Soleus Air DMG-135-60 User manual

V.170405
Model Number:
DMG-135-60
5008441

Thank you for choosing a Soleus Air Commercial Low Grain Refrigerant Dehumidifier. This
Owner’s Manual will provide you with valuable information necessary for the proper care and
maintenance of your new product. Please take a few moments to thoroughly read the instructions
and familiarize yourself with all the operational aspects of your new Soleus Air Dehumidifier.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the
store name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: _____________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
Before installing and using your dehumidifier, please read this owner’s manual carefully. Store this manual in
a safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this manual.
3) Maintain a 12-18 inch clearance space around this unit. Do not block or cover air inlet or outlet grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this
manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced by
the manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.
IMPORTANT INSTRUCTIONS
PURCHASE INFORMATION

RECOMMENDED HUMIDITY LEVELS
• Spring/Summer: 30% - 50%
• Fall/Winter: 35% - 55%
• RestorationWork: Continuous “CO” Operation
WARM AIR EXHAUST IS NORMAL
During operation your dehumidifier will exhaust warm air from the side of the unit. This is normal operation.
LESS MOISTURE BEING REMOVED OVER TIME IS A GOOD THING!
Using a dehumidifier will cause your area to maintain a more comfortable humidity level. Over time, this
humidity level will become more and more stable. Due to the stable humidity level in the area, the
dehumidifier will need to remove less and less moisture over time.
Please do not be concerned if the dehumidifier is removing less moisture from the air or the bucket is taking
longer to fill up. This is a direct result of your dehumidifier creating a more stable humidity level in your area.
WATER IN THE INTERNAL HOLDING TANK!
There might be a small amount of water present in the internal holding tank before using the dehumidifier for
the first time, which is normal. This is caused by the preliminary testing done by the factory.
DEHUMIDIFIER INFORMATION

• Noise level is measured at a distance of 3.28 ft away from the front of the unit.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE PRESENTATION OF THE
MANUFACTURER. SOLEUS N.A HAS NOT CONDUCT-
ED INDEPENDENT TEST TO THE INFORMATION AND
THE SPECIFICATIONS PRESENTED HEREWITHIN.
(1) Commercial Low Grain Refrigerant Dehumidifier
(1) Operating Instructions
(1) Pump Drain Hose (19 Feet)
(1) Power Cord (25 Feet)
Model Number DMG-135-60
Dehumidifying Capacity 135 Pints per day (AHAM)
220 Pints per day (At Saturation)
Power Consumption (Watts) 1100 Watts
Air Flow Volume (High/Med/Low) 588 / 529 / 470 CFM
Power Source 115 V / 60 Hz
Rated Current (Amps) 9.1 A
Sound Pressure Level 58 dB(A)
Weight 110 lbs
Dimensions (W x D x H) 21.25” W x 24” D x 33.5” H
Drain Pump Vertical Capacity 19 Feet
Internal Holding Tank 4 Pints
PACKAGE CONTENTS
SPECIFICATIONS

Removes up to 135 pints at AHAM / 220 Pints At Saturation of
moisture from the air every 24 hours.
Adjustable humidistat from 30%-90% for precise humidity con-
trol.
Dual Floor Fan exhausts air over surface area for a faster dry
time.
SD Card Job Log records ambient temperature and humidity
level on the hour.
Automatic defrost function melts away ice from frozen coils for
continuous, worry-free operation.
3-Speed fan allows you to choose between maximum dehu-
midifying power or quiet operation.
Loss of power protection remembers all settings even when
power is interrupted.
High Airflow Filter protects the unit against damage from air-
borne particles.
24-Hour Timer automatically turns on and off the unit after the
preset hour increment up to 24 hours.
Water pump automatically pumps water up to 19 feet vertically
into a nearby drain, sink or window for continuous operation.
Adjustable Handle for customized transport and storage.
Operates at temperatures down to 39°F. Perfect for use in the
winter.
25 Foot Power Cord easily extends down hallways and up into
stairwells.
PRODUCT FEATURES

