Smeg Swm65eg User manual

TECNOLOGIACHEARREDA

)NSTRUCTIONSBOOK

3

CONTENTS

ENGLISH

Dear Customer,

Thank you for choosing our product.

Please read these instructions carefully before connecting and us-

ing the appliance.

Knowledge of the operating principles will help guarantee correct and safe use of the appliance.

This instruction booklet contains the technical characteristics of the washing machine and is full

of useful information regarding its operation, all designed to help you get the best out of your ap-

pliance. If the appliance is sold or handed over for use by others, remember to give the new user

the instruction booklet.

NOTES AND ADVICE FOR THE USER 4-5

ìDESCRIPTION OF THE APPLIANCE 5

INSTALLING THEWASHING MACHINE 6-8

• Unpacking the washing machine and removing the locking devices 6

• Levelling the washing machine 6

• Connecting to the mains water supply 7

• Connecting to the mains electricity supply 8

USING THEWASHING MACHINE 8-12

• Recommendations prior to use 8

• Use of detergents 9

• How to remove some stains 10

• International clothing care symbols 10

MODEL: ................................................................................................. DATE OF PURCHASE: .............../.............../....................

SERIAL NUMBER: ..........................................................................................................................................................................................

GB

This appliance is marked as complying with European Directive 2002/96/EC,Waste Electrical

and Electronic Equipment (WEEE). Make sure that the pr oduct is disposed of in a correct

manner. The user is ob liged to contribute towards preventing negative consequences f or

health and the environment.

The symbol affxed to the product or accompanying documents signifes that the product

must not be treated as normal domestic refuse , but must be delivered to an authorised col-

lection centre to enable the electric and electronic equipment to be recycled.When disposing

of the appliance, comply with local waste disposal regulations.For further information on the

treatment, recovery and recycling of this product, refer to the appropriate off ces, local domestic

waste collection service or the retailer from where the appliance was purchased.

• Wash cicle 11

• Start button 12

OPTIONAL FUNCTION 12

PROGRAMME TABLES 13

TECHNICAL CHARACTERISTICS 12

MAINTENANCE 15-16

• Cleaning the washing machine 15

• Remove the detergent drawer 15

• Resolving problems

15

16

• Cleaning the ﬁlter

4

NOTES AND ADVICE FOR THE USER

This appliance has been designed for use

as a domestic washing machine. Any other

use is considered as improper and therefore

dangerous.

Any modiﬁcations or attempts to interfere

with the washing machine can be dangerous

for the user and may damage the appliance

itself.

Considering the substantial weight of the

washing machine, speciﬁc safety standards

must be observed during handling.

The washing machine must not be used by

children unless supervised.

Any modifications to the mains water or

electricity supply must be carried out by

authorised technicians only.

When positioning the washing machine,

ensure that the power supply cable is not

kinked or squashed and is accessible.

Before using the washing machine, remove

all the packing and locking devices used for

the transport (locking screws). If this is not

done, serious damage may be caused to

both the appliance and your home.

If the washing machine is installed on a car-

peted ﬂoor, leave sufﬁcient space between

the appliance and the ﬂoor to guarantee the

free circulation of air.

Do not overload the washing machine.

When the appliance is in operation, avoid

any contact with the water being discharged

through the drain hose, as it may be very hot.

Do not touch the door glass either, as this will

tend to heat up during washing.

Use the washing machine for machine-wash-

able items only. In the case of any doubts,

refer to the manufacturer’s instructions on

the label attached to the item to wash (see

“Clothing care symbols”)

Before placing the washing in the washing ma-

chine, make sure that all pockets are empty.

Hard or pointed objects such as coins, pins,

nails, screws or stones can cause serious

damage to the appliance.

Never wash items that have been soiled with

substances containing petrol. In the case

where stains have been removed using va-

porising products, wait until these substances

have fully evaporated from the surface of

the material before loading into the washing

machine.

The use and quantities of detergent, softener

and bleach must comply with the instructions

reported on the packaging.

Do not use detergents designed for hand

washing, in that the excessive suds produced

could damage the internal components.

After washing mats, blankets or any other

long-ﬁbre materials, remove the ﬁlter and

clean it if necessary.

It is advisable to leave the door open at the

end of the wash cycle.

Do not attempt to repair any appliance faults

alone, in that repairs carried out by a non-

professional may cause serious damage

and will invalidate any rights to repairs under

guarantee.

Repairs to the appliance can only be carried

out by personnel authorised by the customer

service centres. All repairs must make use of

original spare parts only.

