Sminn RD125 User manual

innovative in electronics
RD125
PROXIMITY READER
INSTRUCTION MANUAL
DESCRIPTION
The RD 125 is a proximity reader for
TAG-RFID cards or fobs
(radiofrequency contactless reading)
Developed with last generation
electronics that ensure high reliability
and functional security.
Combined with a base station it relays
activation/movement orders to access
control systems, alarm systems, motor
controllers, home automation systems,
etc.
It is designed for industrial, commercial
and/or residential enviroments.
OPERATION
The RD 125 reader detects and communicates with a
RFID key tag or card that is closer than 6 cm (aprox). It
analyzes the key code and sends the access request to
the base station, which con!rms the code and access
privileges. If access is granted the base station activates
a relay.
The RD 125 reader has a dual color led that lights red
when there is no key and green when it detects a key.
Green does not mean access grant, just that a valid key
has been detected.
APPLICATIONS
The RD 125 reader has been designed for identi!cation
and reading of RFID tags and cards. Connected to a
base station it is a reliable system for home automation,
security, access control and control activation.
INSTALLATION
Check the integrity of the product before installing.
It can be installed embedded in a standard switch
case or with a surface separator and cover.
It must be separated from metallic parts or similar
elements. Being a radiofrequency system they can
cause interference limiting the reach and making
power consumption higher.
The RS 485 BUS allows up to 500m wiring distances
depending on the wire used. It also allows up to 32
devices in the same bus assuming there is power for
all of them.
THE MANUFACTURER IS NOT RESPONSIBLE OF THE
DAMAGES A BAD INSTALLATION OR MISUSE CAN
CAUSE.
Wiring
Wiring is done with just four wires connected to the
terminal block in the back. Two of these wires are for
power and the other two for data (connection with base
station). See Fig.1
Positive (+) Connect the positive pole
of +12VDC
Negative (-) Connect the negative pole
of power.
Line (A) Connect the A line of the
RS 485 BUS
Line (B) Connect the B line of the
RS 485 BUS
The RS 485 BUS is used in half duplex mode with just
two wires.
All devices in the BUS must share the same connection.
A terminals must be connected to A terminals and B
terminals must be connected to B terminals. See Fig.2
USE LIMITATIONS
Functionality is not guaranteed if used in di"erent
applications than the speci!ed ones.
The manufacturer reserves the right to change the
speci!cations of these systems as well as this manual
without prior warning.
The equipment must be manipulated only by specialized
and/or skilled personnel.
THE USAGE INSTRUCTIONS OF THIS DEVICE SHALL BE
HANDED TO THE USER, WHO WILL HAVE THEM IN
THEIR POSSESSION. IF THEY ARE MISLAID, THE USER
CAN ASK FOR A COPY OR DOWNLOAD IT DIRECTLY
FROM THE WEBSITE WWW.SMINN.COM
Any modi!cation or adjustment to the system is
forbidden, except for those indicated in this manual.
WARRANTY
This product has undergone a complete TEST during its
manufacturing process that guarantees its reliability and
proper operation. The manufacturer provides 24 months
of warranty to the product from the date printed in the
product and against any anomaly that it may present in
its appearance or operation.
Any damage caused by third parties, natural causes
(#ooding, !re, lightning, etc), arising from improper
handling or installation, vandalism or any other cause
non attributable to the manufacturer will void the
warranty.
The warranty only covers repairs or replacement of the
damaged device. Any expenses derived from assembling,
travelling, transport, natural wear of parts, etc., and, in
general, any expenses that are not part of the repairs or
replacement of the damaged element of the system are
excluded. The installer/provider will ask the manufacturer
for an number or authorization for transport of theRMA
system in warranty. Without this previous requisite, the
manufacturer will not be able neither to process nor
provide warranty service.
WARNING
This product must be used in istallations which has been
conceived for, considering any other as improper use.
The packaging and wrapping be dumped inMUST NOT
the environment.
Keep products, packaging, wrapping, documentation,
etc., out of the reach of children. Follow the current local,
national or European regulations.
The information contained in this document may have
some mistakes that will be corrected in future editions.
The manufacturer keeps the right to modify the content
of this document or the product without prior warning.
Rev.5013

Telecomunica ionst EN 300 330-1/2
Electromagnetic
compatibility EN 301 489-1/3
Low Voltage UNE EN 60730 / EN60950
Fig. 2 BUS wiring
Fig. 1 Terminal block
TECHNICAL H IC ARACTER STICS
Fre uencq y 125 KHz
Power 12V DC (10/22V)
Consumption in stand by < 100 mA
Comunication BUS - RS485 (Half/Duplex)
Wiring 4 (wires shielded CAT5
recommended)
Max. reach > 200 m
Watertightness IP 66
Dimensions 84 mm x 84 mm x15 mm
Case and frame ABS
Operation Temp. -20/ +70ºC
B A
12VDCRS 485
RD 125
S/N: 123456
BUS RS485 Power
12VDC
A
B
FUS. 0.3A
230V
AC
1 2 3 4 5 6 7 8 9
+ A B
NAC NC
-
RUN K1
OK
L N
RD125 RD125 KB120
CE DECLARATION OF CONFORMITY
The company ELSON SISTEMAS, S. L.
Pol. Torrelarragoiti, P6 - A3 - 1ª
48170 Zamudio (SPAIN)- Vizcaya
Declares:
The product: RD 125 Proximity Reader
Manufactured by ELSON ELECTRÓNICA, S.A.
Under the trademark: SMINN
For use in:
Zamudio 201, 0.03.30
José Miguel Blanco Pérez
Chief Technical Officer
