OPERATOR’S MANUAL
Model 24V-GS-CT Form No. SJ-24V-GS-CT-880E-M
CORDLESS GARDEN CHEMICAL SPRAYER
– TOOL ONLY
24-VOLT MAX* | 1 GAL
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Any electrical appliance can be dangerous if used incorrectly.
Some of the safety precautions given in this manual apply
generally to many appliances. Other warnings are specic to
the use of this cordless sprayer.
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in death or serious injury.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in death or serious injury.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory, or mental capabilities prevent them from
using it safely. Children should be supervised to ensure that
they do not play with the appliance.
Before starting up your machine, please check it carefully for
any defects. If you nd any, do not start up your machine.
Contact your authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
mWARNING! When using the cordless garden sprayer,
basic safety precautions should always be followed to reduce
the risk of re, electric shock, and personal injury. These
include:
• Know your garden sprayer. Read and understand the
operator’s manual and observe the warnings and instruction
labels axed to the tool.
• Do not operate the product in explosive atmospheres,
such as in the presence of ammable liquids, gases or
dust. Power tools create sparks which may ignite the dust
or fumes.
• Do not expose appliance to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
• Do not allow bystanders or children in the area while
operating this product. Exposure to some chemicals can
be hazardous.
• Use right appliance. Do not use appliance for any job
except that for which it is intended.
• This product is only suitable for outdoor use.
• Don’t force appliance. It will do the job better and with
less likelihood of a risk of injury at the rate for which it was
designed.
• Stay alert, watch what you are doing and use common
sense when operating this product. Do not use while
you are tired or under the inuence of drugs, alcohol or
medication. A moment of inattention while operating this
product may result in serious personal injury.
• Dress properly. Do not wear loose clothing or jewelry.
Contain long hair. Keep your hair, clothing, and gloves away
from moving parts. Loose clothes, jewelry, or long hair can
be caught in moving parts.
• Use safety equipment. Always wear eye protection with
side shields or goggles and a dust mask. Protect eyes, skin
and lungs against drifting spray and during mixing, lling,
and cleaning.
• Do not overreach. Keep proper footing and balance at all
times. Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
product in unexpected situations.
• Do not use the product if the switch does not turn it on
and o. Any product that cannot be controlled with the
switch is dangerous and must be repaired.
• Store idle appliances indoors. When not in use,
appliances should be stored indoors in dry, and high or
locked-up place - out of reach of children.
• Maintain appliance with care. Keep clean for best
performance and to reduce the risk of injury. Follow
instructions for changing accessories.
• Check damaged parts. Before further use of the
appliance, a guard or other part that is damaged should be
carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other condition that may aect its

