SolaX Power X1-Meter-WiFi User manual

Please read this guide carefully before use.
X1-Meter-WiFi
Quick Installation Guide
01 02 03 04
www.solaxpower.com
614.00258.00
Cut off all power of inverter
before installation!
Wait for 5 minutes after
power off.
Installation
Unscrew the two screw in the
middle of plastic meter box.
The box will be separated into
two parts.
Fix the base cover of box.
1
Connect wires.
Step1: L/N wire and aerial
connection.
Step2: C/ T connection.
I
First, open the C/ T;
Then, View the bottom-marked
current ow of C/T, grid-L wire
across C/T from bottom-marked
L to N;
Last, close the C/ T.
You can x it on the wall or other
place.
23
To grid-NTo grid-L
MK -1 4 9远程计量导轨表
60A
50Hz
运行
反向
WI FI
UL UN
AC22 0V
I-I+AB
RS48 5 电流互 感器
通讯
aerial
grid-L
k l
grid-L wire across C/T from
bottom-marked L to N

06 07 08 09
Power on inverter before
connecting to WiFi!
Please refer to WiFi user manual.
05
Screw the two screw in the
middle of plastic meter box.
MK -149远程 计量导 轨表
60A
50Hz
运行
反向
WI FI
Login monitoring website.
Input “www.solax-portal.com” on
web browser. Fill up username
and password, then click “Login”
to enter home page.
Note: Conrm WiFi conguration
has done successfully, and make
sure Internet service is
accessable.
Click “Inverters”, then edit
related inverter, ll in “Power
meter SN”, click “save”.
Click “Overview” page, user
can monitor inverter and
check the data.
Click “Report Analysis”, then
click on “view ”. User can see
below value display.
Note: Running and WiFi light will
be on.
10
Note: Please make sure the
inverter has been added to the
site. If not, Please refer to WiFi
user manual.
WiFi connection
II Related meter to
solax-portal.com
III
5
1
2 3
4
Press meter on the base cover
of box, then cover the top
cover of box.
Place the top cover
on the base cover.
UL UN
AC220V
I-I+AB
RS485 电流互感器
通讯
MK-149远程 计量导轨 表
60A
50Hz
运行
反向
WIF I
