Soberlink sl2 User manual
!"#$%&'()*(&+"#,-&
'./&0#)1*)2&
/&
Camera
Blue status light/mouthpiece port
LCD screen
Power button
Display buttons
Power/Select button
Right display button
Left display button
Activation
Information
ID: 20000004
PIN: 7081
Checking...
93%
1. Press the Power button on the SL2
2. Go to www.soberlink.net and click on User Login to access your account
3. Once logged in, click the Enroll New Client button
4. On the SL2, select “Start” with the left display button
The device will display the Device ID and Security PIN and will begin checking for
activation on a monitoring portal.
5. On the Monitoring Web Portal, enter the Device ID and Security PIN, along
with the client’s name and time zone, and click Activate.
Once the Activation Information has been entered accurately and there is a
cellular connection, the SL2 will display a “Successfully Activated” message and
the Monitoring Web Portal will show a green checkmark, confirming that the
device is ready to submit a test.
The Device ID is also displayed on the bottom
of the device where the micro-USB port is
located.
U.S. Patent No. 8,381,573
210004BF
Device ID
'./&3$45)467&8*6$-99&
:&
&
Waiting for device response
Device is ready for use
DO
Use the SOBERLINK mouthpiece.
Hold the device at eye level.
Look directly into camera, with your eyes open.
Take a deep breath.
Deliver a firm, steady stream of air.
Wait 20 minutes after eating, drinking, or smoking.
DON’T
Wear sunglasses or hats.
Place fingers on the mouthpiece.
Obstruct the camera in any way.
Block the back air vent.
Use device in extreme temperatures
(operating temp is 32-122˚F).
;-9471&+"#,-<#7-9&
=&
Follow the prompts on the screen
Sending A Test
Client Options
Edit Client Name and/
or Time Zone
Device
Edit Device ID and/or
Security PIN
Administration
Stop Monitoring Client
or Delete Client
Schedule Tests
Create client’s
test schedule
Text Reminders
Enable client text
reminders
Violation Alerts
Assign a contact
to be alerted via
text/email upon
client violation
Client Notes
Add general notes
regarding client
Test Notes
View all test notes
Reporting Options
Pull various reports
based on date
range, client, folder,
or contact
Personal Info
Edit client’s profile
including address
and personal
details.
><#-7(&;66<?)*&
@&
A62-&8)1-&
• The Home Page displays all clients currently being monitored and allows for the addition
of new clients. Each test can be clicked on to open a Test Detail page where the Master
Photo can be set.
Reminder text 15 min before the
scheduled testing window
Reminder text
Notification of retesting requirement
• Enable Schedule will send text reminders to the client’s mobile number at the scheduled test times (shown at
right). Upon first entry of a cell number, the client will receive an opt-in text message and must reply with
“SUBSCRIBE”.
• Enable Retesting will prompt client to retest every 30 min if a test of .02 or higher is submitted (until BAC is below .
02 or 3 hours has elapsed). Lower BAC threshold available upon request.
• Variable Testing Windows allow the testing window to be set for 30 minute, 1 hour, 2 hour, 3 hour or 4 hour
durations. To set the test variable window select the preferred duration from the dropdown. Once a testing
window is set, the duration will apply to all tests for that particular client. The schedule will not allow double
booking of tests.
• The On Demand Test button will immediately initiate a test window with reminders. The On Demand Test will
always be scheduled as a 30 minute testing window. It is not affected by the selected variable testing window.
Missed notification
When retest is required
><#-7(&;66<?)*&B&'$C-,"<-&D"E67& A62-&F&'-<-$(-,&><#-7(&F&'$C-,"<-&
G&
Click the
hour to
schedule
or remove
tests for
the week
Note: Changes to the portal require 30 min to take effect
3"(62)(-,&;-H(&I-99)1-9&
&'-7(&(6&J9-*&
• The Alerts Page allows a contact to sign up for Real-time text or email Alerts based on
certain triggering events, and/or sign up to be emailed Automated Reports summarizing
all their clients’ activity.
• Upon first entry of a cell number or email address, the contact will receive an opt-in
request via text or email and must respond accordingly in order to receive the Alerts.
