Smeg ZAFA403NX User manual

LARDER
Instruction Booklet
KÜHLGERÄT
Bedienungsanleitung
RÉFRIGÉRATEUR
Guide D’utilisation
FRIGORIFERO MONOPORTA
Manuale di istruzioni
KOELKAST
Handleiding
CHŁODZIARKO
Przewodnik uzywania
ZAFA403NX

EN - 1 -
Index
BEFORE USING YOUR FRIDGE ............................................................ 2
Old and out-of-order fridges ............................................................................. 6
Installing and Operating your Fridge ............................................................ 7
Before Using your Fridge ................................................................................. 7
Information on No-Frost Technology ................................................................ 8
USAGE INFORMATION........................................................................... 9
Display and control panel ................................................................................. 9
Using the Control Panel ............................................................................................ 9
Cooler Set Button ...................................................................................................... 9
Operating Your Fridge ............................................................................................... 9
Super Cool Mode ...................................................................................................... 9
When would it be used? ............................................................................................ 9
Activating Super Cool Mode..................................................................................... 10
Economy Mode ........................................................................................................ 10
Cooler Temperature Settings.................................................................................... 10
Screen Saver Mode.................................................................................................. 10
Door Open Alarm Function....................................................................................... 10
Warnings About Temperature Settings............................................................ 10
Accessories ..................................................................................................... 11
Chiller shelf............................................................................................................... 11
Fresh dial ................................................................................................................. 12
ARRANGING FOOD IN THE APPLIANCE ............................................ 13
CLEANING AND MAINTENANCE ......................................................... 14
SHIPMENT AND REPOSITIONING........................................................ 14
Repositioning the door .................................................................................... 15
BEFORE CALLING SERVICE................................................................ 15
Tips for saving energy ..................................................................................... 17
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ........ 18

EN - 2 -
BEFORE USING YOUR FRIDGE
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the instructions.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
natural gas, but it is explosive. In the event of a leak

EN - 3 -
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
–sta󰀨 kitchen areas in shops, o󰀩ces and other
working environments.
–farm houses and by clients in hotels, motels and
other residential type environments.
–bed and breakfast type environments;
–catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 16 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.
• This appliance can be used by children aged from
8 years and above and persons with reduced

EN - 4 -
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are
not expected to use appliances safely unless
continuous supervision is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.

EN - 5 -
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for long
periods, switch o󰀨, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.

EN - 6 -
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding it, because
children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore,
take care not to harm environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE for
the reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual
in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specied purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled and
our company will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing
foods. It is not suitable for commercial or common use and/or for storing substances
except for food. Our company is not responsible for the losses to be occurred in the
contrary case.
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children to
play with the appliance or let them hang o󰀨 the door.
• Do not plug-in or out the plug from the receptacle with wet hands to
prevent electrocution!
• Do not place explosive or ammable material in your fridge for your
safety. Place drinks with higher alcohol amount vertically and by
closing their necks tightly in the fridge.
• Do not cover the body or top of fridge with lace. This a󰀨ects the
performance of your fridge.
• Fix the accessories in the fridge during transportation to prevent damage
to accessories.

EN - 7 -
Installing and Operating your Fridge
Before starting to use your fridge, you should pay attention to the following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• We do not take the responsibility of the damages that occur due to ungrounded usage.
• Place your fridge in a place that it would not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, ovens and heater cores, and
should be at least 5 cm away from electrical ovens.
• It should never be used outdoors or left under the rain.
• When your fridge is placed next to a deep freezer, there should be at least 2 cm between
them to prevent humidity on the outer surface.
• Do not place anything on your fridge, and install your fridge in a suitable
place so that at least 15 cm is available on the upper side.
• If you will place your fridge next to your kitchen cabinets, leave a space
of 2 cm between them.
• Fit the plastic wall spacers to the condenser at the back of the refrigerator
in order to prevent leaning to the wall for good performance.
• Install the distance adjustment plastic (the part with black vanes at the
rear) by turning it 90° to prevent the condenser from touching the wall.
• Refrigerator should be placed against a wall with a free distance not
exceeding 75 mm.
• The adjustable front legs should stabilized in an appropriate height to
allow your fridge operate in a stable and proper way. You can adjust the
legs by turning them clockwise (or in the opposite direction). This should be done before
placing food in the fridge.
• Before using your fridge, wipe all parts with warm water added with a tea spoonful
of sodium bicarbonate, and then rinse with clean water and dry. Place all parts after
cleaning.
Before Using your Fridge
• When it is operated for the rst time or after transportation, keep
your fridge in the upright position for 3 hours and plug it on to allow
e󰀩cient operation. Otherwise, you may damage the compressor.
• Your fridge may have a smell when it is operated for the rst time; the smell will fade
away when your fridge starts to cool.
• When the door of the cooler is closed, a
vacuum seal will form. Wait for about 1 minute
before reopening it.
• This application is optional for easy opening
of the door. With this application, a little
condensation may occur around this area and
you may remove it.
• Do not use plug adapter.

