SOLDER PEAK ZD-409 User manual

Tweezers soldering iron - Model: ZD-409
1.
2. Features
• Twin-tube heating, direct contact with the components, no impact on the surrounding components.
• Especially suitable for rework on mounted circuit board.
• Energy-saving, highly efficient and suitable for circuit board components, intensive soldering and desol-
dering.

• Working together with soldering station, it can remove flake resistor and condenser and SOP elements.
• Rapid heat-up and cooling off.
3. Specifications
• Voltage: 220-240V
• Power: 48W
4. How to use:
Plug it in and it will heat up in three minutes.
Connect the two tips on welding spots for soldering and de-soldering
performance in three seconds.
5. Caution:
1. This appliance is not a toy, and must be kept out of children’s hands.
2. Before cleaning the appliance or changing the filter, always unplug it. Unscrewing the housing is not
permitted.
3. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
4. Turn to professional for cord replacement or service.
6. Warnings:
• Always keep tips tinned to ensure a long life.
• Handle the heated soldering iron with extreme care, as the high temperature of the iron can cause fires
or painful burns.
• This tool must be placed on its stand when not in use.
• Children should be supervised to ensure that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
