Sokkia GSR2700 ISX User manual

GNSS Receiver System
GSR2700 ISX
Operations Manual
CANADA
[phone]
www.sokkiacanada.com
CHINA
[phone]
www.sokkia.com.cn
EUROPE
[phone]
www.sokkia.net
JAPAN
[phone]
www.sokkia.co.jp
SOUTH KOREA
[phone]
www.sokkia.co.kr
LATIN AMERICA
[phone]
www.sokkialatinamerica.com
UNITED STATES
[phone]
www.sokkia.com
OCEANIA
[phone]
www.sokkia.com.au
SINGAPORE
[phone]
www.sokkia.com.sg
POINT, Inc. — Integrated Measurement Solutions
©2007 POINT, Inc. All rights reserved.
Printed in the U.S.A.
090-0-0058
SOKKIA GPS Worldwide

Tplljb
GNSS Receiver System
GSR2700 ISX
Operations Manual

We welcome written communications regarding our products at:
POINT, Inc. 16900 West 118th Terrace, Olathe, Kansas 66061 U.S.A. We strive to provide
the highest quality documentation and welcome your feedback. If you have comments
or suggestions about our online or printed documentation, e-mail us at
[email protected]. For technical questions, contact Technical Support (see
Section 1.7, Obtaining Technical Assistance, page 8).
Document number: 58023002
Part number: 750-1-0058
Rev 1
February 12, 2007
Copyright Notice
© 2006-2007 POINT, Inc. All rights reserved.
Do not reproduce, translate, store in a retrieval system, or transmit in any form or
means (electronic, photocopy, record, or otherwise) without prior written permission
from POINT, Inc. The copyright laws of the United States of America (“U.S.A.”) and/
or the jurisdiction where you are located determine any limits or restrictions of your
rights with regard to this publication and the equipment.
Trademark Notice
SOKKIA® and Spectrum® are registered trademarks of SOKKIA Co., Ltd. SDR® is a
registered trademark of POINT, Inc. The Bluetooth® word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such marks by POINT, Inc. is under license.
Pulse Aperture Correlator (PAC)™ and Pinwheel™ are trademarks of NovAtel Inc. All
other product and brand names are trademarks or registered trademarks of their
respective holders.
GSR2700 ISX FCC and CE Notice
This device complies with CISPR 22 Class B.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try and correct the interference by one or more of the following
measures: a) reorient or relocate the receiving antenna; b) increase the separation
between the equipment and the receiver; c) connect the equipment into an outlet on a
circuit different from that to which the receiver is connected; or d) consult the dealer or
an experienced radio/TV technician for help.
IMPORTANT! To maintain compliance with the limits of a Class B digital device, you
must use properly shielded interface cables (Belden #9539 or equivalent) when you use
the serial data ports, and double-shielded cables (Belden #9945 or equivalent) when
you use the I/O strobe output.
WARNING! Changes or modifications to this equipment not expressly approved by
POINT, Inc. could result in a violation of Part 15 of the FCC Rules and void the user’s
authority to operate this equipment.
WEEE Notice
If you purchased your GSR2700 ISX in Europe, you must return it to your dealer or
supplier at the end of its life. The objectives of the European Community's
environment policy are, in particular, to preserve, protect and improve the quality of
the environment, protect human health and utilize natural resources prudently and
rationally. Sustainable development advocates the reduction of wasteful consumption
of natural resources and the prevention of pollution. Waste electrical and electronic
equipment (WEEE) is a regulated area. Where the generation of waste cannot be
avoided, it should be reused or recovered for its material or energy. WEEE products
may be recognized by their wheeled bin label.
RoHS Notice
The GSR2700 ISX is compliant with the European Union (EU) Restriction of Hazardous
Substances (RoHS) Directive 2002/95/EC.

