Handicare CALYPSO User manual

SERVICE MANUAL
CALYPSO

2 Version 2015v1
© 2011 Handicare
All rights reserved.
The information provided herein may not be reproduced and/or published in any form, by print, photoprint, microfilm or any other means
whatsoever (electronically or mechanically) without the prior written authorization of Handicare.
The information provided is based on general data concerning the constructions known at the time of the publication of this manual. Handicare
executes a policy of continuous improvement and reserves the right to changes and modifications.
The information provided is valid for the product in its standard version. Handicare cannot be held liable for possible damage resulting from
specifications of the product deviating from the standard configuration.
The available information has been prepared with all possible diligence, but Handicare cannot be held liable for possible errors in the
information or the consequences thereof.
Handicare accepts no liability for loss resulting from work executed by third parties.
Names, trade names, etc. used by Handicare
may not, as per the legislation concerning the protection of trade names, be considered as being
available.
XXXXXX-000001000-en.doc

Contents
Version 2015v1 3
This manual.................................................................................................................................................................4
Product reference .......................................................................................................................................................5
Available documentation ...........................................................................................................................................6
Service and technical support...................................................................................................................................7
Identification plate ......................................................................................................................................................7
Identification of the product ......................................................................................................................................7
Warranty ......................................................................................................................................................................8
Used scooters and the environment ........................................................................................................................9
Use according to purpose
1
........................................................................................................................................9
Approval ....................................................................................................................................................................10
CE declaration...........................................................................................................................................................10
1 General safety regulations and instructions ..................................................................................................11
1.1 Decals and instructions on the scooter ..........................................................................................11
1.2 Technical specifications .................................................................................................................11
1.3 Modifications ..................................................................................................................................11
1.4 Safety .............................................................................................................................................11
2 Adjustment options...........................................................................................................................................12
2.1 Seat adjustments ...........................................................................................................................12
2.2 Adjusting the steering column........................................................................................................12
3 Programmer .......................................................................................................................................................13
3.1 Electrical diagram...........................................................................................................................14
3.2 Connections printed circuit board ..................................................................................................14
4 Technical specifications ...................................................................................................................................16
4.1 Product specifications ....................................................................................................................16
4.2 Approval .........................................................................................................................................17
5 Use of the parts lists .........................................................................................................................................18
001: Front tyre assy (3w)..............................................................................................................................19
002: Rear tyre assy (3-4w) ...........................................................................................................................20
003: Front tyre assy (4w)..............................................................................................................................21
004: Free wheel lever assy ..........................................................................................................................22
005: Rear frame assy ...................................................................................................................................23
006: Rear chassis assy ................................................................................................................................24
007: Rear section assy.................................................................................................................................25
008: Rear section assy.................................................................................................................................26
009: Front floorpan assy...............................................................................................................................27
010: Front frame assy (3w) ..........................................................................................................................28
011: 3w scooter assy....................................................................................................................................29
012: Front axle (4w) .....................................................................................................................................30
013: Front frame assy (4w) ..........................................................................................................................31
014: Front section assy (4w) ........................................................................................................................32
015: Front floorpan assy (4w).......................................................................................................................33
016: 4w scooter assy....................................................................................................................................34
017: Transaxle assy .....................................................................................................................................35
018: Head light support assy........................................................................................................................36
019: Console bottom cover assy..................................................................................................................37
020: Tilting tiller assy....................................................................................................................................38
021: 3w scooter assy....................................................................................................................................39
022: 4w scooter assy....................................................................................................................................40
023: Basket support assy .............................................................................................................................41
024: Wig-wag assy .......................................................................................................................................42
025: Armrest assy RH ..................................................................................................................................43
026: Armrest assy LH...................................................................................................................................44
027: Seat assy..............................................................................................................................................45
028: Seat post assy......................................................................................................................................46
029: Front cover tiller assy ...........................................................................................................................47
030: Battery cover assy................................................................................................................................48
031: Console top cover assy ........................................................................................................................49
032: Rear motor cover assy .........................................................................................................................50
033: 3w scooter assy....................................................................................................................................51
034: 4w scooter assy....................................................................................................................................52
035: Parts pack.............................................................................................................................................53
036: Seat frame assy ...................................................................................................................................54

Preface
4 Version 2015v1
This manual
This manual contains the basic instructions for repairs and general maintenance of the Calypso electric scooter.
Mechanics who do repairs on this scooter must be well trained and familiar with the repair methods and the
maintenance of the Calypso electric scooter.
It is important to see to it that work is always done safely, particularly with respect to activities where the scooter
must be lifted up.
We advise that you contact our service department before doing repair work on a scooter that has been involved in
an accident.
The following specifications are important when ordering parts:
-Model
-Manufacture year
-Colour
-Identification number
-Part number
-Name of the relevant part
This information can be found on the identification plate. See 'Identification of the product'.

