EN - Instruction on mounting and use
Closely follow the instructions set out in this manual. All
responsibility, for any eventual inconveniences, damages or fires
caused by not complying with the instructions in this manual, is
declined. This appliance is intended to be used in household and
similar application such as: - staff kitchen areas in shop, offices
and other working environments; - farm houses; - by clients in
hotels, motels and other residential type environments; - bed and
breakfast type environments.
The hood can look different to that illustrated in the drawings
in this booklet. The instructions for use, maintenance and
installation, however, remain the same.
• It is important to conserve this booklet for consultation at any
moment. In the case of sale, cession or move, make sure it is
together with the product.
• Read the instructions carefully: there is important information
about installation, use and safety.
• Do not carry out electrical or mechanical variations on the
product or on the discharge conduits.
• Before proceeding with the installation of the appliance verify
that there are no damaged all components. Otherwise
contact your dealer and do not proceed with the installation.
Note: The parts marked with the symbol "(*)" are optional
accessories supplied only with some models or otherwise not
supplied, but available for purchase.
Caution
• Before any cleaning or maintenance
operation, disconnect hood from the mains
by removing the plug or disconnecting the
mains electrical supply.
• Always wear work gloves for all
installation and maintenance operations.
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
• Children shall not be allowed to tamper
with the controls or play with the appliance.
• Cleaning and user maintenance shall not
be made by children without supervision.
• The premises where the appliance is
installed must be sufficiently ventilated,
when the kitchen hood is used together
with other gas combustion devices or other
fuels.
• The hood must be regularly cleaned on
both the inside and outside (AT LEAST
ONCE A MONTH).
• This must be completed in accordance
with the maintenance instructions provided.
Failure to follow the instructions provided
regarding the cleaning of the hood and
filters will lead to the risk of fires.
• Do not flambé under the range hood.
• Do not remove filters during cooking.
• For lamp replacement use only lamp type
indicated in the Maintenance/Replacing
lamps section of this manual.
The use of exposed flames is detrimental
to the filters and may cause a fire risk, and
must therefore be avoided in all
circumstances.
Any frying must be done with care in order
to make sure that the oil does not overheat
and ignite.
CAUTION: Accessible parts of the hood
may become hot when used with cooking
appliances.
• Do not connect the appliance to the mains
until the installation is fully complete.
• With regards to the technical and safety measures to be adopted
for fume discharging it is important to closely follow the regulations
provided by the local authorities.
• The air must not be discharged into a flue that is used for
exhausting fumes from appliance burning gas or other fuels.
• Do not use or leave the hood without the lamp correctly mounted
due to the possible risk of electric shocks.
• Never use the hood without effectively mounted grids.
• The hood must NEVER be used as a support surface unless
specifically indicated.
• Use only the fixing screws supplied with the product for
installation or, if not supplied, purchase the correct screws type.
• Use the correct length for the screws which are identified in the
Installation Guide.
• In case of doubt, consult an authorized service assistance center
or similar qualified person.

3
WARNING!
• Failure to install the screws or fixing device in accordance
with these instructions may result in electrical hazards.
• Do not use with a programmer, timer, separate remote
control system or any other device that switches on
automatically.
• This appliance is marked according to the European directive
2012/19/EC on Waste Electrical and Electronic Equipment
(WEEE).
• By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate
waste handling of this product.
• The symbol on the product, or on the documents
accompanying the product, indicates that this appliance may not
be treated as household waste. Instead it should be taken to the
appropriate collection point for the recycling of electrical and
electronic equipment. Disposal must be carried out in accordance
with local environmental regulations for waste disposal.
• For further detailed information regarding the process, collection
and recycling of this product, please contact the appropriate
department of your local authorities or the local department for
household waste or the shop where you purchased this product.
Appliance designed, tested and manufactured according to:
• Safety: EN/IEC 60335-1; EN/IEC 60335-2-31, EN/IEC 62233.