GSR2700 ISX Operations Manual i
Chapter 1 Introduction 1
1.1 About the GSR2700 ISX...........................................1
1.2 Features ...................................................................2
1.3 System Components ................................................3
1.4 Document Conventions ............................................6
1.5 Usage Cautions ........................................................6
1.6 Finding More Information..........................................8
1.7 Obtaining Technical Assistance ...............................8
Chapter 2 GSR2700 ISX Components 9
2.1 Enclosure Features ..................................................9
2.2 Ports .......................................................................11
2.2.1 Antenna port....................................................... 12
2.2.2 Communication ports ......................................... 13
2.2.3 Power port .......................................................... 13
2.3 Cables ....................................................................13
2.4 Batteries .................................................................14
2.5 Memory...................................................................15
2.6 Antenna ..................................................................16
2.7 Internal Radio .........................................................17
2.8 Wireless Communication........................................17
2.9 Display Panel..........................................................18
2.10 Audible Annunciator ...............................................18
Chapter 3 Display Panel Operations 19
3.1 Power Button ..........................................................20
3.2 Gauges ...................................................................23
3.2.1 Battery life gauge ............................................... 23
3.2.2 Satellite tracking gauge...................................... 24
3.2.3 Memory gauge ................................................... 25
Contents

Contents
ii GSR2700 ISX Operations Manual
3.2.4 Timer gauge .......................................................26
3.3 Status Indicators .................................................... 28
3.3.1 Receiver health...................................................28
3.3.2 COM port communication status ........................30
3.3.3 Wireless communication status..........................31
3.3.4 Internal radio status............................................32
Chapter 4 Audible Annunciator 34
Chapter 5 System Setup 37
5.1 Operation Overview ............................................... 37
5.2 Setting Up at the Office .......................................... 38
5.3 Setting Up for Field Operations.............................. 39
5.3.1 Typical RTK rover setup .....................................39
5.3.2 Typical RTK base setup .....................................42
5.3.3 Typical static setup.............................................46
Chapter 6 Powering the GSR2700 ISX 48
6.1 Turning the System On and Off ............................. 48
6.2 Power Source......................................................... 48
6.2.1 Internal batteries.................................................48
6.2.2 External power source........................................49
6.3 Powering Peripheral Devices ................................. 50
6.4 Power Consumption............................................... 50
6.5 Insufficient Power................................................... 51
6.6 Charging the Internal Batteries .............................. 52
Chapter 7 Collecting Data 53
7.1 How Data is Stored ................................................ 53
7.2 Data Collection Methods ........................................ 53
7.2.1 Handheld data collection ....................................53
7.2.2 Receiver logging to internal memory with POW-
ERUP 54
7.3 Data File Naming ................................................... 57

Contents
GSR2700 ISX Operations Manual iii
7.4 Data Storage Capacity ...........................................58
7.5 Resetting the Receiver ...........................................59
7.6 Erasing Files Stored on the Receiver .....................59
Appendix A Technical Specifications 60
Appendix B Allegro CX Bluetooth Connections 66
Appendix C Configuring Satel Radios 70
C.1 About the 3ASd and Epic Radios ...........................70
C.2 Radio Cables ..........................................................71
C.3 Setting the Frequency ............................................71
C.4 Setting the Transmitter Output Power ....................72
C.5 Turning On Error Correction ...................................73
C.6 Using a Radio as a Repeater .................................73
Appendix D Installing the USB Driver 75
D.1 Downloading the USB Driver..................................75
D.2 Installing the Driver.................................................75
D.2.1 Windows XP driver installation ........................... 76
D.2.2 Windows 2000 driver installation........................ 77
D.3 Configuring USB COM Ports ..................................78
D.4 Windows Driver Signing .........................................79
Glossary 81
Index 89

iv GSR2700 ISX Operations Manual
Tables
1GSR2700 ISX Features...................................................... 2
2Standard Component Descriptions .................................... 5
3Optional Component Descriptions...................................... 6
4Receiver Underside Descriptions ..................................... 10
5Port Descriptions .............................................................. 11
6Battery Operation Times .................................................. 14
7Display Panel Components .............................................. 19
8Power Button Functions ................................................... 21
9Battery Life Gauge Indicators........................................... 24
10 Satellite Tracking Gauge Indicators ................................. 25
11 Memory Gauge Indicators ................................................ 25
12 Timer Gauge - Baseline Length Mode ............................. 27
13 Timer Gauge - Elapsed Time Mode ................................. 27
14 Temperature Issues ......................................................... 29
15 Voltage Issues.................................................................. 29
16 Firmware Issues ............................................................... 29
17 COM Ports Communication Status LEDs......................... 30
18 Wireless Communication Status LEDs............................. 31
19 Internal Radio Status LEDs .............................................. 33
20 Audible Annunciator Conditions ....................................... 34
21 RTK Rover Setup Components ........................................ 40
22 RTK Base Setup Components (internal radio) ................. 43
23 RTK Base Setup Components (external radio) ................ 44
24 Static Setup Components................................................. 47
25 POWERUP Configurations............................................... 56
26 Auto-Generated File Name Convention ........................... 58