Preface
Version 2015v1 5
Product reference
XXXXXX-010004000-en.doc
A
B
C
D
D
The product has the following decals and labels.
A. Charging connection
B. Automatic fuse
C. Drive – Freewheel
D. Tyre pressure wheels

Preface
6 Version 2015v1
MAX. BAR3,5
A. Charging connection
For charging the batteries, see 'charging'.
PICPRO-010004210-en.doc
B. Automatic fuse
The scooter has a safety fuse feature. See 'automatic fuse' and 'faults'.
PICPRO-010004270-en.doc
C. Driving
The drive of the motor is switched on:
the scooter can be electrically driven.
D. Pushing
The drive of the motor is disconnected:
the scooter can be pushed.
E. Tyre pressure wheels
For tyre pressure of the wheels, see 'product specification sheet'.
The following pictograms are used in this manual:
XXXXXX-010004020-en.doc
CAUTION
Procedures that can result - if they are not executed properly - in damage to the product, the
environment, or human injury.
PICDOC-010004110-en.doc
ATTENTION!
Suggestions and advice for conducting the relevant tasks or activities more easily.
PICDOC-010004120-en.doc
Consult the specified information source(s) first.
PICDOC-010004130-en.doc
Pull the charge cord out of the charging connection of the scooter before doing any
maintenance on the scooter.
PICDOC-010004140-en.doc
Available documentation
The following technical documentation is available / required to service this scooter:
-User manual
-Service manual.
XXXXXX-010005000-en.doc

Preface
Version 2015v1 7
Service and technical support
For information concerning specific settings, maintenance or repair work please contact your dealer. He is always
prepared to help you.
Ensure you have at hand:
Model
Manufacture year
Identification number
This information can be found on the identification plate. See 'Identification of the product'.
XXXXXX-010006000-nl.doc
Identification plate
See fig. 000000002.
On this plate (A) information on the product can be found. See:
'Identification of the product'.
Identification of the product
See fig. 010007010.
A. Model
B. Manufacture year
C. Identification number
D. User area indoors or outdoors
E. Maximum load in kg
For the place of the identification plate, see 'main components'.
XXXXXX-010007010-en.doc
A
¨
LAGE DIJK 10 5705 BZ HELMOND THE NETHERLANDS
TYPE/TYPE/TYP: CAT
YEAR/JAAR/JAHR: 2000 IDNR.: CT 00004
USAGE:  INDOOR/OUTDOOR
GEBRUIKSGEBIED:  BINNEN/BUITEN
GEBRAUCHSBEBIET:INNERHALB/AUSSERHALB
MAX.LOAD/MAX.BELASTB./ZUL.GESAMTGEW.: 100 KG



