Snapper 10305E User manual

Parts Manual for
TWO STAGE
LARGE FRAME
SNOW THROWER
SERIES 5
MODELS
8245
8265
E8265
9265
E9265
10305
11305
10305E
E10305
E10305E
E11305
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE
AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD
IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH
CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
COPYRIGHT © 2000
SNAPPER INC.
ALL RIGHTS RESERVED
(Rev. 5, 7/03/00) MANUAL No. 06037
MODEL 10305E
SHOWN

2
FAMILIARIZATION
MODEL 10305E SHOWN
MANUAL No. 06037 LARGE FRAME SNOWTHROWER
HARDWARE
BAG KITS
PAGE 25 ACCESSORIES
PAGE 25 - 27
BLOWER CLUTCH
Pages 16 - 19
LIGHTS
Pages 18 - 19
DISCHARGE CHUTE
Pages 4 & 5
DIRECTIONAL CONTROL
Pages 16 - 19
BLOWER HOUSING
Pages 6 & 7
AUGERS
Page 3
SCRAPERS
Pages 6 & 7 GEAR BOX, SHAFTS
Pages 10 & 11 SKID SHOES
Pages 6 & 7
IMPELLER
Page 3
TRACTION DRIVE
Pages 14 & 15
WHEELS
Page 21
FRAME
Pages 12 & 13
ENGINE
Page 20
CONTROL PANEL
Pages 16 - 19
HANDLE BARS
Pages 16 - 19
CHUTE CONTROL
Page 16 - 19
DECALS
Pages 22 - 24
TRACTION CLUTCH
Pages 16 - 19

3
AUGERS, IMPELLER
ITEM PART NO. DESCRIPTION
1 4-9928 AUGER, Right Side (8245 Models)
- 4-9935 AUGER, Right Side (8265, 9265 & E9265 Models)
- 4-9922 AUGER, Right Side (10305E, E10305E, N10305E, 11305 &
E11305 Models)
2 1-3864 FITTING, Grease (2)
3 9-1550 BOLT, 5/16-18 x 1-7/8" Shear (2)
4 9-1298 NUT, 5/16-18 Hex Nyloc (2)
5 4-9927 AUGER, Left Side (8245 Models)
- 4-9936 AUGER, Left Side (8265, 9265 & E9265 Models)
- 4-9921 AUGER, Left Side (10305E, E10305E, N10305E, 11305
E11305 Models)
6 4-9677 FAN, Impeller
7 1-3862 PIN, 1/4 x 1-1/2" Roll (2)
8 5-1350 ASSEMBLY, Bearing (Includes Item 11)
9 9-0699 BOLT, 1/4-20 x 3/4" Hex Flange Lock, Grade 5 (6)
10 9-1065 NUT, 1/4-20 Hex Flange Lock (6)
11 1-0817 FITTING, Grease (2)
12 2-8221 SPACER (Used on Model 8245 Models Only) (2)
LARGE FRAME SNOWTHROWER MANUAL No. 06037
RIGHT SIDE
LEFT SIDE
GEARBOX, SHAFTS
(See Pages 8 – 9)

4
DISCHARGE CHUTE
MANUAL No. 06037 LARGE FRAME SNOWTHROWER
COLLECTOR HOUSING
#10-32 HEX JAM NUTS and
#10 LARGE OUTSIDE DIAMETER
FLAT WASHERS
(PART OF CONTROL CABLE)
1
2
5B
5A
6
23
6
9
3
19
22
25
24
4
14
26
19
21
18
16
20
17
14
13
10
11
12
7
8
25
15