CONTROL PANEL
MODE BUTTON
Fan-Only and
Dehumidifier
TIME BUTTON
Set Date, Time
and Timer
SD CARD SLOT
Records useful
reporting every
hour
Fan Speed
Icon
DRAIN BUTTON
Pumps water from
internal holding
tank
INCREASE/DECREASE
Humidity and Settings
1) Adjustable Handle: The handle can adjusted to different heights using the included
Handle Knobs. Screw in the Handle Knobs on either side of the handle to secure the
handle at the customized height.
2) Automatic Draining: Insert the included 19 foot Drain Tube onto the Drain Port locat-
ed on the back of the unit. The Drain Pump is designed to pump water up to 19 feet ver-
tically. The dehumidifier will automatically drain when the internal tank is full during
normal operation.
PRODUCT SETUP
Electricity Consumption
Display
Dehumidifier
Mode Icon
FAN SPEED
BUTTON
Low/Medium/High
POWER
BUTTON
Date/Time Display
Automatically alternates
among date, time, running
time every 10 seconds

OPERATING INSTRUCTIONS
CONTROL PANEL OPERATION
1) Power ON/OFF - Press the POWER button once to manually turn the unit on. Press the POWER button
once more to turn the unit off.
2) Mode Button - Press the MODE button to choose between FAN and DEHUMDIFIER modes.
3) Humidity + and - Buttons - When in Dehumidifier Mode, press the + or - buttons to choose the desired
relative humidity in the room. Each press of the button will change the desired room humidity by 1%. Hold
the + or - buttons and the humidity will change by 5%. The room humidity is selectable from 30%-90% or
Continuous (CO). The unit will cycle on and off to maintain the humidity level chosen on the digital dis-
play. If you want the dehumidifier to operate continuously regardless of the room humidity, press the - but-
ton until you see “CO” on the digital display. This will enable continuous operation and “CO” display on
the control panel.
4) Fan Speed Button- Press the FAN SPEED Button to cycle through the different fan speeds: High, Medi-
um, and Low. The fan speed can be visually distinguished by the fan speed icon on the control panel. For
fast dehumidification, choose High. For moderate dehumidification, choose Medium. For quiet operation,
choose Low.
5) Drain Button - The dehumidifier will automatically drain when the internal tank is full during normal op-
eration. Prior to transporting or storing the unit, press the DRAIN button to remove all remaining water for
the internal holding tank. When the Drain button is pressed, the pump will purge water for 40 seconds. (Be
sure the Drain Tube is installed prior to pressing the Drain Button)
6) Time Button - The Time button can be used to set the Date, Time, and Timer.
Press the Time button to cycle through: Year—Month—Day—Hour—Minutes—Timer. Press the + or - but-
tons to increase or decrease each setting.
Set Date
Year: Press the Time button until Year appears and use the + or - buttons to increase or decrease the Year.
Month: Press the Time button until Month appears and use the + or - buttons to increase or decrease the
Month.
Day: Press the Time button until Day appears and use the + or - buttons to increase or decrease the Day.
Set Time
Hour: Press the Time button until Hour appears. Use the + or - buttons to increase or decrease the Hour.
Minute: Press the Time button until Minutes appear. Use the + or - buttons increase or decrease the Minutes.

CONTROL PANEL OPERATION
Set Timer
Auto On- To program the unit to automatically turn on, press the TIME button repeatedly until Timer function
is displayed while the unit is off. Press + or - to increase or decrease the timer in 1 hour increments until the
desired time increment is displayed. After 5 seconds, the displayed time increment will flash, indicating that it
has been set. Once the set time increment is reached, the unit will automatically turn on.
Auto Shut-Off- To program the unit to automatically turn off, press the TIME button repeatedly until Timer
function is displayed while the unit is on. Press + or - to increase or decrease the timer in 1 hour increments
until the desired time increment is displayed. After 5 seconds, the displayed time increment will flash, indicat-
ing that it has been set. Once the set time increment is reached, the unit will automatically turn off.
7) SD Card Recording - Insert an SD Card into the SD Card Slot with the product label on the SD Card
facing down. When an SD Card is inserted and the unit is powered on, the unit will automatically record the
Date, Time, Temperature, Relative Humidity, Total Operating Time, and Electricity Consumption once every
hour.
PRODUCT USE AND OPERATION
1) SD Card Report Viewing - Place the SD Card into the SD Card Slot on a computer. Open the SD Card
folder to view all stored reports. Click on the file and open to view.
2) Automatic Draining - The dehumidifier will automatically drain when the internal tank is full during nor-
mal operation. Be sure that the Drain Tube is installed or collect bucket is placed below the Drain Port at all
time during operation. (See page 6 for Drain Tube installation instructions)
OPERATING INSTRUCTIONS