D
A
B
C
E

Preface
8 Version 2015v1
Warranty
Definitions of terms used in this warranty:
•Consumable part: Part that is subjected to natural wear and tear or natural contamination during normal
operation within the lifetime of the product (section 9 of Handicare’s general terms and conditions of sale);
•Client: Those who purchase the product directly from Handicare;
•Corrective action: Repair, replace or refund of the product;
•Dealer: Those who re-sell the product to the User;
•Defect: Any circumstance due to which the product is not sound or fit to use, caused by a lack of quality of the
material used to manufacture the product as well as the quality of the manufacturing process;
•Option: An accessory delivered by Handicare to extend the standard product model;
•Product: Product that is delivered according to brochure or contract (e.g. wheelchair, scooter, battery-charger
etc.);
•Part: Part of product that can be exchanged or replaced. This can be an option, accessory, service part or
consumable part;
•Returns: Product or part that needs to be returned;
•RMA-process: Process to return goods, contact Handicare’s Customer Service;
•Service part: Part that is durable and may be subjected to natural wear and tear or natural contamination during
normal operation within the lifetime of the product.;
•User: Those who use the product;
•Warranty: The rights and obligations set forth in this document;
•Warranty period: The period of time during which the warranty is valid;
•Warranty provider: Handicare B.V., Vossenbeemd 104, 5705 CL Helmond, The Netherlands.
Notwithstanding the rights and obligations of Handicare, Client and User set forth in Handicare’s general terms and
conditions of sale, the rights of the Client and/or User towards Handicare in case of defects are limited to the
provisions set forth in this warranty. For the duration of the warranty period Handicare guarantees that the product
is without defects.
In case of any defects the User is required –within two weeks after discovery of the defect- to contact the dealer.
He has to complete a return form and return the product or part via the RMA-process. Handicare will, at its sole
discretion, take the corrective action it seems fit under the given circumstances within a reasonable period of time
(depends on nature of claim) from receipt of the completed return form. The warranty period will not be extended
after a corrective action.
Warranty period table
Power wheelchairs / scooters
Description
Warranty period
Examples include, but are not limited to the parts
mentioned below
Frame
2 years Weldment/frame
Drive system
1 year Transaxle, motor, motor brake
Electronics
1 year Controller, controlling mechanism, wiring harness,
electronic components
Service Parts
New: 1 year after invoice
Repaired: 90 days after invoice
Brakes
Consumable parts
40 days after invoice Wheels, push handles etc.
Options/Accessories
2 years Mirror, mudguards etc.
Not being service part or consumable part.
Handicare will only accept shipment costs and corrective costs related to warranty on equipment during the
warranty period.
This warranty will void in case of:
•The product and/or its parts being modified or items having been added by others than Handicare;
•Changes in cosmetic appearance by use;
•Failure to observe the instructions for use and maintenance, use other than normal use, wear and tear,
negligence, collateral damage by neglect of earlier symptoms, overloading, third-party accidents, non-original
parts used and defects not caused by the product;
•Circumstances beyond our control (flood, fire, etc.).

Preface
Version 2015v1 9
This warranty does not cover:
•Tyres and inner tubes
•Batteries (covered by the battery manufacturer’s warranty).
Clients and/or Users have legal (statutory) rights under applicable national laws relating to the sale of consumer
products. This warranty does not affect statutory rights you may have nor those rights that cannot be excluded or
limited, nor rights against the entity from whom the product was purchased. Clients may assert any rights they have
at their sole discretion.
Used scooters and the environment
If your scooter has become superfluous or needs to be replaced, it can usually be taken back by
your dealer.
If this is not possible, please contact your local authorities for the possibilities of recycling or an
environmentally friendly way of disposing of the used materials.
For the production of the scooter several plastics and metals have been used. The scooter also
contains electronic components that must go to electronic waste.
Used batteries belong to chemical waste.
Use according to purpose
1
The scooter Calypso was designed for the transport of persons to a weight of maximally 125 kg (344 lbs).
Your dealer should give you good user's instructions before you can independently operate the product and
participate in traffic.
You must be able to correct the consequences of actions while driving the Calypso.
Consider operating the Calypso scooter under the monitoring of an experienced dealer during first operations.
The Calypso scooter is not a motorized vehicle in the traffic regulations sense.
The Calypso has a maximum speed of 8 or 10 km/h, depending on the type.
The Calypso has been designed for use in and around the home, on sidewalks, footways, and bike-ways.
If you use the scooter for other purposes than those for which it is intended, Handicare accepts no liability
whatsoever for damage or injury resulting from such use other than that for which the scooter was developed and
designed.
1 'Use according to purpose' as established in EN 292-1 is the use for which the technical product is suitable according to the statement of the manufacturer, including his
instructions in the sales brochure. In case of doubt this is the use that follows from the construction, execution and function of the product. Use according to purpose also
includes taking into consideration the instructions in the owner's manual.

Preface
10 Version 2015v1
Approval
The product meets the following standards:
1. Essential standards as specified in Annex 1 of the EU directive
93/42 EEC.
2. NEN-EN 12182 Technical tools for the handicapped – General standards and testing methods October 1997.
3. NEN-EN 12184 Electrically driven wheelchairs, scooters and associated charging equipment – Standards and
testing methods, April 1999.
4. The Beatle is classified according to EN12184 in class A.
5. The Puma is classified according to EN12184 in class B.
6. ISO 7176-8 Standards and test methods for impact, static, and fatigue strength, July 1998.
7. ISO 7176-14 Standards and test methods for controller systems of electrically driven wheelchairs 1997.
8. ISO 7176-15 Climate test for electrically driven wheelchairs.
9. ISO 7176-16 Standards for resistance to fire, May 1997.
10.ISO 7176-19 Crash test.
The quality is guaranteed by an independent institution that controls the fulfilment of the above mentioned
standards.
CE declaration
The product is in conformity with the provisions of the Medical Devices Directive and thus has CE marking.

