Snap Fresh BBT-ZOY01 User manual

User Manual
geprufte
Sicherheit
CORDLESS MULTI-TOOL
BBT-ZOY01
Read all safety rules and instructions carefully before operating this tool.
[email protected]
[phone]
Please scan the QR CODE for more services.

CONTENTS
Contents..................................................................................................................................................................................2
.......................................................................................................................................................................................
Safety instructions ....................................................................................................................................................4-8
3
..............................................................................................................................................8-9Machine information
..........................................................................................................................................................................10-13
..............................................................................................................................................................................
.....................................................................................................................................................................
...................................................................................................................................................................
..............................................................................................................................................................................
14
14
15
15
Environment
Warranty
Maintenance
Operation
Assembly
Symbols
2

Read the user manual.
Denotes risk of personal injury, loss of
life or damage to the tool in case of
non-observance of the instructions in
this manual.
Do not throw the battery into fi re.
Do not throw the battery into water.
Separate collection for Li-ion battery.
SYMBOLS
The following symbols are used in the user manual or on the product:
3
Do not dispose of the product in
unsuitable.
Risk of electric shock.
Variable electronic speed.
Do not use in rain.
Risk of flying objects. Keep bystanders
away from the work area.
Wear safety goggles.
Wear hearing protection.
Wear a dust mask.
Indoor use only.
Class II machine - Double insulation -
You don’t need any earthed plug.
Time-lag miniature fuse-link.
Max temperature 450C.
The product is in accordance with the
applicable safety standards in the
European directives.

SAFETY INSTRUCTIONS
Read the enclosed safety warnings, the additional safety warnings and the instructions. Failure to
follow the safety warnings and the instructions may result in electric shock, fire and/or serious
injury. Save the safety warnings and the instructions for future reference.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
.
.
.
.
.
.
.
.
.
Keep the work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2) Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use a RCD to reduces the risk of electric shock.
4

5
.
.
3) Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool. Do not
use a power tool while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye protection . Protective equipment such as
dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions
will reduce personal injuries.
.
.
.
.
.
.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger
on the switch or energizing power tools that have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust related hazards.
.
.
.
.
.
.
.
.
4) Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp andclean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
Do not let familiarity gainedfrom frequent use of tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe injury within a fraction of a second.
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

ADDITIONAL SAFETY WARNINGS FOR CORDLESS MULTI-TOOL
•
6
.
.
.
5) Battery tool use and care
Recharge only with the charger specified by the manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when used with another battery pack.
Use power tools only with specifically designated battery packs. Use of any other battery packs
may create a risk of injury and fire.
When the battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fi re.
.
.
.
.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
6) Service
Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
•
Never service damaged battery packs. Service of battery packs should only be performed by the
manufacturer or authorized service providers.
Contact with or inhalation of dust coming free during use (e.g. lead-painted surfaces, wood a
nd metal) can endanger your health and the health of bystanders. Always wear appropriate
protective equipment, such as a dust mask. Always use proper dust extraction during use.
•
Do not work materials containing asbestos. Asbestos is considered carcinogenic.
•
Do not work metal with a magnesium content of more than 80%.
•
Be very careful when working painted surfaces.
•
Do not use accessories which are not specifically designed and recommended by the
manufacturer. Risk of personal injury.
•
Inspect the machine and the accessories before each use. Do not use accessories which are
bent, cracked, or otherwise damaged. If the machine or one of the accessories is dropped,
inspect the machine or the accessory for damage. If necessary, replace the accessory.
Only use accessories that are recommended by the manufacturer.
•
Only use accessories that are suitable for the application.
•
Do not use a battery pack or tool that is damaged or modified. Damaged or modified batteries may
exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
Do not expose a battery pack or tool to fi re or excessive temperature. Exposure to fi re or
temperature above 130 °C may cause explosion. NOTE The temperature „130 °C“ can be replaced by
the temperature „265 °F“.
Follow all charging instructions and do not charge the battery pack or tool outside the temperature
range speci
fi ed in the instructions. Charging improperly or at temperatures outside the speci fi ed
range may damage the battery and increase the risk of
fi re.