2
operation. A guard or other part that is damaged should
be properly repaired or replaced by an authorized service
center unless indicated elsewhere in this manual.
• Keep the sprayer and its handle dry, clean and free
from oil and grease. Always use a clean cloth when
cleaning. Never use brake uids, gasoline, petroleum-
based products, or any strong solvents to clean your tool.
Following this rule will reduce the risk of loss of control and
deterioration of the enclosure plastic.
• Use this product in accordance with these instructions
and in the manner intended, taking into account the
working conditions and the work to be performed. Use
of the product for operations dierent from those intended
could result in a hazardous situation.
• Prevent unintentional starting. Ensure the switch is in the
o-position before connecting to battery pack, picking up
or carrying the appliance. Carrying the appliance with your
nger on the switch or energizing appliance that has the
switch on invites accidents.
mWARNING! Disconnect the battery pack from
the appliance before making any adjustments, changing
accessories, or storing appliance. Such preventive safety
measures reduce the risk of starting the appliance accidentally.
• Use the product only with specically designated
battery packs. Use of any other battery packs may create
a risk of injury and re.
• Have this product serviced by a qualied repair person
using only identical replacement parts. This will ensure
that the safety of the power tool is maintained.
•When servicing the product, use only identical
replacement parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or failure
to follow Maintenance instructions may create a risk of
shock or injury.
Specic Safety Rules for
Garden Sprayer
mDANGER! Risk of re or explosion. Do not spray
ammable liquids such as gasoline. Look for warning symbols
on the liquid container.
mWARNING! Some spray created from products used
with the sprayer contains chemicals that may cause harm to
health. Follow directions on containers of all such products.
To reduce your exposure to these chemicals, wear approved
safety equipment such as face masks that are specially
designed to lter out sprays, gloves, and other appropriate
protective equipment.
mCAUTION! When a ammable liquid is sprayed,
there may be danger of re or explosion, especially in a
closed room.
• Before using any pesticide or other spray materials in this
sprayer, read the label on its original container thoroughly
and follow its directions. Some spray materials are
dangerous and should not be used in this sprayer, as they
can damage the sprayer and cause serious bodily injury or
property damage.
• Electric shock hazard. Never spray toward electrical outlets.
• Do not use commercial grade chemicals or chemicals for
commercial or industrial purposes. Use only consumer
grade water-based lawn and garden chemicals.
• Do not pour hot or boiling liquids into the tank. These can
weaken or damage the hose or tank.
• Spray area must be well ventilated.
• Avoid spraying on windy days. Spray can be accidentally
blown onto plants or objects that should not be sprayed.
• Store the sprayer in a secure, well-ventilated indoor space
with the uid tank empty.
• Do not use caustic (alkali) self-heating or corrosive (acid)
liquids in this sprayer. These can corrode metal parts or
weaken the tank and hose.
• Know the contents of the chemical being sprayed. Read
all Material Safety Data Sheets (MSDS) and container
labels provided with the chemical. Follow the chemical
manufacturer’s safety instructions.
• Do not leave residue or spray material in the tank after
using the sprayer. Clean after each use.
• Do not smoke while using the sprayer, or spray where spark
or ame is present.
• Risk of injection. Do not discharge directly against skin.
• To reduce the risk of electric shock, do not put the sprayer
into water or other liquid. Do not place or store the sprayer
where it can fall or be pulled into a tub or sink.
• Maintain this product. Thoroughly inspect both the inside
and outside of the sprayer and examine the components
before each use. Check for cracked and deteriorated hoses,
leaks, clogged nozzles, and missing or damaged parts.
If damaged, have the product repaired before use. Many
accidents are caused by poorly maintained products.
• Disconnect the battery from the unit before draining,
cleaning, or storing the sprayer. Such preventive safety
measures reduce the risk of accidental starting.
• Always wear eye protection with side shields or goggles.
Failure to do so could result in uids entering your eyes
resulting in possible serious injury.
• Protect your lungs. Wear a face or dust mask when using
the sprayer. Following this rule will reduce the risk of serious
personal injury.
• Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition. Be
aware of possible hazards when not using your battery tool
or when changing accessories. Remove battery pack when
tool is not in use. Following this rule will reduce the risk of
electric shock, re, or serious personal injury.

3
• Store the product out of the reach of children and do
not allow persons unfamiliar with the product or these
instructions to operate the product.
Battery + Charger
Safety Instructions
NOTE: This unit is a tool, only. The battery and the charger are
not included. They must be purchased separately.
Model 24V-GS-CT is compatible with the 24V iON+ System
batteries and chargers. See page 16 for more information.
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only
be guaranteed if undamaged cells are used. Incorrect handling
of the battery pack can cause cell damage.
IMPORTANT! Analyses conrm that incorrect use and poor
care of high-performance batteries are the main factors
responsible for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the cordless garden sprayer and
cause it to malfunction, which can lead to serious personal
injury.
mWARNING! Do not use a battery pack or appliance that
is damaged or modied. Damaged or modied batteries may
exhibit unpredictable behavior resulting in re, explosion or risk
of injury.
Do not modify or attempt to repair the appliance or the battery
pack except as indicated in the instructions for use and care.
Have your battery pack serviced by a qualied repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.
mCAUTION! To reduce the risk of injury, charge the iON+
24V lithium-ion battery pack only in its designated iON+ 24V
lithium-ion charger. Other types of chargers present
risk of re, personal injury and damage. Do not wire a battery
pack to a power supply plug or car cigarette lighter. Such
misuse will permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the
battery pack in rain, snow or in damp or wet locations.
Do not use the battery pack or charger in the presence of
explosive atmospheres (gaseous fumes, dust or ammable
materials) because sparks may be generated when inserting
or removing the battery pack, which could lead to a re.
• Charge in a well-ventilated area – Do not block the
charger vents. Keep them clear to allow for proper
ventilation. Do not allow smoking or open ames near a
charging battery pack. Vented gases may explode.
NOTE: The safe temperature range for the battery is
41°F – 105ºF (5°C – 40.5°C). Do not charge the battery
outside in freezing weather; charge it at room temperature.
Charging improperly or at temperatures outside of the
specied range may damage the battery and increase the
risk of re.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly
wired extension cord poses a risk of re and electric shock.
If an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Check the rated input for the charger before using –
The charger must be plugged into an appropriate
receptacle.
• Use only recommended attachments – Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in risk of
re, electric shock or personal injury.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning
or maintenance. Do not allow water to ow into the charger.
Use a Ground Fault Circuit Interrupter (GFCI) to reduce shock
hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage. Toxic
fumes and materials are created when battery packs are
burned.
• Do not crush, drop or damage battery packs – Do not
use the battery pack or charger if they have sustained a
sharp blow, been dropped, run over or have been damaged
in any way (i.e. pierced with a nail, hit with a hammer,
stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, re or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.

