Smittybilt 35220 User manual

WWW.SMITTYBILT.COM

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220

Installation Instructions

Winch Quick Connect Kit

Part # 35220 (8’)

Part # 35210 (24’

)

Parts Included (Part# 35220)

Qty

Part

s Included (Part# 35210)

Qty

3’ Winch Quick Connect Wire 1 3’ Winch Quick Connect Wire 1

8’ Quick Connect Wire 1

24’ Quick Connect Wire 1

Connector Cover 2 Connector Cover 2

Cable Tie 5 Cable Tie 15

Winch Quick Connector (3ft.)

Note: The 3 ft. cable is intended to be attached to the winch only. The 8 ft. (Part#35220) is used for

power from the winch connect to the battery in the en ine compartment. The 24 ft. (Part#35210)

is intended to be used to winches that are mounted in the rear of a vehicle. The Red cable is the

positive cable and the Black cable is the Ne ative.

Step 1: Install the 3’ connect plu on the winch before boltin the winch down. This will take place of

what typically is a lon red and black cable that connects to the vehicles battery.

Step 2: Most winches have a separate control box with a black plastic cover. Remove the cover from

control box base.( Usin manufacturers instructions) (Fi A)

Step 3: Remove the lon red cable from the solenoid and install the red cable from the 3’ plu into the

same location. (Fi B, C) Note: Use caution when doin this in order not to dama e any other

wires or terminals.

(Fi A) (Fi B) (Fi C)

Step 4: Remove the lon battery ne ative cable attached to the bottom of the motor. (If installed) The

black cable from the 3’ connector will o to the ne ative terminal on the bottom of the motor.

(Fi D)

Please read instructions entirely before installing/using this part.

WWW.SMITTYBILT.COM

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220

Installation Instructions

Winch Quick Connect Kit

Part # 35220 (8’)

Part # 35210 (24’

)

Step 5: Re-install the plastic control box cover you previously removed. Installation of the 3’ connect is

now complete. (Fi E) You may bolt on your winch to your desired accessory.

Note: You can ain access to one piece winches that have the control box inte rated into the desi n

of it by typically by removin the upper lar e bolt and loosenin the lower ones. This will enable

you to either remove or flip forward the cover to ain access to the control box.(Fi F)

WARN NG: Always check with your winches owners manual before attemptin to remove any

bolts or remove anythin from your winch. Follow your winches wirin dia ram when installin

the 3’ connect.

(Fi D) (Fi E) (Fi F)

Battery Quick Connector (8ft, 24ft)

Step 1: Determine the best location to install the disconnect plu . Make sure you will be able to ain

access to it based on the accessory you will be usin it with.

Step 2: Run the cable alon the frame of the vehicle towards the en ine compartment. Take notice to

which side your battery is located when routin wires.

Step 3: Run the cable into and up throu h the en ine compartment towards the battery.

NOTE: Make sure no accessory is connected to the plu before attachin wires to the battery.

Failure to follow a

nd comply to these instructions entirely

can

lead to serious

injury or damage.

WWW.SMITTYBILT.COM

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220

Installation Instructions

Winch Quick Connect Kit

Part # 35220 (8’)

Part # 35210 (24’

)

Step 4: Attach the red (positive) cable to the positive terminal on the battery.

Step 5: Attach the black (ne ative) cable to the ne ative terminal on battery.

Step 6: Secure the cable in appropriate locations usin the included cable ties. Installation is now

complete.
