Soleus Air DS1-30-01B User manual

3058080
V.181113
Dehumidifier must be upright for 24 hours prior to operating.
This ensures that the compressor will function as intended.

Thank you for choosing a Soleus Air Portable Dehumidifier. This Owner’s Manual will provide
you with valuable information necessary for the proper care and maintenance of your new product.
Please take a few moments to thoroughly read the instructions and familiarize yourself with all the
operational aspects of your new Soleus Air Portable Dehumidifier.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the
store name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: _____________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
Before installing and using your dehumidifier, please read this owner’s manual carefully. Store this manual in
a safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this manual.
3) Maintain a 12-18 inch clearance space around this unit. Do not block or cover air inlet or outlet grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit directly by a bathtub, shower or swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced by
the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.
IMPORTANT INSTRUCTIONS
PURCHASE INFORMATION

RECOMMENDED HUMIDITY LEVELS
• Spring/Summer: 35% - 45%
• Fall/Winter: 45% - 55%
WARM AIR EXHAUST IS NORMAL
During operation, your dehumidifier will exhaust warm air from the side of the unit. This is normal operation.
EMPTYING THE BUCKET
The more moisture your dehumidifier removes from the air, the more often you may have to empty the bucket
(unless you are using the continuous drainage option). The number of times the bucket will be emptied de-
pends on the dehumidifier model.
LESS MOISTURE BEING REMOVED OVER TIME IS A GOOD THING!
Using a dehumidifier will balance the humidity level in your room, creating a more comfortable space. Over
time, this humidity level stabilizes, resulting in less moisture accumulating in the air. As this moisture level
decreases, the dehumidifier will not need to collect as much moisture as seen in previous operation.
Please do not be concerned if the dehumidifier is removing less moisture from the air or the bucket is taking
longer to fill up. This simply means that your dehumidifier is working as intended and creating a more stable
humidity level in your space.
WATER IN THE BUCKET!
There might be a small amount of water present in the bucket before using the dehumidifier for the first time.
This is caused by the preliminary testing done by the factory and is normal.
Model Number Pints of moisture removed per
24 hour period
Maximum number of times to
empty the bucket when operating
at full capacity during a 24 hour
period
DS1-30-01 30 Pints 4 Times
DS1-45E-101 45 Pints 6 Times
DS1-70E-101 70 Pints 5 Times
DEHUMIDIFIER INFORMATION

• Noise level is measured at a distance of 3.28 ft away from the front of the unit.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE PRESENTATION OF THE
MANUFACTURER. SOLEUS N.A. HAS NOT CONDUCTED AN INDEPENDENT TEST TO THE INFORMATION AND THE SPECIFICATIONS PRE-
SENTED HEREWITHIN.
(1) Portable Dehumidifier
(1) Operating Instructions
(4) Casters *Pre-installed on 70 Pint Model
Model Number DS1-30-01 DS1-45E-101 DS1-70E-101
Dehumidifying Capacity 30 Pints per day 45 Pints per day 70 Pints per day
Power Consumption (Watts) 445 Watts 445 Watts 690 Watts
Air Flow Volume
(High/Med/Low) 147/129/111 CFM 147/129/111 CFM 205/188/164 CFM
Power Source 115 V / 60 Hz 115 V / 60 Hz 115 V / 60 Hz
Rated Current
(Amps) 2.87 A 4.0 A 6.0 A
Sound Pressure Level
(High/Med/Low) 53/51/49 dB(A) 53/51/49 dB(A) 53/51/49 dB(A)
Weight 31.1 lbs 33.7 lbs 46.9 lbs
Dimensions
(W x D x H)
13.75” W x 10” D x
19.5” H
13.75” W x 10” D x 19.5”
H
15.25” W x 11.25” D x
24.875” H
Energy Star No Yes Yes
Bucket Capacity 8.5 Pints 8.5 Pints 16.9 Pints
PACKAGE CONTENTS
SPECIFICATIONS

