Snom SIP Series User manual

SIP Series
HD351
SIP Cordless 1-line Hotel Telephone
HD351W
SIP Cordless 1-line Wi-Fi Enabled Hotel Telephone
HD3
SIP Cordless 1-line Handset and Charger
User Manual

EN - 2
1. This product should be installed by a
qualified technician.
2. This product should only be connected to
the host equipment and never directly to the
network such as Public Switch Telephone
Network (PSTN) or Plain Old Telephone
Services (POTS).
3. Read and understand all instructions.
4. Follow all warnings and instructions marked
on the product.
5. Unplug this product from the wall outlet
before cleaning. Do not use liquid or
aerosol cleaners. Use a damp cloth for
cleaning.
6. Do not use this product near water such as
near a bath tub, wash bowl, kitchen sink,
laundry tub or swimming pool, or in a wet
basement or shower.
7. Do not place this product on an unstable
table, shelf, stand or other unstable
surfaces.
8. Slots and openings in the back or bottom
of the telephone base and handset are
provided for ventilation. To protect them
from overheating, these openings must
not be blocked by placing the product on
a soft surface such as a bed, sofa or rug.
This product should never be placed near
or over a radiator or heat register. This
product should not be placed in any area
where proper ventilation is not provided.
9. This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the type
of power supply on the premises, consult
your dealer or local power company.
10. Do not allow anything to rest on the power
cord. Do not install this product where the
cord may be walked on.
11. Never push objects of any kind into this
product through the slots in the telephone
base or handset because they may touch
dangerous voltage points or create a short
circuit. Never spill liquid of any kind on the
product.
12. To reduce the risk of electric shock, do not
disassemble this product, but take it to
an authorised service facility. Opening or
removing parts of the telephone base or
handset other than specified access doors
may expose you to dangerous voltages
or other risks. Incorrect reassembling can
cause electric shock when the product is
subsequently used.
13. Do not overload wall outlets and extension
cords.
14. Unplug this product from the wall outlet
and refer servicing to an authorised service
facility under the following conditions:
• When the power supply cord or plug is
damaged or frayed.
• If liquid has been spilled onto the
product.
• If the product has been exposed to rain
or water.
• If the product does not operate
normally by following the operating
instructions. Adjust only those controls
that are covered by the operation
instructions. Improper adjustment of
other controls may result in damage
and often requires extensive work by
an authorised technician to restore the
product to normal operation.
• If the product has been dropped and
the telephone base and/or handset has
been damaged.
• If the product exhibits a distinct change
in performance.
Important safety instructions
The applied nameplate is located at the bottom or rear of the product.
When using your telephone equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric shock and injury, including the following:

EN - 3
15. Avoid using a telephone (other than
cordless) during an electrical storm. There
is a remote risk of electric shock from
lightning.
16. Do not use the telephone to report a gas
leak in the vicinity of the leak. Under certain
circumstances, a spark may be created
when the adapter is plugged into the power
outlet, or when the handset is replaced in its
cradle. This is a common event associated
with the closing of any electrical circuit. The
user should not plug the telephone into a
power outlet, and should not put a charged
handset into the cradle, if the telephone
is located in an environment containing
concentrations of flammable or flame-
supporting gases, unless there is adequate
ventilation. A spark in such an environment
could create a fire or explosion. Such
environments might include: medical use
of oxygen without adequate ventilation;
industrial gases (cleaning solvents; petrol
vapours; etc.); a leak of natural gas; etc.
17. Only put the handset of your telephone next
to your ear when it is in normal talk mode.
18. The power adapters are intended to be
correctly oriented in a vertical or floor mount
position. The prongs are not designed to
hold the plug in place if it is plugged into
a ceiling, under-the-table or cabinet outlet.
19. Use only the power cord and batteries
indicated in this manual. Do not dispose
of batteries in a fire. They may explode.
Check with local codes for possible special
disposal instructions.
20. In wall mounting position, make sure to
mount the telephone base on the wall by
aligning the eyelets with the mounting studs
of the wall plate. Then slide the telephone
base down on both mounting studs until it
locks into place. Refer to the full instructions
in Installation in the user’s manual.
21. This product should be mounted at a height
of less than 2 meters.
22. Listed PoE (The product is considered not
likely to require connection to an Ethernet
network with outside plant routing).
CAUTIONS
• Keep small metallic objects such as pins
and staples away from the handset receiver;
• Risk of explosion if battery is replaced by
incorrect type;
• Dispose of used batteries according to the
instructions;
• Disconnect the telephone line before
replacing batteries;
• For pluggable equipment, the socket-outlet
(power adaptor) shall be installed near the
equipment and shall be easily accessible;
• Avoid using the battery in the following
conditions:-
• High or low extreme temperatures that a
battery can be subjected to during use,
storage or transportation;
• Low air pressure at high altitude;
• Replacement of a battery with an incorrect
type that can defeat a safeguard;
• Disposal of a battery into fire or a hot oven,
or mechanically crushing or cutting of a
battery that can result in an explosion;
• Leaving a battery in an extremely high
temperature surrounding environment that
can result in an explosion or the leakage
of flammable liquid or gas;
• Extremely low air pressure that can result in
an explosion or the leakage of flammable
liquid or gas.
SAVE THESE INSTRUCTIONS

