Smeg KESI120X Technical manual

GB INSTRUCTION ON MOUNTING AND USE

1
7
6
52
4
3
2
1
4
6
7
5
3
2
4
1
5
6
7
3
7
6
5
4
3
2
1
7
6
52
4
1
3
6
5
2
7
3
1
7
6
1
32
5
4
4
1A 1B
1C
1D
1F
1G
1H

gg
j
h
i
g
g
f
f1
f2
2
3
4A 4B 4C

3
4
4
4
4
44
6
6
7
7
7
7
8
8
2a
2a
2a
5
7
9
10
10
10 10
11
11
14,5
273
273
244
214
190
6
12
2b
2a
2b
S
B
5

15
15
15
15
15
16
16
15
15
13A
15
14
H
13F
F
G
6

18
18
18
18
18
18
18
18
18 18
M
17
19
X
X
20
20
19
17
7

Consult the designs in the front pages referenced in the text by
alphabet letters. Closely follow the instructions set out in this
manual. All responsibility, for any eventual inconveniences, damages
or fires caused by not complying with the instructions in this manual,
is declined.
The cooker hood must be placed at a minimum distance of 50 cm
from the cooking plane for electric cookers and 5cm for gas or
mixed cookers.
Do not tile, grout or silicone this appliance to the wall. Surface
mounting only.
The hood is equipped with a top air outlet B for discharge of fumes
to the outside (Ducting version  exhaust pipe and pipe fixing
clamps not provided).
Should it not be possible to discharge cooking fumes and vapour to
the outside, the hood can be used in the filter version, fitting an
activated carbon filter and the deflector F
on the support (bracket) G, fumes and vapours are recycled through
the top grille H by means of an exhaust pipe connected to the top air
outlet B and the connection ring mounted on the deflector F (exhaust
pipe and pipe fixing clamps not provided).
The models with no suction motor only operate in ducting mode, and
must be connected to an external suction device (not supplied).
Expansion wall plugs are provided to secure the hood to most types
of walls/ceilings. However, a qualified technician must verify suitability
of the materials in accordance with the type of wall/ceiling. The wall/
ceiling must be strong enough to take the weight of the hood.
Do not tile, grout or silicone this appliance to the wall. Surface
mounting only.
Do not fix chimney flue to furniture or fly over shelves unless the
chimney flue can be easily remove , in case maintenance is ever
require .
Installation - Fig. 5-6-7
Preliminary information for installing the hoo
Assembling the eflector (Fig. 6 - 3 parts  only for filter version):
The three parts should be fixed with 2 screws, the deflector extension
is adjustable and should correspond to the width of the chimney flue
support, to which it is then fixed.
During electrical connection ensure the power supply is disconnected
at the domestic main switch.
1. Adjust extension of the hood support structure, as the final
height of the hood depends on this, and remember that with
installation completed the hood must be at least 50 cm above the
cook-top for electric cookers and 5 cm for gas or mixed
cookers.
2. a. Fix the two sections of the structure using 8 screws.
b. If the hood is provided with extensions longer than the
minimum, fit the reinforcement bracket S to the frame, using 4
screws.
3. Place the ceiling hole diagram directly above the cook-top (the
center of the diagram must match the center of the cook-top and
the edges must be parallel to the sides of the cook-top  the side
of the diagram with the wording FRONT corresponds to the
control panel side). Prepare the electrical connection.
4. Drill as shown (6 holes for 6 wall plugs  4 plugs for fixture),
screw the outer screws leaving a space of about 1 cm. between
the screw head and the ceiling.
5. Fit an exhaust pipe inside the truss and connect it to the motor
compartment connection ring (exhaust pipe and fixing brackets
are not supplied).
6. Hook the frame onto the 4 screws (see step 4).
CAUTION! The side of the truss with connection box corresponds
to the side of the control panel with hood assembled.
. Tighten the 4 screws.
8. Insert and tighten another 2 screws in the remaining free holes
for secure fixing.
9. Carry out the electrical connection to the mains power supply,
only turn on the power supply upon completion of assembly.
10. Hook the hood onto the truss, ensuring it fits properly  to hook
the hood onto the truss partially tighten 4 screws (see also step
12).
11. Secure the hood to the truss using two screws; this will also help
center the two sections.
12. Tighten the 4 screws securing the truss to the hood.
13. For extractor versions (13A), connect the other end of the
exhaust pipe to the flue.
For filter versions (13F), fit deflector F to the truss and secure it
to the bracket supplied using 4 screws, then connect the
exhaust pipe to the connection ring located on the deflector.
14. Fit the nuts with fixing hooks supplied inside the top and bottom
sections of the flues at the rectangular slots. A total of 10 nuts
must be fitted.
15. Join the two top sections of the flue to cover the truss so that one
of the slots on the sections is situated on the same side of the
control panel and the other on the opposite side. Screw the two
sections together with 4 screws (2 each side- see the plan
diagram for joining the two sections).
16. Fix the top flue assembly to the truss, near the ceiling, with two
screws (one each side).
1 . Carry out electrical connection of control panel and bulbs.
Warning! Make connections taking care to insert the
connectors in the right way.
18. Join the two bottom sections of the flue covering the truss using
6 screws (3 each side, see the plan diagram for joining the two
sections).
19. Insert the bottom section of the flue in its seat so that it
completely covers the motor compartment and electrical
connection box, then ensure it from inside the hood using two
screws.
20. Apply the 2 tabs (supplied) to cover the fixing points of the
bottom flue (CAUTION! THE BOTTOM FLUE TABS ARE THE
NARROWER AND SHALLOWER ONES).
The wider and deeper tabs are those used for the top flue, and
must be cut to size.
21. Turn the mains power on again at the central electrical panel and
check for correct hood operation.
Electrical connection
The electrical tension must correspond to the tension noted on the
label placed inside the cooker hood. Connect the electrical plug,
where provided, to the an easily accessible outlet in conformity with
local standards in force.
Where an electrical plug is not provided (for direct connection to
electrical network) place a standards approved bipolar switch with
an aperture distance of not less than 3mm (accessible) from the
contacts.