• Performance: EN/IEC 61591; ISO 5167-1; ISO 5167-3; ISO
5168; EN/IEC 60704-1; EN/IEC 60704-2-13; EN/IEC 60704-3; ISO
3741; EN 50564; IEC 62301.
• EMC: EN 55014-1; CISPR 14-1; EN 55014-2; CISPR 14-2;
EN/IEC 61000-3-2; EN/IEC 61000-3-3. Suggestions for a correct
use in order to reduce the environmental impact: Switch ON the
hood at minimum speed when you start cooking and kept it
running for few minutes after cooking is finished. Increase the
speed only in case of large amount of smoke and vapor and use
boost speed(s) only in extreme situations. Replace the charcoal
filter(s) when necessary to maintain a good odor reduction
efficiency. Clean the grease filter(s) when necessary to maintain a
good grease filter efficiency. Use the maximum diameter of the
ducting system indicated in this manual to optimize efficiency and
minimize noise.
Use
The hood is designed to be used either for exhausting or filter
version.
Extraction version
In this case the fumes are conveyed outside of the building by
means of a special pipe connected with the connection ring
located on top of the hood.
CAUTION!
The exhausting pipe is not supplied and must be purchased apart.
Diameter of the exhausting pipe must be equal to that of the
connection ring.
CAUTION!
If the hood is supplied with active charcoal filter, then it must be
removed.
Connect the hood and discharge holes on the walls with a
diameter equivalent to the air outlet (connection flange).
! Use a duct of the minimum indispensable length.
! Use a duct with as few elbows as possible (maximum elbow
angle: 90°).
! Avoid drastic changes in the duct cross-section.
Filtration version
The aspirated air will be degreased and deodorised before being
fed back into the room.
In order to use the hood in this version, you have to install a
system of additional filtering based on activated charcoal.
Attention! If the hood is not supplied with carbon filter, then it
must be ordered and mounted.

4
Installation
The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the range
hood must be not less than 50cm from electric cookers and 65cm
from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.
Electrical connection
The mains power supply must correspond to the rating indicated
on the plate situated inside the hood. If provided with a plug
connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after installation.
If it not fitted with a plug (direct mains connection) or if the plug is
not located in an accessible area, after installation, apply a double
pole switch in accordance with standards which assures the
complete disconnection of the mains under conditions relating to
over-current category III, in accordance with installation
instructions.
WARNING!
Before re-connecting the hood circuit to the mains supply and
checking the efficient function, always check that the mains cable
is correctly assembled.
The hood is provided with a special power cable ; if the cable is
damaged, request a new one from Technical Service.
Mounting
Before beginning installation:
• Check that the product purchased is of a suitable size for the
chosen installation area.
• Remove the charcoal (*) filter/s if supplied (see also relative
paragraph). This/these is/are to be mounted only if you want
lo use the hood in the filtering version.
• Check (for transport reasons) that there is no other supplied
material inside the hood (e.g. packets with screws (*),
guarantees (*), etc.), eventually removing them and keeping
them.
Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must verify
suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take the
weight of the hood.
Do not tile, grout or silicone this appliance to the wall. Surface
mounting only.
Operation
The hood is fitted with a control panel with aspiration speed
selection control and a light switch to control cooking area
lights.
a. ON/OFF light switch
b. Speed 1/OFF switch
c. 2-speed selection
d. 3-speed selection

5
Maintenance
Cleaning
Clean using ONLY a cloth dampened with neutral liquid
detergent. DO NOT CLEAN WITH TOOLS OR
INSTRUMENTS. Do not use abrasive products. DO NOT USE
ALCOHOL!
Grease filter
Fig. 10-21
Traps cooking grease particles.
The grease filter must be cleaned once a month using non
aggressive detergents, either by hand or in the dishwasher,
which must be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolor
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.
Charcoal filter (filter version only)
Fig. 20
It absorbs unpleasant odors caused by cooking.
The saturation of the charcoal filter occurs after more or less
prolonged use, depending on the type of cooking and the
regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least
every four months.