Preface
Version 2015v1 11
1 General safety regulations and instructions
Handicare accepts no liability whatsoever for damage or injury caused by the failure to (strictly) adhere to the safety
guidelines and instructions or else due to carelessness during the use and cleaning of the scooter and possible
accessories. Depending on the specific work circumstances or the accessories used, additional safety instructions
may be required. Please contact your dealer immediately if you observe a potential danger during the use of the
product.
The user of the scooter (see under 'use according to purpose') is at all times fully responsible for
the fulfilment of the locally applicable safety regulations and guidelines.
1.1 Decals and instructions on the scooter
Signs, symbols and instructions placed on this scooter comprise part of its safety facilities. They must never be
covered or removed and must remain present and clearly legible throughout the entire lifespan of the scooter.
Immediately replace or repair illegible or damaged signs, symbols and instructions. Contact your dealer with regard to
this.
1.2 Technical specifications
The technical specifications may not be changed.
1.3 Modifications
Modification of (parts of) this product is not permitted.
1.4 Safety
To avoid accidents and undesirable situations, it is of great importance to pay attention to the following safety
instructions.
•Pay extra attention to riding on slopes:
-Never drive the Calypso up a slope with an angle greater than 6°.
-On slopes always drive slowly and with awareness.
-Do not drive down slopes with loose gravel or a sandy surface, because one of the back wheels might slip.
-Do not turn on a slope.
•Never take curves at full speed. Decrease speed on the approach and on the curve.
•Be sure that no items of clothing hang loose. These could become caught between the
wheels.
•Adjust your riding according to the circumstances:
-Drive carefully on slippery roads, resulting from rain, ice, or snow!
-Avoid the Calypso from coming into contact with sea water. Sea water is caustic and may damage the
scooter.
-Avoid the Calypso from coming into contact with sand. Sand can affect the moving parts of the scooter,
resulting in unnecessarily rapid wear.
•Never operate the scooter when you are under the influence of drugs, alcohol or medication
that could affect your driving ability.
•You must have sufficient visual acuity to be able to drive safely in the scooter.
•You are obliged to put the lights on when the view is hindered.
•The standard version of your scooter was tested according to the strictest EMC
requirements. Mobile telephones have no influence on the driving behaviour of the scooter.
When using a mobile telephone in the vicinity of a scooter with special adaptations, you are
advised to first switch off the scooter.
•Your scooter may influence electromagnetic fields such as alarm systems.
•If the electronics of the scooter is not properly screened off, this may affect sensitive
electrical appliances, such as shop alarms and garage openers. The scooter has been tested
for this. Should any problems of this nature occur, please report these to your supplier
immediately.

General safety regulations and instructions
12 Version 2015v1
2 Adjustment options
XXXXXX-010500000-en.doc
2.1 Seat adjustments
The Calypso seat offers a number of adjustment options to increase the sitting and driving comfort.
The following may be adjusted:
A. Seat height
B. Seating width
C. Arm-rests
D. Steering column
E. Headrest
2.1.1 Adjusting the seat height
The whole seat can be readjusted in height. This adjustment should be made by the dealer.
2.1.2 Adjusting the seat width
See fig. 000000021.
The space between the two arm-rests can be adjusted according to your wishes.
The holder for the arm-rests can be shifted in width on both sides
Do the adjustment, or have it done by someone, and then sit down in the seat.
The width adjustment must be done as follows:
Loosen the caps (A) on both sides.
Slide the arm-rests (B) to the desired width.
Firmly tighten both caps again.
2.1.3 Adjusting the arm-rest
See fig. 000000022.
Both arm-rests can be folded up completely.
2.2 Adjusting the steering column
See fig. 000000023.
The angle of the steering column can be adjusted as follows:
Loosen the locking handle (A) by turning it to the left (anti-
clockwise).
Push the steering column (B) forward or backward until the ideal
position is reached.
Tighten the locking handle (A) again by turning it to the right.
This will lock the steering column.
A A
B B
A
B

