SCHUNK DRG 44 Installation and operating instructions

Assembly and operation manual
DRG
Radial Gripper
Original Operating Manual

Imprint
2 06.00 | DRG | Assembly and operation manual | en | 389041
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK SE & Co. KG.
All rights reserved.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 389041
Version: 06.00|27/07/2023|en
Dear Customer,
Thank you for trusting our products and our family-owned company, the leading technology
supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions. Ask
us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
Customer Management
Tel. [phone]
Fax [phone]
[e-mail]
Please read the operating manual in full and keep it close to the product.

Table of Contents
06.00 | DRG | Assembly and operation manual | en | 389041 3
Table of Contents
1 General ............................................................................................. 5
1.1 About this manual............................................................................... 5
1.1.1 Presentation of Warning Labels ..................................................... 5
1.1.2 Applicable documents ................................................................. 6
1.1.3 Sizes........................................................................................ 6
1.1.4 Variants ................................................................................... 6
1.2 Warranty ........................................................................................... 6
1.3 Scope of delivery................................................................................. 6
1.4 Accessories ........................................................................................ 7
2 Basic safety notes ................................................................................ 8
2.1 Intended use...................................................................................... 8
2.2 Constructional changes......................................................................... 8
2.3 Spare parts ........................................................................................ 8
2.4 Gripper fingers .................................................................................. 8
2.5 Ambient conditions and operating conditions ........................................... 9
2.6 Personnel qualification ........................................................................ 9
2.7 Personal protective equipment .............................................................. 10
2.8 Notes on safe operation........................................................................ 11
2.9 Transport........................................................................................... 11
2.10 Malfunctions ...................................................................................... 11
2.11 Disposal ............................................................................................ 12
2.12 Fundamental dangers .......................................................................... 12
2.12.1 Protection during handling and assembly ....................................... 12
2.12.2 Protection during commissioning and operation ............................... 13
2.12.3 Protection against dangerous movements ....................................... 13
2.13 Notes on particular risks ....................................................................... 14
3 Technical data ..................................................................................... 16
4 Design and description .......................................................................... 17
4.1 Design .............................................................................................. 17
4.2 Characterization.................................................................................. 17
5 Assembly............................................................................................ 18
5.1 Installing and connecting ..................................................................... 18
5.2 Connections ....................................................................................... 19
5.2.1 Mechanical connection................................................................ 19
5.2.2 Pneumatic connection................................................................. 20

Table of Contents
4 06.00 | DRG | Assembly and operation manual | en | 389041
5.3 Mounting the sensor............................................................................ 22
5.3.1 Overview of sensors .................................................................... 22
5.3.2 Mounting inductive proximity switch IN .......................................... 22
5.3.3 Mounting inductive proximity switch IN 80...................................... 24
5.3.4 Mounting magnetic switch MMS 22 ................................................. 26
5.4 Setting the opening angle limits............................................................. 27
5.4.1 DRG 44 - 80 .............................................................................. 27
5.4.2 DRG 100.................................................................................... 28
6 Troubleshooting................................................................................... 29
6.1 Procukt does not move......................................................................... 29
6.2 Product is not executing the complete stroke ............................................ 29
6.3 Product opens or closes abruptly ............................................................ 29
6.4 Product does not achieve the opening and closing times ............................. 30
6.5 Gripping force is dropping..................................................................... 30
7 Maintenance ....................................................................................... 31
7.1 Notes................................................................................................ 31
7.2 Maintenance and lubrication intervals..................................................... 31
7.3 Lubricants/Lubrication points (basic lubrication) ....................................... 31
7.4 Disassembly and assembly .................................................................... 32
7.4.1 Type 44 - 80 ............................................................................. 32
7.4.2 From type 100 and up ................................................................. 33
7.5 Servicing and assembling the product ..................................................... 34
7.5.1 Assembling with assembly device .................................................. 35
7.5.2 Assembly device......................................................................... 36
7.6 Drawings........................................................................................... 38
8 Mounting kit proximity switch................................................................. 40
9 Translation of the original declaration of incorporation ................................. 41
10 UKCA declaration of incorporation ............................................................ 42
11 Information on the RoHS Directive, REACH Regulation and Substances of Very High
Concern (SVHC) ..................................................................................... 43