4
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth.
If a damaged battery pack leaks battery chemicals, use
rubber or neoprene gloves to safely dispose of it. If skin
is exposed to battery uids, wash the aected area with
soap and water and rinse with vinegar. If eyes are exposed
to battery chemicals, immediately ush with water for 20
minutes and seek medical attention. Remove and dispose
of contaminated clothing.
• Do not short circuit – A battery pack will short circuit if
a metal object makes a connection between the positive
and negative contacts on the battery pack. Do not place a
battery pack near anything that may cause a short circuit,
such as paper clips, coins, keys, screws, nails and other
metallic objects. A short-circuited battery pack poses a risk
of re and severe personal injury.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105ºF (40.5ºC), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. Store the battery pack in a cool place, ideally at 77°F
(25°C) and charged to at least 40%.
2. Lithium-ion batteries are subject to a natural aging
process. The battery pack must be replaced at the latest
when its capacity falls to just 80% of its capacity when
new. Weakened cells in an aged battery pack are no
longer capable of meeting the high power requirements
needed for the proper operation of your garden sprayer,
and therefore pose a safety risk.
3. Do not throw battery packs into an open re as this poses
a risk of explosion.
4. Do not ignite the battery pack or expose it to re.
5. Do not exhaustively discharge batteries. Exhaustive
discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage
or non-use of partially discharged batteries. Stop working
as soon as the performance of the battery falls noticeably
or the electronic protection system triggers. Place the
battery pack in storage only after it has been fully charged.
6. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
7. Avoid damage and shocks. Immediately replace batteries
that have been dropped from a height of more than one
meter or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suered serious damage. In such instances, please read
the waste disposal information for proper battery disposal.
8. If the battery pack suers overloading and overheating,
the integrated protective cuto will switch o the
equipment for safety reasons.
IMPORTANT! Do not press the ON/OFF switch any more
if the protective cut-o has been activated. This may
damage the battery pack.
9. Use only original battery packs. The use of other batteries
poses a re risk and may result in injuries or an explosion.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger
to a power supply with the voltage marked on the rating
plate. Never connect it to a dierent mains voltage.
2. Protect the battery charger and its cord from damage.
Keep the charger and its cord away from heat, oil and
sharp edges. Have damaged cords repaired without delay
by a qualied technician at an authorized Snow Joe®+
Sun Joe®dealer or call the Snow Joe®+ Sun Joe®
customer service center at 1-866-SNOWJOE
(1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
grounded appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before recharging.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging
and cell damage. Do not leave batteries in the charger for
days on end.
8. Never use or charge batteries if you suspect that it has
been more than 12 months since the last time they were
charged. There is a high probability that the battery pack
has already suered dangerous damage (exhaustive
discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a re.
10. Do not use batteries that have been exposed to heat
during the charging process, as the battery cells may have
suered dangerous damage.
11. Do not use batteries that have suered curvature or
deformation during the charging process or those that
exhibit other atypical symptoms (gassing, hissing,
cracking, etc.).

5
12. Never fully discharge the battery pack (maximum
recommended depth of discharge is 80%). A complete
discharge of the battery pack will lead to premature aging
of the battery cells.
Protection from environmental inuences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and ammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Do not expose a battery pack or appliance
to re or excessive temperature. Exposure to re or
temperature above 265ºF (130°C) may cause explosion.
5. Do not keep the battery charger in places where the
temperature is liable to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads,
overcharging and exposure to direct sunlight will result
in overheating and cell damage. Never charge or work
with batteries that have been overheated – replace them
immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41ºF – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect
the battery pack, charger and cordless tool from humidity
and direct sunlight. Only place fully charged batteries in
storage (charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than 60
minutes must be discarded.
9. When handling batteries, be wary of electrostatic
charge. Electrostatic discharges can damage the
electronic protection system and the battery cells. Avoid
electrostatic charging and never touch the battery poles.

