WattWheels OMNIA User manual

WATTWHEELS LTD
1
OMNIA E-BIKE MANUAL

WATTWHEELS LTD
2
CONTENTS:
INTRODUCTION PAGE 3
INSTALLATION PAGE 4
LCD DISPLAY PAGE 5-7
BRAKES, TYRES, GATES BELT DRIVE, NEXUS HUB PAGE 9
RANGE PAGE 10
RIDER SEAT HEIGHT & COMFORT PAGE 11
BATTERY & CHARGING PAGE 12 - 13
USEFUL TIPS PAGE 14
PARKING STORAGE & TRANSPORT PAGE 15
SAFETY CHECKS & BASIC TROUBLESHOOTING PAGE 16-17
ERROR CODES PAGE 18
SERVICING PAGE 19
WARRANTY INFORMATION PAGE 20-22

WATTWHEELS LTD
3
WELCOME
First off, welcome to the Wattwheels family! We’re so happy to have you on board! You have picked a great model and, in this manual, we’re going to
break down the basics to make sure that your bike remains in top shape and performs to the highest standard.
You’re about to experience the ride of your life. To get you out and having fun as quickly and as safely as possible please read entire the manual
carefully, paying close attention to the safety section.
Also, we highly recommend familiarizing yourself with local regulations for e-bikes and the components of the model that you have before your first
ride.
Please also ensure that the bike is regularly serviced as per the instructions outlined later in this document. Failure to get the bike serviced can result
warranty claims being void if they are required. A bike is a vehicle, and like a car needs to be serviced regularly. See our instructional video located in
the video section of our website to learn the basics before having your first ride
PLEASE KEEP A NOTE OF THE BIKE SERIAL NUMBER LOCATED ON THE FRONT HEAD TUBE (UNDER THE LOGO) WRITE THIS ON YOUR INVOICE
Wattwheels assumes that all persons involved in using, repairing, maintaining, cleaning, or disposing of this or any Wattwheels product must have
fully read and understood the content and meaning of these operating instructions.
Additionally, Wattwheels claims no responsibility for any injury or damage resulting in improper use of any electric bike.
USING THIS MANUAL
This manual contains details of the electric bike, its equipment, and information on its operation and maintenance. Read it carefully and familiarize
yourself with the Omnia before using it to ensure safe use and prevent accidents. This manual contains many warnings and cautions concerning the
safe operation and consequences if safe setup, operation, and maintenance are not performed. All information in this manual should be carefully
reviewed and if you have any questions, you should contact your local retailer immediately.

WATTWHEELS LTD
4
Because it is impossible to anticipate every situation or condition which can occur while riding, this manual makes no representations about the safe
use of bicycles under all conditions. There are risks associated with the use of any bicycle which cannot be predicted or avoided, and which are the
sole responsibility of the rider. You should save this manual, along with any other documents that were included with your bicycle, for future
reference, however all content in this manual is subject to change or withdrawal without notice. Visit www.wattwheels.co.nz to download the latest
version. Wattwheels makes every effort to ensure accuracy of its documentation and assumes no responsibility of liability if any errors or inaccuracies
appear within.
INSTALLATION IF REQUIRED:
1. COMPLETLEY CHARGE THE BATTERY BEFORE THE FIRST USE
(Red light is on when battery is charging, green when fully charged. Approx. time is around 4-5 hours)
2. ATTACH THE HANDLEBARS
3. ATTACH THE PEDALS
(Beware: The left-hand pedal has a reverse thread. To tighten, please turn anti-clockwise, right-hand pedal is clockwise))
4. GREASE THE SEAT TUBE THEN INSERT THE SEAT POST
6. INSERT THE FRONT WHEEL AND TIGHTEN WHEEL NUTS WITH A 15mm SPANNER
(PLEASE BE CAREFUL NOT TO PRESS THE BRAKE LEVERS WHILE THE WHEELS ARE NOT INSTALLED. DOING SO WILL RESULT IN THE BRAKES PADS
CLAMPING TOGETHER, AND YOU WILL NOT BE ABLE TO INSERT THE FRONT WHEEL RESETTING THE BRAKE PISTONS IN WHICH YOU WILL NEED A BIKE
SHOP TO PERFORM)
7. CHECK ALL SCREWS AND BOLTS ARE TIGHT, SEAT POST THE CORRECT HEIGHT AND BRAKES WORKING PROPERLY

WATTWHEELS LTD
5
LCD DISPLAY
The image shows the various features and information displayed on the LCD display. The display is controlled using the buttons remote located on
the display.