General
06.00 | DRG | Assembly and operation manual | en | 389041 5
1 General
1.1 About this manual
This manual contains important information for a safe and
appropriate use of the product.
This manual is an integral part of the product and must be kept
accessible for the personnel at all times.
Before starting work, the personnel must have read and
understood this operating manual. Prerequisite for safe working
is the observance of all safety instructions in this manual.
In addition to these instructions, the documents listed
under }1.1.2 [/6] are applicable.
NOTE: The illustrations in this manual are intended to provide a
basic understanding and may deviate from the actual version.
1.1.1 Presentation of Warning Labels
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Dangers for persons!
Non-observance will inevitably cause irreversible injury or death.
WARNING
Dangers for persons!
Non-observance can lead to irreversible injury and even death.
CAUTION
Dangers for persons!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.

General
6 06.00 | DRG | Assembly and operation manual | en | 389041
1.1.2 Applicable documents
lGeneral terms of business *
lCatalog data sheet of the purchased product *
The documents labeled with an asterisk (*) can be downloaded
from schunk.com.
1.1.3 Sizes
This operating manual applies to the following sizes:
lDRG 44
lDRG 54
lDRG 64
lDRG 80
lDRG 100
1.1.4 Variants
This operating manual applies to the following variations:
lDRG with gripping force maintenance "O.D. gripping" (AS)
lDRG with gripping force maintenance "O.D. gripping" (AS) -
high-temperature (V/HT)
1.2 Warranty
If the product is used as intended, the warranty is valid for 24
months from the ex-works delivery date under the following
conditions:
lObserve the maximum service life. }3 [/16]
lObserve the ambient conditions and operating
conditions, }2.5 [/9]
lObserve the specified maintenance and lubrication
intervals, }7 [/31]
Parts touching the workpiece and wear parts are not included in
the warranty.
1.3 Scope of delivery
The scope of delivery includes
lRadial Gripper DRG in the version ordered
lAccessory pack
Content of the accessory pack:
l2x throttle check valves
l6 x centering sleeves for mounting
l2 x O-ring for hose-free direct connection
l2 x locking screw for hose connections

General
06.00 | DRG | Assembly and operation manual | en | 389041 7
l2 x screws, fully threaded
l2 x thread seals
l1 x nut
l2 x cylindrical pin
Accessory pack for Standard High-temperature
version (HT)
DRG 44 5510242 35510242
DRG 54 5510243 35510243
DRG 64 5510244 35510244
DRG 80 5510245 35510245
DRG 100 5510246 35510246
1.4 Accessories
A wide range of accessories are available for this product
For information regarding which accessory articles can be used
with the corresponding product variants, see catalog data sheet.
Seal kit for Standard High-temperature
version (HT)
DRG 44 5519863 395519863
DRG 54 5519864 395519864
DRG 64 5519865 395519865
DRG 80 5519866 395519866
DRG 100 5519867 395519867

Basic safety notes
8 06.00 | DRG | Assembly and operation manual | en | 389041
2 Basic safety notes
2.1 Intended use
The product is designed exclusively for gripping and temporarily
holding workpieces or objects.
lThe product may only be used within the scope of its technical
data, }3 [/16].
lThe product is intended for installation in a machine/
automated system. The applicable guidelines for the machine/
automated system must be observed and complied with.
lThe product is intended for industrial and industry-oriented
use. Its use outside enclosed spaces is only permitted if
suitable protective measures are taken against outdoor
exposure. The product is not suitable for use in salty air.
lThe product can be used within the permissible load limits
and technical data for holding workpieces during simple
machining operations, but is not a clamping device according
to EN 1550:1997+A1:2008.
lAppropriate use of the product includes compliance with all
instructions in this manual.
lAny utilization that exceeds or differs from the appropriate
use is regarded as misuse.
2.2 Constructional changes
Implementation of structural changes
By conversions, changes, and reworking, e.g. additional threads,
holes, or safety devices can impair the functioning or safety of
the product or damage it.
lStructural changes should only be made with the written
approval of SCHUNK.
2.3 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
lUse only original spare parts or spares authorized by SCHUNK.
2.4 Gripper fingers
Requirements of gripper fingers
Accumulated energy can make the product unsafe and risk the
danger of serious injuries and considerable material damage.