EN - 4
Table of contents
Important safety instructions.............2
Parts check list....................................5
Telephone layout ...............................7
Installation....................................... 10
Set up .............................................. 16
Voice Menu.................................................. 17
Operation.........................................18
Appendix ........................................ 20
Troubleshooting..........................................20
Maintenance ................................................26
Disclaimer and Limitation of Liability .......26
European Directives ...................................26
Declaration of Conformity.........................26
Disposal of batteries and product............ 27

EN - 5
Parts check list
Items contained in the respective cordless telephone package:
Model name Model
number
Parts included
Telephone base
with overlay
Base Stand |
Wall Mount
Bracket
Ethernet
cable | Short
Ethernet
cable |
Telephone
Base Power
Adapter
Cordless
handset and
Handset
battery
Handset
charging
base | Power
adapter
SIP Cordless
1-line Hotel
Telephone
HD351
Caution:
Rechargeable Li-ion Battery
BT239865
Model No.:523450AR1000
3.7V 3.7Wh 1000mAh
Li-ion
Made in China
1ICP6/34/50 2021-08-05
-Bur n hazar d, fire h azard ,
explosionhazard.
Do not c rush, d isass emble ,-
dispo se in fir e.
-Do no t expos e to high t emp.
-Do no t allow m etal ob jects t o
conta ct term inals .
-Dispose of pro perly.
Yi Yang Corun Battery Co., Ltd.
+ -
(60°C/ 140°F)
SIP Cordless
1-line Wi-Fi
Enabled Hotel
Telephone
HD351W
Caution:
Rechargeable Li-ion Battery
BT239865
Model No.:523450AR1000
3.7V 3.7Wh 1000mAh
Li-ion
Made in China
1ICP6/34/50 2021-08-05
-Bur n hazar d, fire h azard ,
explosionhazard.
Do not c rush, d isass emble ,-
dispo se in fir e.
-Do no t expos e to high t emp.
-Do no t allow m etal ob jects t o
conta ct term inals .
-Dispose of pro perly.
Yi Yang Corun Battery Co., Ltd.
+ -
(60°C/ 140°F)

EN - 6
Parts check list (continued)
Items contained in the respective cordless telephone package:
Model name Model
number
Parts included
Telephone base
with overlay
Base Stand |
Wall Mount
Bracket
Ethernet
cable | Short
Ethernet
cable |
Telephone
Base Power
Adapter
Cordless
handset and
Handset
battery
Handset
charging
base | Power
adapter
Cordless 1-line
Handset and
Charging Base
HD3
Caution:
Rechargeable Li-ion Battery
BT239865
Model No.:523450AR1000
3.7V 3.7Wh 1000mAh
Li-ion
Made in China
1ICP6/34/50 2021-08-05
-Bur n hazar d, fire h azard ,
explosionhazard.
Do not c rush, d isass emble ,-
dispo se in fir e.
-Do no t expos e to high t emp.
-Do no t allow m etal ob jects t o
conta ct term inals .
-Dispose of pro perly.
Yi Yang Corun Battery Co., Ltd.
+ -
(60°C/ 140°F)

EN - 7
Telephone layout
SIP Cordless 1-line Hotel Telephone - HD351
SIP Cordless 1-line Wi-Fi Enabled Hotel Telephone - HD351W
Telephone Base
1 Find Handset button
2 Charging poles
3 Charge LED
4 Message waiting LED
5
Speed dial keys
MESSAGE key
MUTE key
HOLD key
6EMERGENCY key
7 Numeric dial keys
8VOLUME – key
9VOLUME + key
10 SPEAKER key
11 1312
1
2
4
5
6
7
8 9 10
3
11 Power adapter input
12 NET Ethernet port
13 PC Ethernet port

