1. Introduction
1.1 Overview
The Solid State Logic X-Rack unit has been developed from the successful range of XLogic outboard
equipment and provides a flexible solution to those engineers requiring a larger number of processing
units in a compact package.
The additional space provided by the X-Rack allows the processing modules to be vertically orientated,
providing a more familiar interface to users of Solid State Logic’s renowned range of mixing consoles, and
makes it possible to include Solid State Logic’s Total Recall system – the first time this has been available
on an analogue outboard unit.
1.1.1 This Manual
The object of this manual is to provide purchasers of the X-Rack unit with information in the following
areas:
• Operation of the unit
• Safety considerations
• Installation requirements
• lectrical connections and cabling
• Connector pin-outs
• Specifications and physical dimensions
This manual is applicable to X-Rack units from serial number XRK110 onwards and assumes that the X-Rack
unit is running V1.4/2 or later software. Please refer to ection 4 of this manual for instructions on how to
check the current software version and how to obtain and install a newer version if required.
1.2 Warranty
Pursuant to the Solid State Logic Terms and Conditions, under uropean consumer law the purchaser has
full statutory warranty rights for two years from the date of delivery of the product. The warranty is valid
only in those Member States of the uropean Union ( U) who have adopted the applicable U law into
their national legislation, otherwise a warranty term of one year will apply. The applicable national
legislation governing the sale of consumer goods is not affected by this warranty. Warranty claims will
only be accepted if the purchased product has been used for its intended purpose. Any purchased product
used for an unintended purpose will not be eligible for warranty protection. For all warranty inquiries or
claims please address the claim to us if the purchase was directly from us or otherwise to the dealer from
which you purchased the product within a period of two months from the date on which you detected its
lack of conformity with the terms of the warranty. Please include your original proof of purchase when
initiating the claim.
1.2.1 Out of Warranty Repairs
In the event of a fault arising after the warranty period has expired the unit should be returned to Solid
State Logic either directly or via your local dealer. You will be charged for the time spent on the repair (at
Solid State Logic's current repair rate) plus the cost of parts and shipping. Note that no units can be
accepted for repair without prior arrangement (see below).
1.2.2 All Returns
• No unit will be accepted for repair by Solid State Logic unless accompanied by a valid RMA (Return
Material Authorisation) number, obtainable from Solid State Logic prior to shipping.
• All units should be shipped to Solid State Logic in suitable rigid packaging – Solid State Logic cannot
be held responsible for any damage caused by shipping units in other packaging. In such cases Solid
State Logic will return the unit in a suitable box, which you will be charged for.
• Please include all items – such as this manual, cables etc. – originally provided with unit.