Basic safety notes
06.00 | DRG | Assembly and operation manual | en | 389041 9
lExecute the gripper fingers in such a way that the product
reaches either the "open" or "closed" position in a de-
energized state.
lOnly change gripper fingers if no residual energy can be
released.
lMake sure that the product and the top jaws are a sufficient
size for the application.
2.5 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the
product unsafe, leading to the risk of serious injuries,
considerable material damage and/or a significant reduction to
the product's life span.
lMake sure that the product is used only in the context of its
defined application parameters, }3 [/16].
lMake sure that the product is a sufficient size for the
application.
lMake sure that the environment is free from splash water and
vapors as well as from abrasion or processing dust. Exceptions
are products that are designed especially for contaminated
environments.
2.6 Personnel qualification
Inadequate qualifications of the personnel
If the personnel working with the product is not sufficiently
qualified, the result may be serious injuries and significant
property damage.
lAll work may only be performed by qualified personnel.
lBefore working with the product, the personnel must have
read and understood the complete assembly and operating
manual.
lObserve the national safety regulations and rules and general
safety instructions.
The following personal qualifications are necessary for the
various activities related to the product:
Trained electrician Due to their technical training, knowledge and experience,
trained electricians are able to work on electrical systems,
recognize and avoid possible dangers and know the relevant
standards and regulations.

Basic safety notes
10 06.00 | DRG | Assembly and operation manual | en | 389041
Qualified personnel Due to its technical training, knowledge and experience,
qualified personnel is able to perform the delegated tasks,
recognize and avoid possible dangers and knows the relevant
standards and regulations.
Instructed person Instructed persons were instructed by the operator about the
delegated tasks and possible dangers due to improper behaviour.
Service personnel of
the manufacturer
Due to its technical training, knowledge and experience, service
personnel of the manufacturer is able to perform the delegated
tasks and to recognize and avoid possible dangers.
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
lWhen working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
lObserve the valid safety and accident prevention regulations.
lWear protective gloves to guard against sharp edges and
corners or rough surfaces.
lWear heat-resistant protective gloves when handling hot
surfaces.
lWear protective gloves and safety goggles when handling
hazardous substances.
lWear close-fitting protective clothing and also wear long hair
in a hairnet when dealing with moving components.

Basic safety notes
06.00 | DRG | Assembly and operation manual | en | 389041 11
2.8 Notes on safe operation
Incorrect handling of the personnel
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
lAvoid any manner of working that may interfere with the
function and operational safety of the product.
lUse the product as intended.
lObserve the safety notes and assembly instructions.
lDo not expose the product to any corrosive media. This does
not apply to products that are designed for special
environments.
lEliminate any malfunction immediately.
lObserve the care and maintenance instructions.
lObserve the current safety, accident prevention and
environmental protection regulations regarding the product's
application field.
2.9 Transport
Handling during transport
Incorrect handling during transport may impair the product's
safety and cause serious injuries and considerable material
damage.
lWhen handling heavy weights, use lifting equipment to lift
the product and transport it by appropriate means.
lSecure the product against falling during transportation and
handling.
lStand clear of suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
lImmediately remove the product from operation and report
the malfunction to the responsible departments/persons.
lOrder appropriately trained personnel to rectify the
malfunction.
lDo not recommission the product until the malfunction has
been rectified.
lTest the product after a malfunction to establish whether it
still functions properly and no increased risks have arisen.