EN - 8
1 Handset earpiece
2 VOLUME keys
3TALK/FLASH key
4 OFF/Cancel key
5 Numeric dial keys
6 HOLD key
7MESSAGES key
8 Speed dial keys
9 Low battery LED
10 Microphone
11 SPEAKER key
12 MUTE key
13 Charging contacts
14 Message waiting LED
15 Speakerphone
Telephone layout
SIP Cordless 1-line Hotel Telephone
SIP Cordless 1-line Wi-Fi Enabled Hotel Telephone - HD351W
Handset
1
2
3
4
5
6
7
8
9
10
12
13
11
15
14

EN - 9
Cordless 1-line Handset Charging
Base - HD3
1
2
1 Charge LED
2 Charging poles

EN - 10
Installation
SIP Cordless 1-line Hotel Telephone -
HD351
SIP Cordless 1-line Wi-Fi Enabled Hotel
Telephone - HD351W
Telephone base installation
The telephone comes ready for desktop use.
1. Install the telephone base as shown below.
• NOTE: Power adapter is not required
for Power over Ethernet (PoE).
2. When the telephone base has been initially
installed, make sure the power adapter
is securely plugged into an outlet not
controlled by a wall switch, and the Ethernet
cable is plugged into the network wall jack.
• The battery is fully charged after 11
hours of continuous charging. For best
performance, keep the cordless handset
in the telephone base when not in use.
3. Press on the telephone base. Listen for a
dial tone, then press again to hang up.
Note
• The dial tone will not be played if the SIP
account used by this telephone cannot be
registered.
• The power adapter is sold separately.
• Use only the power adapter described in
"Technical specifications" on page 28.
CAUTIONS
Use only the supplied Ethernet cables. The
supplied Ethernet cables are not designed
for use in any other IT devices. Misusing them
on your other IT devices shall be prohibited.
To order a replacement, contact authorized
service personnel, your seller, or Snom.
Installation option - install base
stand for desktop
To mount the telephone base on the base
stand
1. Align the grooves of the base stand with the
telephone base.
2. Slide the base stand up to secure it.
To unmount the base stand
Simply slide the base stand down, and lift it
from the telephone base.

EN - 11
Installation option - converting
from desktop to wall mount position
To mount the telephone base on the wall
1. Unmount the base stand from the telephone
base. Disconnect all cords and cables
from the telephone base. Put the cordless
handset aside.
2. Turn the telephone base over with the
bottom side facing up.
3. Align the grooves with the wall mount
bracket.
4. Slide the wall mount bracket up.
5. Connect the telephone as described in
"Telephone base installation" on page
10, but use the short Ethernet cable. The
short Ethernet cable and power adapter
cable stick out from the hole in the wall
mount bracket.
6. Mount the telephone base on the wall by
positioning the eyelets on the telephone
base and the mounting bracket against the
mounting studs. Then slide the telephone
base down on both mounting studs until it
locks into place.
7. Replace the cordless handset on the
telephone base cradle.
To remove the wall mount bracket from
the telephone base
1. Slide the telephone base up to remove it
from the mounting studs on the wall.
2. Disconnect all cords and cables from the
telephone base.
3. Slide the wall mount bracket down and lift it
from the telephone base.

EN - 12
wall mount bracket dimensions
Unit: mm

EN - 13
Installing or replacing a cordless
handset battery
To install or replace the handset battery, follow
the steps below.
1. Hold the handset.
2. Press both thumbs down on the edge of
the battery cover near the speaker, and
slide the battery cover downwards.
3. Lift the battery cover off the handset.
4. If you are replacing the battery: Place your
thumb in the slot below the battery, and
lift the battery out of the handset battery
compartment
5. Place the top of the battery in the handset
battery compartment so that the battery
connectors are aligned.
6. Push the bottom of the battery down into
the battery compartment.
7. Align all the tabs on the handset cover
against the corresponding grooves on
the handset, then slide the handset cover
closed.
CAUTIONS
• There may be a risk of explosion if a
wrong type of handset battery is used.
Use only the supplied rechargeable
battery or replacement battery (Model
No. 523450AR1000). To order a
replacement, contact authorized service
personnel, your seller, or Snom.
• Dispose of used batteries according to
the instructions.
Installation notes
CAUTION! Please be careful of sharp edges
of base stand that can cause harm during the
installation process.
Avoid placing the phone too close to:
• Communication devices such as
television sets, DVD players, or other
cordless telephones
• Excessive heat sources
• Noise sources such as a window with
traffic outside, motors, microwave ovens,
refrigerators, or fluorescent lighting
• Excessive dust sources such as a
workshop or garage
• Excessive moisture
• Extremely low temperature
• Mechanical vibration or shock such as
on top of a washing machine or work
bench