5
DISCHARGE CHUTE
ITEM PART NO. DESCRIPTION
1 2-8208 CHUTE, Discharge
-- 2-8217 CHUTE, Remote Control Discharge (8245 Model Only)
2 2-4773 DECAL, Hand Danger
3 2-8235 DEFLECTOR, Remote Control Discharge
-- 2-8184 DEFLECTOR (8245 Model Only)
4 2-8253 PIN, Hinge
5A 1-6324 T-KNOB (Plastic)
5B 3-5744 T-KNOB (w/5/16-18 insert)
6 9-1076 WASHER, 5/16 Flat (2)
7 9-1072 BOLT, 5/16-18 x 1” Square Neck Carriage, Grade 5
8 9-1021 SCREW, 5/16-24 x 3/4" Hex Head Cap, Grade 5 (3)
9 9-1074 NUT, 5/16-24 Hex Center Lock, Grade B
10 3-9765 RING, Chute (59 Tooth, 229 Degrees)
-- 4-7855 RING, Chute (Euro) (48 Tooth, 187 Degrees)
11 1-1938 RETAINER (Chute Ring to Housing) (2)
12 9-1077 BOLT, 5/16-18 x 5/8" Square Neck Carriage, Grade 5 (3)
13 9-1070 NUT, 5/16-18 Hex Flange Lock, Grade 5 (3)
14 9-1075 SCREW, #10-24 x 5/8" Hex Washer Self-Tap, Grade 5 (8)
15 9-1069 NUT, 5/16-18 Hex, Grade B or 5
16 3-2813 MOUNT, Cable
17 9-1064 BOLT, 1/4-20 x 1/2" Short Neck Carriage, Grade 5 (2)
18 9-1023 WASHER, 1/4” Internal Tooth Lock (2)
19 9-1100 NUT, 1/4-20 Hex (3)
20 4-5172 CABLE, Control
21 9-1099 NUT, 1/4-20 Hex Center Lock, Grade B or 5
22 9-1098 WASHER, 1/4 Flat (2)
23 2-3798 BOLT, 1/4-20 x 1-1/2" Eye
24 1-9692 WIRE, Safety
25 2-3673 PUSH-ON Fastener, 5/32” Dia. (2)
26 3-2559 RETAINER, Safety Wire (2)
LARGE FRAME SNOWTHROWER MANUAL No. 06037

6
COLLECTOR HOUSING
MANUAL No. 06037 LARGE FRAME SNOWTHROWER
30
22 14
13 10
16
8 9 12
11
18
32
31
21
20
7
2
6
19
5 25 23
27
4
22
13
5 22
20
1 25
28
29
24
15
21
17
3
26
19 5

7
COLLECTOR HOUSING
ITEM PART NO. DESCRIPTION
1 5-2134 ASSEMBLY, 24" Blower (8245 Models) (Includes 1-6578 Decal)
-- 5-2135 ASSEMBLY, 26" Blower (8265 & 9265 Models) (Incl. 1-6578 Decal)
-- 5-3421 ASSEMBLY, 30" Blower (10305E & 11305E Models) (Includes 2-6629 Decal)
2 3-3035 GUIDE, Cable (8265, 9265, E9265, 10305E, E10305E, N10305E),
11305 & E11305)
3 9-1021 SCREW, 5/16-24 x 3/4” Hex Head Cap, Grade 5
4 9-1074 NUT, 5/16-24 Hex Center Lock, Grade B
5 9-1070 NUT, 5/16-18 Hex Flange Lock, Grade 5 (9)
6 2-8280 DECAL, Danger Rotating Auger
-- 2-8711 DECAL, Foot Danger (Euro)
7 2-8281 DECAL, Heavy Duty Snow
8 3-4303 BRACKET, Worm Shaft Support
9 1-2117 BUSHING
10 1-4001 PIN, 1/8 x 3/4" Roll
11 2-8222 CONNECTOR
12 4-2809 SHAFT, Worm (3/8-16 threaded)
13 1-1724 WASHER, 13/32 Spring (2)
14 2-8348 WORM
15 9-0539 SCREW, 1/4-20 x 1/2” Hex Washer Self-Tap
16 9-0858 SCREW, 5/16-18 x 1/2" Hex Washer Self-Tap (2)
17 3-8009 BAR, Stiffener (10305E, 11305 & E11305 Models Only)
18 9-1082 PIN, 3/32 x 3/4" Cotter
19 3-7982 SHOE, Skid (2)
20 9-0324 SCREW, 3/8-16 x 1" Hex Washer Self-Tap (2)
21 1-6360 WASHER, 3/8” Flat
22 9-0001 BOLT, 5/16-18 x 3/4" Short Neck Carriage, Grade 5 (11)
23 9-0731 BOLT, 5/16-18 x 1/2" Short Neck Carriage, Grade 5 (5)
24 3-6122 BLADE, Scraper (8245 Models)
-- 3-9770 BLADE, Scraper (8265 & 9265 Models)
-- 3-6006 BLADE, Scraper (10305E, 11305 & E11305 Models)
25 9-1076 WASHER, 5/16 Flat
26 2-8177 BRACKET, Worm
27 4-2894 PLUG, Dome 5/16” (2)
-- 4-2895 PLUG, 5/16” Dome (2)
28 9-1514 WASHER, 3/8” Flat
29 9-1585 NUT, 3/8-16 Hex Center Lock, Grade 5 or B
30 3-7971 DRIFT CUTTER (2)
31 9-0187 WASHER, 5/16 Split Lock (4)
32 9-0196 NUT, 5/16-18 Hex (4)
LARGE FRAME SNOWTHROWER MANUAL No. 06037