Basic safety notes
12 06.00 | DRG | Assembly and operation manual | en | 389041
2.11 Disposal
Handling of disposal
The incorrect handling of disposal may impair the product's
safety and cause serious injuries as well as considerable material
and environmental harm.
lFollow local regulations on dispatching product components
for recycling or proper disposal.
2.12 Fundamental dangers
General
lObserve safety distances.
lNever deactivate safety devices.
lBefore commissioning the product, take appropriate
protective measures to secure the danger zone.
lDisconnect power sources before installation, modification,
maintenance, or calibration. Ensure that no residual energy
remains in the system.
lIf the energy supply is connected, do not move any parts by
hand.
lDo not reach into the open mechanism or movement area of
the product during operation.
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly may impair the product's safety
and cause serious injuries and considerable material damage.
lHave all work carried out by appropriately qualified
personnel.
lFor all work, secure the product against accidental operation.
lObserve the relevant accident prevention rules.
lUse suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads may cause serious injuries and even death.
lStand clear of suspended loads and do not step into their
swiveling range.
lNever move loads without supervision.
lDo not leave suspended loads unattended.

Basic safety notes
06.00 | DRG | Assembly and operation manual | en | 389041 13
2.12.2 Protection during commissioning and operation
Falling or violently ejected components
Falling and violently ejected components can cause serious
injuries and even death.
lTake appropriate protective measures to secure the danger
zone.
lNever step into the danger zone during operation.
2.12.3 Protection against dangerous movements
Unexpected movements
Residual energy in the system may cause serious injuries while
working with the product.
lSwitch off the energy supply, ensure that no residual energy
remains and secure against inadvertent reactivation.
lNever rely solely on the response of the monitoring function
to avert danger. Until the installed monitors become effective,
it must be assumed that the drive movement is faulty, with its
action being dependent on the control unit and the current
operating condition of the drive. Perform maintenance work,
modifications, and attachments outside the danger zone
defined by the movement range.
lTo avoid accidents and/or material damage, human access to
the movement range of the machine must be restricted. Limit/
prevent accidental access for people in this area due through
technical safety measures. The protective cover and protective
fence must be rigid enough to withstand the maximum
possible movement energy. EMERGENCY STOP switches must be
easily and quickly accessible. Before starting up the machine
or automated system, check that the EMERGENCY STOP system
is working. Prevent operation of the machine if this protective
equipment does not function correctly.

Basic safety notes
14 06.00 | DRG | Assembly and operation manual | en | 389041
2.13 Notes on particular risks
DANGER
Risk of fatal injury from suspended loads!
Falling loads can cause serious injuries and even death.
lStand clear of suspended loads and do not step within their
swiveling range.
lNever move loads without supervision.
lDo not leave suspended loads unattended.
lWear suitable protective equipment.
WARNING
Risk of injury from objects falling and being ejected!
Falling and ejected objects during operation can lead to serious
injury or death.
lTake appropriate protective measures to secure the danger
zone.
WARNING
Risk of injury from sharp edges and corners!
Sharp edges and corners can cause cuts.
lUse suitable protective equipment.
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
lBefore starting any work on the product: Switch off the power
supply and secure against restarting.
lMake sure, that no residual energy remains in the system.

Basic safety notes
06.00 | DRG | Assembly and operation manual | en | 389041 15
WARNING
Risk of injury from crushing and impacts!
Serious injury could occur during movement of the base jaw, due
to breakage or loosening of the gripper fingers or if the
workpiece is lost.
lWear suitable protective equipment.
lDo not reach into the open mechanism or the movement area
of the product.
WARNING
Risk of injury due to spring forces!
Parts are under spring tension on products which clamp using
spring force or which have gripping force maintenance. While
disassembling components can move unexpectedly and cause
serious injuries.
lDisassemble the product cautiously.
lMake sure that no residual energy remains in the system.
WARNING
Risk of injury from objects falling during energy supply failure
Products with a mechanical gripping force maintenance can,
during energy supply failure, still move independently in the
direction specified by the mechanical gripping force
maintenance.
lSecure the end positions of the product with SCHUNK SDV-P
pressure maintenance valves.

