Smiths Kiosk Guide

Issue 002 - October 2018 | SmithsEP.co.uk | 1
Pedestal Range
Installation, commissioning
and user manual
Kiosk
Trafalgar
Tube
Issue 002 | October 2018
ENGLISH | UK | IRL | SmithsEP.co.uk

2 | SmithsEP.co.uk | Issue 002 - October 2018
Introduction
This product has been assembled and prepared
for easy installation.
In the event of any visible damage, please contact
us on [phone].
Please leave this Installation and User Guide with
the owner of the property.
Contents
Introduction 2
Declaration of conformity 3
Symbols used in this guide 3
Important safety and installation instructions 4
Application 5
Product Information 5
Installation - Kiosk and Trafalgar 6
Commissioning - Kiosk and Trafalgar 7
Installation - Tube 8
Commissioning - Tube 11
Fault nding 12
User Manual
Important safety guidance 14
Introduction 15
Operation 15
Fault nding 16
Registering your product 17
Disposal 17
After sales and spares 17

Issue 002 - October 2018 | SmithsEP.co.uk | 3
Declaration of conformity
EC Declaration of conformity
We, Smith’s Environmental Products Limited
1-2 Blackall Industrial Estate
South Woodham Ferrers
Chelmsford
Essex CM3 5UW
Tel: [phone] Fax: [phone]
Declare under sole responsibility that the products:
Product name:
Natural Convectors
Product range:
Pedestal: Kiosk, Trafalgar and Tube
Conform to the following European Union
directives and harmonised standards:
EN 442-2-2014
EN 442-1-2014 Clause 5.3
Construction Products Regulation No.
3052011
This Declaration is made on behalf of Smith’s
Environmental Products Limited by:
Gary Haynes
Chief Executive Ofcer
Date 08.09.17
Symbols
This manual contains information and
prescriptions marked by the following symbols.
Ignoring these safety provisions
marked by the symbol “caution:
hazard” may endanger the safety
of people.
The removal of the screws can
cause the output of hot uids
under high pressure from heating
system. Drain the system or close
the isolating valves.
High temperature surface. Take
utmost care to prevent people
from getting in contact with the
hot surfaces of the appliance.

4 | SmithsEP.co.uk | Issue 002 - October 2018
Important safety and installation instructions
Prior to installation, read these installation and operating instructions. The installation and operation should
also be in accordance with national regulations and accepted codes of good practice.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
To guard against injury, basic safety precautions should be observed, including the
following:
1. Read and follow all safety instructions and all the important notices on the appliance
before installing, using and maintaining the appliance. Failure to do so may cause
personal injury or damage to the appliance or installation.
2. Risk of scalding. To avoid injury before any servicing operation wait until the water has
cooled inside the appliance. Do not touch the uid or the appliance when temperature
is higher than 60°C.
3. Improper use.
This is an appliance to be used in heating systems with clean water without
abrasive particles.
4. Installation.
The appliance must be mounted in a stable/xed position in a dry, frost-free and
waterproof place, with sufcient ventilation around it. Make sure that the appliance is
securely and correctly installed before operating it and that there is enough room
around it for maintenance operations, dismantling, checking for free inspection.
Non-observance of the safety instructions results in the loss of any claims to damages.
The indicated limit values are binding and cannot be exceeded for any reason whatsoever.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Issue 002 - October 2018 | SmithsEP.co.uk | 5
Application
Kiosk, Trafalgar and Tube are primarily
intended for installation at oor level against
a wall or window.
Tube may be installed in any orientation on the
oor or against the wall. Natural convectors can
help reduce condensation on oor to ceiling glass
when position in front of them, providing a
consistent blanket of warm exiting air from
the emitter.
These products are designed for use on standard
two-pipe pumped central heating systems.
Pipe connections are 15mm and may be
used as either ow or return. TRV should be at
Flow end. This product is not suitable for
one-pipe systems.
The heater must be installed In line with best
plumbing practices and with reference to industry
standards, such as the CIBSE Domestic Heating
Design Guide. Isolating valves (as supplied) must
be tted to system ow and return connections.
Failure to t isolating valves may mean that the
product is not serviceable in the event of failure.
Wall mounted - horizontal
Except Tube
Floor mounted
Inverted mounted
Wall mounted - vertical
Tube can be installed in the
vertical plane, but the TRV
should be at low level.
Î
Î
Î
P
Product mounting options
Product performance
Heat output
150
200
Model A
Tube .5m 500
Tube 1m 1000
Tube 1.5m 1500
Tube 2m 2000
A
Product
length
∆T °C
20 ∆T 30 ∆T 40 ∆T 50 ∆T 60 ∆T 70 ∆T
Kiosk
0.5m 22 39 60 83 109 136
1.0m 73 133 202 281 367 459
1.5m 125 226 345 479 626 783
2.0m 176 320 487 677 884 1106
Trafalgar
0.5m 39 72 110 154 201 253
1.0m 133 243 373 519 681 856
1.5m 226 414 635 885 1160 1459
2.0m 320 585 898 1250 1640 2062
Tube
0.5m 36 64 96 132 170 212
1.0m 88 157 237 325 421 524
1.5m 141 251 378 519 671 836
2.0m 193 344 519 712 922 1148
Entering ambient air temperature of 20°C
Outputs in Watts. In accordance with EN442 - BSRIA veried
210
A
92
Model A
Kiosk .5m 500
Kiosk 1m 1000
Kiosk 1.5m 1500
Kiosk 2m 2000
206
A
180
Model A
Trafalgar .5m 500
Trafalgar 1m 1000
Trafalgar 1.5m 1500
Trafalgar 2m 2000