GB

Before connecting the appliance read these instructions carefully.

Repairing the failure arising from inappropriate connections or use of the appliance

is not covered by the guarantee.

5

NOTES AND ADVICE FOR THE USER

DESCRIPTION OF THE APPLIANCE

A- Door

B- Filter

C- Adjustable feet

D- Top cover

E- Drum

F - Control panel

G - Detergent drawer

1

The washing machine is a domestic appliance capable of washing any type of fabric at any time.

GB

C

F

E

B

THE MANUFACTURER WILL NOT BE HELD RESPONSIBLE FOR ANY INCIDENTS RESULT-

ING FROM NON-COMPLIANCE WITH SAFETY STANDARDS OR THE REQUIREMENTS OF

THIS INSTRUCTION BOOK.

The washing machine has been constructed

in steel panels which have been treated

and painted to guarantees that its aesthetic

qualities remain unaltered over time.

The motor and all moving parts have been

designed and manufactured to guarantee

the minimum possible noise levels

The large easily-accessible stainless steel

drum will ensure a better quality wash and

help to prolong the life of your washing

The easy to use control panel will satisfy all

washing and drying needs (see control panel

and programme table).

The wide door makes loading and unloading

the washing much easier.

The very high stability of the appliance is the

result of constant research by our technicians

into the equilibrium of masses in move-

ment.

A

GD

Never insert or remove

the plug from the mains

socket with wet hands.

When servicing or clean-

ing the washing machine,

remember to disconnect

it from the mains elec-

tricity supply.

Do not pull the power sup-

ply cable to unplug the

washing machine from

the mains supply. Pull the

plug only.

It is advisable to unplug

the washing machine

from the mains electric-

ity supply and close-off

the water supply after

each wash.

Do not expose the ap-

pliance to atmospheric

agents.

The washing machine

must be connected to a

mains socket ﬁtted with

an efﬁcient earth comply-

ing with current safety

standards.

Do not use extension

leads or multiple plug

adapters to connect the

washing machine to the

mains electricity supply.

The washing machine

can only be opened once

the led or display indi-

cates that the cycle has

ﬁnished. On some mod-

els, this is signalled by a

ﬂashing start button.

6

LEVELLING THEWASHING MACHINE

After having selected the most suitable location for the appliance, make sure it is

level by regulating the adjustable feet (Fig. 6).

Pay particular attention to the positioning and levelling of the washing machine and

make sure that the lock nuts are tight.

If the appliance is not le velled correctly, it will be unstab le and

noisy and may cause damage.

If the washing machine is installed on a carpeted ﬂoor, leave sufﬁcient space between

the appliance and the ﬂoor to guarantee the free circulation of air.

It is not advisable to install the appliance in rooms where the temperature could fall

below 0°C.

In the under -worktop versions, screw in the f eet until the spring is full y

compressed, thus allowing the appliance to be installed under the w orktop

(Fig. 6B).

For transport reasons, the washing machine’s oscillating group

is locked in place b y 4 spacer s and scre ws. Before using the

machine, remo ve the spacer s and loc king scre ws. Keep the

screws and spacers for future use.

Close off the holes using the plugs supplied. The plugs can be

found in the bag containing the documents.

For transport reasons, the washing machine’s oscillating group

is locked in place by 4 spacers and screws. Before using the

machine, remove the locking screws with a suitable tool.

Insert a screwdriver in the holes and lever out the 4 plastic spacers

as shown in the f gure.

INSTALLING THEWASHING MACHINE

(according to the model)

Installation must be carried out by qualiﬁed personnel in line with the instructions supplied by the manu-

facturer. Incorrect installation may result in damage and injury.

The appliance can be installed anywhere providing that the ambient temperature is not less than 3°C

and that the wires or pipes on the rear of the machine are not squashed.

2

3

WARNING!! The washer/drier version must not be installed behind a locked door, a

sliding door or with a hinged door on the opposite wall to the washer/drier itself.

4

5

6

6B

GB

7

INSTALLING THEWASHING MACHINE

CONNECTING THE WATER SUPPLY

The mains water pressure m ust be between 0.05 and 1.00 Mpa

(0.5 - 10 bar.)

Before connecting the washing machine, open the valve and allow a certain

quantity of water to ﬂow out in order to clean the pipes of any sand or rust.

This operation is particularly important in the case where the washing machine

has been left standing for a long time or when connecting to a new water supply

system.

The ﬁll hose must be connected to the mains supply using a ¾” threaded con-

nection.