EN - 8 -
Information on No-Frost Technology
No-frost refrigerators di󰀨er from other static refrigerators in their
operating principle.
In normal refrigerators the humidity entering the refrigerators due
to opening the door and the humidity inherent in the food causes
freezing in the backside of air duct. To defrost the frost and ice
in the backside of air duct, you are periodically required to turn
o󰀨 the refrigerator, place the food that needs to be kept cooled in
a separately cooled. The situation is completely di󰀨erent in no-
frost refrigerators. Dry and cold air is blown into the refrigerator
compartment homogeneously and evenly from several points
via a blower fan. Cold air dispersed homogeneously and evenly
between the shelves cools all of your food equally and uniformly,
thus preventing humidity and freezing. Therefore your no-frost
refrigerators allows you ease of use, in addition to its huge capacity
and stylish appearance.

EN - 9 -
USAGE INFORMATION
Display and control panel
1
3
4
2
1. It is super cooling indicator.
2. It is cooler set value screen.
3. Sr alarm indicator.
4. Cooler set button.
Using the Control Panel
Cooler Set Button
The cooler set button allows changes to be made to the temperature of the cooler
compartment. Super cool and economy mode can also be activated using this button.
Sr Alarm
Sr alarm will change to red and an alarm will sound if any problems occur.
Operating Your Fridge
Super Cool Mode
When would it be used?
• To cooling huge quantities of food.
• To cooling fast food.
• To cooling food quickly.
• To store seasonal food for a long time.

EN - 10 -
Activating Super Cool Mode
Push the cooler set button until the super cool symbol illuminates. The buzzer will sound
twice and the mode will be set.
During Super Cool Mode
Super cool mode can be cancelled in the same way it is selected.
Economy Mode
Activating Economy Mode
• Press the cooler set button until the economy symbol illumintes.
• If no button is pressed for 1 second the mode will be set and the buzzer will sound twice
as conrmaiton.
• To cancel, press the cooler set button.
Cooler Temperature Settings
• The initial temperature value for the cooler setting indicator is "5 / Economy mode".
• Press the cooler set button once.
• When you rst press the button, the previous value will appear on the setting indicator
of the cooler.
• Whenever you press this button, a lower temperature will be set (+8 °C, +6 °C,
5/economy, +4 °C, +2 °C, or super cool).
• If you press the cooler set button until the super cool symbol appears on the cooler
setting indicator, and do not press any buttons for 1 second, super cool will ash.
• If you continue to press the same button, it will restart from +8 °C.
Screen Saver Mode
Purpose
This mode saves energy by switching o󰀨 all control panel lighting when the panel is left
inactive.
How to Use
• Screen saver mode will be activated automatically after 30 seconds.
• If you press any key while the lighting of the control panel is o󰀨, the current machine
settings will reappear on the display to let you make any change you wish.
• If you do not cancel the screen saving mode or press any key for 30 seconds, control
panel will remain o󰀨.
To deactivate the screen saving mode,
• To cancel the screen saving mode, rst of all, you need to press any key to activate the
keys, select ”5” set value and then press and hold the cooler set button for 10 seconds.
• To reactivate screen saving mode, select ”5” set value and then press and hold the
cooler set button for 10 seconds.
Door Open Alarm Function
If fridge door is opened more than 2 minutes, appliance sounds ‘beep beep’.
Warnings About Temperature Settings
• Do not switch to another adjustment before completing a setting.
• The temperature setting should be done by taking into consideration how often the fridge