Programmer
Version 2015v1 13
3 Programmer
A programmer is nescesarry for programming the Calypso. A programmer will always be deliverd with a user
manual.
The standard adjustments are stated in the table below.
Function SP1B
Programming < 2002
Programming > 2002
8 km/hr
8 km/hr
10 km/hr
Forward acceleration 13 25 25
Forward deceleration 8 15 15
Reverse acceleration 15 25 25
Reverse deceleration 14 20 20
Forward speed 100 100 100
Reverse speed 40 45 40
Invert throttle polarity NO YES YES
Power down timer 0 0 0
Engineering menu SP1B
Programming < 2002
Programming >
2002
8 km/hr
8 km/hr
10 km/hr
Current limit 60 60 60
Motor compensation 95 90 80
Hold factor 240 % 152 % 152 %
Mid current 15,5 / 0 % 15 / 0 % 15 / 0 %
Brake time 40 40 40
ISO test OFF ON ON
Inhibit polarity LO LO LO
Bridge hold time 20 20 20
Throttle gain 100 % 100`% 100 %
Pulse reverse alarm YES YES YES
Wig-wag throttle YES YES YES
Low battery flash inhibit NO NO NO
Throttle deadband 15 % 15 % 15 %
Output voltage 24 24 24
TruCharge cable resistance 45 45 45
TruCharge calibration 100 100 100
Programmer
Code
SP1-B 10237

Programmer
14 Version 2015v1
3.1 Electrical diagram
CANNON JACK
CONNECTOR
CONNECTOR
BATTERY (12V)
CIRCUIT
BREAKER
25A
BATTERY (12V)
RED
RED
WHITE
RED
BROUW
BLUE
GREEN
YELLOW
BLACK
GRAY
GRAY
BRAKE
LAMP 24V 5W x2
LAMP 24V 5W x2
RED
ORANGE
RED
RED
WHITE
BLACK
WHITE
CONTROLLER
BLACK
DC MOTOR
MOTOR
BLACK
BLACK
RED
BLACK
RED RED RED RED
BLACK
BLACK BLACK
BLACK BLACK
BLACK
BLUE
FUSE 10A
FUSE 5A
SPEED CONSOLE
3.2 Connections printed circuit board
A
B
C D E
JK
1 2 43 8765 9
1 2 BA C
2 31 21
1
2
1
2
3
4
5
6
7
8
I
2
1
LM
21 21
GF
21 21
H
2
1
For the connections of the printed circuit board, see the table below.

Programmer
Version 2015v1 15
Nr.
Cable function
Number of the connections
Colour of the cables
A Horn - Black
+ Red
B Console main connector H1 Black
M- Brown
M+ Red
H2 Orange
NC
V1 Green
V2 Blue
NC
C Key switch 1 White
2 Yellow
D Speed control A Black
B Blue
C Red
E Controller connection 1 Red
2 Purple
3 Blue
4 Green
5 Yellow
6 Grey
7 Black
8 White
9 Orange
F Lighting switch S Black
W Red
G Front light 1 Black
2 Red
H Fuse connector 1 Black
2 Red
I NC
NC
J Hazard lights 1 Black
2 Red
K Turn indicator switch 1 Red
2 White
3 Green
L Indicator right 1 Black
2 White
M Indicator left 1 Black
2 White