8
BELTS, IDLER, DRIVE PLATE, SHEAVE
MANUAL No. 06037 LARGE FRAME SNOW THROWER
1
2 3
4
5
6 7
8
9
10
10
11
12
13 13
14
15
16
17
18
18
19
20
21
22 22
23
23
24
24
25
26
27
28
29
ENGINE PULLEY
(See Page 20)
IDLER
(See Page 20)

9
BELTS, IDLER, DRIVE PLATE, SHEAVE
ITEM PART NO. DESCRIPTION
1 5-3580 ASSEMBLY, Idler Arm (Includes Items 2 & 3)
2 9-1559 RIVET (2)
3 1-3859 PAD, Brake
4 1-3919 SPRING
5 9-0791 BOLT, 3/8-16 x 1-1/2" Square Neck Carriage, Grade 2
6 9-0122 WASHER, 3/8 Flat
7 1-3850 PULLEY, Idler
8 9-0499 NUT, 3/8-16 Hex Top Lock
9 9-1069 NUT, 5/16-18 Hex, Grade B or 5
10 1-6314 WASHER, 5/16 x 1-1/4" Flat
11 1-3849 SPACER
12 9-1072 BOLT, 5/16-18 x 1" Square Neck Carriage, Grade 5
13 1-3931 HOUSING, Bearing
14 1-3924 BEARING (Includes Two #10-32 Socket Set Screws)
15 9-0001 BOLT, 5/16-18 x 3/4" Short Neck Carriage, Grade 5
16 9-1070 NUT, 5/16-18 Hex Flange Lock, Grade 5 (3)
17 1-3867 SHEAVE, Blower (Includes Two 5/16 Set Screws)
18 1-3937 BELT, Blower (All Models with Briggs Engines)
-- 1-3939 BELT, Blower (All Models with Tecumseh Engines)
19 1-0776 RING, 1/2 External Snap (Heavy Duty)
20 1-3861 KEY, #11 Woodruff
21 5-1358 PLATE, Drive (Includes Item 22)
22 1-4295 BEARING, Ball (2)
23 1-3936 BELT, Traction (All Models with Briggs Engines)
-- 2-9101 BELT, Traction (All Models with Tecumseh Engines)
24 1-4296 WASHER, 1/2 Shim (4) (Used with Item 21) (4)
25 9-0187 WASHER, 5/16 Split Lock
26 1-7734 COVER, Belt Guard
27 9-1122 SCREW, 1/4-20 x 1/2" Hex Washer Self-Tap
28 3-4302 WASHER, 3/4 x 1-1/8" Flat
29 1-1791 RETAINER, 5/16 Bolt
LARGE FRAME SNOWTHROWER MANUAL No. 06037

10
GEARBOX, SHAFTS
MANUAL No. 06037 LARGE FRAME SNOW THROWER
NOTE: USE 4 OZ. OF #2-9577
BENALENE 900 GREASE
FOR LUBRICATION.
1
1
2
3
4
4
5
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
20
21