7
•
•
SAFETY WARNINGS FOR BATTERY
Do not open the battery. Danger of shortcircuiting.
Protect the battery against heat, e. g., against continuous intense sunlight, fire, water, and moisture.
Danger of explosion.
•
•
•
In case of damage and improper use of the battery, vapors may be emitted. Ventilate the area
and seek medical help in case of complaints. The vapors can irritate the respiratory system.
Use the battery only in conjunction with your SnapFresh product. This measure alone protects the
battery against dangerous overload.
The battery can be damaged by pointed objects such as nails or screwdrivers or by force applied
externally. An internal short circuit can occur and the battery can burn, smoke, explode or overheat.
Only use accessories with the correct dimensions.
•
Do not use accessories that require liquid coolants. Risk of electric shock.
•
Make sure that the accessories are properly mounted. Do not use adapters or other aids to mount
accessories with another spindle diameter.
•
Make sure that the maximum speed for the accessory is larger than or the same as the maximum
speed of the machine. Refer to the rating plate on the machine.
•
Let the machine run at no load in a safe area after mounting the accessories. If the machine
vibrates strongly, immediately switch off the machine, remove the mains plug from the mains,
and try to solve the problem.
•
Make sure that the workpiece is properly supported or fixed.
Wear safety goggles. Wear hearing protection. Wear a dust mask. If necessary, use other protective
means, such as safety gloves, safety shoes, etc. Risk of personal injury.
•
Keep bystanders away from the work area. Make sure that all persons in the work area wear
protective equipment. Risk of personal injury.
•
Keep the mains cable away from the rotating accessory. If the mains cable touches the rotating
accessory, your hands or arms may come in contact with the accessory. Risk of personal injury.
•
Hold the machine by the insulated gripping surfaces where the accessory may contact hidden
wiring or the mains cable. If the accessory contacts a ‘live’ wire, the exposed metal parts of the
machine can also become ‘live’. Risk of electric shock.
•
Do not use the machine while carrying it at your side. Risk of personal injury.
•
Do not use the machine near flammable materials. Risk of fire.
•
Beware that the accessory continues to rotate for a short period after switching off the machine.
Do not attempt to bring the accessory to a standstill yourself.
•
Never put the machine down on a table or a workbench before it has been switched off.
•
•
•
Regularly clean the ventilation slots. Risk of electric shock.

MACHINE INFORMATION
Intended use
2
2
8
SAFETY WARNINGS FOR CHARGER
Intended use
Charge only BBT-DC20A and BBT-DC40A type rechargeable Battery packs with the charger. Other
types of batteries may burst to cause personal injury and damage.
•
•
•
•
The appliance is not to be used by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction.
Children being supervised not to play with the appliance.
Do not recharge non-rechargeable batteries!
During charging, batteries must be placed in the well ventilated area!
Electrical safety
Always check that the voltage of the power supply corresponds to the voltage on the rating
plate.
• Do not use the machine if the mains cable or the mains plug is damaged.
• Only use extension cables that are suitable for the power rating of the machine with a minimum
thickness of 1.5mm . If you use an extension cable reel, always fully unroll the cable.
2
TECHNICAL SPECIFICATIONS
Model No. BBT-ZOY01
Rated voltage 20V
No load speed 5000-18000/min
Weight 0.96 kg
Sound pressure (Lpa)
Acoustic power (Lwa)
Uncertainty (K)
Vibration (sawing in steel)
81.8 dB(A)
92.8 dB(A)
3 dB(A)
4.657 m/s
Uncertainty (K) 1.5 m/s
Model Number BBT-DC20A
Battery type Lithium-ion
Voltage 20V
Capacity 2.0 Ah
Recommended charger BBT-YFT20V
Weight 0.3 kg
Model Number BBT-YFT20V
Charger input 100-120V~60Hz 65W
Charger output 21V 2.5A
Charging time 2Ah battery 60 minutes
Charging time 4Ah battery 120 minutes
Recommended batteries
BBT-DC20A, BBT-DC40A
Weight 0.36 kg
Your cordless multi-tool has been designed for light sanding, sawing and scraping applications.

9
•
•
Only use the following batteries of the SnapFresh
power 20V battery platform. Using any other
batteries could cause serious injury or damage to the tool.
BBT-DC20A 20V, 2Ah Lithium-ion
BBT-DC40A 20V, 4Ah Lithium-ion
The following charger of the can be used to charge these batteries.
BBT-YFT20V Quick charger
The batteries of the SnapFresh power 20V battery platform are interchangeable with all the SnapFresh
power 20V battery platform tools.
Vibration level
The vibration emission level stated in this instruction manual has been measured. It may be used to
compare one tool with another and as a preliminary assessment of exposure to vibration when using
the tool for the applications mentioned
.
Using the tool for different applications, or with different or poorly maintained accessories, may
significantly increase the exposure level.
The times when the tool is switched off or when it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns.
Wear hearing protection.