6 | SmithsEP.co.uk | Issue 002 - October 2018
1. Remove product
from packaging
2. Remove x 2 screws from each
end of the casing
3. Slide the casing up from
the chassis
4. Position heater in
required location
Please note:
When installing a thermostatic radiator valve the
following aspects must be considered to ensure that
the valve performs to its optimum level.
1. The valve should be in a position where it is in
contact with free air circulation within the area
and is not subject to draughts as this will effect
the valve’s performance
2. The valve must not be installed in a position
where the head is likely to be damaged or
where the valve is subject to excessive heat,
either at time of installation or in
operating conditions
3. Ensure that the system is clean and free from
debris and the installation is in accordance with
good plumbing practices
5. Unscrew both end panels
to access Flow and Return
pipe unions
Installation - Kiosk & Trafalgar
➀Heat Exchanger
➁TRV (Thermostatic Radiator Valve)
➂LSV (Lockshield Valve)
➃End Panels
➄Bleed valve
➀
➁
➂
➃
➃
➄

Issue 002 - October 2018 | SmithsEP.co.uk | 7
8. Secure product to the oor
9. Commissioning
• Align the TRV head over the valve body with
the indicator point at setting V. Ensure that the
TRV head is square to the body, screw the TRV
head onto the body in a clockwise direction
until tight, being careful not to over – tighten
the head on the body
• Turn on the heating system
• Fully open Thermostatic Radiator Valve (in the
system ow) to Setting V while leaving the Lock
Shield Valve (in the system return) totally closed
• Allow the system to ll the heat emitter
• Open the air vent situated on the heat
exchanger
• Once the heat emitter is free of air, close
the air vent
• Open Lock Shield Valve and allow the heating
system to run for minimum of 1 hour
• After minimum 1-hour period, the heating
system may require further bleeding.
Follow best practices when purging the heating
system of air
Note: It may be necessary to balance the heating
system to achieve best ow and/or water
temperature.
10. Re-t casing
6. Prepare ow/return connection
and connect to heating system
using suitable ttings
• Pipe connection is 15mm
• Flow connection should be TRV End
• Isolating valves must be tted to ow and
return pipework for servicing
7. Ret end panels
Commissioning
All factory tted connections/compression joints
should be inspected prior to lling the system, in
case of loosening during transit

8 | SmithsEP.co.uk | Issue 002 - October 2018
1. Remove product
from packaging
2. Remove x 2 screws from inside
legs of the product to release the
end trim
4. TRV and Lockshield valves are
pre-tted to the heat exchanger
Installation - Tube
Standalone:
Tube is designed to be installed as standalone
heat emitters.
Each unit stands on its own with pipework being
made through the feet in each end of the product.
The heat-exchanger within the products casing is
factory tted with TRV & LSV.
3. Slide the end trim away from
product casing
0.5m 1.0m 2.0m 1.5m
Product lengths/sections in products

Issue 002 - October 2018 | SmithsEP.co.uk | 9
6. Prep ow and return
connections and ready system
pipework for connection
Check connection is good and undamaged
from transit.
7. Fix both ends to the oor
using suitable xings
8. Connect system pipework to
the TRV and Lockshield valves of
each end of the product
5. Position heater where required
Pipe entry is through ooring surface.