Tables
GSR2700 ISX Operations Manual v
27 Hours of Storage with 64 MB Logging Capacity ...............59
28 GSR2700 ISX Technical Specifications............................60

vi GSR2700 ISX Operations Manual
Figures
r
1Standard RTK Rover System Components........................ 4
2Standard RTK Base System Components ......................... 4
3Optional System Components ........................................... 5
4GSR2700 ISX..................................................................... 9
5Receiver Underside View ................................................. 10
6Ports ................................................................................. 11
7Internal Radio Antenna..................................................... 12
8Antenna Radome ............................................................. 16
9Display Panel Components .............................................. 19
10 Power Button Functions ................................................... 21
11 Typical RTK Rover Setup................................................. 40
12 Typical RTK Base Setup (internal radio) .......................... 42
13 Typical RTK Base Setup (external radio) ........................ 43
14 Typical Static Setup.......................................................... 46
15 Satel Radios ..................................................................... 70

Chapter 1
GSR2700 ISX Operations Manual 1
Introduction
This manual provides complete information about your
GSR2700 ISX receiver and its functions, including components,
system setup, operations, and data collection.
1.1 About the GSR2700 ISX
The SOKKIA GSR2700 ISX is a fully integrated, high-precision
GNSS solution for use in both RTK and post-processing
applications. It integrates a dual-frequency receiver, antenna,
memory, batteries, wireless connectivity, and a differential
correction radio into one compact enclosure.
For wireless connectivity, the GSR2700 ISX supports Bluetooth®
wireless technology to allow you to communicate with other
Bluetooth-enabled devices (for example, your handheld data
collector), providing a completely cable-free option.
For differential correction transmission flexibility, the
GSR2700 ISX uses either an internal UHF or GSM/GPRS radio. It
also offers the innovative feature of voice messages to indicate
receiver status during field operation.
Surveyors can use the GSR2700 ISX for topographic, stake out,
and control surveys. Excellent acquisition and reacquisition times
mean this receiver continues to excel in environments where
signal obstructions are present and frequent interruptions of
signals can be expected.
The GSR2700 ISX features a rugged design for use in adverse
environments, and it is engineered to provide years of reliable
operation.
You can also use the GSR2700 ISX handheld component (SDR+)
and desktop post-processing software (Spectrum® Survey Suite)
with the GSR2700 ISX. When used together, these components
provide a powerful, flexible, and easy-to-use GNSS system.

2 GSR2700 ISX Operations Manual
Chapter 1 Introduction
1.2 Features
The GSR2700 ISX is capable of the following modes of operation:
• RTK rover operation
• RTK base operation
• Navigation
• Differential GPS
• Static post-processing
• Stop-and-go kinematic post-processing
The GSR2700 ISX features are summarized in Table 1. For
detailed technical information, see Appendix A, Technical
Specifications, page 60.
Table 1: GSR2700 ISX Features
General
Full code and carrier tracking of: GPS: 14 L1, 14 L2, and support for L5 GPS.
GLONASS: 12 L1, 12 L2. SBAS: 2. L-band: 1
New triple frequency receiver board: GLONASS constellation tracking with
support for future full GLONASS real-time positioning
Full wave-length carrier measurements from new integrated GNSS antenna
with Pinwheel™ technology
Patented Pulse Aperture Correlator™ (PAC) technology for high-accuracy GPS
measurement, multipath rejection, ionospheric corrections in position
calculations
New high performance long range RTK algorithm that minimizes the delay in
achieving fixed solutions
Optional internal UHF or GSM/GPRS radio for differential correction
transmission or reception
Rugged, shock resistant, waterproof, buoyant enclosure with lead-free
components
Bluetooth™ wireless technology
Two bidirectional communication ports that can transfer data at rates up to
230400 bps (serial through COM1), and 1 Mbps (USB through COM2)
Capability to log data to internal memory—64 MB internal memory standard
(options up to 2 GB available)
2 Input/Output strobe signals: mark input (position & time), 1PPS timing output