N.B. On electronic washing machines f tted with a dual solenoid

valve (hot and cold water), connect the red hose to the hot water

supply valve and the other hose to the cold water supply valve.

If a hot water supply is not available, both hoses must be connected to the

cold supply using the f tting supplied (see f g. 8)

Connect the ﬁll hose (ﬁg. 9).

N.B. Washing mac hines and condensation type washer/drier s

must be connected to the mains water supply using the new hoses

provided with the appliance. The old hoses must not be re-used.

During the wash, the water supply valve must be fully open.

The drain hose must be positioned at a height of between 60 cm and 90 cm

(ﬁg. 10).

If the water is drained directly into the drainage system, the free end of the drain

hose must be inserted in a pipe of internal diameter not les than 40 mm.

The drain hose connection to the drainage system must not be hermetically

sealed, as this would cause a build up of air in the siphon and allow water to

leak out.

If the wash water is drained into a washbasin, sink or other similar system, the

free end of the hose must be reinforced at the bend using the bracket supplied

with the washing machine. Place the hose over the edge of the washbasin

and anchor the bracket in such as manner that prevents the hose from falling

(ﬁg. 11). The washbasin outlet must be clean and must allow the water to ﬂow

freely.

8

10

11

9

7

GB

8

INSTALLING THEWASHING MACHINE

USING THEWASHING MACHINE

RECOMMENDATIONS PRIOR TO USE

Warning: Before carrying out the f rst wash, allow the washing

machine to effect a short wash cycle without any washing.

This will allow the operation of the washing machine to be checked

and will clean the drum.

Before each wash make sure that:

the water connections are correct, the drain hose is properly positioned (see

connecting to the water supply) and that the water supply valve is open.

with dry hands, insert the plug in the mains socket.

sort the wash into types of fabric (refer to clothing care symbols).

check that there are no objects left in any of the pockets of the items to wash,

as these may damage the washing, the appliance or the ﬁlter.

12

13

Make sure that the v oltage indicated on the identif cation plate

attached to the inside of the f lter door corresponds to that of the

mains supply (f g. 12).

All cut-outs, electric wiring and mains sockets must have a rating such that ena-

bles them to support the maximum load indicated on the identiﬁcation plate.

Once the appliance has been installed, it must be connected to the mains supply

through a single-pole switch.

The mains supply to which the appliance is connected must be ﬁtted with an

earthing system. If this is not the case, the manufacturer will not be held liable

for any incidents that may occur (ﬁg. 13).

If the mains socket to which the appliance is connected is faulty or unsuitable,

it must be replaced by a qualiﬁed electrician.

The washing machine must not be connected to the mains supply using indirect

methods such as extension leads or multiple adapters.

During maintenance work, the washing machine must be disconnected from

the mains electricity supply.

Do not insert or remove the plug from the mains socket with wet hands.

If the power supply cable is damaged in any way, contact the appropriate spe-

cialised service centre.

The plug used to connect the machine to the power supply must never be

ﬁxed behind the machine, but must be in a position easily accessible in an

emergency.

14

15

Open

Closed

GB

CONNECTING TO THE MAINS ELECTRICITY SUPPLY

9

USING THEWASHING MACHINE

USE OF DETERGENTS

The washing machine is ﬁtted with a three-compartment detergent drawer

compartment for pre-wash or soak soap powder (1)

compartment for normal wash soap powder (2)

softener compartment (3)

Use a low-suds detergent and softener (if required) recommended for automatic

washing machines. Follow the dosage instructions written on the packet.

N.B. Too much detergent can produce excessive suds and ma y

result in a poor wash.

Too little detergent will produce an unsatisfactory wash.

N.B.When adding detergent to the dispenser, remember to avoid

any spillage into the softener compar tment, in that this w ould

create a soap y rinse and stain the fabrics white . Vice versa, if

softener is ad ded to the deter gent compartment, the quality of

the wash will be compromised.

N.B. When using a liquid deter gent (recommended f or pro-

grammes without pre-wash) proceed as follows: remove the baffe

from its housing at the front of compartment 2 and insert it in the

guides near the centre of the same compartment.

close the detergent drawer before starting the wash.

Warning! Do not attempt to remo ve the detergent drawer while

the washing machine is in operation, as this will cause water to

f ow out.

20

16

1

2

3

NO

YES

19

17

18

GB

10

USING THE WASHING MACHINE

Stains exist that cannot be removed by machine washing alone. Before trying to remove any type of

stain by hand, ﬁrst try the removal procedure on a small area of hidden fabric. Start from the edge of

the stain and working inwards, this will prevent a dark ring from forming around the site of the stain. A

few methods to adopt for removing stains are reported below.

