MDD BACtrack S35 User manual

TABLE OF CONTENTS INTRODUCTION
This device is intended to measure alcohol in
human breath. Measurements obtained by this
device are used in the diagnosis of alcohol
intoxication.
Introduction ..................................................... 2
Dose-specific Effects of Alcohol...................... 5
Sensor Cleansing ............................................. 7
Preparation ...................................................... 7
Components Diagram ..................................... 8
Operation ......................................................... 9
Specifications.................................................. 12
Precautions..................................................... 13
Verification and Calibration.......................... 14
One-Year Limited Warranty.......................... 15
Track your B.A.C. – BACTRACK!
The BACtrack®Alcohol Detector is an alcohol screening
device, used for the detection of alcohol in the breath.
The BACtrack provides a digital result, indicating the
approximate BAC (Blood Alcohol Content) of the test
subject. The BACtrack is powered by two AAA batteries
and is very easy to use. Simply turn on the unit and begin
testing in a matter of seconds. However, before you begin
testing, there are a few things you should know. Please take
a moment to read your owner’s manual in its entirety and
familiarize yourself with the BACtrack.
Alcohol and Its Effects on the Human Body
Alcohol is absorbed from the mouth, throat, stomach
and intestines into the bloodstream.
Alcohol ingested by the human body can be detected
in the breath because of its presence in the bloodstream.
Alcohol cannot be digested, and it cannot be chemically
changed in the bloodstream. As the blood flows through
the lungs, alcohol in the bloodstream moves across the
membranes of the lung’s air sacs (alveoli) into the
air. The concentration of the alcohol in the alveolar air
is directly related to the concentration of the alcohol in the
2
1

blood. As the alveolar air is exhaled, the alcohol in it can
be detected by the breath alcohol testing device.The alcohol
concentration in the breath is related to that in the blood, and
because of this, an individual’s BAC can be determined by
measuring alcohol in the breath. The ratio of breath alcohol to
blood alcohol is generally estimated to be 2,100:1. Therefore,
2,100 milliliters (ml) of alveolar air will contain approximately
the same amount of alcohol as 1 ml of blood.
Alcohol is a Drug
Alcohol is the chemical (ethanol or ethyl alcohol) resulting
from the fermentation of grapes or grain. Alcohol is absorbed
directly into your bloodstream. From your bloodstream, the
fluids in your body tissues absorb the alcohol. Your brain is
made up of a large concentration of fluids and will absorb a
large amount of any alcohol you drink. Your liver eliminates
the absorbed alcohol at its own rate of time and nothing you
eat or drink can speed up the process. Your liver does this
by oxidizing the alcohol (converting it into water and carbon
dioxide). Coffee, food or any other “cure” will not sober you
up. Only time will do that.
How does alcohol affect my body?
Alcohol is a depressant. It has a relaxing effect on the
muscles in your body. The muscles of your eyes relax and
lose focus. Your eyesight will become fuzzy and you may
experience double vision. Brain activity is slowed. Your
judgment, reflexes, and coordination are all negatively
affected.Some vision impairments that occur when you have
been drinking include:
• Narrowing of your eld of vision
• Reduction in your depth perception
• Decreased ability to see in darkness
• Increased sensitivity to glare and a longer time
for your eyes to readjust from the glare
Some mental (brain) impairment can occur when you have
been drinking, including:
• Reduced awareness of danger
• Becoming overly condent and reckless
• Difculty in making decisions
• Reduction in balance
• Slowed reexes
• Impaired judgment
How does alcohol affect my driving?
We can’t emphasize enough how dangerous it is for you
to drink and drive. Your vision and your brain are the
most important factors in driving safely. If you jeopardize
either by drinking, and then you drive, you are likely to be
involved in a serious or fatal collision.
34

