Soleus Air DME-95IP-01 User manual

3092402
V151214
95 Pint Portable Dehumidifier
With Internal Pump
Model Number: DME-95IP-01
Operating Instructions

2
General Dehumidifier Information
RECOMMENDED HUMIDITY LEVELS
 Spring/Summer: 35% - 50%
 Fall/Winter: 35% - 40%
WARM AIR EXHAUST IS NORMAL
During operation your dehumidifier will exhaust warm air from the top of the unit. This is normal operation.
EMPTYING THE BUCKET
The more moisture your dehumidifier removes from the air, the more often you may have to empty the bucket
(unless you are using the continuous drainage option). The number of times the bucket will be emptied de-
pends on the dehumidifier model.
LESS MOISTURE BEING REMOVED OVER TIME IS A GOOD THING!
Using a dehumidifier will cause your area to maintain a more comfortable humidity level. Over time, this
humidity level will become more and more stable. Due to the stable humidity level in the area, the
dehumidifier will need to remove less and less moisture over time.
Please do not be concerned if the dehumidifier is removing less moisture from the air or the bucket is taking
longer to fill up. This is a direct result of your dehumidifier creating a more stable humidity level in your area.
DON’T REMOVE THE STYROFOAM IN THE BUCKET!
All Soleus Air dehumidifiers are equipped with a reliable Styrofoam float system. The Styrofoam located in-
side the float in the bucket is essential to the bucket full system working properly. Please do not remove the
Styrofoam from the float.
Model Number
Reference Number
Pints of moisture removed per every
24 hour period
Maximum number of times to empty
the bucket when operating at full
capacity during a 24 hour period
DME-95IP-01
95 Pints Up to 9 times

3
FEATURES
Removes up to 95 pints of moisture from the air every 24 hours.
This is not the bucket size.
Adjustable humidistat for precise humidity control.
Digital humidistat displays set humidity level and current room
humidity level.
Operates at temperatures down to 41°F. Perfect for basement
use in the winter.
Automatic defrost function melts away ice from frozen coils for
continuous, worry-free operation.
3-Speed fan allows you to choose between maximum dehumidi-
fying power or quiet operation.
Bucket full indicator and audible alarm signals as soon as the
bucket is full and ready to be emptied.
Ultra quiet operation allows for use almost anywhere. Perfect for
heavy traffic areas like a family room or bedroom.
Loss of power protection remembers all settings even when
power is interrupted.
Auto-restart automatically continues operation when power is re-
stored. No need to manually restart the dehumidifier.
24-Hour Timer automatically turns on and off the unit after the
preset time of 0.5 up to 24 hours.
MyHome modes allow you to choose the location in which you
are using your dehumidifier (Sleeping Space, Living Space or
Basement) for preset comfort and balanced operation.

4
Thank you for choosing a Soleus Air Portable Dehumidifier. This owner’s manual will provide you
with valuable information necessary for the proper care and maintenance of your new product. Please
take a few moments to thoroughly read the instructions and familiarize yourself with all the opera-
tional aspects of your new Dehumidifier.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT INSTRUCTIONS
Before installing and using your dehumidifier, please read this owner’s manual carefully. Store this manual in a
safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this
manual.
3) Maintain at least 12-18 inches clearance space around this unit. Do not block or cover air inlet or outlet
grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced
by the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.

5
SPECIFICATIONS
 Noise level is measured at a distance of 3.28 ft away from the front of the unit.
 Power consumption is measured when the fan runs at the highest speed setting.
 These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE
PRESENTATION OF THE MANUFACTURER. SOLEUS HOME COMFORT HAS NOT CONDUCTED INDEPENDENT
TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED HEREWITHIN.
PACKAGE CONTENTS
(1) Portable Dehumidifier
(1) Operating Instructions
(4) Casters
(1) Garden Hose Connector Extension Adapter
(1) Internal Pump Drain Tub Kit
Bucket Capacity 13 Pints
Model Number
DME-95IP-01
Dehumidifying Capacity 95 Pints per day
Power Consumption (Watts) 740 Watts
Air Flow Volume (High/Med/Low) 323/ 247/ 176CFM
Power Source 115 V / 60 Hz
Rated Current (Amps) 7.1A
Sound Pressure Level (High/Med/Low) 60/55/50 dB(A)
Weight 59.4lbs
Dimensions
(W x D x H) 18.375” W x 14.5” D x 24.625” H
Energy Star No

