BWI Eagle AIR-EAGLE SR 38-2000-VBR Manual

PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE® SR
2.4 G
Hz
RF Receiver
MODEL
3
8
-
2000
-
VBR
DESCRIPTION
The AIR-EAGLE SR is an RF system designed for short to medium range
wireless remote control of electrical apparatus in a variety of industrial
applications. Systems can consist of any number of receivers and
handheld or contact input transmitters working together. This receiver is
equipped with 4 independent relays that can switch 5 amps @ 120VAC or
30VDC. The relays are user programmable for momentary or
toggle/latching operation and can be directly interfaced with the
customer's equipment or P.L.C. Eight user selectable frequencies allow
multiple systems to be used in the same area. Capable of receiving
remote signals transmitted from up to 600 feet away, the Air-Eagle SR
Receiver utilizes spread-spectrum technology and provides the utmost
security and reliability even in the noisiest RF environments.
MODEL NOTES
This receiver was designed specifically to communicate with a “VBR”
transmitter and features a confirmation signal that is sent back to the
transmitter causing it to vibrate when its transmission has been received.
INSTALLATION
DISCONNECT AC Power from all equipment before installation.
1. Mount the AIR-EAGLE SR RECEIVER in a convenient location.
2. Install antenna. The unit has an antenna connector located on the
right side on the enclosure. Attach the supplied portable antenna to
this connector.
3. Connect AC power and control to the proper terminals in your control
circuit.
TERMINAL STRIP WIRING
1 N/O Relay #1 7 N/O Relay #3 13 120 VAC - (Neutral)
2 C Relay #1 8 C Relay #3 14 120 VAC - (Hot)
3 N/C Relay #1 9 N/C Relay #3
4 N/O Relay #2 10 N/O Relay #4
5 C Relay #2 11 C Relay #4
6 N/C Relay #2 12 N/C Relay #4
Dimensions (with mounting plate) 6.3” L x 4.8” W x 2.3” H
CONTROLS AND INDICATORS
.
LED1 Illuminated when power is applied to receiver
LED2 Illuminated when relay #1 is energized
LED3 Illuminated when relay #2 is energized
LED4 Illuminated when relay #3 is energized
LED5 Illuminated when relay #4 is energized
RF1 RF module that receives data from the remote
transmitter
REL1 thru REL4 Four SPDT output control relays
SEL1 Seven dip switches for selecting relay options
and operating frequency

AIR-EAGLE® SR
2.4 G
Hz
RF Receiver
MODEL
3
8
-
2000
-
VBR
RELAY & FREQUENCY SET-UP
The unit is shipped from the factory with SEL1 switches in the open
positions. All four relays will operate as maintained momentary and unit is
receiving commands on frequency one. If you wish to change these
default settings, follow the instructions on the table below.
1) Remove power from unit
2) Remove top cover.
3) Select desired relay operation and/or network frequency using table
below.
4) Reattach cover and apply power.
5) Programming is now complete.
RELAY CONFIGURATION
SEL1
SWITCH
NUMBER
OPEN CLOSED
SW1
Relay
#1 momentary
(default)
Relay #1 toggle/latch
SW2
Relay #2 momentary
(default)
Relay #2 toggle/latch
SW3
Relay #3 mo
mentary
(default)
Relay #3 toggle/latch
SW4
Relay #4 momentary
(default)
Relay #4 toggle/latch
Maintained Momentary – Relay mimics button or input – when
depressed or closed, relay will be energized; when released, relay de-
energizes
Toggle Latch – Relay changes (and holds) its state each time the
corresponding button or input is depressed or closed.
FREQUENCY SET
-
UP
SEL1
(SW5-7)
Network
Frequency SW5 SW6 SW7
1
(default)
OPEN
OPEN
OPEN
2 CLOSED OPEN OPEN
3
OPEN
CLOSED
OPEN
4 CLOSED CLOSED OPEN
5
OPEN
OPEN
CLOSED
6
CLOSED
OPEN
CLOSED
7
OPEN
CLOSED
CLOSED
8
CLOSED
CLOSED
CLOSED
SPECIFICATIONS
A
C Input
120 VAC,
5
W,
5
0
/60 Hz
Relay Contacts
SPDT 5 amp @
120VAC
or
3
0VDC
Fuse Protected
1 amp
Receiver Frequency
2.4 GHz Spread Spectru
m
Receiver Range
–
Dependent
upon transmitter
–
see below:
Using SR Series TX
Approximately 100 feet
Using SR+ Series TX
Appro
x
i
mately 6
00 feet
Receiver Channels
Eight independent network frequencies
Operating Temperature
-
40
o
F to +185
o
F
En
closure
Polycarbonate, IP66 (NEMA 4)
Weight
Approx 2 lbs.
APPROVALS
United States (FCC) OUR-XBEEPRO
Canada (IC) 4214A-XBEEPRO
Europe (CE) ETSI
REPLACEMENT PARTS & ACCESSORIES
PC Board
3
8
-
2002
-
VBR
Standard
Antenna (Included):
2.4GHz TNC Portable Antenna (For
distances up to
6
00 feet*)
49
-
1201
Optional Antennas and Accessories –
Used to increase range in both non line of sight and line of sight
applications.
-
Contact BWI Eagle for recommendations
2.4GHz Thru
-
Hole Mount Mobile Antenna
49
-
2201
2.4GHz Magnetic Mount Mobile Antenna
49
-
2202
2.4GHz Omni Directional Antenna
49
-
3201
2.4GHz 13dB Yagi Antenna
49
-
3202
Flex Coax Cable w/Connectors –
Connects external antenna(s) to base
unit(s).
49-4000-XX
(XX = # of Feet)
Inline Lightening
Arrestor
49
-
5002
2 Ft. Bulkhead Assembly (Used when
mounting receive inside another enclosure)
49
-
5004
* = Line of Sight
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects in material and workmanship
for a period of 1 year after date of purchase. Said warranty to include the
repair or replacement of defective equipment. This warranty does not
cover damage due to external causes, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair, improper installation, or improper
testing. This limited warranty, and any implied warranties that may exist
under state law, apply only to the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warranty replaces all other warranties, express or implied including,
but not limited to, the implied warranties or merchantability and fitness for
a particular purpose. BWI Eagle makes no express warranties beyond
those stated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allow the exclusion of implied warranties so this limitation may not
apply to you. To obtain warranty service, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss during shipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 03/01/2019 / PRODUCT REV. 9