DOSE-SPECIFIC EFFECTS OF ALCOHOL
*
Dose-Specific Effects
Slight euphoria. Loss of shyness. Depressant
effects are not apparent. Impairment possible
in some individuals.
Feeling of well-being, relaxation, lower
inhibitions and sensation of warmth. Euphoria.
Some minor impairment of reasoning and
memory. Lowering of caution. Driving skills may
be impaired at this level of intoxication.
Slight impairment of balance, speech, vision,
reaction time, and hearing. Euphoria. Judgment
and self-control are reduced. Caution, reason and
memory are impaired. Driving skills are always
impaired at this level of intoxication and higher.
Signicant impairment of motor coordination
and loss of good judgment. Speech may be
slurred. Balance, vision, reaction time and
hearing will be impaired. Euphoria.
Dose-Specific Effects
Gross motor impairment and lack of physical
control. Blurred vision and major loss of
balance. Euphoria is reduced and dysphoria
(anxiety, restlessness) is beginning to appear.
Dysphoria predominates. Nausea may appear.
Needs assistance in walking. Total mental
confusion. Dysphoria with nausea and
some vomiting.
Loss of consciousness.
Onset of coma. Possible death due to
respiratory arrest.**
BAC
0.02 - 0.03%
0.04 - 0.06%
0.07 - 0.09%
0.10 - 0.12%
BAC
0.13 - 0.15%
0.16 - 0.20%
0.25%
0.30%
0.40% and up
From California Department of Motor Vehicles (http://www.dmv.ca.gov)1Bailey,
William J., Drug Use in American Society, 3rd ed., Minneapolis: Burgess, 1993
*The effects of alcohol intoxication are greatly influenced by individual variations among
users. Some users will be intoxicated at a much lower BAC than shown above.
**Death can occur at a lower BAC in some individuals.
The generally accepted legal standard for alcohol intoxication in the United
States is 0.08%. However, your driving skills can be impaired at a level of
0.04% or lower. It is never safe to drink any amount of alcohol and drive.
5 6

SENSOR CLEANSING
When the breathalyzer is used for the rst time, or if the
unit has not been used for an extended period of time
(3 weeks or more) air borne pollutants may form on the
sensor surface. To maximize accuracy, clean the sensor by
performing 2 tests, allowing it to run a complete cycle each
time, and disregard the results. Whether or not alcohol is
present on the breath for the sensor cleaning doesn’t matter.
After running through the complete testing process twice,
cleansing is complete, and you can test again normally.
PREPARATION
Installing the Batteries
Install two Alkaline AAA batteries in the battery compartment.
COMPONENTS DIAGRAM
78
Front View
Detachable
Mouth Piece
Power
Button
Battery CoverŁ
(back)
Display

OPERATION
Test subjects should wait 20 minutes after eating, drinking,
or smoking before blowing into the BACtrack Breathalyzer.
Failure to wait 20 minutes can provide inaccurate test results
and damage the sensor.
STEP 1: Attach a mouthpiece to the
breathalyzer. It protects the sensor from
droplets from the mouth, which could
damage it. The mouthpiece also ensures
a consistent blowing pressure, therefore
contributing to a more accurate reading.
910
STEP 2: Press the start button.
The BACtrack will begin a countdown.
STEP 3: When the countdown
approaches 2, begin to inhale a
deep breath.
STEP 4: When the countdown reaches
zero, blow and a line will appear on the
screen. Blow through the mouthpiece
continuously for ve seconds while the
beeps sounds and then stops.
STEP 5: Once the sensor has analyzed
the breath sample, the estimated BAC
value is displayed. NOTE: For most
accurate results, wait one minute between
tests. When testing high alcohol levels,
wait 3-5 minutes between tests.

SPECIFICATIONS
Dimensions 1.45 x 0.55 x 2.44 inches
(3.7 x 1.4 x 6.2 cm)
Weight 2 oz. (56 grams)
Sensor Technology Advanced Semiconductor
Detection Range 0.00 - 0.40 %BAC
Power Supply Two AAA Alkaline Batteries - not included
Battery Life 100 - 150 tests
Warm Up Time 11 - 13 seconds
Response Time 5 seconds
Operating
Temperature
50 - 104 degrees Fahrenheit
(10 - 40 Celsius)
Display shows ‘FL’
The FL notication can appear in three cases:
• The user did not blow continuously for
ve seconds.
• The user may still have alcohol in
their saliva, and the measured alcohol
concentration is uneven. Users should wait
20 minutes after their last drink to make
sure alcohol in the mouth is fully absorbed
and a proper breath sample can be taken.
• The user may have blown too hard.
Try again with a more moderate and
consistent blow.
Display shows ‘H’
Reading exceeds upper limit of .40% BAC.
Make sure user has waited 20 minutes after
consuming alcohol before blowing.
Display shows ‘Er’
The sensor is damaged. Contact support
for assistance.
11 12
Error Notifications
DISPLAYS
Display shows ‘Lo’
When low battery icon appears, replace with
new AAA Alkaline batteries.
Display shows ‘0.00’
If an attempt at the breath sample is detected,
but not completed, the unit will display .00
and then power off.