10
ASSEMBLY
A
3
8
1
6
5
7
2
4
C
8
7
1
2
B
5

1. On/off switch
2. Speed adjustment wheel
3. Mounting point for accessories
4. Grip
5. Quick change lever
6. Work light
7. Battery
8. Battery unlock button
9. Battery LED indicators button
10. Battery LED indicators
11. Charger
12. Charger LED indicators
11
Before any work on the power tool, remove the battery.
The battery must be charged before first use.
DESCRIPTION
The numbers in the text refer to the diagrams on page 10-11.
D
10
12
7
11
9
12

12
Inserting the battery into the machine (Fig. C)
Ensure that the exterior of the battery is clean and dry before connecting to the charger or
machine.
Insert the battery (7) into the base of the machine as shown in Fig. C.
Push the battery further forward until it clicks into place.
•
•
Removing the battery from the machine (Fig. C)
Push the battery unlock button (8).
Pull the battery out of the machine as shown in Fig. C.
•
•
Checking the battery charging status (Fig. D)
• To check the battery charge status, push the button (9) on battery shortly.
• The battery has 3 lights indicating the charge level, the more lights that burn, the more charge
the battery has left.
•
When the lights are not burning it means the battery is empty and must be charged immediately.
•
•
•
•
Charging the battery with the charger (Fig. D)
Take the battery (7) off from the machine.
Turn the battery (7) to upside down position and slide it onto the charger (11) as shown in Fig. D.
Push the battery until it is fully pushed into the slot.
Plug the charger plug into an electrical outlet and wait for a while. The LED indicators on the
charger (12) will lighten up and show the charger status.

13
The charger has 2 LED indicators (12) which indicate the status of the charging process:
Red LED Status Green LED status Charger status
Off Off No power
Off On
Standby mode:
-No battery is
inserted or,
-Battery inserted
but charging has
finished
On Off Battery charging in
progress
• Fully charging the 2Ah battery may take up to 60 minutes.
• Fully charging the 4Ah battery may take up to 120 minutes.
After the battery is fully charged remove the charger plug from the outlet and remove the battery
from the charger.
When the machine is not being used over a longer period of time it is best to store the battery
in charged condition.
Removing and mounting accessories (fig. B)
Worn or damaged accessories must be replaced immediately.
Only use sharp and undamaged accessories.
•
Release the quick change lever (5) and slide the accessory forward to remove from the holder.
• Slide the accessory in the holder and fasten the quick change lever (5).
The sanding pad and the sanding paper must be used for sandingapplications.

14
OPERATION
MAINTENANCE
Before cleaning and maintenance, always switch off the machine and remove the battery
pack from the machine.
Clean the machine casings regularly with a soft cloth, preferably after each use. Make sure that the
ventilation openings are free of dust and dirt. Remove very persistent dirt using a soft cloth moist-
ened with soapsuds. Do not use any solvents such as gasoline, alcohol, ammonia, etc. Chemicals
such as these will damage the synthetic components.
Switching on and off (fig. A)
• To switch on the machine, slide the on/off switch (1) to the front.
• To switch off the machine, slide the on/off switch (1) to the rear.
Setting the speed (fig. A)
The speed adjustment wheel is used for setting the speed. The speed adjustment wheel can be set
to 6 positions. The ideal speed depends on the application and on the material to be worked.
Do not set the speed during use.
• Turn the speed adjustment wheel (2) to the required position.
Hints for optimum use
•Clamp the workpiece. Use a clamping device for small workpieces.
•Draw a line to define the direction in which to guide the accessory.
•Firmly hold the machine by the grip.
•Switch on the machine.
•Wait until the machine has reached full speed.
•Place the accessory on the workpiece.
•Slowly move the machine along the pre-drawn line, firmly pressing the accessory against the
workpiece.
•Do not apply too much pressure on the machine. Let the machine do the work.
• Switch off the machine and wait for the machine to come to a complete standstill before putting
the machine down.

15
If a defect arises and a valid claim is received within the Warranty Period, at its option, Babytec
will either 1) repair the defect at no charge, using new or refurbished replacement parts, or 2)
replace the product with a new product that is at least functionally equivalent to the original product,
or provide a store credit in the amount of the purchase price of the original product. A replacement
product or part, including a part installed in accordance with instructions product by Babytec,
assumes the remaining warranty of the original product. When a product or part is exchanged, any
replacement item becomes your property and the replaced item becomes Babytec’s property.
When a store credit is given, the original product must be returned to Babytec and becomes
Babytec’s property. To obtain warranty service, e-mail Babytec Warranty Service at support@snap-
freshtools.com. Please be prepared to describe the product that needs service and the nature of
the problem.
ENVIRONMENT
Faulty and/or discarded electrical or electronic apparatus have to be collected at the
appropriate recycling locations.
WARRANTY
Ningbo Babytec Technology Co., Ltd (Hereinafter referred to as Babytec) warrants this product
against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR
from the date of purchase by the original purchaser (’Warranty Period’).
The following circumstances are excluded from this guarantee:
• Repairs and or alterations have been made or attempted to the machine by unauthorized service
centers;
• Normal wear and tear;
• The tool has been abused, misused or improperly maintained;
• Non-original spare parts have been used.
Allrightsreservedby Ningbo Babytec Technology Co.,Ltd
[phone]
(Monday - Friday 9 a.m. - 5 p.m. EST 6 a.m. - 2 p.m. PST)