EN - 11 -
If turbo fan is available on your product ;
Do not block air inlet and outlet openings when storing
food, otherwise air circulation that provided by turbo fan
will be impaired.
Chiller shelf
Keeping food in the Chiller compartment instead of the freezer
or refrigerator compartment allows food retain freshness and
avour longer, while preserving its fresh appearance. When
chiller tray becomes dirty, remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or sugar freeze
at temperature lower than that)
Normally people use the chiller compartment for raw sh, lightly
pickled, rice, etc...
!Do not put foods you want to freeze or ice trays in order to make ice.
Removing the Chiller shelf
• Pull the chiller shelf out toward you by sliding on rails.
• Pull the chiller shelf up from rail to remove.
Accessories
(In some models)
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
T/SN Between 10 and 43 (°C)
door is opened and closed, how much food is stored in it and the ambient temperature
in which the fridge is located.
• Depending on the ambient temperature, your fridge must operate nonstop up to 24
hours in order to cool down completely after it is plugged in for the rst time. During this
period, do not open the doors of your fridge frequently and do not overll.
• To prevent any damage on the compressor of your fridge when you want to restart
your fridge after unplugging it or after a power failure is restored, there is a function
which makes your fridge operate after a 5-minute delay. Your fridge will start operating
normally after 5 minutes.
• Fridge has been designed to operate in the ambient temperature ranges specied in
the standards according to the class of climate mentioned in the information label. The
operation of the fridge in environments with temperature values not complying with the
ones specied is not recommended for cooling e󰀩ciency.
• Your appliance is designed to operate
at ambient temperatures between
10°C - 43°C.

EN - 12 -
Fresh dial
When the humidity controler in the closed position, it
allows fresh fruit and vegetables to be stored longer.
In case of the crisper is totally full, the fresh dial is located
in front of crisper, should be opened. By means of this
the air in the crisper and humidity rate will be controlled
and endurance life will be increased.
If you see any condensation on glass shelf, humidity
control should be taken into the open positions.
Visual and text descriptions on the accessories section may vary
according to the model of your appliance.
Adjustable Door Shelf (In some models)
Six di󰀨erent height adjustments can be made to provide storage
areas that you need by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the shelf and pull the buttons on the side of the
door shelf direction of arrow. (Fig.1)
Position door shelf the height you need by moving up and down.
After you get the position that you want the door shelf, release the
buttons on the side of the door shelf (Fig.2) Before releasing the
door shelf, move up down and make sure the door shelf is xed.
Note: Before moving door shelf is loaded, you must hold the
shelf by supporting the bottom. Otherwise, door shelf could fall
o󰀨 the rails due to the weight. So damage may occur on the door
shelf or rails.
Fig. 1
Fig. 2
Fig. 1
Fig. 2
Fig. 2
Fig. 1
1.1.1 Adjustable Glass Shelf (In some models)
Adjustable glass shelf mechanism provides higher storage spaces with a simple movement.
To cover the glass shelf, push it.
You can load your food as you want in the resulting extra space. To bring the shelf in its
original position, pull it toward you.
(In some models)

EN - 13 -
ARRANGING FOOD IN THE APPLIANCE
• For normal operating conditions, adjusting the temperature value of the cooler partition
of the fridge to 4°C will be enough.
• To reduce humidity and consequent increase of frost never place liquids in unsealed
containers in the refrigerator. Frost tends to concentrate in the coldest parts of the
evaporator and in time will require more frequent defrosting.
• Never place warm food in the refrigerator. Warm food should be allowed to cool at
room temperature and should be arranged to ensure adequate air circulation in the
refrigerator compartment.
• Nothing should touch on the back wall as it will cause frost and the packages can stick
on the back wall. Do not open the refrigerator door too frequently.
• Arrange the meat and cleaned sh(wrapped in packages or sheets of plastic) which you
will use in 1-2 days,in the bottom section of the refrigerator compartment(that is above
the crisper) as this is the coldest section and will ensure the best storing conditions.
• You can put the fruits and vegetables into crisper without packing.
NOTE: Potatoes, onions and garlic should not be stored in the refrigerator.
Food Maximum Storing time Where to place in the
fridge department
Vegetables and fruits 1 week Vegetable bin
Meat and sh 2 - 3 Days
Wrapped in plastic foil or bags or in
a meat container
(on the glass shelf)
Fresh cheese 3 - 4 Days In special door shelf
Butter and margarine 1 week In special door shelf
Bottled products
milk and yoghurt
Until the expiry date
recommended by the
producer
In special door shelf
Eggs 1 month In the egg shelf
Cooked food All shelves

EN - 14 -
CLEANING AND MAINTENANCE
• Disconnect unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• The refrigerator should be cleaned periodically using a solution of
bicarbonate of soda and lukewarm water
• Clean the accessories separately with soap and
water. Do not clean them in the washing machine.
• Do not use abrasive products, detergents or soaps. After washing,
rinse with clean water and dry carefully. When the cleaning
operations have been completed reconnect the plug of the unit
with dry hands.
• You should clean the condenser (back of the appliance)
with broom ones a year in order to provide energy saving
and increase the productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.
SHIPMENT AND REPOSITIONING
• Original package and foam may be kept for re-transportation (optionally).
• You should fasten your fridge with thick package, bands or strong cords and follow the
instructions for transportation on the package for re-transportation.
• Remove movable parts (shelves, accessories,
vegetable bins etc.) or x them into the fridge
against shocks using bands during re-positioning
and transportation.
!Carry your fridge in the upright position.
Replacing LED Lighting
If your fridge has LED lighting contact the help desk as this should be changed by authorized
personnel only.