Description of the hoo - Fig. 1
1 Control panel
2 Grease filter
3 Grease filter release handle
4 Halogen lamp
5 Vapour screen
6 Telescopic chimney
7 Air outlet (used for filter version only)
Operation 
Mo el with electronic controls
1- Motor OFF button
2-ON button and motor speed selection button 1 - 2 - 3 - 1 - 2 -
. . . .
3- Speed 1 LED
4- Speed 2 LED and metal grease filter saturation LED (in this
latter case, the LED will flash - See instructions on grease filter
cleaning).
5- Speed 3 LED and active carbon filter saturation LED (in this
latter case, the LED will flash - See instructions on active
carbon filter replacement).
Warning!
The active carbon filter saturation LED is not activated.
In order to activate the active carbon filter saturation indicator,
press buttons 2 and 7 simultaneously for 3 seconds. Initially,
only LED 4 will flash, then after the 3 seconds have passed,
LED 5 will also start flashing, indicating that the active carbon
filter saturation control system is active.
To switch off the system, re-press the same two buttons: after
3 seconds LED 5 will stop flashing and the device will be
switched off.
6 - Intensive speed LED
7 - Intensive speed ON switch
This speed should be used when the concentration of cooking
fumes or odours is particularly strong (for example when frying,
cooking fish etc.). The fast speed will run for about 5
minutes and then return to the speed previously set automatically
(1, 2 or 3), or switch off if no speed was selected. T o
turn off the fast speed, before the end of the 5 minutes, press
button 1 or button 2.
8 - OFF lamp button
9 - ON lamp button
If the hood fails to operate correctly, briefly disconnect it from the
mains power supply for almost 5 sec. by pulling out the plug. Then
plug it in again and try once more before contacting the Technical
Assistance Service.
1234 56789
Operation 
Mo el with button panel
A. on/off light switch
B. on/off aspiration switch and minimum power selection
B+C. medium power selection aspiration switch
B+D. maximum power selection aspiration switch
E. operating gauge (foreseen in the model with round buttons)
a. on/off light switch
b. off aspiration switch
c. minimum power selection aspiration switch
. medium power selection aspiration switch
e. maximum power selection aspiration switch
Operation 
All cooker hoo versions
Use the high suction speed in cases of concentrated kitchen
vapours. It is recommended that the cooker hood suction is switched
on for 5 minutes prior to cooking and to leave in operation during
cooking and for another 15 minutes approximately after terminating
cooking.
ABCD
DEF GH
ABC D E
abcde

