H-KING Glue-N-Go A380 PP Kit User manual

INSTRUCTION MANUAL

1

2
Packing List
Tools
1: PP A380 fuselage *1
2: Carbon tube 5mm *6
3: Carbon strip 5*1mm *4
4: Pull rod 1.2mm *4
5: Motor mount *1
6: 2mm Quick rod adjuster *4
7: Hinge *4
8: Hook and loop tape *1
9: M3 screws *4
1: 1.5mm allen wrench
2: Phillips screwdriver
3: Modelling knife
4: Wire cutters
5: Hot melt glue gun and
glue sticks
6: Foam-safe glue
7. Instant CA glue
(foam-safe)

3
Electronic Equipment
Motor：2212/2216 2200KV-2600KV*1
Prop：5×5 3 blades x 1 pc
ESC：40A x 1 pc
Servo：9 grams x 4 pcs
(one is a reversed servo)
Battery：1300-2200mah 3S 40-60C
Y cord: 2 pcs
30cm extension x 2 pcs
50cm extension * 1 pcs
Butt joint and hot glue the vertical fuselages together as shown.
(Recommended)

4
Notice don’t let glue flow into the carbon strip’s groove.
Hot glue the horizontal fuselages together as shown.

5
Glue the carbon strips onto the fuselage by using foam-safe CA glue.
Apply foam-safe glue on both sides of the fuselage, then wait for a while and
press both fuselage halves together.

6
Use a Xacto knife to cut a slot as shown.
Then glue the wing together by using hot glue.
Then glue the vertical fuselages together. Make sure the carbon strip are inserted
into the groove on both sides. Ensure the working table is flat and even. Then get
some heavy weights to put it on top of the fuselage until the glue is dry.

7
Then cut off the bulge as shown by using a knife.
Assemble the horizontal fuselage on wing by using hot glue. Align the motor hole.
Then wait for the glue to dry. Assemble the horizontal fuselage on wing using by
hot glue. Align the motor/prop cutout . Set it aside and let the glue to dry.
Assemble the vertical fuselage onto the horizontal fuselage by using hot glue.

8
Glue carbon tube on wing by using foam-safe glue as shown.
Then flip the plane over and put the plane on a work table. Install and glue the
carbon rod through the hole on the vertical fuselage as shown.

9
Assemble the horizontal tail onto the fuselage by using hot glue. Keep the vertical
straight and true.
Then glue the carbon tube on the horizontal tail (very similar to the wing installation).

10
Stick the carbon strips onto the vertical tail by using foam-safe glue.
Install motor on motor mount with 4 pcs M3 screws.
Glue the carbon tube onto the horizontal tail (very similar to the wing installation).

11
Assemble quick rod adjuster and install it onto the hinge. Apply some locktite glue
when all grub screws are tightened.
Install and glue the control horns onto the flying surfaces as shown.
Before we install all the electronic components onto the airframe, make sure the
servo arms are perpendicular to the servo case. This is to ensure that the servo
horns are travelled symmetrically in both directions. Notice: A reversed servo is
used for the horizontal tail.

12
Position the aileron servo and glue the servo into place as shown.
Install both control horns on the elevator by using the hot glue as shown.
Install the supplied push rods onto the push rod adjusters and trim it accordingly.

13
Position each of the elevator servo halfway(Note: one servo is in reversed rota-
tion) into the servo cutout. Once satisfied with the fit, hot glue the servo in place
as shown. Ensure the control surfaces are all levelled. Then install the push rod
onto the quick rod adjuster and lock it in place with the grub screws. Trim the
excess push rod accordingly.
Install the motor and prop onto the fuselage by using hot glue. Ensure the thrust
line is straight and level
Connect the elevator servo lead and the aileron servo lead by using some Y cord
extensions.

14
Install a receiver and an Esc onto the fuselage by using the supplied hook and
loop tape. Please tidy up all the servo leads by using some nylon cable ties to
prevent from the prop catching the servo leads.
Position the battery according to the C of G location. Once satisfied with the C of
G, mark the battery location on the fuselage and you may secure it on the fuse-
lage by using the supplied hook and loop tape.

15
Position the vertical tail to the fuselage, slide the carbon strip into the slot on the
fuselage and secure it by using hot glue. Ensure the vertical fin is perpendicular
to the wing and the stabiliser.
Install winglet on the wing tip by using hot glue

16
Fix aileron on wing and horizontal tail using foam glue. Notice : Don’t use fiber
tape or other kinds of tape. Foam glue is a good hinge for PP sheets.
C of G location is right at the red dot shown in the picture below.