WATTWHEELS LTD
6
TRIP/ODO & TIME
To toggle between the various modes short press the M key to switch between them.
BATTERY DISPLAY CAPCITY
The LCD readout on the handlebar of your Omnia features a battery capacity gauge (much like the fuel gauge on a car). It is recommended that users
stop operating the bike on electric once the indicator starts flashing on the last bar and recharge. Remember you can still ride without using the
motor or display.
PAS (Pedal Assist Modes)
Pedal assist modes (shown at the top of your display) start from 1 and goes up to 3. PAS level 1 is the first pedal assist level and will give you some
slight assistance. Press the up and down arrows on the control panel to toggle between the levels. As you select the higher levels, the assistance will
increase with level 3 basically doing all the work for you. Using higher levels of PAS will drain the battery faster. The recommended level is PAS 1-2 to
ensure good battery life. Note- PAS 0 means no assistance from the motor and you would have this on if you wanted to ride without assistance but
measure distance/speed etc.
If the bike is stationary for a period of 5 minutes or longer without any movement it will automatically turn off. These are safety features employed on the bike.
If transporting the bike on the back of a vehicle, please ensure the display is covered with a waterproof cover. Although they are designed to be ridden in wet
conditions traveling at high speeds in wet weather can cause water to get past the display seals.

WATTWHEELS LTD
7
WALK MODE
To activate the walk mode, hold down the key for two seconds. This will propel the bike forward at around 6km/h. This can be used if you need to
walk the bike up a hill and need some assistance in doing so.
TRIP - Distance ridden. This can be reset each time you ride the bike if you wish.
TIME -- Displays the total time ridden on each ride.
AVG –Average riding speed.
MAX –Displays the maximum speed you have reached.
ODO - Displays total distance ridden on the bike. This cannot be reset and keeps accumulating.
SPECIAL FUNCTIONS
Hold down the M key for 10 seconds to get to the special menu. Here there are four functions that can be changed.
Trip Reset- Turn on the display and wait 10sec. While the bike is stationary press the M key for two seconds. Highlight the data clearance menu and
press M to select. Toggle to Yes using the arrows and confirm with a press of the M button
Unit setting –Km/h or Mph. Here you can select either option. Default is KM/h
Auto off –Here you can change how long it will take for your Omnia to turn off when it’s been sitting idle. Default is 5 mins
Password Set- You can select a 4-digit password for when you turn your Omnia on. This is an added security feature
Please contact your local retailer if you need any assistance on this. Alternatively, you can check Wattwheels website for up-to-date instructional
videos.

WATTWHEELS LTD
8
BRAKES
The Omnia electric bikes are equipped Tektro hydraulic disc brakes. Please be aware the hydraulic disc brakes are very strong, so care is to be taken
braking while getting familiar with the bike. The front wheel brake is located on right hand side with the rear wheel brake on the left. For riders which
prefer the brakes the other way around please get your nearest bike shop to switch over if required.
TYRE PRESSURE
To avoid flats, keep tyre pressure at the recommended PSI. You will find the pressure range written on the side of the tyre. For good all round use we
recommend 60-70PSI
Gates Carbon Belt Drive
Your Omnia is equipped with a Gates CDX carbon belt drive system. Unlike a normal bike with a chain, The Gates carbon belt does not have any
moving parts and does not require any form of lubrication. It is important to get familiar with the instructions and care details of the Gates carbon
belt for proper use and maintenance.
Instructions can be found here: https://www.gatescarbondrive.com/resources/manuals-and-tech
Shimano Nexus Hub
The Omnia is fitted with a Shimano Nexus 3 speed hub gearing system. Unlike a regular derailleur system, the gears are on the inside of the rear hub
shell and does not require a derailleur. To change gear on a Shimano Nexus gearing system requires you to stop pedalling, use the grip shifter to
change gear then resume pedalling again. Failure to do this may cause the gears to “clunk” and wear prematurely.
More info can be found here: https://bike.shimano.com/en-EU/product/component/nexus-inter3/SG-3D55.html