The charcoal filter may NOT be washed or regenerated.
Remove the grease filters.
Apply one charcoal filter each side and hook in onto the hood.
Refit the grease filter.
Replacing lamps
Disconnect the appliance from the electricity.
Warning! Prior to touching the light bulbs ensure they are
cooled down.
Extract the drawer completely.
Put the grill back.
Replace the damaged lamp.
Use E14 2,5W max LED lamps only. For more details, check
enclosed leaflet “ILCOS D” (alfanumeric position “1e”).
If the lights do not work, make sure that the lamps are fitted
properly into their housings before you call for technical
assistance.

6
中文-安装和使用说明
请务必严格遵守本手册中的说明指示。对于因不遵
守本手册中的说明指示而导致的设备问题、损伤与
火灾，本公司概不负责。本抽油烟机的设计用途为
抽吸烹饪产生的油烟与蒸汽，仅供家庭使用。
产品若与图示不同，请以实物为准。任何与安
装、使用、保养说明不符的特点描述，也请以
实物为准。
•必须妥善保管所有产品附带的手册，以便随时查阅。
如果出售、转让或搬迁本机，请确保说明手册与产
品同在。
•请仔细阅读说明：内有关于安装、使用和安全的重
要信息。
•切勿对产品或排气管进行电气或机械更改。
•请先检查确保抽油烟机完整无损，然后才可
进行安装。否则请联系经销商，不可进行安装。
备注：标有(*)
号的零件是只为某些型号供应的可选性配件，或是
不随机供应而需另行购买的零件。
警告
·在进行任何清洁或维护操作之前
，请切断抽油烟机的电源，拔下插
头或切断居所内的总开关。
·所有安装和维护操作都必须使用
工作手套。
·8岁或以上儿童，身体、感官或
智力残障人士，或缺乏经验和必要
知识的人士，必须在监控下或获得
必要的安全使用指示并理解相关危
险之后，方可使用本设备。
·儿童必须得到监控，不可玩弄本
设备。
·儿童不得在缺乏监控的情况下，
对本设备进行清洁和维护。
·如果抽油烟机与其他燃气或燃烧
设备同时使用，安装地点必须具有
良好的通风条件。
·抽油烟机必须经常进行内外清洁
（至少每月一次），请遵守维护说
明指示。不遵守抽油烟机的清洁及
滤网的更换清洁规范，可导致火灾
风险。
·严禁在抽油烟机下明火烧烤食物
·更换灯泡只可使用本手册的灯泡
维护/更换章节中指示的灯泡类型。
使用明火会损害滤网，可能会导致
火灾，在任何情况下必须避免。
油炸必须注意控制，避免过热的烹
油着火。
注意：使用炉灶时，抽油烟机可触
及的部分可能会发热。
• 安装未全部完成时，切勿使设备通电。
•关于排烟需采取的技术与安全措施，必须严格遵守
当地有关部门的规定。
•抽吸的空气不得排入燃气设备或其他燃烧设备产生
油烟的排烟管道。
•如抽油烟机的灯泡安装不当，切勿使用，亦不可置
之不理，会有触电风险。
• 切勿使用格栅安装不当的抽油烟机！
•抽油烟机切不可用于放置物品，除非有本说明手册
有明确指示。
•安装只可使用产品配送的固定螺丝，如果没有配送，
请购买类型正确的螺丝。
• 请使用安装指南中指定的螺丝正确长度。
•如有疑问，请联系授权的售后服务中心或类似的合
资格人员。
注意!
·安装不符合本手册规定的螺丝和固定设备，可能
会导致电气风险。
·切勿使用独立的编程器、计时器、遥控器或任何
自动开启的设备。
本设备标明符合关于废旧电气电子设备的2012/19/EC
欧盟指令（WEEE）。请确保本产品以正确方式处理，
用户必须预防它对环境与健康可能产生的负面影响。
产品或附属文件上的标志
表示本产品不得作为家庭垃圾处理，必须交付
