Solace LoRa Data RF Kit User manual

INSTALLATION
GUIDE
MODEL
PARTS
PROGRAMMING
solaceremotestarters.com REV.02/02/18
LoRa Data RF Kit
DATA PROTOCOL SELECTION
With the Antenna plugged in and powered up:
1 Leave Ignition in OFF position
2 Press programming button (antenna button) 8x within 10 seconds (White LED will flash 2x)
3 Choose your protocol below by pressing the programming button:
TYPE 1 - Press 2x - Solace RF (Default)
TYPE 2 - Press 4x - iDatalink RF
TYPE 3 - Press 6x - Fortin RF
TYPE 4 - Press 8x - D2D
TYPE 5 - Press 10x - Future Use
4 After 3 seconds White LED will flash the number of times according to your selection.
DAC-ADPTREMOTESANTENNA
REMOTE
PROGRAMMING
REMOTES MAY BE
DIFFERENT THAN
PICTURED
REMOTE PROGRAMMING - ONLY REQUIRED FOR D2D
Follow the “Remote Programming Procedure” from the manufactures programming instructions.
Visit the appropriate website or download the “LoRa Antenna Full Guide w/modules” at
www.solaceremotestarters.com
For Devices that do not have a remote coding procedure follow the procedure below.
ANTENNA IN RF CONN 2
RF CONN 3
BLACK - GROUND
RED - 12V+ (FUSED)
RF CONN 1
STEP 1STEP 2STEP 3STEP 4STEP 5
Turn the
Ignition ON then
OFF 2x leaving it in
the ON position at
the 2nd time.
Press and release the
programming button on
the antenna 2 times.
The LED will ash 1x then
2x.
Turn the
Ignition OFF
to exit
programming.
Press and hold for 3 seconds
until LED ashes turns on solid.
Release programming
button.
Press the button on each
transmitter. LED on
antenna will ash 1x
for each remote
programmed.
2X HOLD
x1

INSTALLATION
GUIDE
MODEL
solaceremotestarters.com REV.02/02/18
LoRa Data RF Kit Module Connection
Fortin
iData
DEI
EVO-ALL
DBALL 2 / 3
EVO-ONE
iDATASTART ADS-AL-CA
Solace
“S” Series “i” Series
4/5X10 , DS4 / +
IC4
ANTENNA IN RF CONN 2
RF CONN 3
RF CONN 1
BLACK - GROUND
RED - 12V+ (FUSED)
RF CONN 1 - iDATALINK / EVO-ONE
RF CONN 2 - D2D
RF CONN 3 - EVO-ALL
DAC-ADAPT
ANTENNA IN ANTENNA IN
BLACK - GROUND
RED - 12V+ (FUSED)
BLACK - GROUND
RED - 12V+ (FUSED)
TYPE 1
TYPE 2
TYPE 3
TYPE 4
RF CONN 3 RF CONN 1
RF CONN 1
RF CONN 1
RF CONN 2RF CONN 2