EN - 15 -
Repositioning the door
• It is not possible to change the opening direction of your fridge door, if the door handles
on your fridge are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any handles.
• If the door opening direction of your fridge may be changed, you should contact the
nearest Authorized Service to have the opening direction changed.
BEFORE CALLING SERVICE
Errors
Your fridge will warn you if the temperatures for the cooler is at improper levels or if a
problem occurs with the appliance. Alarm indicator ( ) is displayed in the control panel.
ERROR TYPE ( ! ) Alarm indicator
MEANING "Failure" Warning
WHY There is/are some part(s) out of order or there is a failure in the cooling process.
The product is plugged for the rst time or a long-time power interruption for 1 hour.
WHAT TO DO
Check the door is open or not and check if the product working 1 hour. If the door is
not open and the product had worked 1 hour, call service for assistance as soon as
possible.
If your fridge is not working properly, it may be a minor problem, therefore check the
following, before calling an electrician to save time and money.
Your fridge is not operating
Check if:
• There is power
• The plug is correctly connected to the socket
• The plug or mains fuse has blown
• The socket is faulty. Examine this by plugging your fridge into a working socket.
What to do if your appliance performs poorly;
Check that;
• You have not overloaded the appliance ,
• The fridge temperature set to 2.
• The door is closed perfectly ,
• There is no dust on the condenser ,
• There is enough place at the rear and side walls.

EN - 16 -
our fridge is operating noisily
Cracking (ice cracking) noise occurs:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Motor noise: Indicates the compressor is operating normally. The compressor may
cause more noise for a short time when it is rst activated.
Bubbling noise and splash: Due to the ow of the refrigerant in the tubes of the
system.
Air blowing noise: Indicates normal operation of the system due to the circulation of
air.
There is a build-up of humidity inside the cooler
Check if:
• All food is packed properly. Containers must be dry before being placed in the fridge.
• The fridge door is opened frequently. Humidity of the room enters the fridge when
the doors are opened. Humidity increases faster when the doors are opened more
frequently, especially if the humidity of the room is high.
The door is not opening and closing properly
Check if:
• There is food or packaging preventing the door from closing
• The door compartments, shelves and drawers are placed properly
• The door joints are broken or torn
• Your fridge is level.
Recommendations
• If the appliance is switched o󰀨 or unplugged, wait at least 5 minutes before plugging the
appliance in or restarting it in order to prevent damage to the compressor.
• If you will not use your fridge for a long time (e.g. in summer holidays) unplug it. Clean
your fridge according to chapter cleaning and leave the door open to prevent humidity
and smell.
• If a problem persists after you have followed all the above instructions, please consult
the nearest authorised service centre.
• The appliance you have purchased is designed for domestic use only. It is not suitable
for commercial or common use. If the consumer uses the appliance in a way that does
not comply with this, we emphasise that the manufacturer and the dealer will not be
responsible for any repair and failure within the guarantee period.

EN - 17 -
Tips for saving energy
1.Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near
heat source (radiator, cooker.. etc). Otherwise use an insulating plate.
2.Allow ward food and drinks to cool down outside the appliance.
3.When placing, drinks and slops they must be covered. Otherwise humidity increases at
the appliance. Therefore the working time gets longer. Also covering drinks and slops
helps to save smell and taste.
4.When placing food and drinks, open the appliance door as briey as possible.
5.Keep close the covers of any di󰀨erent temperature compartment in the appliance (crisper,
chiller ...etc ).
6. The door gasket must be clean and pliable. In case of wear, if your gasket is detachable,
replace the gasket. If not detachable, you have to replace the door.

EN - 18 -
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
1) Turbo fan *
2) Wine rack / bottle shelf *
3) Refrigerator shelves
4) Top crisper / Chiller shelves *
5) Bottom crisper cover
6) Bottom crisper
7) Levelling feet
8) Bottle shelf
9) Door shelves
10) Egg holder
* In some models
10