WAX: Scrape the wax using a rounded point

in order not to damage the fabric. Then, with

the fabric placed between two pieces of ab-

sorbent paper, run a hot iron over the stain.

BALL POINT PENS AND FELT-TIP PENS: clean using

a soft cloth soaked in ethyl alcohol.Take care

not to spread the stain.

DAMP AND MOULD: if the fabric supports the

use of bleach, carry out a wash cycle adding

bleach. Otherwise, soak the soiled part in

hydrogen peroxide (10 volumes) and leave

for 10 to 15 minutes.

LIGHT SCORCH MARKS LEFT BY IRONING: follow the

instructions for mould and damp.

RUST: use products specially designed for rust

stains, following the manufacturer’s instruc-

tions written on the packet.

CHEWING GUM: rub ice over the fabric, scrape

away as much chewing gum as possible

and then rub with a piece of cotton soaked

in acetone.

INTERNATIONAL CLOTHING CARE SYMBOLS

Before placing the clothes in the washing machine and selecting the wash programme, examine the

symbols on the manufacturer’s label. The table reported below will provide a useful guide to reading

the symbols.

PAINT: do not allow the paint to dry. Rub the

area with the solvent recommended by the

paint manufacturer (e.g. water, turps, trichlo-

roethylene), soap and then rinse.

LIPSTICK: stains on cotton or wool can be elimi-

nated using a cloth soaked in ether. Stains

on silk require the use of trichloroethylene.

NAIL VARNISH: place a sheet of absorbent

paper on the stained material, then dampen

the back of the fabric with acetone, frequently

changing the absorbent paper placed over

the stain. Continue in this manner until the

stain has disappeared.

TAR OR DIRT: spread a little fresh butter over

the stain, allow to stand and then wash with

oil of turpentine.

GRASS: delicately soap the stain, use diluted

bleach. Good results can be obtained on

woollen fabrics using 90% alcohol.

BLOOD: put into soak in cold water with added

salt, then wash with washing soap.

HOW TO REMOVE SOME STAINS

GB

11

MAIN FUNCTIONS OF THE WASHING MACHINE

S Led Start

C Optional function buttons

L Start button

P Programme and temperature knob

CL

SWM65EG

SP

GB

USING THEWASHING MACHINE

(follow these instructions and the washing machine will run the selected wash cycle)

1. Open the door.

2. Load the washing in the drum and close the door.

Warning: Do not o verload the mac hine. It is not ad visable to wash items that absorb lar ge

quantities of water such as carpets.

3. Add a low-suds detergent and softener designed for automatic washing machines in the respective

compartments of the detergent drawer (see chapter “USE OF DETERGENTS”).

4. Close the detergent drawer. Do not open the drawer while the machine is working as this may

cause water to spill out.

5. Rotate the programmer knob (P) to select the required programme and temperature according to

the type of fabric to wash (see: “PROGRAMME TABLES”).

6. Select the (C) buttons with the functions required (see “OPTIONAL FUNCTIONS”).

7. Press button (L) to start the wash cycle (see “START BUTTON”)

8. At the end of the wash cycle, turn the program selector knob (P) on “STOP” and the light (B) will

switch off.

9. Open the door and remove the washing.

10. With dry hands, unplug the washing machine from the mains supply.

11. Close the water feed valve.

WASH CYCLE:

“EASY LOGIC”TECHNOLOGY

The electronic washing machine is f tted with an “EASY LOGIC” system that automaticall y

recognises the quantity of washing loaded.The machine can thus regulate the amount of water

to use for the wash and pr oportion the wash time accor dingly, thus saving water, time and

energy. In the case where the amount of washing is less than the maxim um recommended

load (see technical characteristics table), the quantity of water used f or the wash will be re-

duced by 2 litres for each kg less of washing. In the case of a half-load or less, the machine

will automatically carry out one rinse less than programmed. N.B.The“EASY LOGIC” function

is only active for cotton programmes.

12

USING THEWASHING MACHINE

START BUTTON:

L

STOP

PROGRAMMER KNOB “STOP”:

OPTIONAL FUNCTIONS

When this button is pressed, the machine carries out a pre-wash cycle at a maxi-

mum temperature of 40°C. This function can only be used with the “COTTON” and

“SYNTHETIC” programmes.

