Smiths Medical CADD-Prizm VIP 6100 Reference guide

The pump may be running or stopped to view functions.
To View Event Log
1. Press OPTIONS.
2. Press ´or Îuntil Event Log option appears.
3. Press ENTER to display Event Log.
4. Press Îto page back through Event Log entries or
´to page forward.
5. When finished, press NEXT.
To Clear Milliliters Given
1. Stop the pump.
2. Press NEXT repeatedly until Milliliters Given screen
appears.
3. Press ENTER to clear and update date and time.
Recordkeeping Functions
The CADD-Prizm®pump signals with audible alarms
and messages on the display when a condition requires
your attention. In addition to referring to this table, use
the ? key while the alarm is occurring for information
about the alarm and corrective action.
Reservoir Volume Low
Level of fluid in the reservoir is low. Prepare to install a
new reservoir.
Reservoir Volume Zero
Reservoir volume is 0.0 mL. Press NEXT to stop alarm.
Install new reservoir if appropriate.
9-volt battery Low
9-volt battery is low but pump is operable. Change
battery soon.
9-volt battery Depleted
9-volt battery is depleted and cannot operate pump;
install fresh battery immediately.
High Pressure
Possible blockage downstream (between pump and
patient), clamp or kink in fluid path. Find cause and
remove blockage to continue.
Or, press STOP/START to stop pump and silence alarm;
remove blockage and restart pump.
Upstream Occlusion (Model 6101 only)
Fluid is not flowing from the reservoir to the pump.
Check for a kink, a closed clamp or an air bubble in
tubing between reservoir and pump.
Press STOP/START to silence alarm; remove
obstruction and restart pump.
Error Detected
Pump fault occurred. Close tubing clamp, remove pump
from service.
Air In Line Detected
Air in fluid path. Press NEXT to silence alarm. Make
sure tubing is threaded in Air Detector properly. If fluid
path contains air, close clamps, disconnect from patient
and prime fluid path.
3 beeps Every 5 Minutes; Stopped on Main Screen
Pump is stopped. Start pump if appropriate.
Alarms and Troubleshooting
Product(s) described may not be licensed or available for sale in Canada or other
countries outside of the United States.
Smiths Medical ASD, Inc.
6000 Nathan Lane North
Minneapolis, MN 55442, USA
Tel: [phone]
Toll-Free USA: 1-800-258-5361
www.smiths-medical.com
Smiths Medical Canada Ltd.
Markham, Ontario, Canada, L3R 4Y8
Phone: [phone]
Toll-Free: 1-800-387-4346
CADD, CADD-Prizm, the Medication Cassette Reservoir design, and the Smiths
Medical design mark are trademarks of Smiths Medical. The symbol ® indicates
the trademark is registered in the U.S. Patent and Trademark Office and certain
other countries. ©2018 Smiths Medical. Product referenced is CE-marked.
All rights reserved. IN19808EN-012018
MPAUCA-1601
WARNING: This Quick Reference Card should be used
by clinicians only. Do not permit patients to have access
to this card, as the information would allow access to all
programming and operating functions.
A. Green indicator light: blinks
when pump is running
B. Amber indicator light: blinks
when pump is stopped
or alarming
C. Polemount bracket recess
(back of pump)
D. Power jack (for power pack
or AC adapter)
E. Data in/out jack (for printer
or modem cable)
F. Battery compartment (side
of pump)
G. Cassette (part of reservoir
or administration set that
attaches to pump)
H. Air Detector
CADD-Prizm®VIP
Ambulatory Infusion Pump
Model 6100 and 6101
Quick Reference Card for Clinicians
Continuous Lock Level 1
Power DataIn/Out
START
STOP
Y
N
LOCK
DOSE
NEXT
ENTER OPTIONS
?
