Solar SIS C25M 1848 User manual

Solar Infra Systems Int. Ltd Issue 12/12/2012
What is an Air Solar Heater
This SIS air solar heater uses the sun’s
solar energy to heat air through a window in
the home, apartment, cottage, boat, RV, and
circulate this heated air in the room. This is
not a solar PV panel or solar water heater.
The heater is hung or placed in a south
facing closed window inside the room or
space to be heated.
This SIS model air solar heater heats air.
It is like an electric room convection air space
heater except it is operated by the sun’s solar
energy. Hang or set it in a sun facing window,
or side-ways, or even upside down, and it will
maintain heat in a large room or area in the
home. The heating capacity is equivalent to a
150 to 500 watt electric heater, depending on
the daytime sun and cloud cover.
The model air solar heater is also
transparent and will still let most of the
window sunlight into the room.
Sunlight and a PV panel also operate a
fan on the heater. The fan draws the room air
into the heater and then pulls the air through
metal solar energy collectors heated by the
sun. The solar heated air is recirculated back
into the room. The fan has a speed control so
the air exchange in the room can be set,
usually to 1 to 1-1/2 hours, at up to 75 cubic
feet per minute.
Patented technology and
international patents pending.
IMPORTANT
This SIS solar air
heater is designed for
interior installation behind
a single pane window for
best efficiency. Double
pane, low-E, argon, and
triple pane will reduce this
efficiency to less than 40%
to 65%. .
The SIS Solar Air
Heater, mounted inside
the room, behind the
window glass, reverses
this heat loss, collects the solar heat coming
through the glass, and heats the air in the
room. Ordinary single glazing works best with
an interior Air Solar Heater.
SIS has a range of exterior mount models
that are not affected
by glass obstruction
and are capable of
heating an entire
house. For more
information call 1 855
535 2056 or email us
at
[e-mail]
Also the perfect answer to
heating sheds, garages,
cottages, and stored boats and
RV’s where there is limited or
no electricity.
Solar-Infra Systems International Ltd
209-19138 26th Avenue, Surrey, BC, V3S 3V7
Canada. Toll Free 1-855-535-2056
T-604-535-2056 F-604-535-0681
www.solarinfrasystems.com
OPERATING INSTRUCTIONS
SOLAR THERMAL AIR HEATER
Consumer Model SIS C25M 1848
Issue 1/6/2013e
The SIS Air Solar Heater Installation
1. Hang, or set on the sill, in a south facing window. The window should be
ordinary single glazing. Turn the speed control knob to maximum.
2. Large glass areas, such as solariums, can have too much heat loss through the
glass to the air outside, for this size of SIS air solar heater. It may require more
than one heater or a larger model. Please contact us at
[e-mail] and we will help you size the solar heating.
3. The Solar Heater can be mounted between the window and a venetian blind.
Make sure the blind is open enough to allow fan recirculation into the room.
4. Use the fan speed control to adjust the room temperature. The slower the air
flow, the higher the outlet temperature, because of the increased air retention
time in the heater. Rooms and home areas usually are planned for 1 to 2 air
changes every three hours. Turn the knob clockwise to increase the air flow.
5. The fan capacity is 75 cubic feet of air per minute. Divide this into the volume of
the room or heated area and this will show the number of air changes per hour.
6. For example:
Air changes = Room 20ft x 15ft x 10 ft high = 3000 cubic feet volume.
Air Changes= 3000 cubic ft = .66 air changes per hour
75 cu ft/min x 60 min/hr (~2 air changes every 3 hours)
7. Cloudy, low sunlight, or rain conditions may not produce enough Photovoltaic
Panel energy on the front of the heater to operate the fan, even though there
may be enough solar energy for the heater to add 3-4 degrees to the room
temperature. Use the AC adapter to operate the fan from household power. (a
timer can schedule the fan for day use only). The cost is minimal.
8. For cottages and homes without power, an optional large PV panel will be
available for increased sensitivity for low sunlight conditions.
9. WHAT IS YOUR PAYBACK: We use a NASA/Government program that
calculates the energy savings and heating output in most locations in the world.
Email your location, home area, electricity cost per kWh, heating fuel and unit
cost, and we will send you the time payback estimate on the savings in energy
by using an air solar heater or fill in form at www.solarinfrasystems.com
Don’t forget to fill out the
Warranty Card and the Solar
Energy Payback Estimator
Radiative
Conductive
Total Compared to
Heat Heat Heat Single Pane Indoor
Window Construction Loss Loss Loss Heat Loss Glass
(Btu/hr/ft2) (Btu/hr/ft2) (Btu/hr/ft2) Reduction Temp(°F)
Single Pane Clear 35 21 56 ---- 26
Double-Pane Clear 21 13 34 39% 44
Double-Pane Low-E 5 15 20 41% 54
Double-Pane Low-E Argon 2 16 18 47% 56
Triple-Pane Low-E 2 11 13 62% 59
Triple-Pane Low-E Argon 1 11 12 65% 60