N.B. When using this function, remember to put some detergent

in the pre-wash compartment too.

PREWASH:

SPIN EXCLUSION:

When this button is pressed, the machine carries out a wash cycle and stops before

spinning.

GB

The stop function resets the washing machine. If, for any reason, you want to change

the wash programme or add more washing to the load during the wash cycle, simply

place the programmer knob in position “STOP”.Then re-position the knob on the new

programme and press the “START”button.At this point, before the programme restarts,

any water in the machine will be drained.

Warning!! only use this function if strictly necessary and then only if the

programme to reset has been running f or a f ew minutes. Before open-

ing the door after a reset, wait 2 min utes for the loc king mechanism to

release.

After having carried out all the operations described in points 1 to 6 in the paragraph

“WASHING CYCLE” press this button and the washing machine will begin its washing

cycle. The relative LED will light up after 2-3 seconds, to indicate that the door is locked

and the program has started.

When this button is pressed, the machine carries out a wash cycle at the set

temperature but for longer. The button is active with “COTTON” and “SYNTHETIC”

programmes.

ENERGETIC WASH:

SPIN LOAD IMBALANCE CONTROL:

This washing mac hine is equipped with a special electr onic control system f or correctly

balancing the wash load. Prior to each spin, the system ensures that the washing is e venly

distributed in the drum. If the washing is not evenly distributed, the f nal spin speed is reduced,

and if the load is very unbalanced, the spin is not effected.

If one of the f ollowing buttons is selected, the corresponding LED will s witch on. But if it has

been selected by mistake or you have changed your mind, simply press it a gain to cancel the

selection.

NB.The use of this function depends on the type of programme selected.

Consequently, if the wash programme does not include this function, the

button cannot be enabled (see “PROGRAMME TABLE”).

13

PROGRAMME TABLES

GB

60

40

30

40

35

90

60

40

FUNCTION ENABLED FUNCTION DISABLED

OPTIONAL WITH PRE-WASH BUTTON PRESSED

DELICATES

WOOL

PROGRAMMER

KNOB

WASH

TEMPERATURE

FABRIC TYPE

SYMBOL BUTTONS ENABLED

SYNTHETICS

DELICATES

Hand washable fabrics

DRAIN AND

SPIN

RINSES

HAND

WASH

COLD

COLD WASH

COLD

COTTON

WOOL

Delicate coloured synthetic

fabrics that are lightly soiled

Delicate coloured fabrics

that are lightly soiled

Colourfast synthetic fabrics

that are heavily soiled

Delicate coloured synthetic

fabrics that are lightly soiled

Delicate coloured synthetic

fabrics that are lightly soiled

SYNTHETICS

Delicate fabrics

To rinse and refresh

the washing

Drain and final spin

Fabrics in delicate cotton,

viscose and mixed fibres, lightly

soiled for about 35/40 min.

QUICK

WASH

Machine washable wool

Detergent

compartment

COLD

COTTON

COTTON *

COTTON

Heavily soiled white cotton

fabrics with organic stains.

For shirts, tablecloths, towels

that are resistant and

normally soiled

White and coloured fabrics that

are resistant and heavily soiled

* Benchmark program for energy classif cation, in accordance with the EN 60456 standar d,

running at max. spin speed and with energetic wash button selected.

*** The wool wash cycle of this machine has been approved by Woolmark for the washing of

machine washable Woolmark products provided that the garments are washed according to

the instructions on the garment label and those issued by the manufacturer of this washing

machine. M0402-M0403-M0404-M0405.

14

TECHNICAL CHARACTERISTICS

5.0 kg.

2.5 kg.

1.0 kg.

400

59.5

85.0

55.0

SWM65EG

min. 0,05 MPa - max. 1 MPa

Width

cm.:

Height

cm.:

Depth

cm.:

Dimensions:

Max. spin: (rpm)

Maximum

recommended

load:

Water pressure:

Max. absorbed power/Electrical connection see rating plate

MODEL

GB

NOTES:

................................................................................................................................................................................................................................................................................................................

15

MAINTENANCE

CLEANING THE FILTER

WARNING!! Before starting the operations described belo w, make sure

that the washing machine is empty. Do not remove the f lter

while the washing mac hine is running, or when full of wa-

ter.

Place a cloth or tray under the ﬁlter to collect any water that may still be inside

Open the ﬁlter door, unscrew the ﬁlter and remove it by turning it in an anticlockwise

direction (ﬁg. 24-25).

The ﬁlter must be cleaned periodically.