6
CASTER INSTALLATION
Tilt the dehumidifier no more than 45⁰and forcibly insert the casters. Make sure the ring around the caster is
flush against the bottom of the dehumidifier.(Fig.1)
CONTROL PANEL & DIGITAL DISPLAY
INCREASE/DECREASE
Room
Humidity Level
Preset
MODE
Button
Child-Lock LED
Indicator
Bucket Full
LED Indicator
Power On
LED Indicator
Digital Humidistat
Display
MyHome MODE LED
Indicators
Fan Speed
LED Indicators
TIMER
Button FAN
SPEED
Button
Pump Mode Button
Clean Filter
LED Indicator
Timer On
LED Indicator
FILTER
Button
POWER
Button

7
OPERATING INSTRUCTIONS
1) When first operating the dehumidifier, run it in Continuous mode for 24 hours.
2) Power On and Off - Press the POWER button once to manually turn the unit on. Press the POWER
button once more to turn the unit off.
3) Humidity Selection - Press the or buttons to choose the desired relative humidity in the room.
Each press of the button will change the desired room humidity by 5%. The room humidity is selectable
from 35%-80% or continuous. The unit will cycle on and off to maintain the humidity level chosen on the
digital display. If you want the dehumidifier to operate continuously regardless of the room humidity, press
the MODE button until you see “CO” on the digital display. This will enable continuous operation and
the “Continuous” indicator will light up on the control panel.
4) Fan Speed Control - Press the FAN SPEED Button to cycle through the different fan speeds: High,
Medium, and Low. The fan speed can be visually distinguished by the fan speed indicators on the control
panel.
5) Timer Auto On- To program the unit to automatically turn on, press the TIMER button when the unit is
off. Each press of the button will change the timer setting to 30 min increments (.5 hours). After 10 hours,
each press of the TIMER button will increase the timer in 1 hour increments. Once the desired time is
reached, the unit will automatically turn on.
Timer Auto Shut-Off- To program the unit to automatically turn off, press the TIMER button when the
unit is on. Each press of the button will change the timer setting to 30 min increments ( .5 hours). After 10
hours, each press of the TIMER button will increase the timer in 1 hour increments. Once the desired time
is over, the unit will automatically shut down.
OPERATING INSTRUCTIONS

8
OPERATING INSTRUCTIONS
6) Bucket Full - When the water bucket is full of water, the unit will automatically shut off , make a beeping
noise, and the Bucket Full Indicator will light up. The dehumidifier will not function until the water
bucket is emptied and placed back inside the unit. The bucket should be cleaned every few weeks to prevent
the growth of mold, mildew and bacteria. Use a mild detergent to clean the bucket. Once clean, completely
dry the bucket and place it back inside the dehumidifier.
NOTE: When the bucket is full or removed from the machine, the compressor will turn off, but the fan
will continue to run for a few minutes. This is completely normal. The dehumidifier will not be remov-
ing moisture from the air at this time.
NOTE: When removing moisture from the air, the dehumidifier will exhaust warm air from the top ex-
haust vent.

9
7) Clean Filter - When the filter needs to be cleaned, the filter indicator will light up (after 250 hours of
use). Remove the filter from the front of the unit by completely removing the dehumidifier bucket with two
hands and then pulling down on the filter tab directly below the front intake grill. Clean the filter with
warm, soapy water. Dry thoroughly before replacing the filter. Once the filter is completely dry, place the
filter back in the unit and press the FILTER button to reset the filter indicator.
CAUTION: DO NOT OPERATE THE DEHUMIDIFIER WITHOUT THE INCLUDED FILTER
8) MyHome Mode - Preset location settings allow the user to easily move the dehumidifier room-to- room
and select the corresponding mode for the location in which the dehumidifier is operating for optimum per-
formance. Choose from Sleeping Space, Living Space or Basement.
9) Child-Lock Mode- To lock the control panel, press the and buttons at the same time for 3 seconds.
Locking the control panel prevents someone from accidentally changing the settings. When locked, the
LOCK Indicator will light up. Hold the and buttons at the same time again for 3 seconds to unlock
the control panel.
OPERATING INSTRUCTIONS
NOTE: Do not clean filter in dishwasher

10
10) Internal Pump Mode- The internal pump allows the unit to operate without having to empty the bucket.
Included is a Drain Pump Hose Kit. To install the Pump Drain Hose Kit, open cover on the back of the
unit. Insert the included Gasket into the Drain Adapter. Force the Drain Hose onto the Drain Adapter. Lo-
cate the UPPER drain port on the back of the unit. Then install the Drain Adapter with Drain Hose onto the
upper drain port on the back of the unit as pictured below. Once securely installed, lead the Drain Hose to a
nearby drain, sink or out of a window up to 16’ height from the base of the unit. Turn on the unit and press
the PUMP button to activate the internal pump.
NOTE: While in Pump Mode, if the unit is turned off, the pump will remove all remaining water from inter-
nal tank prior to the unit completely powering down, the pump indicator light will stay on in this period.
Please don't unplug power cord until pump indicator light is off.
