1
Installation
Instructions
Front Counter Weight Kit
Mfg. No. 1694946
Installation
“J”-HOOK REMOVAL
1. Remove Mower Deck. See Operator’s Manual
MOWER DECK REMOVAL & INSTALLATION.
2. Remove and retain 7/16-14 x 2 capscrews (A, Figure
2) and 7/16-14 locknuts (B) from front axle (D).
Discard “J”-hook (C).
For the LT-200 Series
Figure 1. Contents
Kit Contents:
Ref. Part No. Qty. Description
1 1960074 2 Clips, Hair Pin
2 1732995A 1 Bracket
3 1715758 2 Rods
4 1732993A 1 Counter Weight
This kit is to install a front counter weight onto a
LT-200 Series Lawn Tractor.
Before beginning any service work turn off the
PTO, set the parking brake, turn off the ignition,
and disconnect the spark plug wire(s).
WARNING
1
3
Figure 2. Remove “J”-Hook
A. Capscrews, 7/16-14 x 2
B. Locknut, Flange, 7/16-14
C. “J”- Hook
D. Front Axle
D
4
2
A
B
C
2
Installation Instructions Rear Weight Carrier Kit
Form No. 1733188-00
Rev. 06/2005
© 2006 Simplicity Manufacturing, Inc. All Rights Reserved
TP 200-4306-00-AT-N
Snapper, INC.
535 Macon Street
McDonough, GA 30253 USA
BRACKET INSTALLATION
1. Install the new bracket (C, Figure 3) to front axle (D)
securing with existing 7/16-14 capscrews (A) and
existing 7/16-14 locknuts (B).
WEIGHT AND DECK INSTALLATION
1. Use one of the rods (A, Figure 5) in the lower hole of
bracket (D) to Install Mower Deck. See Operator’s
Manual MOWER DECK REMOVAL &
INSTALLATION. Secure rod (A) with clip (B).
2. Insert one of the rods (A) through the hitch (D) and
weight (C). Secure rod (A) with clip (B).
Figure 3. Install Front Weight Carrier Bracket
A. Capscrews, 7/16-14 x 2 (Existing)
B. Locknut, Flange, 7/16-14 (Existing)
C. Bracket, Front Weight Carrier (New)
D. Front Axle (Existing)
D
A
B
C
Figure 4. Remove and Discard Rod & Clip
A. Clip, Safety Pin
B. Rod
C. Hitch, Deck
A
B
C
Figure 5. Rods and Weight
A. Rods
B. Clip, Hair Pin
C. Weight
D. Bracket
D
B
A
A
C