Solar Infra Systems Int. Ltd Issue 12/12/2012
SIS Model C25M 1848
SPECIFICATIONS
Specifications subject to change without notice.
Dimensions
Controls
Turn the Fan Speed Control
knob clockwise to increase the
fan circulation. Start out with
this setting until you find the
room temperature comfortable.
Turn off the fan when
you do not want the heater
to operate.
Sun Orientation
US Metric
Peak EfficiencyAve 80% 80%
Ave Max DailyPower
Output 1
736 btu/hr/sqft 2.32 kWhr/m2
Window Mounting Single Glaze Single Glaze
Heater Mounting Tilt
in Window
Vertical (90°) Vertical (90°)
Azimuth (Direction
facing Sun)
0° (Due South) 0° (Due South)
Ave Total Annual
Solar Radiation 2-
Tilted (90°) 12 mon
3.7mbtu/sqft 1,090 kWh/m2
Total Annual Heating
Delivered (9 mon)
4.1 mbtu 1201 kWhr
Air Flow Range 10-75 cfm 17-127 m3/hr
Max Air Pressure .093inH2O 2.37mmH2O
Noise Level 32.95db 32.95db
Ave Temperature
Increase3 Sept-May
44.8 °F 24.9°C
Max Air Temperature
Increase
110°F 45°C
Solar Collector Infra
Red Absorption
95% 95%
Solar InfraRed
Transmission
Polycarbonate Panel
90% 90%
Number of Staged
Solar Collectors
26 26
Staged Collector
Projected Area
45.64sqft 4.24m2
PV Panel 7W14vdc 7W 14vdc
AC Adapter AC 110/220vac-12 vdc 500ma
Collector Material aluminum/steel aluminum/steel
Plastic Panel4
Materials
UL94v-0 UL94v-0
Heater Weight 15lbs 6.8 kg
1. Based on 80%ofsolarradiationon90
tilted heater(vertical) behind
single glazewindow at49
N lattitude. 9months of year (Sept toMay)
2. RETScreen data(NRCan/CanmetENERGY) (NASAsolar data)
3. Retscreen 49
Nlatitude -123.1
Elongitude.
4. Underwriter'sLaboratories -selfextinguishing.Conformsto windowand
wall coveringbuildingstds.
Turn Fan
Control
Knob to
maximum
An AC adapter is
supplied to operate
the fan when cloudy
or low sunlight
conditions are not
enough for the PV
panel to operate the
fan. Plug in the AC
adapter into the
heater and adjust the
fan speed.
20deg
20deg
True
South
South (or North in the southern
hemisphere) facing covers 20 degrees
on both sides of a true south. More east
catches morning solar and west
catches afternoon solar.
Watch for roof eves that overhang
and shade the window and heater as
well as trees and buildings that block
the sun’s path.
WARRANTY TERMS
If a defect arising solely from faulty hardware, materials or workmanship appears under proper use of this equipment:
For defects in hardware, materials and workmanship, within a period of 12 months from the date of purchase, Solar Infra Systems will repair the defect, or at its option, replace the defective
part or parts.
The main exclusions from the warranty are if the equipment has been:
1. Neglected, mishandled or inappropriately used; or
2. Modified or altered in any way except with the prior approval of Solar Infra Systems.
Solar Infra Systems is not liable for any consequential loss.
1 Solar Infra Systems is not liable to the Buyer for any defect unless the Buyer immediately gives Solar Infra Systems notice in writing or email of the alleged defect with full
particulars of the operating conditions under which it became apparent and returns this equipment, or relevant part, shipping paid to Solar Infra Systems.
2 Any items returned to Solar Infra Systems are at Buyer’s risk. Repaired or replacement items will be despatched shipping paid to the address requested by Buyer.
3 Solar Infra Systems total liability relating to the supply of this equipment is limited to the Buyer’s purchase price of the product .
The warranty is given to the Buyer of this equipment from Solar Infra Systems or Solar Infra Systems subsidiaries.
The warranty cannot be transferred by the Buyer to any other person or company.
Contact: email:[e-mail] Tel: Toll Free 1-855-535-2056.
Solar-Infra Systems International Ltd
209-19138 26th Avenue, Surrey, BC, V3S 3V7
Canada. Toll Free 1-855-535-2056
T-604-535-2056 F-604-535-0681
www.solarinfrasystems.com
Don’t forget to fill out the Warranty Card and the Solar Energy Payback Estimator