Removes up to 30/45/70 pints (depending on model) of moisture
from the air every 24 hours. This is not the bucket size.
Adjustable humidistat for precise humidity control.
Digital humidistat displays set humidity level and current ambient
humidity level.
Operates at temperatures down to 41°F. Perfect for basement
use in the winter.
Automatic defrost function melts away ice from frozen coils for
continuous, worry-free operation.
3-speed fan allows you to choose between maximum dehumidify-
ing power or quiet operation.
Bucket full indicator and audible alarm signals as soon as the
bucket is full and ready to be emptied.
Ultra quiet operation allows for use almost anywhere. Perfect for
heavy traffic areas like a family room or bedroom.
Loss of power protection remembers all settings even when
power is interrupted.
Auto-restart automatically continues operation when power is
restored. No need to manually restart the dehumidifier.
24-Hour Timer automatically turns on and off the unit after the
preset time of 0.5 up to 24 hours.
MyHome modes allow you to choose the location in which you
are using your dehumidifier (Sleeping Space—55%, Living
Space—50% or Basement—45%) for preset comfort and bal-
anced operation.
PRODUCT FEATURES

Caster Installation is only required for the 30 and 45 pint models.
(The 70 Pint model includes pre-installed casters.)
1) To install casters on the 30 or 45 pint model, remove the bucket from the dehumidifier. (Fig. 1)
2) Remove and open the box containing the casters from inside the bucket. (Fig. 2)
3) Tilt the dehumidifier no more than 45⁰ and forcibly insert the casters. Make sure the ring around the
caster is flush against the bottom of the dehumidifier. (Fig. 3)
POWER
BUTTON INCREASE/DECREASE
ROOM
HUMIDITY LEVEL
TIMER
BUTTON
FILTER
BUTTON FAN
SPEED
BUTTON
PRESET
MODE
BUTTON
Clean Filter
LED Indicator
Fan Speed
LED Indicators
Child-Lock
LED Indicator
MyHome Mode
LED Indicators
Bucket Full
LED Indicator
Power On
LED Indicator
Digital Humidistat
This button does
not operate or offer
any function
Fig. 1
Timer
LED Indicator
CASTER INSTALLATION
CONTROL PANEL
Fig. 2
Fig. 3
Step 1 Step 2 Step 3

CONTROL PANEL OPERATING INSTRUCTIONS
1) When first operating the dehumidifier, run it in Continuous mode for 24 hours.
2) Power On and Off - Press the POWER button once to manually turn the unit on. Press the POWER
button once more to turn the unit off.
3) Humidity Selection - Press the or buttons to choose the desired relative humidity in the room. Each
press of the button will change the desired room humidity by 5%. The room humidity is selectable from
35%-80% or continuous. The unit will cycle on and off to maintain the humidity level chosen on the digital
display. If you want the dehumidifier to operate continuously regardless of the room humidity, press the
MODE button until you see “CO” on the digital display. This will enable continuous operation and the
“Continuous” indicator will light up on the control panel.
4) Fan Speed Control - Press the FAN SPEED button to cycle through the different fan speeds: High, Me-
dium, and Low. The fan speed can be visually distinguished by the fan speed indicators on the control
panel. For fast dehumidification, choose High. For moderate dehumidification, choose Medium. For quiet
operation, choose Low.
5) Timer Auto On- To program the unit to automatically turn on, press the TIMER button when the unit is
off. Press or to increase or decrease the timer in 30 min increments (.5 hours) up to 10 hours. After
10 hours, each press of the or buttons will increase the timer in 1 hour increments up to 24 hours.
Once the desired time is reached, the unit will automatically turn on.
Timer Auto Shut-Off- To program the unit to automatically turn off, press the TIMER button when the
unit is on. Each press of the or buttons will change the timer setting in 30 min increments ( .5 hours)
up to 10 hours. After 10 hours, each press of the or buttons will increase or decrease the timer in 1
hour increments up to 24 hours. Once the desired time is over, the unit will automatically power off.
6) MyHome Modes - Preset humidity level settings allow the user to easily move the dehumidifier room-to-
room and select the corresponding mode for the location in which the dehumidifier is operating for opti-
mum performance. Press the MODE button to choose from Sleeping Space (55%), Living Space (50%) or
Basement (45%).
7) Child-Lock Mode- To lock the control panel, press and hold the TIMER button for 3 seconds. Locking
the control panel prevents someone from accidentally changing the settings. When locked, the LOCK
indicator will light up. Press and hold the TIMER button for 3 seconds to unlock the control panel.
NOTE: Fan will continue to run even when the compressor is off. This is normal and allows the unit to
circulate air and operate more efficiently.
OPERATING INSTRUCTIONS Dehumidifier must be upright for 24 hours prior to operating.
This ensures that the compressor will function as intended.

