Soleus Air iCongo DS1-30-01 User manual

Model No.: DS1-30-01
DS1-45E-101
DS1-70E-101
3058080
30 Pints/45 Pints/70 Pints
Portable Dehumidifier
Operating Instructions
V160328

2
General Dehumidifier Information
RECOMMENDED HUMIDITY LEVELS
 Spring/Summer: 35% - 50%
 Fall/Winter: 35% - 40%
WARM AIR EXHAUST IS NORMAL
During operation your dehumidifier will exhaust warm air from the side of the unit. This is normal operation.
EMPTYING THE BUCKET
The more moisture your dehumidifier removes from the air, the more often you may have to empty the bucket
(unless you are using the continuous drainage option). The number of times the bucket will be emptied de-
pends on the dehumidifier model.
LESS MOISTURE BEING REMOVED OVER TIME IS A GOOD THING!
Using a dehumidifier will cause your area to maintain a more comfortable humidity level. Over time, this
humidity level will become more and more stable. Due to the stable humidity level in the area, the
dehumidifier will need to remove less and less moisture over time.
Please do not be concerned if the dehumidifier is removing less moisture from the air or the bucket is taking
longer to fill up. This is a direct result of your dehumidifier creating a more stable humidity level in your area.
WATER IN THE BUCKET!
There might be a small amount of water present in the bucket before using the dehumidifier for the first time,
which is normal. This is caused by the preliminary testing done by the factory.
Model Number Pints of moisture removed per every
24 hour period
Maximum number of times to empty
the bucket when operating at full
capacity during a 24 hour period
D630-
30 Pints 4 Times
D645E-
45 Pints 6 Times
'6(
70 Pints 5 Times

3
FEATURES
Removes up to 30/45/70 pints (depending on model) of moisture
from the air every 24 hours depending on the unit you have. This
is not the bucket size.
Adjustable humidistat for precise humidity control.
Digital humidistat displays set humidity level and current room
humidity level.
Operates at temperatures down to 41°F. Perfect for basement
use in the winter.
Automatic defrost function melts away ice from frozen coils for
continuous, worry-free operation.
3-Speed fan allows you to choose between maximum dehumidi-
fying power or quiet operation.
Bucket full indicator and audible alarm signals as soon as the
bucket is full and ready to be emptied.
Ultra quiet operation allows for use almost anywhere. Perfect for
heavy traffic areas like a family room or bedroom.
Loss of power protection remembers all settings even when
power is interrupted.
Auto-restart automatically continues operation when power is re-
stored. No need to manually restart the dehumidifier.
24-Hour Timer automatically turns on and off the unit after the
preset time of 0.5 up to 24 hours.
MyHome modes allow you to choose the location in which you
are using your dehumidifier (Sleeping Space, Living Space or
Basement) for preset comfort and balanced operation.

4
Thank you for choosing a Soleus Air Portable Dehumidifier. This owner’s manual will provide you
with valuable information necessary for the proper care and maintenance of your new product. Please
take a few moments to thoroughly read the instructions and familiarize yourself with all the opera-
tional aspects of your new Dehumidifier.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT INSTRUCTIONS
Before installing and using your dehumidifier, please read this owner’s manual carefully. Store this manual in a
safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this
manual.
3) Maintain at least 12-18 inches clearance space around this unit. Do not block or cover air inlet or outlet
grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced
by the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.

5
SPECIFICATIONS
 Noise level is measured at a distance of 3.28 ft away from the front of the unit.
 Power consumption is measured when the fan runs at the highest speed setting.
 These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE
PRESENTATION OF THE MANUFACTURER. SOLEUS HOME COMFORT HAS NOT CONDUCTED INDEPENDENT
TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED HEREWITHIN.
PACKAGE CONTENTS
(1) Portable Dehumidifier
(1) Operating Instructions
(4) Casters
(1) Bucket Handle
Model Number DS1-30-01 DS1-45E-101 DS1-70E-101
Dehumidifying Capacity 30 Pints per day 45 Pints per day 70 Pints per day
Power Consumption
(Watts) 330 Watts 460 Watts 730 Watts
Air Flow Volume
(High/Med/Low) 147 / 130 / 112 CFM 135 / 125 / 105 CFM 205 / 190 / 165 CFM
Power Source 115 V / 60 Hz 115 V / 60 Hz 115 V / 60 Hz
Rated Current
(Amps) 2.87A 4 A 6.3A
Sound Pressure Level
(High/Med/Low) 53/51/49dB(A) 53/51/49dB(A) 53/51/49 dB(A)
Weight 32lbs 34.2 lbs 47.4 lbs
Dimensions
(W x D x H)
13.375” W x 10” D x
19.5” H
13.375” W x 10” D x
19.5” H
15.25” W x 11.25” D x
24.875” H
Energy Star No Yes Yes
Bucket Capacity 8.5 Pints 8.5 Pints 16.9 Pints

6
CASTER INSTALLATION
1) Remove casters from the bucket.
For the 70 Pint, the four casters can be taken out from the side
of the bucket directly. (Fig. 1)
For the 30 Pint and 45 Pint, please check if the casters are under
the lid of the bucket. If so, please remove lid to access casters,
then re-placed the lid before operation. (Fig. 2)
2) Tilt the dehumidifier no more than 45⁰and forcibly insert the casters. Make sure the ring around the caster
is flush against the bottom of the dehumidifier.
CONTROL PANEL & DIGITAL DISPLAY
POWER
BUTTON
INCREASE/DECREASE
ROOM
HUMIDITY LEVEL
TIMER
BUTTON
FILTER
BUTTON FAN
SPEED
BUTTON
PRESET
MODE
BUTTON
Clean Filter
LED Indicator
Fan Speed
LED Indicators
Child-Lock
LED Indicator
MyHome Mode
LED Indicators
Bucket Full
LED Indicator
Power On
LED Indicator
Digital Humidistat
Display
This button does
not operate or offer
any function
Fig. 1
4 casters in
plastic bag
packed inside
bucket
Timer
LED Indicator