SIS Air Solar Heater
Retscreen Performance Estimate
SOLAR PAYBACK ESTIMATOR: See What Air Solar Heating Can Do!
Please fill out this form and we will run a RETScreen analysis for you
to show the air solar heating and the cost savings estimate. (Mail, fax, or email)
Name
Email
Telephone
1Location: Country, state, prov, etc
2Nearest large City
3Heating Period (example Oct to May) please check
4Your average inside temperature degF degC
5Do you have a South facing wall, roof,
or direction ?? To sun path.
6Shading from trees, buildings, in season % estimated
7
Home, Apartment, Building
aApproximate area sqft sqM
bNumber of floors
cBasement insulated or not
dWindow glaze on south facing side
Single glaze
Double glaze
Other
eR-value for roof and walls
fApprox age of building
8 Electricity and Heating System
aCost of electricity per kilowatt hour
bHeating fuel (gas, oil, propane,etc)
cCost per unit of heating fuel
(gal, therm, GJ, liter, cuM, etc)
eAge of furnace
fLast serviced
gHeating system efficiency
hHave you had an energy audit?
iSend me RETScreen File
(requires Microsoft Office Excel)
We use RETScreen to analyze an air solar heating unit or system for your application. The program
was developed by Natural Resources Canada, using NASA solar data. The program is used world-
wide since the 1990's and has solar data for most world locations. The program is a free download
at www.retscreen.net. (You need Microsoft Office Excel to use the program). We normally send you
a PDF file of the results of the analysis, but we can also send a RETSCreen file to run more
comparisons.
Solar-Infra Systems International Ltd 209-19138 26th Avenue, Surrey, BC, V3S 3V7 Canada.
Toll Free 1-855-535-2056
T-604-535-2056 F-604-535-0681 www.solarinfrasystems.com email: [email protected]
Issue 1-3-2013

SIS Air Solar Heater
Retscreen Performance Estimate
Radiative
Conductive
Total Compared to
Heat Heat Heat Single Pane Indoor
Window Construction Loss Loss Loss Heat Loss Glass
(Btu/hr/ft2) (Btu/hr/ft2) (Btu/hr/ft2) Reduction Temp(°F)
Single Pane Clear 35 21 56 ---- 26
Double-Pane Clear 21 13 34 39% 44
Double-Pane Low-E 5 15 20 41% 54
Double-Pane Low-E Argon 2 16 18 47% 56
Triple-Pane Low-E 2 11 13 62% 59
Triple-Pane Low-E Argon 1 11 12 65% 60
In house windows, the U factor is the rate of heat loss, through the glass of the window, from inside the house to the outside. The heat
loss rate depends on the difference between the temperature inside the room and outside the house. Double glazing, Low E, some tints,
reduce the heat loss through the window.
The SIS Solar Air Heater, mounted inside the room, behind the window glass, reverses this heat loss, collects the solar heat coming
through the glass, and heats the air in the room. Ordinary single glazing works best with a Solar Air Heater.
IMPORTANT
The SIS Consumer Model is designed for interior use, inside a single pane south-facing
window, and not for outdoor applications.
Double pane, Low-E, Triple Pane, all reduce the amount of solar heat that enters the
window. The efficiency of the interior air solar heater will decrease, compared the single
pane windows.
The SIS Consumer Solar Air Heater, mounted inside the room, behind the window glass, reverses
this heat loss, collects the solar heat coming through the glass, and heats the air in the room.
Issue 1-3-2013

Thank you for purchasing a Solar Infra Heater
Detailed information and a hanging kit is found in the instruction
package
Please note that this package also contains an A/C to D/C adapter.
Please remove all plastic wrap before activating the unit in the sun
The unit must be placed on the inside of a south exposed window
This unit is not designed for exterior or outdoor installations. Other
models with waterproof fans are available
Efficiency ratings have been measured from behind single pane
windows. The efficiency will decrease when behind thermo pane or
“E” glass that reduces infra red energy transmission. Solar infra can
tell you the length of time it will take for this unit to pay back the
purchase price in energy savings based on the season, your location
and local energy costs. Please email us at [e-mail]
or call toll-free at 1 855 535 2056
The heater may be simply placed on the windowsill
leaning against the glass or suspended from the window
header with the supplied mounting kit. The discharge
fan must face the interior of the room
Please retain the original shipping carton for a period in case of any
issues you may have with our product and contact us directly.
[e-mail]
Toll free @1 855 535 2056