8) Bucket Full - When the water bucket completely fills with water, the unit will automatically shut off, make
an audible beep, and the Bucket Full Indicator will light up. The dehumidifier will not function until the wa-
ter bucket is emptied and placed back inside the unit. The bucket should be cleaned every few weeks to pre-
vent the growth of mold, mildew and bacteria. Use a mild detergent to clean the bucket. Once clean, com-
pletely dry the bucket and place it back inside the dehumidifier.
NOTES: When the bucket is full or removed from the dehumidifier, the compressor will turn off, but the fan
may continue to run for a few minutes. This is completely normal. The dehumidifier will not be removing mois-
ture from the air at this time. When removing moisture from the air, the dehumidifier will exhaust warm air
from the side exhaust vent. Do not place a full bucket on the floor because the bottom of the bucket is uneven.
OPERATING INSTRUCTIONS

A Dehumidifier operating in a basement will have little or no effect in drying
out an adjacent enclosed storage area, such as a closet, unless there is adequate
circulation of air in and out of the area.
• Do not use outdoors.
• This dehumidifier is intended for indoor use only. Place the dehumidifier on
a smooth, level floor surface that is strong enough to support the unit with a
full bucket of water.
• Allow at least 18” of air flow on all sides.
• Place the dehumidifier in an area where the temperature will not fall below
41°F. The coils can become covered with frost at temperatures below 41°F,
which may reduce performance.
• Use the dehumidifier in areas that have excessive moisture such as entry-
ways, bathrooms, basements, and laundry rooms. NOTE: Place the dehumid-
ifier away from a clothes dryer.
• Use the dehumidifier to prevent moisture damage anywhere books or valuables are stored.
• Use the dehumidifier in a basement to help prevent moisture damage.
• The dehumidifier must be operated in an enclosed area to be most effective.
• Close all doors, windows and other outside openings to the room.
When frost builds up on the evaporator coils, the compressor will cycle off and the fan will continue to run un-
til the frost disappears. When the coils are completely defrosted, the compressor will automatically restart and
dehumidification will resume.
CHOOSING A LOCATION
AUTOMATIC DEFROST
END OF SEASON STORAGEEND OF SEASON STORAGE

Garden Hose Installation Setup
Water can be automatically emptied by attaching a garden hose to the continuous drainage port on the back of
the dehumidifier. This will allow the unit to run continuously (depending on the selected humidity level) with-
out having to empty the water bucket. To drain, simply attach a standard garden hose (not included). The
thread standard for garden hoses in the US and its territories is known as GHT or "garden hose thread" which
has an outer diameter of 1 1/16 inches (1.0625 inches or 27.0 mm) and a pitch of 11.5 TPI.
• Place dehumidifier on a level surface
• Unscrew the cap on the back of the unit to access the garden hose nozzle
• Thread a garden hose (not supplied) onto the accessible nozzle, lead to a floor drain and cut to length
• Make sure that there are no kinks or knots in the garden hose (See picture below)
• Turn on the unit and press the MODE button until set to CONTINUOUS
Garden Hose Installation Reference Guide
IMPORTANT NOTES:
Placing the dehumidifier on an uneven surface or improper hose installation may result in water filling up the
bucket and cause the unit to shut off. Empty bucket if shut-off occurs, then check dehumidifier location and
hose for proper setup. The bucket must be in place and securely seated for the dehumidifier to operate.
For more details, please scan below QR code for operation instruction video:
CONTINUOUS DRAINAGE