A Dehumidifier operating in a basement will have little or no effect in drying out an adjacent enclosed storage
area, such as a closet, unless there is adequate circulation of air in and out of the area.
• Do not use outdoors.
• This dehumidifier is intended for indoor use only. Place the dehumidifier on a smooth, level floor surface
that is strong enough to support the unit with a full bucket of water.
• Allow at least 12”-18” of air flow on all sides.
• Place the dehumidifier in an area where the temperature will not fall below 39°F. The coils can become
covered with frost at temperatures below 39°F, which may reduce performance.
• Use the dehumidifier in cooking, laundry, bathing and dishwashing areas that have excessive moisture.
NOTE: Place the dehumidifier away from a clothes dryer.
• Use the dehumidifier to prevent moisture damage anywhere books or valuables are stored.
• Use the dehumidifier in a basement to help prevent moisture damage.
• The dehumidifier must be operated in an enclosed area to be most effective.
• Close all doors, windows and other outside openings to the room.
When frost builds up on the evaporator coils, the compressor will cycle off and the fan will continue to run un-
til the frost disappears. When the coils are completely defrosted, the compressor or fan (depending on the mod-
el) will automatically restart and dehumidification will resume.
CHOOSING A LOCATION
AUTOMATIC DEFROST

Replace Filter - The filter will need to be changed periodically as dirt visible ac-
cumulates. This can vary greatly depending on air quality and amount of use.
When the filter is dirty, replace it with a Soleus Air Replacement Filter.
CAUTION: DO NOT OPERATE THE DEHUMIDIFIER WITHOUT A FILTER.
Clean the Unit Housing -
1) Keep the unit from being exposed directly to the sun to prevent color
fading.
2) Clean the surface with a damp cloth and dry it with a soft towel.
Storage / Transporting the Unit
How to Drain the Internal Water Tank
1) Place a collection under the Drain Port or lead the installed Drain Tube to a sink or drain.
2) Press the Drain Button—This will drain remaining water in the Internal Water Tank (approximately
40 seconds)
3) Unplug the unit and remove the power cord from the back of the unit
4) Inspect the filter and replace if needed.
5) Your dehumidifier is now ready for storage or transportation.
6) The unit should be stored in a cool dry place.
MAINTENANCE

Problem Possible Causes Solutions
Dehumidifier does not start The dehumidifier is unplugged. Make sure the dehumidifier’s plug is pushed completely into
the outlet.
The fuse is blown / circuit break-
er is tripped.
Check the house fuse / circuit breaker box and replace fuse or
reset breaker.
Power Failure. There is a protective time delay (up to 3 min.) to prevent trip-
ping of the compressor overload. For this reason, the unit may
not start normal dehumidification for 3 min. after it is pow-
ered back on.
Dehumidifier does not dry the
air as it should
Not enough time allowed for unit
to remove moisture.
When first installed, allow at least 24 hours to maintain the
desired dryness.
Airflow is restricted. Make sure there are no curtains, blinds, or furniture blocking
the front or top of the dehumidifier. See the CHOOSING A
LOCATION section on Page 9.
Dirty filter. See the REPLACE FILTER section on Page 10.
The humidity level on the control
panel may not be set low enough.
For drier air, press the - button to lower the humidity level
desired for the room, or set the dehumidifier to CO for maxi-
mum dehumidification.
Doors and windows may not be
closed tightly.
Check that all doors, windows, and other openings are secure-
ly closed.
Room temperature is too low. Moisture removal is best at higher room temperatures. Lower
room temperatures will reduce the moisture removal rate.
This model is designed to operate at temperatures above 39°F.
Dehumidifier runs too much The area to be dehumidified is
too large.
An additional dehumidifier may be required for the room be-
ing dehumidified.
Doors and windows are open. Close all doors and windows to the outside.
Frost appears on the coils The dehumidifier has recently
been turned on or the room
temperature is below 39°F.
This is normal. Frost will usually disappear within 60
minutes.
Fan Noise Air is moving through the unit. This is normal.
TROUBLESHOOTING
For any questions or Technical Support, please call
customer service 877-665-9765