1. Wait at least 20 minutes after drinking, eating or smoking
before testing. Not observing this waiting period can
cause inaccurate readings and damage the sensor.
2. Do not blow smoke, food, or liquids into the BACtrack
as this will damage the sensor.
3. Do not test in areas with strong winds, smoke, or in an
area where a large amount of alcohol is being consumed.
4. Send your tester in for periodic calibration service as
required.(See calibration).
5. The BACtrack Breathalyzer is designed to be used in a
temperature range of 50-104 degrees F (10-40 degrees C).
6. Avoid testing in the presence of any substances that
contain methyl alcohol, isopropyl alcohol or acetone.
These substances may interfere with the results of the test.
7. You cannot use the results of this product in court.
8. Do not use the BACtrack as a tool to determine whether
you should operate a motor vehicle or equipment, or
perform any other dangerous act.
9. Do not drink and drive. Always have a designated
driver when alcohol is being consumed.
PRECAUTIONS VERIFICATION AND CALIBRATION
13 14
The BACtrack is calibrated during manufacture using advanced
alcohol simulation equipment. Known alcohol concentrations
are passed through the sensor to set baseline values for testing.
During testing, the unit compares users’ breath samples to these
baseline values.
The accuracy of breath alcohol testers can fluctuate after six
to twelve months of normal use, depending on the number of
tests performed and operating conditions.
If this product is providing inconsistent test results, is not
providing any test results, or provides unusually high or low test
results, the product should be recalibrated immediately by a
trained professional.
The product should be recalibrated at least every six to twelve
months. If the product is used every day, it may need to be
recalibrated as frequently as every month.
Calibration Instructions
Please visit www.bactrack.com or call 415-693-9756 for
information on how to get your BACtrack Breathalyzer
recalibrated.
During recalibration, a professional technician will reset the
sensor baseline values and also perform a full diagnostic check
to ensure the accuracy and reliability of the product.

KHN Solutions’ warranty obligations for this product are limited to
the following:
KHN Solutions warrants this product against defects in materials
and workmanship under normal use for a period of ONE (1) YEAR
from the date of retail purchase by the original end-user purchaser
(“Warranty Period”). Except as provided in the preceding sentence
or applicable law, KHN Solutions provides this product “as is”. If a
defect arises and a valid claim is received by KHN Solutions within
the Warranty Period, at its option, KHN Solutions will either (1)
repair the product, (2) exchange the product with a product that is
new or which has been manufactured from new or serviceable used
parts and is at least functionally equivalent to the original product, or
(3) refund the purchase price of the product. When a refund is given,
the product for which the refund is provided must be returned to KHN
Solutions and becomes KHN Solutions’ property. This warranty is
limited to the original end-user purchaser and is not transferable to,
or enforceable by, any subsequent owner.
Exclusions, Limitations, and Disclaimers
KHN Solutions makes no warranties, express or implied, as to the
ability of this product to determine whether, or the extent to which,
a test subject’s mental or physical functioning, or judgment, may
be impaired by blood alcohol including whether the test subject
is intoxicated under any denition of that word. KHN Solutions
expressly disclaims any liability for direct, indirect, incidental,
special, orconsequential damages of any nature under any legal
theory.
ONE-YEAR LIMITED WARRANTY
15 16
Any act or failure to act based on a reading from this product
shall be at the test subject’s or user’s own risk. KHN Solutions
assumes no responsibility for consequences to or of test subjects
who use this product and later are shown to have been under the
influence of alcohol or to have had their judgment or any mental or
bodily function impaired by alcohol. Correlation between breath
alcohol content and blood alcohol concentration depends on many
variables, including environmental factors (such as air quality, wind,
humidity, temperature, etc.) and health conditions of the test subject.
A low BAC reading does not mean that the test subject’s physical
or mental performance or judgment (including reaction times) can
respond to an emergency. The concentration of alcohol in the blood
of a test subject cannot be exactly determined by using a breath
alcohol screening product.
KHN Solutions does not warrant that the operation of the product will
be error-free. KHN Solutions is not responsible for any consequences
arising from failure to follow instructions or relating to the product’s
use. This warranty does not apply: (a) to consequences caused
by accident, abuse, tampering, misuse, ood, re, earthquake or
other external causes; (b) to consequences caused by operating
the product outside the permitted or intended uses described by
KHN Solutions; (c) to consequences caused by service performed
by anyone who is not a representative of KHN Solutions or a KHN
Solutions Authorized Service Provider; or (d) to a product or part
that has been modied to alter functionality or capability without the
written permission of KHN Solutions.
TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY AND
THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDI-
TIONS, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR

IMPLIED. AS PERMITTED BY APPLICABLE LAW, KHN SOLUTIONS
SPECIFICALLY DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
AND WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. IF
KHN SOLUTIONS CANNOT LAWFULLY DISCLAIM STATUTORY OR
IMPLIED WARRANTIES THEN TO THE EXTENT PERMITTED BY LAW,
ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE
DURATION OF THE EXPRESS WARRANTY AND TO THE REPAIR OR
REPLACEMENT SERVICE AS DETERMINED BY KHN SOLUTIONS IN
ITS SOLE DISCRETION.
No KHN Solutions reseller, agent, or employee is authorized to make
any modication, extension, or addition to this warranty.
If any term is held to be illegal or unenforceable, the legality
or enforceability of the remaining terms shall not be affected
or impaired.
EXCEPT AS PROVIDED IN THIS WARRANTY AND TO THE MAXIMUM
EXTENT PERMITTED BY LAW, KHN SOLUTIONS IS
NOT RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES UNDER ANY LEGAL THEORY,
INCLUDING BUT NOT LIMITED TO LOSS OF USE; LOSS OF
REVENUE OR INCOME; LOSS OF ACTUAL OR ANTICIPATED
PROFITS (INCLUDING LOSS OF PROFITS FROM A CONTRACT);
LOSS OF THE USE OF MONEY; LOSS OF ANTICIPATED SAVINGS;
LOSS OF BUSINESS; LOSS OF OPPORTUNITY; LOSS OF GOODWILL,
OR LOSS OF REPUTATION.
This Breath Alcohol Tester is intended to measure alcohol in human
breath. Readings obtained by this device are used in the diagnosis of
alcohol intoxication. The accuracy of this device has been established
at a Blood Alcohol Concentration of 0.008 and 0.032. Accuracy
at a Blood Alcohol Concentration greater than .032 has not been
established.
Some countries, states and provinces do not allow the exclusion or
limitation of incidental or consequential damages or allow limitations
on how long an implied warranty or condition may last, so the above
limitations or exclusions may not apply to you. This warranty gives you
specic legal rights, and you may also have other rights that vary by
country, state or province. This Limited Warranty is governed by and
construed under the laws of the country in which the product purchase
took place.
Obtaining Warranty Service
Please be sure to read this instruction manual carefully if you believe
your product is not operating properly. If you still feel that your product
requires warranty service, please follow these instructions:
Obtain a Return Authorization (RA) number by calling toll-free
877-334-6876 or by emailing [email protected].
When shipping the product back to KHN Solutions, please package
the product carefully and ship using a major carrier (UPS, FedEx, USPS,
etc). To ensure proper credit for a
returned item, be sure to obtain a delivery conrmation on the return
shipment. The customer is responsible for all return shipping charges.
Include the following information with your returned product:
• Your Return Authorization number
• Name, address, and phone number as stated at the time
of order
• A copy of your original sales receipt
17 18