GSR2700 ISX Operations Manual 3
Introduction Chapter 1
1.3 System Components
When you receive your GSR2700 ISX system, ensure that you
have received all of the components for your specific
configuration (rover or base).
Standard rover components are illustrated in Figure 1, Standard
RTK Rover System Components, page 4. Standard base components
are illustrated in Figure 2, Standard RTK Base System Components,
page 4.
NOTE Generally, the system components are illustrated with the
assumption that an internal radio is being used.
Components are described in Table 2, Standard Component
Descriptions, page 5.
Low power consumption
Peripheral power supply output to COM1 and COM2
LED display status indictors
Voice messages or sounds to indicate receiver status
Output Data Log Formats
Proprietary ASCII and binary
CMR Standard: CMR, CMR+
NMEA Standard: GPGGA, GPGLL, GPGRS, GPGSA, GPGST, GPGSV,
GPRMB, GPRMC, GPVTG, GPZDA
RTCM V2.3 Standard: Types 1, 2, 3, 9, 16, 18/19, 20/21, 22, 59FKP, 59N
RTCM V3.0 Standard: Types 1001–1006
RTCA Standard: Types 1, 7
NTRIP protocol support for RTK
Maximum Data Logging Rates (per second)
Computed Data: Position, speed, direction, & clock offset = 20
Measured Data (Observations): Pseudorange & carrier phase = 20
Table 1: GSR2700 ISX Features (continued)

4 GSR2700 ISX Operations Manual
Chapter 1 Introduction
Figure 1: Standard RTK Rover System Components
Figure 2: Standard RTK Base System Components
GPS Receiver System
GSR2700 IS
OperationsManual
431
56
7 8 9
1 2 3
54 6
GPS Receiver System
GSR2700 IS
OperationsManual
7 8 9

GSR2700 ISX Operations Manual 5
Introduction Chapter 1
Figure 3 illustrates optional components that you may also want
to use with your system. Components are described in Table 3,
Optional Component Descriptions, page 6.
Figure 3: Optional System Components
Table 2: Standard Component Descriptions
Number Description
1GPS receiver
2Tribrach and tribrach adapter
3Internal radio antenna
4Quick release
5AC adapter
6PC download cable (USB)
7Tape measure
8Manual
9Hard case
1 2 3
45

6 GSR2700 ISX Operations Manual
Chapter 1 Introduction
1.4 Document Conventions
This manual uses notes and cautions to emphasize important
information.
NOTE A note further explains information in the previous paragraph.
1.5 Usage Cautions
Table 3: Optional Component Descriptions
Number Description
1PC download cable (serial)
2 External battery
3External battery cable
4Data collector
5Data collector mounting bracket
CAUTION
A caution provides information about
possible sources of difficulty or situations
that may damage the product.
CAUTION
• If your receiver has an internal radio, always ensure that the
radio antenna is properly connected to your receiver before
turning the unit on.
Never disconnect the radio antenna while the internal radio
is still powered. Disconnecting the antenna while the
receiver is on may cause irreparable damage to the
internal circuitry of your radio, particularly when the radio is
transmitting information.