K&
><#-7(&;66<?)*&B&3<-*(9&D"E67& A62-&F&'-<-$(-,&><#-7(&F&3<-*(9&
SOBERLINK POSITIVE TEST ALERT
Client Name: Laura Riley
Received: 5/20/2013 9:25pm PDT
BAC Level: .052
Status: Positive
NOTE: Laura Riley has submitted a test with a BAC of .052. If retesting is enabled
for this client, they have been prompted to retest.
SOBERLINK LATE POSITIVE TEST ALERT
Client Name: Laura Riley
Received: 5/21/2013 7:49pm PDT
BAC Level: .069
Status: Positive
NOTE: Laura Riley has submitted a test with a BAC of .069 after missing the
scheduled test time. Received 5/21/2013. If retesting is enabled for this
client, they have been prompted to retest.
SOBERLINK COMPLIANT SECONDARY TEST RECEIVED
Client Name: Laura Riley
Received: 5/20/2013 9:55pm PDT
BAC Level: .006
Status: Retest Cancelled
NOTE: Laura Riley has submitted a compliant secondary test. The retest cycle
has been cancelled. Received 5/20/2013 9:55pm PDT.
SOBERLINK LATE TEST ALERT
Client Name: Laura Riley
Scheduled: 5/20/2013 2:00pm PDT
Status: Late
NOTE: Laura Riley has submitted a compliant test after missing the scheduled
test time.
If retest is compliant, the contacts will be notified with a “Compliant Retest” alert
DEFINITIONS
Missed
Late
Positive
Compliant Secondary
A scheduled test that is not received within the test window.
A test that is received after a missed test, but before the next scheduled test.
A test result of .02 BAC or higher, which will initiate a retest cycle
(if retesting is enabled).
The first test result below .02 BAC that follows a positive test and is within
the secondary test window.
3<-*(9&'-7(&(6&>67()$(9& A62-&F&'-<-$(-,&><#-7(&F&3<-*(9&
L&
Connectivity and Declined Photo Alerts are not shown.
• Selecting a client and choosing Report allows the user to download various reporting options based on a date
range and including or excluding test notes. The Reports can also be accessed from the top toolbar.
• The report types are as follows:
Client Detail Report - shows a test by test list of testing history for one client
Consolidated Report - shows a summary of testing history for one client, including total positive/missed/late, etc.
Digest Report - shows a summary of testing history for multiple clients
Automated Reports - goes to a client’s Alerts page where the User can sign up for a summary report to be regularly
emailed on a daily, weekly, or monthly basis, that can be filtered for All Clients or Non-Compliant Clients only.
><#-7(&;66<?)*&B&M-N6*(9&D"E67& A62-&F&'-<-$(-,&><#-7(&F&M-N6*(9&
O&
1. Archive Client
Log on to your account and choose Edit
under the client who has finished using SOBERLINK.
Click the Stop Monitoring button. This will move the client,
along with all client’s tests, to the Archive Section and
will “release” the Device to be activated
under a new client’s name.
2. Reset SL2
To reset the SL2 to factory settings, press both buttons
simultaneously to display the Menu Options screen, then
follow the instructions below:
Scroll down to highlight Reset Device
Click power button
Click left display button
Click right display button
Click power button
Once reset, the “Device Requires Activation” screen will appear.
The SL2 is now ready to be put back into inventory or assigned to
a new client, as shown in step 3 below.
3. Reassign SL2
To give the SL2 to a new client, click Start to receive the Device ID and
Security PIN. From www.soberlink.net log on to the account where the
new client will be monitored. Once logged into the desired account, click
Enroll New Client, enter the client’s name, select the time zone and
folder where the client will be added and enter the Device ID and Security
PIN from the SL2 screen.
Device Requires
Activation
START CANCEL
93%
Stop
Monitoring
M-9(6*#71&'./&(6&P)$(6*Q&'-R719&
PREV NEXT
New Design
Old Design
Menu Options
to select
Test history
Air blank test
Check for updates
Reset Device
ST&
'./&'N-$#U$)4679&
SS&