WATTWHEELS LTD
9
DRIVING RANGE
The range of your Omnia is the distance the bike will travel on a single full charge of the battery pack. The range values in this manual are estimates
based on expected usage characteristics. Some of the factors which effect range include changes in elevation, speed, payload, and acceleration,
number of starts and stops and ambient air temperatures. Tyre pressure and terrain are also important variables to consider.
We suggest that you ride conservatively when you first get your Omnia Bike to get to know your bike and travel routes.
Once you become familiar with the range requirements of your travel routes, and the capabilities of your Omnia Bike you can then adjust your riding
characteristics if you so desire.
The following table provides general estimates and outlines various factors effecting range and their combined estimated effects on range. This table
is meant to help owners understand the factors that can increase or decrease range, but Wattwheels makes no claims to the range that individual
users might obtain.
RANGE EXTENDERS
Range extenders are available for purchase to extend the range of your Omnia. The range extenders are battery packs that look like drink bottles and
fit inside of a bottle cage on the seat tube and plug into the frame near the charging port. The range extenders will double the battery capacity of your
Omnia. The range extenders are easy to install and only require plugging in and can be taken with you and used as a battery bank if you wish.
With the battery gauge located on the bottom of the display please take note on new bikes the gauge can drop quite quickly initially. If this happens don’t be
alarmed as this is normal and is due to the BMS (battery management system) we use in the bikes, and it will take a few charges for the cells to balance out.
There will also be instances of voltage sag where the voltage drops when using a high level of PAS, biking up hills or under a heavy load which again is normal.
As mentioned, it is good to do a few smaller rides first to get familiar with the bike and the range you can get depending on what settings you have the bike on.
Pay close attention to the section in looking after your battery to prolong and maximise its life.

WATTWHEELS LTD
10
ADJUSTING THE SEAT HEIGHT
Loosen the seat clamp using a 5mm hex key to raise or lower the seat height to the required position.
Ensure the seat post and seat are properly adjusted before riding. Do not raise the seat post beyond the MINIMUM INSERTION marking etched onto the seat
post. If your seat post extends from the frame beyond these markings, the seat post or frame may break, which could cause you to lose control and fall. Prior
to first use, be sure to tighten the seat clamp properly. A loose seat clamp or seat post binding bolt can cause damage to the bicycle or can cause you to lose
control or fall. Periodically check to make sure these the seat clamp is properly tightened.
RIDER COMFORT
To obtain maximum comfort, the rider should not overextend his or her arms reach when riding. To obtain the most comfortable riding position and
offer the best possible pedalling efficiency, the seat height should be set correctly in relation to the rider’s leg length. The correct saddle height should
not allow leg strain from over extension, and the hips should not rock from side to side when pedalling. While sitting on the bicycle with one pedal at
its lowest point, place the ball of your foot on that pedal. The correct saddle height will allow the knee to be slightly bent in this position.

WATTWHEELS LTD
11
BATTERY & CHARGING
To charge the battery first open the rubber cap located on the seat tube above the motor and plug the charging pin into the port, then plug the
charger into the wall socket. It is important to always plug the charger into the bike first and then the wall socket.

WATTWHEELS LTD
12
The charge left in the battery should be 50%-75% for long storage times.
Cleaning the battery and battery housing should only be done while disconnected and powered off. Use a dry rag or if needed a lightly damp rag.
DO NOT spray with high-pressured water as it may cause damage or possible short-circuiting. Only charge the battery with the supplied charger as others may
not function properly, and this increases the possibility of fire or explosion.
Do not store the charger or battery in a wet/damp place or in direct sunlight.
Lithium-ion batteries can last longer if you recharge with 10-15% of the charge remaining to prevent damage to the cells. Keep both the battery and charger
out of the reach of children and if there appears to be an issue with the charger or battery, stop use immediately and contact either the manufacturer or
Wattwheels at [e-mail]
BEST PRACTISES FOR EXTENDING BATTERY LIFE
o Avoid sudden starts and stops.
o Use low levels of PAS
o Keep within the recommended weight limit

WATTWHEELS LTD
13
CHARGING
•Firstly, insert plug of the charger into charging socket on the bike/ battery.
•Second, Insert the charger into the socket of the home power supply. It shows the power has already been put through when the indicator lamp of
the charger is on.
•It is charging when the indicator light is red. When the light turns from red to green, it indicates that the battery is fully charged.
•After the green light is on, the charger is “fill slowly mode". It will not be harmful to the battery if left to charge for a longer period or overnight. We do
recommend not leaving for longer than 48hours if possible
DO NOT use the charger of other brands to charge. The charger may not be compatible with some brands