Note: Make sure power is off and the power cord is not plugged into an elec-
trical outlet prior to performing any maintenance on the unit.
Clean or Replace Filter - The Clean Filter indicator will illuminate every 250 hours of operation as a
reminder to clean the filter. A clean filter will keep the unit operating at optimum performance. Remove the
filter from the back of the unit by using your thumbs to press down on the filter tabs directly above the filter.
Clean the filter with warm, soapy water. Dry thoroughly before replacing the filter. Once the filter is complete-
ly dry, place the filter back in the unit and press the FILTER button to reset the filter indicator.
CAUTION: DO NOT OPERATE THE DEHUMIDIFIER WITHOUT THE INCLUDED FILTER
Clean the Unit Housing -
1) Keep the unit from being exposed directly to the sun to prevent color
fading.
2) Clean the surface with a damp cloth and dry it with a soft towel.
MAINTENANCE
End of Season Storage / Transporting the Unit
1) Turn off the dehumidifier
2) Unplug the unit and secure the power cord to the back of the unit
3) Clean or replace filter - Refer to Operating Instructions Clean or Replace Filter section
4) Empty any water remaining in the bucket and rinse bucket with a mild detergent
5) Insert the empty water bucket back into the dehumidifier
6) Your dehumidifier is now ready for storage or transportation
7) The unit should be stored in a cool dry place
NOTE: While in Pump Mode, if the unit is turned off, the pump will remove all remaining water from inter-
nal tank prior to the unit completely powering down. The pump indicator light will stay on during this period.
Do not unplug the power cord until pump indicator light is off.
NOTE: Do not clean filter in dishwasher

Problem Possible Causes Solutions
Dehumidifier does not start The dehumidifier is unplugged. Make sure the dehumidifier’s plug is pushed completely into
the outlet.
The fuse is blown / circuit break-
er is tripped.
Check the house fuse / circuit breaker box and replace fuse or
reset breaker.
Dehumidifier has reached its
present level or the bucket is full.
The dehumidifier automatically turns off when either condi-
tion occurs. Change to a lower setting or empty the water
bucket and replace properly.
Bucket is not in the proper
position.
The bucket must be in place and securely seated for the dehu-
midifier to operate.
Power failure. There is a protective time delay (up to 3 min.) to prevent trip-
ping of the compressor overload. For this reason, the unit may
not start normal dehumidification for 3 min. after it is pow-
ered back on.
Dehumidifier does not dry the
air as it should
Not enough time allowed for unit
to remove moisture.
When first installed, allow at least 24 hours to maintain the
desired dryness.
Airflow is restricted. Make sure there are no curtains, blinds, or furniture blocking
the front or back of the dehumidifier. See the CHOOSING A
LOCATION section on Page 9.
Dirty filter. See the Clean or Replace Filter section on Page 11.
The Humidity Control may not
be set low enough.
For drier air, press the button to lower the percent humidi-
ty desired in the room, or set the dehumidifier to CO for max-
imum dehumidification.
Doors and windows may not be
closed tightly.
Check that all doors, windows, and other openings are secure-
ly closed.
Clothes dryer may be blowing
moist air into the room.
Install the dehumidifier away from the dryer. The dryer
should be vented outside.
Room temperature is too low. Moisture removal is best at higher room temperatures. Lower
room temperatures will reduce the moisture removal rate.
This model is designed to operate at temperatures above 41°F.
Dehumidifier runs too much The area to be dehumidified is
too large.
The capacity of your dehumidifier may not be adequate for
the room size or amount of moisture in the air.
Doors and windows are open. Close all doors and windows to the outside.
Frost appears on the coils The dehumidifier has recently
been turned on or the room
temperature is below 41°F.
This is normal. Frost will usually disappear within 60
minutes.
Controls cannot be set The compressor will turn off and
the fan will automatically
continue to run for approximately
3 minutes at a fixed setting.
This is normal. Wait approximately 3 minutes and set the fan
speed at the desired level.
Fan Noise Air is moving through the unit. This is normal.
TROUBLESHOOTING