10 | SmithsEP.co.uk | Issue 002 - October 2018
12. Screw the TRV onto
the product
11. Ensure that the TRV is set on
the V position
10. Ret retaining screws to x
the end panels
9. Ret end trims
Installation - Tube

Issue 002 - October 2018 | SmithsEP.co.uk | 11
Commissioning
13. Commissioning
• Align the TRV head over the valve body with
the indicator point at setting V. Ensure that the
TRV head is square to the body, screw the TRV
head onto the body in a clockwise direction
until tight, being careful not to over – tighten
the head on the body
• Turn on the heating system
• Fully open Thermostatic Radiator Valve (in the
system ow) to Setting V while leaving the Lock
Shield Valve (in the system return) totally closed
• Allow the system to ll the heat emitter
• Open Lock Shield Valve and allow the heating
system to run for minimum of 1 hour
• After minimum 1-hour period, the heating
system may require further bleeding.
Follow best practices when purging the heating
system of air
Note: It may be necessary to balance the heating
system to achieve best ow and/or water
temperature.
All factory tted connections/compression joints
should be inspected prior to lling the system, in
case of loosening during transit

12 | SmithsEP.co.uk | Issue 002 - October 2018
Fault nding
Fault Possible cause Checking/Solution
Lack of heat/poor heating
performance
Poor ow rate in heating system
Check pump is operating correctly
Bleed air from system
Balance heating system
Debris in heat exchanger
Check and clean any foreign material from heat exchanger,
See Instructions for safe cleaning
Remove any external restrictions from both inlet and outlet grilles
Heat emitter valves incorrectly set
Check Thermostatic Radiator Valve (TRV) is open
Check that Lock Shield Valve is open
Air present within heating system Ensure that heating system is completely free of air, purge air
from heating system using best practices
TRV Valve Thermostatic Radiator Valve (TRV) head faulty, Replace
Heat Source
Ensure boiler is on and calling for heat
Check pump is operating correctly
Ensure both ow and return pipe to heat emitter are of
adequate temperature
Ensure that heating system is completely free of air
In the event of any difculty, please contact us on [phone].
It will be more helpful if you do not remove the product from the central heating system.

Issue 002 - October 2018 | SmithsEP.co.uk | 13
Kiosk
Trafalgar
Tube
Pedestal Range
User manual
Issue 002 | October 2018
ENGLISH | UK | IRL | SmithsEP.co.uk

14 | SmithsEP.co.uk | Issue 002 - October 2018
Important safety and installation instructions
Prior to installation, read these installation and operating instructions. The installation and operation should
also be in accordance with national regulations and accepted codes of good practice.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
To guard against injury, basic safety precautions should be observed, including the
following:
1. Read and follow all safety instructions and all the important notices on the appliance
before installing, using and maintaining the appliance. Failure to do so may cause
personal injury or damage to the appliance or installation.
2. Risk of scalding. To avoid injury before any servicing operation wait until the water has
cooled inside the appliance. Do not touch the uid or the appliance when temperature
is higher than 60°C.
3. Improper use.
This is an appliance to be used in heating systems with clean water without
abrasive particles.
4. Installation.
The appliance must be mounted in a stable/xed position in a dry, frost-free and
waterproof place, with sufcient ventilation around it. Make sure that the appliance is
securely and correctly installed before operating it and that there is enough room
around it for maintenance operations, dismantling, checking for free inspection.
Non-observance of the safety instructions results in the loss of any claims to damages.
The indicated limit values are binding and cannot be exceeded for any reason whatsoever.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Issue 002 - October 2018 | SmithsEP.co.uk | 15
How it works
These products are natural convector heaters and
work by air convection currents passing through
the high efciency aluminium nned copper tube
heat exchanger through which hot water passes
supplied by your central heating system.
As the air heats up it increases in volume and rises
which in turn draws low level room air in through
the heater which is in turn heated.
How to operate
This product is tted with a Thermostatic
Radiator Valve (TRV) to enable the user to set
and control the ambient room temperature.
Turning the control knob clockwise will increase
the temperature setting. The indications (0, ❄, I,
II, III, IIII, V) on the control knob range between 5
and 28°C. In position 0 the valve will open when
temperature drops to 5°C.
Once the TRV is set, it will automatically adjust
the system ow (on/off) to maintain room
temperature. Follow TRV instructions to maximise
life expectancy.
Tamper setting
The head can be set to a single, non-adjustable
position. Lower the locking mechanism as
described previously and rotate the head until the
indicator is pointing to the desired setting. Rotate
the locking mechanism reset mark anti-clockwise
to the desired setting and push the locking
mechanism up against the head until it locks into
position.
To remove the setting limit, simply lower the
mechanism again and rotate until the reset marks
are aligned and move upwards back into position.
The valve can now be adjusted through its full
setting range.
Maintenance
The valve should be opened to maximum in the
summer to reduce the risk of sticking. Other
suggestions would be to ensure the system is
fully power ushed prior to installing the TRV.
Proprietary inhibitors should be added to the
system when relling.
Cleaning the valve head
The thermostatic head can be cleaned using a
mild soap solution. DO NOT USE ABRASIVE PAD,
BLEACHING AGENTS OR SOLVENTS etc as they
will cause damage to the valve head.