EN - 14
Handset registration
Place the cordless handset on the telephone
base cradle. Handset registration happens
automatically the first time a cordless handset
is placed on the telephone base.
When the registration process completes, the
MESSAGE WAITING LED flashes once and you
hear 3 rising beeps as confirmation.
Each telephone base accommodates up to
five cordless handsets. When you already have
five registered handsets, you can replace one
of them by a new handset if any one of the
five registered handsets is disconnected from
the base. For example, it is out of range, or its
battery is removed or depleted. The previous
registered handset is then deregistered from
the telephone base.
Handset deregistration
When a registered cordless handset is idle,
press *331734#, then press HOLD. You will hear
a confirmation tone when the deregistration
process completes.
Register a handset to another
telephone base
Any cordless 1-line handset can register to any
cordless 1-line telephone base.
When a registered cordless handset is idle,
place it on another telephone base. This cordless
handset automatically registers to the new
telephone base.
Handset battery charging
The battery must be fully charged before
using the cordless handset for the first time.
The CHARGE LED turns on when the cordless
handset is charging on the telephone base.
The battery is fully charged after 11 hours of
continuous charging. For best performance, keep
the cordless handset in the telephone base or
charging base when not in use.

EN - 15
Installation
Cordless 1-line Handset and Charging
base - HD3
install charging base for desktop
To mount the charging base on the base
stand
1. Align the grooves of the base stand with the
charging base.
2. Slide the base stand up to secure it.
To unmount the base stand
Simply slide the base stand down and lift it
from the charging base.
Charging base installation
The telephone comes ready for desktop use.
1. Install the charging base as shown below.
• Make sure the power adapter is
securely plugged into an outlet not
controlled by a wall switch.
• The battery is fully charged after 11
hours of continuous charging. For
best performance, keep the cordless
handset in the charging base when not
in use.
2. Press on the handset. Listen for a dial
tone, and then press again to hang up.
CAUTIONS
Use only the supplied power adapter.
The supplied power adapter is not designed
for use in any other IT devices. Misusing it
on your other IT devices shall be prohibited.
To order a replacement, contact authorized
service personnel, your seller, or Snom.

EN - 16
Set up
SIP Cordless 1-line Hotel Telephone - HD351
SIP Cordless 1-line Wi-Fi Enabled Hotel Telephone - HD351W
Default settings are indicated by asterisks (*).
Setting Options Adjustable by
Listening volume- Handset 1, 2, 3, 4*, 5, 6 User and administrator
Speakerphone volume - Handset 1, 2, 3, 4*, 5, 6 User and administrator
Speakerphone volume - telephone base 1, 2, 3, 4, 5*, 6, 7, 8, 9 User and administrator
Ringer volume - telephone base 1, 2, 3, 4, 5*, 6, 7, 8, 9 User and administrator
Ringer tone Tone 1*, Tone 2, Tone 3 Administrator only
All telephone settings are programmed through the administrative web portal.
Please refer to the SIP Phone Configuration Guide for details.

EN - 17
Voice Menu
The Voice menu enables you to use the handset to query and change telephone settings.
To access the Voice Menu:
1. When the telephone is idle, press this key sequence on the handset: TALK Û Û Û
Û.
A digitized voice on the handset will announce Voice Menu options.
2. Press the number key on the handset to select the desired menu option, or enter
information.
A list of menu options is shown in the diagram below.
For example, to find out the IP address of the telephone, press 1for Network Configuration,
then press 2for IP Address.
3. When you are finished with the Voice menu, press OFF on the handset or place it in the
cradle.
NOTE: if you changed any network settings, your telephone will automatically reboot. This
will enable your new settings to take effect.
7
ware
Version
3
Factory Reset
1 Reset
Speed Dial to
Default*
2 Clear All
Speed Dial*
5
Reboot
* requires password
(default 1234)
1
Network
Configur on
2
IP Address*
3
Subnet Mask*
1
WAN Port Type
4
Gateway*
1 DHCP*
2 Sta c IP*
5
DNS*
6
WiFi Status**
7
WiFi Network**
1 Enable**
2 Disable**
2
Phone
Configur on
1
Phone Number
2
Server IP
Address
4
Call Forward
3
Port
4
Edit Speed Dial*
6
Web Access
Portal
1 Enable
2 Disable
** Only applicable to
Wi-Fi enabled model HD351W