Problem Possible Causes Solutions
Water on the floor Drain Tube is not connected. Install the Drain Tube onto the Drain Port on the back of the
unit. See the PRODUCT SETUP Section on Page 6.
Drain Tube connection may be
loose.
Check the Drain Tube connection. See the PRODUCT SET-
UP Section on Page 6.
Unit will not turn on The fuse is blown / circuit break-
er is tripped.
Check the house fuse / circuit breaker box and replace fuse or
reset breaker.
Unit is on, but fan is not
running
Dehumidifier has reached the
humidity level set on the control
panel.
The dehumidifier automatically turns off when the set humid-
ity level is met. To continue operation, reduce humidity set-
ting or activate Continuous Mode.
Power Failure. There is a protective time delay (up to 3 min.) to prevent trip-
ping of the compressor overload. For this reason, the unit may
not start normal dehumidification for 3 min. after it is pow-
ered back on.
TROUBLESHOOTING
For any questions or Technical Support, please call
customer service 877-665-9765

For any questions or Technical Support, please call customer service [phone]
Self-
Diagnosing
Code
Description Resolution
E4 Bucker Full Indicator
Press Drain button to remove water from internal bucket. If
the error code still appears, please call Customer Services
at [phone]
E2 Temperature Sensor Failure
Please call Soleus Customer Service at [phone]
E3 Humidity Sensor Malfunction
E5 Defrost Sensor Malfunction
SELF-DIAGNOSING CODES

LIMITED WARRANTY
Two Year Components Limited Warranty
Five Year Compressor Limited Warranty
Soleus N.A. warrants the accompanying Soleus Air Dehumidifier to be free of defects in material and workmanship for
the applications specified in its operation instruction for a period of TWO (2) years for components and FIVE (5) years
for the compressor from the date of original retail purchase in the United States.
If the unit exhibits a defect in normal use, Soleus N.A. will, at its option, either repair or replace it, free of charge within
a reasonable time after the unit is returned during the warranty period.
As a condition to any warranty service obligation, the consumer must present this Warranty Certificate along with a
copy of the original purchase invoice.
THIS WARRANTY DOES NOT COVER:
• Damage, accidental or otherwise, to the unit while in the possession of a consumer not caused by a defect in
material or workmanship.
• Damage caused by consumer misuse, tampering, or failure to follow the care and special handling provisions
in the instructions.
• Damage to the finish of the case, or other appearance parts caused by wear.
• Damage caused by repairs or alterations of the unit by anyone other than those authorized by Soleus N.A.
• Freight and Insurance cost for the warranty service.
• Filter and Accessories
ALL WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT ABILITY ARE LIMITED TO
ONE-YEAR DURATION OF THIS EXPRESS LIMITED WARRANTY. SOLEUS N.A. DISCLAIMS ANY LIABIL-
ITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES AND IN NO EVENT SHALL SOLEUS N.A.’S LIA-
BILITY EXCEED THE RETAIL VALUE OF THE UNIT FOR BREACH OF ANY WRITTEN OR IMPLIED WAR-
RANTY WITH RESPECT TO THIS UNIT.
This warranty covers only new products purchased from our authorized dealers or retailers. It does not cover used, sal-
vaged, or refurbished products.
As some states do not allow the limitation or exclusion of incidental or consequential damages, or do not allow
limitation on implied warranties, the above limitations and exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that vary from state to state.
For Technical Support and Warranty Service
Please Call [phone]
www.soleusna.com