Maintenance
Prior to any maintenance operation ensure that the cooker hood is
disconnected from the power supply.
Cleaning
The cooker hood should be cleaned regularly internally and externally.
For cleaning use a cloth moistened with denatured alcohol or neutral
liquid detergents. Avoid abrasive detergents.
Warning:
Failure to carry out the basic standards of the cleaning of the cooker
hood and replacement of the filters may cause fire risks.
Therefore we recommend oserving these instructions.
Grease filter
This must be cleaned once a month (and, for the model with
electronic control panel, every time LED 4 starts to flash  see
preceding page) using non aggressive detergents, either by hand or
in the dish-washer, which must be set to a low temperature and a
short cycle.
When washed in a dish-washer, the grease filter may discolour
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle (f) - (Fig.
2).
Only for mo el with electronic control panel:
Once the grease filters have been cleaned, press button 1 (see
preceding page) for about 3 seconds until you hear the acoustic
signal (beep): the LED 4 will now stop flashing.
Charcoal filter (filter version only)
It absorbs unpleasant odours caused by cooking.
The charcoal filter can be washed once every two months (when
using the hood 2,5 hours per day, in avarage and, for the model with
electronic control panel, every time LED 5 starts to flash  see
preceding page) using hot water and a suitable detergent, or in a
dish-washer at 65°C (if the dish-washer is used, select the full cycle
function and leave dishes out).
Eliminate excess water without damaging the filter, then remove the
mattress located inside the plastic frame and put it in the oven for 10
minutes at 100° C to dry completely. Replace the mattress every 3
years and when the cloth is damaged.
Remove the filter holder frame by turning the knobs (g) 90° that affix
the chimney to the cooker hood (Fig. 3).
Insert the pad (i) of activated carbon into the frame (h) and fit the
whole back into its housing (j).
Only for mo el with electronic control panel:
Once you have replaced the charcoal filter, press button 1 (see
preceding page) for about 3 seconds until you hear the acoustic
signal (beep).
LED 5 will now stop flashing.
Replacing lamps - Fig. 4
Warning!
Prior to touching the light bulbs ensure they are cooled down.
For models shown in Fig. 1A:
1. press on the lamp cover and release to open. (fig. 4A).
2. Replace the damaged light bulb.
Only use halogen bulbs of 20W max (G4), making sure you do
not touch them with your hands.
3. Close the lamp cover (it will snap shut).
For models shown in Fig. 1B-1C-1D-1G-1H:
1. Extract the guard by levering it off with a small screwdriver or
similar tool.. (fig. 4B).
2. Replace the damaged light bulb.
Only use halogen bulbs of 20W max (G4), making sure you do
not touch them with your hands.
3. Close the lamp cover (it will snap shut).
For models shown in Fig. 1E:
1. Use a small screwdriver as a lever on the borders of the lamp in
order to remove the lightbulb. (fig. 4C).
2. Slide out the lightbulb to be replaced and replace with a new 12V
20W 30° Ø35 12V GU4 PHILIPS STANDARD LINE code
425409.
If the lights o not work, make sure that the lamps are fitte
properly into their housings before you call for technical
assistance.
Caution
This appliance is designed to be operated by adults. Children should
not be allowed to tamper with the controls or play with the appliance.
Do not use the cooker hood where the grill is not correctly fixed! The
suctioned air must not be conveyed in the same channel used for
fumes discharged by appliances powered by other than electricity.
The environment must always be adequately aerated when the
cooker hood and other appliances powered by other than electricity
are used at the same time. Flambé cooking with a cooker hood is
prohibited. The use of a free flame is damaging to the filters and may
cause fire accidents, therefore free flame cooking must be avoided.
Frying of foods must be kept under close control in order to avoid
overheated oil catching fire. Carry out fumes discharging in
accordance with the regulations in force by local laws for safety and
technical restrictions.

LI2CVA Ed. 04/04