6
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
WARNING: Never direct adjustable
nozzle at persons, animals,
the unit or any other electric
components.
READ THE OPERATOR'S
MANUAL(S) – Read, understand,
and follow all instructions in the
user manual(s) before attempting
to assemble and operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
Symbols SymbolsDescriptions Descriptions
Store indoors. Indoor use only. Only use
battery charger indoors.
Wear safety gloves during use to
protect hands.
Wear safety footwear at all times to
provide protection against objects
that may accidentally fall on feet.
Wear mask for protection during
spraying.

7
Know Your Cordless Garden Chemical Sprayer
Read the owner’s manual and safety rules carefully before operating the garden chemical sprayer. Compare the illustration below
to the unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future
reference.
1. Adjustable nozzle
2. Telescoping wand
3. Telescoping lock
4. Spray wand
5. Trigger
6. Trigger gun
7. Trigger gun connection
8. Hose
9. Battery compartment
10. Motor housing
11. Tank latch (2)
12. Tank
14
56
8
9
7
10
11
12
14
13
15
16
23
13. Tank connection
14. Measuring cup
15. On/O switch
16. Handle + Trigger gun holder
SOLD SEPARATELY Battery + Charger options available at sunjoe.com
24VBAT-LTW 24VBAT
24VBAT-LTX 24VBAT-LTE 24VBAT-LT 24VBAT-XR 24VCHRG-QC 24VCHRG-DPC

8
Technical Data
Motor ................................................................................ 10 W
Battery Voltage Max* .................................................. 24V D.C.
Spray Pressure ............................................................ 72.5 PSI
Flow ..................................................... 20.3 oz/min (0.6 L/min)
Telescopic Spray Wand Length ................... 17.7 in. to 28.7 in.
(45 cm to 73 cm)
Tank Capacity ........................................................... 1 Gal (4 L)
Measuring Cup Capacity ................................... 4  oz (120 ml)
Hose Length ...................................................... 47 in. (120 cm)
Net Weight ............................................................ 4 lbs (1.8 kg)
*Initial no-load voltage, when fully charged, peaks at 24 volts; nominal voltage
under typical load is 21.6 volts.
Unpacking
Carton Contents
• Cordless garden sprayer with hose
• Spray wand assembly
• Manual with registration card
NOTE: In order to operate this cordless garden chemical
sprayer you will need 24V iON+ System batteries and chargers.
See page 16 for battery options and specications, or visit
sunjoe.com.
1. Carefully remove the cordless garden sprayer and check
to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
garden sprayer. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suocation risk!
mWARNING! Do not insert battery until assembly is
complete. Failure to comply could result in accidental starting
and possible serious personal injury.
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read o the
battery charge level from the LEDs of the battery indicator:
• All 3 level monitoring LEDs are lit: Battery charge level
is high.
• 2 level monitoring LEDs are lit: Battery charge level is
decreasing. Stop work as soon as possible.
• 1 level monitoring LED is lit: Battery is at. Stop work
IMMEDIATELY and charge the battery. Otherwise the
battery’s service life will be greatly shortened.
NOTE: If the charge level button does not appear to be
working, insert the charger and charge as needed.
NOTE: Immediately after using the battery pack, the charge
level button may display a lower charge than it will if checked
a few minutes later. The battery cells “recover” some of their
charge after resting.
In order to operate this cordless chemical garden sprayer
you will need an 24V iON+ System battery and charger. See
page 16 for battery and charger options and specications,
or for more information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Charge level button
The battery is at 30% capacity
and requires charging
The battery is at 60% capacity
and requires charging soon
The battery is at full capacity
Light IndicatorsLights