WATTWHEELS LTD
14
USEFUL TIPS
• This specified load of the Omnia is 130kg, please don't exceed this otherwise it will void the warranty
• While riding, if the level of charge shows only one bar flashing is recommended to ride without power, in PAS 0 and charge as soon as you can.
• Turn off the display while parking or storing the bike.
• Inspect the bolts on a regular basis, to ensure that they are tight, and all components are secure. Pay close attention to crank bolts, cranks, stems,
front, and rear wheel nuts.
This is especially important if you are riding in demanding conditions.
• Regularly check the brake pads. The provided pads should be replaced if they have:
-Been contaminated
-Have less than .8mm of material
-Cracks or deformation
• To replace the brake pads or perform other maintenance please take it to a qualified bicycle mechanic at your local bike shop.
• Properly inflate your tyres according to riding conditions. Under-inflated tyres are prone to get flats, especially if riding off-road.
• Please don't dismantle and repair parts by yourself. Please go to your local bike shop. This bike comes with a manufacturer’s warranty (document
included) so for warranty claims please contact Wattwheels and we will arrange a service agent close to you to look at the bike. We carry spare parts
so anything electrical that a standard bike shop doesn’t have we will ship to your nearest retailer

WATTWHEELS LTD
15
PARKING, STORAGE & TRANSPORT
Please follow these basic parking, storage, and transport tips to ensure your bike is well cared for on and off the road.
o When pushing the bike manually, turn off the power to avoid accidental acceleration from the motor.
o It is recommended to park indoors.
o Switch off the power to conserve battery. Remove the range extender battery (if installed) from the bike and take with you for security if needed.
o in public places, your Omnia Bike must be parked in accordance with local rules and regulations.
o If you must park outdoors in rain, or wet conditions you should only leave your Omnia Bike outside for a few hours and proceed to park the bike in
a dry location afterwards to allow all the systems to dry out. It is recommended to dry the bike off with a towel prior to storage. Never put your Omnia
away wet. Much like a regular bike, using in wet conditions mandates a more regular maintenance schedule to ensure your bike does not become
rusty, corroded and to ensure all systems are always working safely.
o Do not park, store, or transport your Omnia Bike on a rack that is not designed for the size and weight of the bike.
o Locking up your bike is recommended to ensure your bike is secure and the chance of theft is reduced. Wattwheels makes no claims or
recommendations on the proper lock, hardware, or procedures to secure your bike, but we do recommend you take the appropriate precautions to
keep your Bighorn bike safe from theft. Consult your local Wattwheels dealer for their lock recommendations.

WATTWHEELS LTD
16
2. Wheels and Tyres
o Ensure tyres are inflated to within the recommended limits displayed on the tyre sidewalls.
o Ensure tyres have tread and have no BULGES OR EXCESSIVE WEAR.
o Ensure rims run true and have no obvious wobbles or kinks.
o Ensure all spokes are tight and not broken.
o Check axle nuts and quick releases to ensure they are tight. If your bicycle is outfitted with quick release axles, ensure the locking
levers are correctly tensioned and in the closed position.
3. Steering
o Ensure the handlebar and stem are correctly adjusted and tightened and allow proper steering.
o Ensure the handlebars are set correctly in relation to the forks and the direction of travel.
4. Chain
o Ensure the chain is lubed, clean and runs smoothly.
o Extra care is required in wet or dusty conditions
5. Bearings
o Ensure all bearings are lubricated, run freely and display no excess movement, grinding or rattling.
o Check headset, wheel bearings, pedal bearings and bottom bracket bearings.
6. Cranks and Pedals
o Ensure pedals are securely tightened to the cranks.
o Ensure the cranks are securely tightened and are not bent.
7. Derailleurs
o Check that the derailleur is adjusted and functioning properly.
o Ensure shift and brake levers are attached to the handlebar securely.
o Ensure shift cables are properly lubricated.
8. Frame and Fork
o Check that the frame and fork are not bent or broken.
o If either are bent or broken, they should be replaced.
9. Accessories
o Ensure all reflectors are properly fitted and not obscured.
o Ensure all other fitting on the bike are properly secured and functioning.
o Ensure rider is wearing a helmet and any other required riding safety gear.
10. Motor Drive Assembly and
Throttle
o Ensure mid-motor is spinning smoothly and the motor bearings are in good working order.
11. Battery Pack
o Ensure battery is charged before use.
o Ensure there is no damage to battery pack.
SAFETY CHECK
BASIC STEPS
1. Brakes
o Ensure front and rear brakes work properly.
o Ensure brake pads are not over worn and are correctly positioned in relation to the disc.
o Ensure brake hoses are correctly bleed and display no obvious wear.