7
OPERATING INSTRUCTIONS
1) When first operating the dehumidifier, run it in Continuous mode for 24 hours.
2) Power On and Off - Press the POWER button once to manually turn the unit on. Press the POWER
button once more to turn the unit off.
3) Humidity Selection - Press the or buttons to choose the desired relative humidity in the room.
Each press of the button will change the desired room humidity by 5%. The room humidity is selectable
from 35%-80% or continuous. The unit will cycle on and off to maintain the humidity level chosen on the
digital display. If you want the dehumidifier to operate continuously regardless of the room humidity, press
the MODE button until you see “CO” on the digital display. This will enable continuous operation and
the “Continuous” indicator will light up on the control panel.
4) Fan Speed Control - Press the FAN SPEED Button to cycle through the different fan speeds: High,
Medium, and Low. The fan speed can be visually distinguished by the fan speed indicators on the control
panel.
5) Timer Auto On- To program the unit to automatically turn on, press the TIMER button when the unit is
off. Press or to increase or decrease the timer in 30 min increments (.5 hours) up to 10 hours. After 10
hours, each press of the button will increase the timer in 1 hour increments up to 24 hours. Once the
desired time is reached, the unit will automatically turn on.
Timer Auto Shut-Off- To program the unit to automatically turn off, press the TIMER button when the
unit is on. Each press of the or buttons will change the timer setting in 30 min increments ( .5 hours)
up to 10 hours. After 10 hours, each press of the or buttons will increase or decrease the timer in 1
hour increments up to 24 hours. Once the desired time is over, the unit will automatically power off.
NOTE: Fan will continue to run even when the compressor is off. This is normal and allows the unit to
circulate air and operate more efficiently
OPERATING INSTRUCTIONS

8
OPERATING INSTRUCTIONS
6) Bucket Full - When the water bucket is full of water, the unit will automatically shut off , make a beeping
noise, and the Bucket Full Indicator will light up. The dehumidifier will not function until the water
bucket is emptied and placed back inside the unit. The bucket should be cleaned every few weeks to prevent
the growth of mold, mildew and bacteria. Use a mild detergent to clean the bucket. Once clean, completely
dry the bucket and place it back inside the dehumidifier.
NOTE: When the bucket is full or removed from the machine, the compressor will turn off, but
the fan will continue to run for a few minutes. This is completely normal. The dehumidifier
will not be removing moisture from the air at this time.
NOTE: When removing moisture from the air, the dehumidifier will exhaust warm air from the
side exhaust vent.
NOTE: Do not place a full bucket on the floor, because the bottom is uneven.

9
7) Clean Filter - When the filter needs to be cleaned, the filter indicator will light up (after 250 hours of
use). Remove the filter from the back of the unit by using your thumbs to press down on the filter tabs
directly above the filter. Clean the filter with warm, soapy water. Dry thoroughly before replacing the
filter. Once the filter is completely dry, place the filter back in the unit and press the FILTER button to
reset the filter indicator.
CAUTION: DO NOT OPERATE THE DEHUMIDIFIER WITHOUT THE INCLUDED FILTER
8) MyHome Modes - Preset humidity level settings allow the user to easily move the dehumidifier room-
to- room and select the corresponding mode for the location in which the dehumidifier is operating for
optimum performance. Press the MODE button to choose from Sleeping Space, Living Space or Base-
ment.
9) Child-Lock Mode- To lock the control panel, press and hold the TIMER button for 3 seconds. Lock-
ing the control panel prevents someone from accidentally changing the settings. When locked, the
LOCK Indicator will light up. Press and hold the TIMER button for 3 seconds to unlock the control
panel.
OPERATING INSTRUCTIONS
NOTE: Do not clean filter in dishwasher

10
A Dehumidifier operating in a basement will have little or no effect in drying out an adjacent
enclosed storage area, such as a closet, unless there is adequate circulation of air in and out of
the area.
 Do not use outdoors.
 This dehumidifier is intended for indoor use only. Place the dehumidifier on a smooth, level
floor surface that is strong enough to support the unit with a full bucket of water.
 Allow at least 12”-18” of air flow on all sides.
 Place the dehumidifier in an area where the temperature will not fall below 41°F. The coils
can become covered with frost at temperatures below 41°F, which may reduce performance.
 Use the dehumidifier in cooking, laundry, bathing and dishwashing areas that have excessive
moisture. NOTE: Place the dehumidifier away from a clothes dryer.
 Use the dehumidifier to prevent moisture damage anywhere books or valuables are stored.
 Use the dehumidifier in a basement to help prevent moisture damage.
 The dehumidifier must be operated in an enclosed area to be most effective.
 Close all doors, windows and other outside openings to the room.
CHOOSING A LOCATION
AUTOMATIC DEFROST
When frost builds up on the evaporator coils, the compressor will cycle off and the fan will continue to run until the frost disappears.
When the coils are completely defrosted, the compressor or fan (depending on the model) will automatically restart and
dehumidification will resume.
