cooking
When cooking is over, the oven will automatically switch off and, at the
same time, an intermittent alarm will sound. After switching off the alarm,
the display will once again show the right time together with the symbol
, indicating that the oven has returned to manual operation mode.

Instructions for the user
46
5.2.5 Adjusting alarm volume
The acoustic alarm has three different settings. These can be operated,
while the alarm is sounding, by pressing key .
5.2.6 Switching off the alarm
The alarm switches off automatically after seven minutes. They can be
manually de-activated by pressing the keys and together.
5.2.7 Minute Counter
The programmer can also be used as a simple minute counter. By
pressing key , the display shows ; keep the key pressed and
at the same time press keys o . On releasing the key ,
programmed counting will begin and the display will show the current
time and the symbol .
After set-up, to see the remaining time, press the key .
Use as a minute counter does not interrupt functioning of the oven at the
end of the programmed time.
5.2.8 Cancellation of set data
Once the programme has been set, keep the key of the function to be
cancelled pressed, while at the same time is reached by means
of variation keys o . Time cancellation will be considered as end-of-
cooking time by the programmer.
5.2.9 Changing the set data
The cooking data entered can be changed at any time by keeping the
function key pressed and at the same time adjusting the keys o .

Instructions for the user
47
6. USE OFTHE COOKING HOB
6.1 Lighting of the cooking hob burners
Before lighting the cooking hob burners check that the flame cap crowns
are properly positioned with their appropriate burner caps: niche Amust
be centred with pin B.
Grid Cshould be used with Chinese woks.
Each knob corresponds to the burner indicated. The appliance is
equipped with an electronic lighting device. Just press and turn the knob
anticlockwise to the maximum flame symbol until the burner lights.
Keep the knob pressed for about 2 seconds to let the thermocouple heat
up. If the burner turns off when the knob is released, it means that the
thermocouple isn’t hot enough. Repeat ignition and keep the knob
pressed longer.
If the burners turn off accidentally, a safety device will trip after about 20
seconds to cut off gas flow (even with the gas tap open).
6.2 Practical advice for using the cooking hob burners
For better use of the burners and lower gas consumption, use covered
containers that are proportional in size to the burner to prevent the flame
from licking the sides (see paragraph “6.3 Diameter of containers”).
When water reaches the boiling point, lower the flame so that it doesn’t
overflow. To avoid burns or damage to the hob, all recipients or griddle
plates must be placed within the perimeter of the cooking hob. All
containers have to have a flat and smooth bottom. When using fats or
oils, be extremely careful that they don’t overheat and catch fire.
If the flame accidentally goes out, turn off the control knob and wait at
least 1 minute before trying to re-light the burner.

Instructions for the user
48
6.3 Diameter of containers
BURNERS
1 Auxiliary
2 Semi rapid
3 Rapid
4 Ultra rapid
5 Ultra rapid
Ø min. and max. (in cm)
12-14
16-20
18-24
20-24
20-26
7. USE OFTHE OVENS
7.1 Warnings and general advice
Before using the oven for the first time, pre-heat it to maximum
temperature (250°C) long enough to burn any manufacturing oily
residues which could give the food a bad taste.
After a power failure, the display will flash at regular intervals showing
. To regulate, refer to paragraph "5.2 Electronic Programmer”.
During cooking, do not cover the bottom of the oven with aluminium or
tin foil and do not place pans or oven trays on it as this may damage the
enamel coating. If you wish to use greaseproof paper, place it so that it
will not interfere with the hot air circulation inside the oven.
To prevent any steam in the oven creating
problems, open the door in two stages: half open
(5 cm approx.) for 4-5 seconds and then full
y
open. To access food, always leave the door
open as short a time as possible to prevent the
temperature in the oven from falling and ruining
the food.
7.2 Oven Light
It comes on when the function switch knob is turned to any position.
7.3 Storage compartment
A storage compartment, accessible by
pulling on the top edge of the door, is
located beneath the ovens.
Never store inflammable materials such as
rags, paper or the like. The compartment is
intended only for holding the metal
accessories of the range.

Instructions for the user
49
8. AVAILABLE ACCESSORIES
The oven features 4 support positions for
plates and racks of different height.
Oven grill: for cooking food on plates, small
cakes, roasts or food requiring light grilling.
Plate grill: for placing above plate for
cooking foods that might drip.
Oven plate: useful for catching fat from
foods on the grill above.
Pastry plate: for baking cakes, pizza and
oven desserts.
Roasting spit: useful for cooking chicken,
sausages and anything else requiring
uniform cooking over the whole surface.
Only for auxiliary oven.
Spit Frame: to be inserted in the guides of
the auxiliary oven before using the spit.
Accessories on Request
You can order the lower base and self-cleaning oven panels through
Authorised Assistance Centres.

Instructions for the user
50
9. COOKING HINTS
In fan-assisted mode preheating should be carried out at 30/40°C above
the cooking temperature. This considerably shortens cooking times and
reduces power consumption, as well as giving better cooking results.
Keep the oven door closed during cooking
9.1 Traditional cooking (main and auxiliary ovens)
FUNCTION SWITCH
THERMOSTAT SELECTOR SWITCH FROM
50° TO 250°C
This traditional cooking method, in which heat comes from above and
below, is suitable for cooking food on a single level. You have to pre-
heat the oven until the set temperature is reached. Place the food in the
oven only after the thermostat indicator light has turned off. very fatty
meats may be put in when the oven is still cold. Put frozen meat in
immediately, without waiting for it to thaw. The only precaution you need
to take is to set the temperature about 20°C lower and cooking time
about 1/4 longer than you would for fresh meat.
Use high-rim pans to prevent fat splashing and
dirtying the sides of the oven.

Instructions for the user
51
9.2 Hot-air cooking (main oven)
FUNCTION SWITCH
THERMOSTAT SELECTOR SWITCH FROM
50° TO 250°C
This system is suitable for cooking on several levels, including different
types of food (fish, meat etc.), without the tastes and smells mingling. Air
circulation in the oven ensures a uniform distribution of heat. Pre-heating
is not necessary.
Multiple cooking is possible as long as the cooking temperature of the
different foods is the same.
9.3 Grill cooking (main and auxiliary ovens)
FUNCTION SWITCH
THERMOSTAT SWITCH AT MAXIMUM
Permits rapid browning of foods. You are advised to place the pan in the
highest guide. For short-term cooking of small quantities, place the grid
in the third guide from the bottom. For long-term cooking and grills, put
the grid in the lowest guide in accordance with the size of the pieces.
Make sure that the oven door is closed during cooking.

Instructions for the user
52
9.4 Hot-air grilling (main oven)
FUNCTION SWITCH
THERMOSTAT SWITCH FROM 50° TO 200°C
Ensures uniform heat distribution with greater heat penetration into the
food. Food will be lightly browned on the outside and remain soft inside.
Keep the oven door closed during cooking. Heating up time must
not exceed 60 minutes.
9.5 Delicate cooking (auxiliary oven)
FUNCTION SWITCH
THERMOSTAT SELECTOR SWITCH FROM
50° TO 250°C
Ideal for pastries and cakes with wet covering and little sugar and damp
desserts in moulds. Excellent results can also be achieved in completing
cooking at the bottom and with dishes requiring heat in the lower area in
particular. The plate is best inserted at bottom level.