Rinse the ﬁlter under running water to eliminate any residues. Replace the ﬁlter by

screwing it in clockwise, making sure it closes and seals properly.

CLEANING THEWASHING MACHINE

The washing machine has been speciﬁcally designed to reduce maintenance to a

minimum. Nevertheless, it is important that it is cleaned regularly.

Before cleaning, make sure that the appliance has been disconnected from the power

supply and that the water supply valve has been closed.

The external structure and the parts of the washing machine in plastic must be

cleaned with a soft damp cloth only.

WARNING!! Ne ver use chemicals, abrasive products, alcohol, soap, petrol

or other solvents to clean the appliance as these may cause

damage. (f g. 21)

After washing, leave the door open for a short time to allow rubber parts to dry.

Periodically wash out the detergent compartments. To do this, remove the detergent

compartment and rinse it under running water (ﬁg. 22). Then replace it.

REMOVING THE DETERGENT DRAWER

open the detergent drawer;

press on the word “PUSH” with the right hand and pull out the drawer with the

left hand (ﬁg. 23).

22

23

21

24

25

GB

16

GB

RESOLVING PROBLEMS

If, after all these checks have been carried out, the appliance still does not work, inform the near-

est customer service centre. When contacting the service centre, inform them of the appliance

model, serial number and type of fault.The data relating the appliance can be found on the rating

plate aff xed to the inside of the f lter door. This information will help the service centre operator

in procuring the necessary spare parts, thus guaranteeing a speedy and eff cient repair.

The washing machine does not work (warning

lights are off) (Display off)

• Make sure that:

1) The mains power supply is working

2) The plug is inserted correctly in the socket

3) The On/Off button has been pressed, or if not

present, check that the programming knob is

positioned on a programme.

The washing machine does not work (warning

lights are off) (Display lit)*

• Make sure that:

1) The programme has been selected

2) The door is closed properly

3) The “Start” button has been pressed (elec-

tronic models only)

4) Refer to the information provided for “The

washing machine does not ﬁll with water”

The washing machine does not f ll with water*

• Check that:

1) There is water in the water supply system

2) The water ﬁll pipe is connected to the washing

machine

3) The mains water supply valve is open

4) The ﬁlter is not blocked If it is, clean the ﬁlter

after ﬁrst unplugging the appliance from the

power supply

The washing mac hine continuously f lls and

drains the water**

• Check that:

1) The drain hose has been installed at the cor-

rect height (60-90 cm)

2) The end of the drain hose is not under water

The washing machine does not drain or spin**

• Check that:

1) The drain hose is properly connected

2) The drain hose is not kinked

3) The drain ﬁlter is not blocked

4) The no-spin function has not been selected

5) The Stop with water function has not been

selected.

The washing machine vibrates and is noisy

• Make sure that:

1) All the locking elements used for transporta-

tion have been removed.

2) The washing machine is perfectly level

3) Bulky items such as sheets, tablecloths etc.

are not all bundled in one part of the drum

The door will not open

• Make sure that:

1) The wash cycle has ﬁnished.

2) The Stop with water function has not been

selected (automatic on some models).

The washing has not been spun properly

• Make sure that:

1) The washing is evenly distributed in the drum

2) The correct spin speed has been selected

The washing machine stops during a wash

• Make sure that:

1) The mains power supply is working

There is still a lot of detergent in the compart-

ment

• Make sure that:

1) The mains water supply valve is open

2) The ﬁlter between the valve and the supply

hose is clean

The washing is not c lean at the end of the

wash cycle

• Make sure that:

1) The drum has not been overloaded

2) The correct amount of detergent has been

used

3) The correct programme has been selected

The washing has shrunk or faded

• Make sure that:

1) The correct washing programme has been

selected

2) The correct washing temperature has been

selected

The washing mac hine does not dr y (washer-

dryer models only)

• Make sure that:

1) The mains water supply valve is open

2) The drain ﬁlter is clean

3) The washing machine is switched on (indicator

light or display lit)

4) The drying program has been selected

5) The drying time has been set

If the appliance is not working properly, check through the following troubleshooting guide before call-

ing for technical assistance. In some models malfunctions are indicated by an error code displayed at

the end of the cycle.

Code: E:00 Carry out all the checks listed in paragraphs marked with *

E:01 Carry out all the checks listed in paragraphs marked with **

E:02 Technical malfunction “Call Customer Service”

E:03 Technical malfunction “Call Customer Service”

MAINTENANCE

Smeg SWM65EG User manual

Popular Washer manuals by other brands