®
F
G
A
B
C
E
D
H
Keypad
STOP/
START Stops and starts the pump
LOCK Displays or changes lock level (security level)
?Help key: displays more information about a screen
ENTER Sets new value; selects choice from menu; clears
screen
NEXT Advances to next programming screen; backs out of
an option or menu
DOSE Inoperable in Continuous delivery mode
OPTIONS Displays the Options Menu, pages through options
´
Answers yes; increases values on programming
screen; pages through menus; pages through Event
Log
Î
Answers no; decreases values on programming
screen; pages through menus; pages through Event
Log

To Remove Used Cassette
1. Stop the pump.
2. Close all tubing clamps.
3. If necessary, use key to unlock used cassette.
4. Use side of key or coin to unlatch used cassette.
5. Disconnect tubing from patient.
6. Remove and discard used cassette.
To Attach New Cassette
1. Close tubing clamp.
2. Insert new cassette hooks into pump’s hinge pins.
3. Place pump with cassette on firm surface and push
down on top of pump.
4. Use coin or side of key to latch cassette.
WARNING: Attach the cassette
properly. A detached or improperly
attached cassette could result in
unregulated gravity infusion of
medication from the fluid container
or a reflux of blood. If you are using a
CADD®administration set or CADD™
medication cassette reservoir that does
not have the flow stop feature, you
must use a CADD®extension set with anti-siphon valve
or a CADD®administration set with either an integral or
add-on anti-siphon valve to protect against unregulated
gravity infusion that can result from an improperly
attached cassette.
5. Gently twist and pull on cassette to make sure it is
attached properly.
6. If Reset Reservoir to — ml? appears, press ´if
appropriate.
7. When Prime Tubing? appears, open tubing clamp
and press ´if appropriate. Follow priming
instructions on pump’s screen. When primed, close
tubing clamp.
8. If applicable, thread tubing through Air Detector.
9. When Start the Pump? appears, connect new
tubing to patient’s access site, open tubing clamp,
and press ´.
The Continuous Rate may be adjusted within the limits
programmed in Lock Level 0.
To Adjust the Continuous Rate
Pump must be in LL1.
1. Stop the pump.
2. Press NEXT repeatedly to display Continuous Rate
screen.
3. Press ´or Îto select desired new rate.*
4. Press ENTER to save new rate.
5. Press NEXT repeatedly to review the program.
6. Restart the pump.
* If you cannot increase the setting, it may already be at
the maximum.
Adjusting the Program
Reservoir Volume
Volume of fluid in filled reservoir
Continuous Rate
Continuous rate of drug delivery in mL/hr
Milliliters Given
Displays total amount delivered since date and time
shown
Air Detector Status
Shows whether Air Detector is required, turned on or
off (appears if Air Detector is attached)
Programming Screens
To View Current Lock Level
1. Press LOCK.
2. Press NEXT to return to original screen.
To Start or Stop Pump
1. Press STOP/START.
2. Press ´.
To Change Battery
1. Stop the pump.
2. Press button on the battery door and slide battery
door forward.
3. Remove and discard used battery.
4. Match + and - markings on new battery with
markings on pump.
5. Insert battery; the pump should beep.
6. Replace the battery door.
7. The pump will power up.
Pump Operations
D. Zurn 05/16/96
Prizm Latched, Unlocked
01/25/95 D. Zurn
«Prizm Match
Battery»
01/25/95 D. Zurn
«Prizm Open
Door w/Button»
Changing the Cassette
Priming the Fluid Path Using the Prime Option
The priming feature is available either:
a) when you attach a cassette (see right panel), or
b) in the Options Menu.
To access the Prime option in the Options Menu,
pump must be in LL0 or LL1:
1. Stop the pump.
2. Press OPTIONS.
3. Prime should be displayed; press ENTER.
4. Follow priming instructions on pump’s screen.
Priming the Fluid Path
To Reset Reservoir Volume Without
Changing Cassette
1. Stop the pump.
2. Press NEXT to display Reservoir Volume screen.
3. Press ENTER.
4. If message appears asking you to reset the
Reservoir Volume, press ´. (If message does not
appear, Reservoir Volume may already be reset.)
Resetting the Reservoir
Using the ? Key
1. For information about screen or alarm, press ? key.
2. If a ? appears in lower right corner, press ? to see
more help.
3. Press NEXT to exit help.