16 | SmithsEP.co.uk | Issue 002 - October 2018
Fault nding
Fault Possible cause Checking/Solution
Lack of heat/poor heating
performance
Poor ow rate in heating system
Check pump is operating correctly
Bleed air from system
Balance heating system
Debris in heat exchanger
Check and clean any foreign material from heat exchanger,
See Instructions for safe cleaning
Remove any external restrictions from both inlet and outlet grilles
Heat emitter valves incorrectly set
Check Thermostatic Radiator Valve (TRV) is open
Check that Lock Shield Valve is open
Air present within heating system Ensure that heating system is completely free of air, purge air
from heating system using best practices
TRV Valve Thermostatic Radiator Valve (TRV) head faulty, Replace
Heat Source
Ensure boiler is on and calling for heat
Check pump is operating correctly
Ensure both ow and return pipe to heat emitter are of
adequate temperature
Ensure that heating system is completely free of air
This product is covered by a free 5-year parts and labour guarantee (TRV 2 years).
Please refer to the Fault nding table below for advice.
In the event of difculty, please contact us on [phone].
It will be helpful if you do not disconnect the product from your central heating system.

Issue 002 - October 2018 | SmithsEP.co.uk | 17
Thank you for purchasing a Smith’s product. It has
been designed and manufactured to the highest
quality standards to ensure it gives you efcient
and trouble-free service for many years. To back
up our commitment, included with your product
is the following warranty:
Heat Emitter 5 years (TRV 2 years) from date
of purchase
This gives you the peace of mind that in the
unlikely event of product failure, we will repair
or replace the product completely free of charge
providing the product has been installed, used and
maintained in accordance with the instructions.
Your statutory rights are not affected by this
warranty.
It is important to register as soon as possible
online at: smithsep.co.uk/product-registration/.
This will ensure you will receive prompt and
efcient service if your product requires attention
within the warranty period. If you do not register
your product, you will be required to produce
proof of purchase prior to receiving service.
For more details please visit our website:
SmithsEP.co.uk
Registering your product Disposal
As part of the policy of continuous product
improvement, Smith’s Environmental Products LTD
reserves the right to alter specication without
prior notice.
If you are purchasing replacement equipment your
retailer may offer a ‘take back’ scheme, or will
be able to give details of the nearest approved
authorised treatment facility. Proper recycling and
waste disposal will help conserve resources whilst
preventing detrimental effects on our health
and the environment.
Approved CQS ISO
9001:2015
After sales and spares
If you experience any problems with the use of
your product, please contact our after-sales ofce
[phone].
For product information, customer services or
sales support call us on [phone]
For the Republic of Ireland, contact MT Agencies
on 01 864 3363
Sales: [e-mail]
General information: [e-mail]
Smith’s Environmental Products Ltd
Blackall Industrial Estate, South Woodham Ferrers,
Chelmsford, Essex CM3 5UW
SmithsEP.co.uk
@SmithsEP_UK
#ThinkSmiths

18 | SmithsEP.co.uk | Issue 002 - October 2018
Notes

Issue 002 - October 2018 | SmithsEP.co.uk | 19
Notes

20 | SmithsEP.co.uk | Issue 002 - October 2018
To view the full product information
download the datasheet at:
www.SmithsEP.co.uk
For product information, customer services or
sales support call us on [phone]
For the Republic of Ireland, contact MT Agencies
on 01 864 3363
Sales: [e-mail]
General information: [e-mail]
Smith’s Environmental Products Ltd
Blackall Industrial Estate, South Woodham Ferrers,
Chelmsford, Essex CM3 5UW
SmithsEP.co.uk
@SmithsEP_UK
#ThinkSmiths
Issue 002 | October 2018
Happy to help
Smith’s Environmental Products Ltd is one of the
leading manufacturers of heating and cooling
products in the UK. We are committed to
achieving the highest standards and our faith is
supported by a free ve year parts and labour
guarantee with every product*. Our customer
service is second to none and we are happy to
offer any help and guidance that you might need.
Stockists
All products are available nationally from Builders’
Merchants, Plumbers’ Merchants, Heating
Equipment Distributors and Kitchen Equipment
Distributors. In the event of difculty, please
contact us or visit our website SmithsEP.co.uk for
details of your nearest stockist.
Information and advice
Full technical specications and list prices is
available to download from our website or in
hard copy from our ofce. Also available on our
website are price lists, individual product data
sheets, installation & user guides, where to buy,
who to contact and a media centre.
Alternatively contact our ofce 9.00am to 5.00pm
Monday to Friday.
*Thermostatic Radiator Valve - 2 year warranty
As part our commitment to continuous
improvement Smith’s Environmental Products may
change the specifications of its products without
prior notification or public announcement.
All descriptions, illustrations, drawings and
specifications in this publication present only
general particulars and shall not form part of
any contract. All dimensions are in mm unless
otherwise stated.
Smith’s, providing comfort for the built environment