Problem Possible Causes Solutions
Water on the floor Hose connection may be loose. Check the hose connection. See the CONTINUOUS MODE-
GARDEN HOSE INSTALLATION AND SET UP
Section on Page 10.
Hose is attached but not draining
into a drain.
Disconnect the hose if using the bucket or place the hose near
a drain.
Unit will not turn on The fuse is blown / circuit break-
er is tripped.
Check the house fuse / circuit breaker box and replace fuse or
reset breaker.
Unit is on but fan is not
running
Dehumidifier has reached its
present level or the bucket is full.
The dehumidifier automatically turns off when either condi-
tion occurs. Change to a lower setting or empty the water
bucket and replace properly.
Bucket is not in the proper
position.
The bucket must be in place and securely seated for the dehu-
midifier to operate.
Power failure. There is a protective time delay (up to 3 min.) to prevent trip-
ping of the compressor overload. For this reason, the unit may
not start normal dehumidification for 3 min. after it is pow-
ered back on.
Continuous Mode is on, but
water is draining in bucket
Incorrect drain hose is installed. Garden hose must be used while operating Continuous Mode.
Dehumidifier on uneven surface. Make sure that the unit is placed on a flat, level surface.
TROUBLESHOOTING

For any questions or Technical Support, please call customer service [phone]
Self-
Diagnosing
Code
Description Resolution
E1 Compressor Overheat Protection
Please call Soleus Customer Service at [phone]
E2 Condenser Overheat Protection
EH Humidity Sensor Malfunction
SELF-DIAGNOSING CODES

Three Year Components Limited Warranty
Five Year Compressor Limited Warranty
Soleus N.A. warrants the accompanying Soleus Air Dehumidifier to be free of defects in material and workmanship for
the applications specified in its operation instruction for a period of THREE (3) years for components and FIVE (5)
years for the compressor from the date of original retail purchase in the United States.
If the unit exhibits a defect in normal use, Soleus N.A. will, at its option, either repair or replace it, free of charge within
a reasonable time after the unit is returned during the warranty period.
As a condition to any warranty service obligation, the consumer must present this Warranty Certificate along with a
copy of the original purchase invoice.
THIS WARRANTY DOES NOT COVER:
• Damage, accidental or otherwise, to the unit while in the possession of a consumer not caused by a defect in
material or workmanship.
• Damage caused by consumer misuse, tampering, or failure to follow the care and special handling provisions
in the instructions.
• Damage to the finish of the case, or other appearance parts caused by wear.
• Damage caused by repairs or alterations of the unit by anyone other than those authorized by Soleus N.A.
• Freight and Insurance cost for the warranty service.
• Filter and Accessories
ALL WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT ABILITY ARE LIMITED TO
THE DURATION OF THIS EXPRESS LIMITED WARRANTY. SOLEUS N.A. DISCLAIMS ANY LIABILITY
FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES AND IN NO EVENT SHALL SOLEUS N.A’S LIABILITY
EXCEED THE RETAIL VALUE OF THE UNIT FOR BREACH OF ANY WRITTEN OR IMPLIED WARRANTY
WITH RESPECT TO THIS UNIT.
This warranty covers only new products purchased from our authorized dealers or retailers. It does not cover used, sal-
vaged, or refurbished products.
As some states do not allow the limitation or exclusion of incidental or consequential damages, or do not allow
limitation on implied warranties, the above limitations and exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary from state to state.
For Technical Support and Warranty Service
Please Call [phone]
www.soleusna.com
LIMITED WARRANTY