EN - 18
Operation
SIP Cordless 1-line Hotel Telephone -
HD351
SIP Cordless 1-line Wi-Fi Enabled
Hotel Telephone - HD351W
Cordless 1-line Handset and Charging
base - HD3
Using the cordless handset and the
telephone base
The cordless handset and the telephone
base speakerphone cannot be used at the
same time on a call. However, calls can be
switched between the cordless handset and
the telephone base speakerphone.
Receive a call
When there is an incoming call, the telephone
rings and the message waiting LED flashes on
the telephone base.
Answer a call using the cordless handset
while it is not on the telephone base or
charging base
On the cordless handset, press or .
• The key illuminates when in use.
The key illuminates when in
speakerphone mode.
Answer a call using the cordless handset
while it is cradled on the telephone base
or charging base
Lift the cordless handset from the telephone
base or charging base.
• The key illuminates when in use.
The key illuminates when in
speakerphone mode.
Answer a call using the telephone base
On the telephone base, press .
• The key illuminates when in use.
Place a call
Place a call using the cordless handset
On the cordless handset, press or
. Listen for a dial tone and then dial the
desired number, or press a Speed Dial key on
the cordless handset to dial a programmed
number.
• The key illuminates when in use.
The key illuminates when in
speakerphone mode.
Place a call using the telephone base
On the telephone base, press . Listen for a
dial tone and then dial the desired number, or
press a Speed Dial key on the telephone base
to dial a programmed number.
• The key illuminates when in use.
End a call
End a call when using the cordless
handset
Press on the cordless handset or place it in
the telephone base or charging base. The call
ends when all handsets hang up.
End a call when using the telephone base
Press .
Switch a call between the cordless
handset and the telephone base
speakerphone
• To switch a call from the cordless handset
to the telephone base speakerphone,
press on the telephone base.
• To switch a call from the telephone base
speakerphone to the cordless handset
which is not on the telephone base
cradle, press or on the cordless
handset.
• To switch a call from the telephone base
speakerphone to the cordless handset
which is cradled on the telephone
base, lift the cordless handset from the
telephone base.

EN - 19
Share a call
A maximum of two cordless handsets can be
used at the same time on an external call.
Join a call
During a call, press or on another
cordless handset to join.
Handset speakerphone
During a call, press on the cordless handset
to switch between speakerphone mode and
handset earpiece mode. The key illuminates
when in speakerphone mode.
Volume
Listening volume can be adjusted on the
cordless handset and the telephone base.
Adjust the listening volume
• During a call on the handset, press
and to adjust the listening volume.
The next call returns to the default
listening volume.
• During a call on the telephone base,
press and to adjust the listening
volume. The next call returns to the
default listening volume.
Adjust the ringer volume of the telephone
base
Ringer volume of the telephone base can be
adjusted. When the telephone base is idle,
press and to adjust the ringer volume.
Call waiting
1. When you hear a call waiting tone during
a call, press on the cordless handset to
put the current call on hold and take the
new incoming call.
2. Press at any time to switch back and
forth between calls.
Mute
Mute the microphone
1. During a call, press MUTE / .
• The MUTE / key on the handset /
telephone base illuminates when the
mute function is turned on. You can hear
the party on the other end, but they
cannot hear you.
2. Press MUTE / again to resume the
conversation.
• The light on the key turns off.
Message waiting indicator
When a voice message is received, the
message waiting LED on the telephone base
flashes.
Play messages
Press MESSAGE / in idle mode to play
messages.
Hold
To place a call on hold:
During a call, press the HOLD / key.
To take the call off hold:
Press or on the handset, OR press on
the telephone base.

EN - 20
Appendix
Troubleshooting
If you have difficulty with the telephones, please try the suggestions below.
In case of malfunction, contact authorized service personnel, your seller, or Snom.
For cordless telephone
Question Suggestions
1. The telephone does not work at all.
• Make sure the Cat-5 network cable
is plugged into the LAN port of the
telephone base and the network wall
jack with Power over Ethernet (PoE).
• Make sure the battery is installed and
charged correctly. For optimum daily
performance, return the cordless handset
to the telephone base, charging base or
charging stand after use.
• Unplug the Cat-5 network cable from the
network wall jack. Wait for approximately
15 seconds, then plug it back in.
• Charge the battery in the cordless handset
for up to 16 hours.
• If the battery is completely depleted,
charge the battery for at least 30 minutes
before use.
• Remove the battery and then install it
again. If that still does not work, it may
be necessary to purchase a new battery.
• Disconnect the telephone base from the
network wall jack and connect a different
working SIP telephone. If the other SIP
telephone does not work, the problem is
probably in the wiring or network server.
Check your SIP server settings. Refer to
the SIP Phone Configuration Guide for
details.
• Make sure the energy-saving charging
mode is not activated. If this mode is
activated, all telephone functions will be
disabled, except battery charging.