Technical data
16 06.00 | DRG | Assembly and operation manual | en | 389041
3 Technical data
Size DRG 44 - 100
Ambient temperature [°C]
Min. [°C]
Max. [°C]
- 10
+ 90
Ambient temperature for
high temperature version
Min. [°C]
Max. [°C]
- 10
+ 130
IP rating 67
Noise emission [dB(A)] ≤ 70
Pressure medium Compressed air, compressed air
quality according to ISO
8573-1:2010 [7:4:4]
Nominal working pressure [bar] 6.0
Min. pressure [bar] 4.0
Max. pressure [bar] 6.5
More technical data is included in the catalog data sheet.
Whichever is the latest version.

Design and description
06.00 | DRG | Assembly and operation manual | en | 389041 17
4 Design and description
4.1 Design
Radial gripper DRG
1 Hose-free direct connection at the base
2 Main air connections
3 Base jaw
4 Thread for control cams
5 Case
6 Groove for magnetic switch
4.2 Characterization
Sealed 180° angular gripper for use in contaminated
environment.

Assembly
18 06.00 | DRG | Assembly and operation manual | en | 389041
5 Assembly
5.1 Installing and connecting
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
lBefore starting any work on the product: Switch off the power
supply and secure against restarting.
lMake sure, that no residual energy remains in the system.
CAUTION
Damage to the gripper is possible!
If the maximum permissible finger weight or the permissible
mass moment of inertia of the fingers is exceeded, the gripper
can be damaged.
lA jaw movement always has to be without jerks and bounce.
lYou must therefore implement sufficient reduction and/or
damping.
lObserve the information in the catalog data sheet.
1. Check the flatness of the mounting surface,
}5.2.1 [/19].
2. Connect the product via the hose-free direct
connection, }5.2.2 [/20].
3. OR: Connect supply lines to the main air connections A and
B, }5.2.2 [/20].
ðUnscrew locking screws.
ðScrew on air connections.
ðOR: Screw on throttle valve in order to be able to perform
sufficient throttling and/or dampening.
4. Screw the product to the machine/system, }5.2.1 [/19].
ðUse suitable connecting elements (adapter plates) if
necessary.
ðObserve the permissible depth of engagement as well as
strength class, if required.
5. Connect the sensor, see Sensor Assembly and Operating
Manual.
6. Install the sensor, }5.3 [/22].

Assembly
06.00 | DRG | Assembly and operation manual | en | 389041 19
5.2 Connections
5.2.1 Mechanical connection
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
Tab.: Requirements for evenness of the mounting surface (Dimensions in mm)
Mounting The module can be mounted from the front, from the rear, and
from below:
Assembly options
Item Mounting 44 54 64 80 100
1 Module from
below
M4 x
max. 9
M5 x
max. 12
M6 x
max. 14
M6 x
max. 14
M10 x
max.
20
2 Module from the
rear
M4 x
max. 7
M5 x
max. 10
M6 x
max. 12
M8 x
max. 16
M10 x
max.
20
3 Module from the
front
- M4 x 40 M5 x 45 M5 x 55 M8 x
65
4 Top jaws M3 M4 M5 M6 M8
5 Centering
diameter
20H7 20H7 25H7 30H7 -
Tab.: Mounting material

Assembly
20 06.00 | DRG | Assembly and operation manual | en | 389041
NOTE
The cylindrical pins (37) or centering sleeves (39) needed for
centering are supplied in the accessory kit:
Mounting from
below
1. Mount the module using the guide sleeves (39) supplied.
Alternatively, use the cylindrical pins (37) and the centering
diameter (5).
2. Fasten the module using the fixing bores provided.
3. Fasten the top jaws using the fixing bores provided.
Mounting from the
rear or front
1. Mount the module using the cylindrical pins (37) provided.
2. Fasten the module using the fixing bores provided.
3. Fasten the top jaws using the fixing bores provided.
5.2.2 Pneumatic connection
CAUTION
Damage to the gripper is possible!
If the maximum permissible finger weight or the permissible
mass moment of inertia of the fingers is exceeded, the gripper
can be damaged.
lA jaw movement always has to be without jerks and bounce.
lYou must therefore implement sufficient reduction and/or
damping.
lObserve the information in the catalog data sheet.
CAUTION
Throttling of the product must be done by external throttle
glands.
lAttach the supplied flow control couplings on the product.
CAUTION
Observe the requirements for the air supply
}3 [/16].