9
Charger Operation
mWARNING! Charge only iON+ 24V lithium-ion
battery packs with their compatible iON+ 24V lithium-ion
charger. Other types of batteries may cause personal injury
and damage. To reduce the risk of electric shock, do not allow
water to ow into the charger's AC/DC plug.
When to Charge the iON+ 24V
Lithium-iON Batteries
NOTE: The iON+ 24V lithium-ion battery packs do not develop
a "memory" when charged after only a partial discharge.
Therefore, it is not necessary to run down the battery pack
before inserting the charger plug.
• Use the battery charge indicator lights to determine when to
charge your iON+ 24V lithium-ion battery pack.
• You can "top-o" your battery pack's charge before starting
a big job or after a long day of use.
Charging the Battery
1. Push the push lock button on the battery to pull the
battery pack out from the battery compartment (Fig. 1).
2. Depending on your Snow Joe®+ Sun Joe®charger
model, how to recharge your lithium-ion battery will vary.
You may either insert your 24-volt battery into the
24VCHRG-QC Quick Charger (sold separately) or the
24VCHRG-DPC Dual Port Charger (sold separately)
(Figs. 2 – 3).
3. The battery indicator LEDs will illuminate one by one
during the charging process. Unplug the charger
immediately when the 3 LEDs are all illuminated.
4. The 24VCHRG-QC Quick Charger (sold separately) and
the 24VCHRG-DPC Dual Port Charger (sold separately)
are also equipped with additional charging indicating
lights which will indicate the charging status (Figs. 2 – 3).
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from
the outlet rst, then disconnect the charger from the battery
In order to operate this cordless chemical garden sprayer
you will need an 24V iON+ System battery and charger. See
page 16 for battery and charger options and specications,
or for more information visit sunjoe.com.
TOOL ONLY
BATTERY + CHARGER SOLD SEPARATELY
Fig. 1
Push lock button
Fig. 2 Battery pack
24VCHRG-QC
quick charger
(Sold separately)
red
Charging
green
Fully
Charged
Fig. 3 Battery pack
24VCHRG-DPC
dual port charger
(Sold separately)
red
Charging
green
Fully
Charged

10
mWARNING! This charger does not automatically turn o
when the battery is fully charged. Please take care not to leave
the battery plugged into the charger. Switch o or unplug the
charger at the mains when charging is complete.
5. Timely recharging of the battery will help prolong the
battery's life. You must recharge the battery pack when
you notice a drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become
fully discharged as this will cause irreversible damage to
the battery.
6. When charging is complete, remove the battery from the
charger by pulling the push lock button and sliding the
battery backward to unlock it from the charger.
Assembly
mCAUTION! To prevent accidental starting that could
cause serious personal injury, always remove the battery pack
from the product when assembling parts.
1. Insert the water outlet end of the trigger gun into the end
of spray wand as show (Fig. 4), and thread to tighten.
2. Insert the trigger gun inlet end into the trigger gun
connection on the hose and thread to tighten securely
(Fig. 5). The sprayer is ready to use.
Operation
mWARNING! Do not allow familiarity with the product
to make you careless. Remember that a careless fraction of a
second is sucient to inict serious injury.
mCAUTION! Always wear eye protection during
operation. Failure to do so could result in uids entering your
eyes resulting in possible serious injury.
This garden sprayer is designed for use with most consumer
grade home and garden chemicals, such as insecticides,
fungicides, weed killers, and fertilizers. Follow instructions
below for proper operation of this unit.
mWARNING! The garden sprayer is intended for
household use only.
Filling the Tank
mWARNING! Always follow the chemical manufacturer’s
instructions printed on their product labelling for use, cleaning,
and storage. Clean thoroughly after each use, following
the instructions in the Maintenance section of this manual.
Chemicals should be stored out of the reach of children.
Failure to do so may result in serious personal injury.
Liquids to be sprayed must be as thin as water. Thicker liquids
will not spray properly. Follow the instruction below to ll the
tank with proper solution. You can also premix the solution and
pour it into the tank, using a funnel if needed.
mWARNING! If powder detergent is desired, make
sure to dissolve the powder in water completely to avoid any
clogging.
NOTE: If using a measuring container other than the cup, or if
using a funnel to ll the tank, be sure to thoroughly clean and
rinse these items after use. If premixing the spray solution,
rinse the container used for mixing.
1. Turn o the unit and remove the battery.
2. Unscrew the measuring cup and remove it from the tank
(Fig. 6).
Fig. 4
Trigger gun
Spray wand
Fig. 5
Trigger gun
Trigger gun connection
Hose
Fig. 6
Measuring
cup
Tank