Technical specifications
16 Version 2015v1
4 Technical specifications
XXXXXX-010900000-nl.doc
4.1 Product specifications
Manufacturer: Handicare
XXXXXX-010901000-nl.doc
4.1.1 Calypso
Technical specification according to ISO 7176-15
Model Calypso 3-wheel version
Calypso 4-wheel version
Maximum user's weight 125 kg
Description
Min.
Max.
Total length 1180 mm
Total width 620 mm
Total weight incl. batteries 78 – 86 kg
1
82 -90 kg
1
Transport weight heaviest part 22 kg
Static stability downward 9°
Static stability upward 9°
Static stability sideways 9°
Energy consumption: theoretic maximum distance 38 km
2
Dynamic stability on slopes 6°
Climbing capacity for obstacles 50 mm
Maximal speed forward 8 / 10 km/h
Minimum brake distance from maximum speed 1500 mm
Seat angle 5°
Effective seating depth 440 mm
Effective seating width 440 - 580 mm
Sitting height from the front 460 - 485 - 510 - 535 mm
Back angle 95°- 130°
Back height 400 mm
1
Values given are applicable to the use of a 30 Ah and 40 Ah battery, respectively.
2
Tested according to EN12184 with 40Ah batteries.
Description
Minimum radius 1030 mm 1610 mm
3
Capacity to drive over obstacles 50 mm
Ground clearance 120 mm
Turning space 1585 mm 1780 mm
3
Test data
Weight test dummy 125 kg
Operating force
Control force < 60 N
Resetting automatic fuse < 60 N
Electronic switches < 15 N
Parking brake < 60 N
Inserting charging plug < 60 N
Technical data
Diameter front wheel 260 x 85 mm
Diameter drive wheels 260 x 85 mm
Tyre pressure wheels 350 kPa (3.5 Bar)

Technical specifications
Version 2015v1 17
Batteries
Maximum dimensions batteries 210 x 175 x 180 mm
Weight scooter without batteries 78 kg 82 kg
3
Battery capacity 30 Ah/5,5A-5h
40 Ah/6.8A-5h
Maximum permissible charging voltage 13.6 V
Maximum charging current 5 A
Connector type A DIN 72311
Touch up pencil Red 951558 motip
Green 953617 motip
3
Applicable to Calypso 4-wheel version.
4.2 Approval
The product meets:
1. NEN-EN 12182 Technical tools for the handicapped - General standards and testing methods October 1997.
2. NEN-EN 12184 Electrically driven wheelchairs, scooters and associated charging equipment - Standards and
testing methods April 1999.
3. The Calypso 3-wheel scooter is classified according to EN12184 (1999) in
class A & B.
4. The Calypso 4-wheel scooter is classified according to EN 12184 (1999) in
class B.
5. ISO 7176-8 Requirements and test methods for impact, static, and fatigue strength July 1998.
6. ISO 7176-9 climate tests for electric wheelchairs & scooters.
7. ISO 7176-14 Standards and test methods for controller systems of electrically driven wheelchairs 1997.
8. ISO 7176-16 Requirements of resistance to fire May 1997.

Spare parts
18 Version 2015v1
5 Use of the parts lists
This document is meant as a reference book to be able to order parts for the scooter as shown on the front.
How to order:
To order parts please specify:
Serial number (see the identification plate).
Group (to which the relevant part belongs).
Article number.
Number of parts required.
Description (in the relevant language).
Dimensions (if applicable).
Remark:
•If a part does not have a position number, it means that the relevant part cannot be bought separately. The
relevant part is part of the composition that is shown. Only the composition can be ordered, so it must be
replaced in its entirety.
•Boxed position numbers refer to the relevant drawing.
Order address:
Please send orders by post or fax to your supplier.
Service technicians:
Repairs may only be done by trained and authorized service technicians.
In the execution of their work they are at all times fully responsible for the fulfilment of locally applicable safety
guidelines and standards.
Temporary employees and persons in training may only execute repair and replacement work under the
supervision of an authorized service technician.
XXXXXX-020904000-en.doc

Spare parts
Version 2015v1 19
001: Front tyre assy (3w)
Pos
Ar
t
icle number
Units
Description
1 05010.4100 1 Tyre
2 05010.4000 1 Tube
3 143001 2 Outer rim
4 00000.1701 4 Lock nut M6
5 00000.2302 4 Flat washer M6
6 00000.4104 4 Hex bolt M6x60
7 131905 1 Axle front wheel
8 4B2006 2 Bearing 6202ZZ
9 133002 2 Collar front wheel
10 00000.3500 2 Set screw M6x5
11 00001.1463 1 Label max 3.5 bar
- B24F02 1 Front tyre assy (3w)

Spare parts
20 Version 2015v1
002: Rear tyre assy (3-4w)
Pos
Article number
Units
Description
1 1008952 2 Tyre
2 05010.4000 2 Tube
3 143102 2 Inner rim
4 143003 2 Outer rim
5 00000.4104 8 Hex bolt M6x60
6 00000.2302 8 Flat washer M6
7 00000.1701 8 Lock nut M6
8 00001.1463 2 Label max 3.5 bar
- B24R02 2 Rear tyre assy