WATTWHEELS LTD
17
BASIC TROUBLESHOOTING
Symptoms
Possible Causes
Most Common Solutions
It does not work
1. Insufficient battery power
2. Faulty Connections
3. Battery not fully seated in tray
4. Improper turn on sequence
5. Brakes are applied
1. Charge the battery pack
2. Clean and repair connections
3. Install battery correctly
4. Turn on bike with proper sequence
5. Disengage brakes
Incorrect distance, speed
readings and/or
reduced top speed
1. Insufficient battery power
2. Speed sensor is not centred or missing
1. Charge or replace battery
2. Check on the rear wheel that the spoke magnet matches up in the
front centre of the black sensor. May need to slide around.
When powered on the motor
does not respond
1. Loose wiring
2. Loose or damaged throttle
3. Loose or damaged motor plug wire
4. Damaged motor
1. Repair and or reconnect
2. Tighten or replace
3. Secure or replace
4. Repair or replace
Reduced range
1. Low tyre pressure
2. Low or faulty battery
3. Driving with too many hills, headwind, braking and/or
excessive load
4. Batter discharged for long period of time without
regular charges, aged or damaged.
1. Adjust tyre pressure
2. Check connections or charge battery
3. Assist more with pedals or adjust route
4. Replace the battery
The battery will not charge
1. Charger not connected properly
2. Charger damaged
3. Battery damaged
4. Wiring damaged
1. Adjust the connections
2. Replace
3. Replace
4. Repair or replace
Wheel or motor makes
strange noises
1. Damaged motor bearings , cogs or seals
2. Damaged wheel spokes or rim
3. Damaged motor wiring
1. Replace
2. Repair or replace
3. Repair or replace motor.

WATTWHEELS LTD
18
Error code
ERROR CODES
"04" shown at speed
throttle doesn't turn back to zero position (stay on the high position)
"05" shown at speed
throttle failure
"07" shown at speed
overvoltage protection
"08" shown at speed
failure of motor's hall signal wire
"09" shown at speed
failure of motor's phase wire
"10" shown at speed
Motor temperature is too high, and reaches the protection point
"11" shown at speed
failure of the motor's temperature sensor
"12" shown at speed
failure of the current sensor
"13" shown at speed
failure of the temperature of the battery
"14" shown at speed
Controller temperature is too high, and reaches the protection point
"15" shown at speed
failure of the controller's temperature sensor
"21" shown at speed
failure of the speed sensor
"23" shown at speed
failure of the light
"24" shown at speed
failure of the light sensor
"25" shown at speed
torque signal failure of the torque sensor
"26" shown at speed
speed failure of torque sensor
"30" shown at speed
communication failure
"--" shown at speed
BMS communication failure

WATTWHEELS LTD
19
SERVICING
To ensure your bike remains in great shape just like a car it requires regular servicing. Failure to do so may void any potential warranty claims. Please
retain your receipts for proof of service
2-3 MONTHS: 12 MONTHS:
DATE: DATE:
STORE/MECHANIC: STORE/MECHANIC:
SIGNATURE: SIGNATURE:
6 MONTHS: 24 MONTHS:
DATE: DATE:
STORE/MECHANIC: STORE/MECHANIC:
SIGNATURE: SIGNATURE:

WATTWHEELS LTD
20
WARRANTY
To activate your warranty please go to https://www.wattwheels.co.nz/warranty. A link is located at the bottom of
our webpage.
Wattwheels Ltd warrants that all new products are warranted to the original purchaser against manufacturing defects in materials and/or workmanship for the
following periods:
Motor/Battery 24 months
Frame 60 months (Folding bikes & trikes is 36months)
Additional Components 12 months
For commercial operations where the bikes are being used a hire bike then the following applies:
Motor/Battery 12 months
Frame 24 months (Folding bikes is 18months)
Additional Components 6 months
The warranty period is calculated from the point of delivery. The original receipt of purchase is required to establish proof of purchase and must be provided to
Wattwheels for all warranty claims. Wattwheels will require the customer to complete a MANDATORY standard procedure for warranty claims that will involve media
such as photos and videos to help Wattwheels after sales staff establish the fault with the product.
Goods we sell are subject to a full comprehensive warranty. The costs/inconvenience caused by the loss of use of the product, is not covered whilst the warranty
procedure takes place. The warranty for replacement components will be based on the date of delivery. Under no circumstance will a replacement component have
a warranty date different than the original date of delivery. If a replacement is necessary due to a defect in materials and/or workmanship, then upon return to
Wattwheels, the component will be replaced during the warranty period.
Wattwheels will have no obligation under this warranty in the event the product is damaged or destroyed as a result of any of the following events: components
used on a non Wattwheels product, damage or destruction by abuse; collision; theft; improper maintenance or mishandling of the product; natural forces such as