GSR2700 ISX Operations Manual 7
Introduction Chapter 1
• If travelling with or shipping the GSR2700 ISX by air, ensure
that you remove the tripod or survey pole, or any other
mount component from the socket on the receiver’s
underside (Figure 5, Receiver Underside View, page 10).
The receiver contains a vent that is designed to equalize
pressure inside the housing. If any component is in the 12
cm (5/8") thread mount socket, air flow to the pressure vent
may be limited or blocked and internal damage could occur
to the receiver.
• This receiver incorporates circuitry to absorb most static
discharges. However, severe static shock may cause
inaccurate operation of the unit. Use anti-static precautions
where possible.
• This device is a precision instrument. Although it is
designed for rugged operating conditions, it performs best
when handled with care.
• When the port covers are closed, the enclosure is sealed to
provide protection against adverse environmental
conditions. To minimize the possibility of damage, always
keep the ports covered except when in use.
• The GSR2700 ISX can accept an input supply voltage in the
range of +9 to +18 VDC. Do not operate the receiver
outside the specified voltage range.
• Drawing more than the specified maximum current (1 amp
combined total) from the two COM ports will cause an
internal fuse to interrupt the current to prevent damage to
the unit. If this happens, immediately reduce the load and
allow the unit to automatically reset its protection circuitry.
• Always use the correct cables with the receiver and handle
them correctly (don’t pinch or bend sharply). Failure to do
so will damage the receiver, and void the unit’s warranty.
CAUTION

8 GSR2700 ISX Operations Manual
Chapter 1 Introduction
1.6 Finding More Information
The following documents provide supporting documentation to
this manual:
•Planning Reference Manual. Describes how to use Planning
software, including determining satellite availability and
editing configurations.
•GSR2700 IS/ISX Config Tool for Allegro CX Release Notes.
Describes how to use the Config Tool software on the Allegro
CX to configure basic receiver settings, including audio
language and volume, internal radio settings, and default
(factory reset) POWERUP configuration.
•POWERUP Configuration Manager Release Notes. Describes
how to use POWERUP Configuration Manager software utility
to customize, edit, or delete the receiver’s default POWERUP
configuration (advanced users).
NOTE GSR2700 IS/ISX Config Tool and POWERUP Configuration
Manager software tools are available from the POINT, Inc.
website at www.point-inc.com (select Support).
•Spectrum Survey Reference Manual. Describes how to process
and adjust your data using Spectrum Survey software.
•SDR+ User’s Guide. Describes how to use the SDR+ data
collection software (for example, if you are using the
GSR2700 ISX receiver with SDR+ for data collection).
1.7 Obtaining Technical Assistance
Technical support is available from the distributor where you
purchased this product. When you contact technical support,
please make sure you have the following information:
• Your receiver information, including: serial number, part
number, model, firmware version, and internal radio
information and/or any other modular details (if applicable).
• A descriptive and concise explanation of the problem.
For a list of SOKKIA worldwide offices, see the list at the back of
this manual.

Chapter 2
GSR2700 ISX Operations Manual 9
GSR2700 ISX
Components
The GSR2700 ISX enclosure is fully sealed and houses your
system’s GNSS receiver, antenna, batteries, memory, internal
radio (if installed), and wireless communication device. The
integration of components into a single enclosure makes it
unnecessary to use a backpack.
2.1 Enclosure Features
The top of the GSR2700 ISX encloses the antenna and radome,
surrounded by a shock-absorbing protective bumper.
One side of the receiver shows the radio antenna port and the
display panel (see Figure 4), which you can use to control and
monitor the system.
Brightly colored LEDs display the status of your system.
Figure 4: GSR2700 ISX

10 GSR2700 ISX Operations Manual
Chapter 2 GSR2700 ISX Components
The ports are accessible from the underside of the unit. See
Figure 5 for a view of the underside of the receiver. For details
about the ports, see Section 2.2, Ports, page 11.
Figure 5: Receiver Underside View
Table 4: Receiver Underside Descriptions
Number Description
1Standard 12 cm (5/8”) survey mount socket, compatible with a
standard quick release fitting for mounting the unit on a tripod or
survey pole. The mounting socket accepts a threaded stud up
to 19 mm (0.75”) in length.
2The internal antenna for the Bluetooth wireless communication
device (square raised area). For more information about the
wireless communication device, see Section 2.8, Wireless
Communication, page 17.
3Phase center offset label (antenna specifications).
CAUTION
If travelling with or shipping the
GSR2700 ISX by air, remove the tripod or
survey pole from the survey mount socket
(see #1 in Figure 5). This will prevent any
damage that can occur if the pressure vent
inside the receiver is blocked.
2
1
3
