Solid State Logic XLogic Super Analogue User manual

Super Analogue Channel
Owner’s Manual

Solid State Logic
Super-Analogue™ Outboard
Owner’s Manual
82S6XL040D
S U P E R A N A L O G U E
C H A N N E L

As research and development is a continual process, Solid State Logic reserves the right
to change the features and specifications described herein without notice or obligation
E&OE
Revision 0A, September 2003
Revision 0B, January 2004
Revision 0C, June 2004
Revision 0D, July 2004
Minor changes, November 2004
Minor changes, June 2005
Solid State Logic
Begbroke, Oxford, England, OX5 1RU • [phone]
320 West 46th Street, 2nd Floor, New York, NY 10036, USA • [phone]
Suite 401, 5757 Wilshire Blvd, Los Angeles, CA 90036, USA • [phone]
3-55-14 Sendagaya, Shibuya-Ku, Tokyo 151-0051, Japan • [phone]
7 bis, rue de la Victoire, le Blanc Mesnil, Paris 93150, France • [phone]
Via Timavo 34, 20124 Milano, Italy • [phone]
Visit SSL at URL: http://www.solid-state-logic.com
© Solid State Logic
All Rights reserved under International and Pan-American Copyright Conventions
Solid State Logic, SSL and XLogic are trademarks of Solid State Logic
All other product names and trademarks are the property of their respective owners
No part of this publication may be reproduced in any form or
by any means, whether mechanical or electronic, without the
written permission of Solid State Logic, Oxford, England
XLogic Channel Owner’s Manual

Contents
1.0 Introduction 3
2.0 Safety Considerations 4
Safety Warnings 4
3.0 Installation 7
Setting the mains voltage selector 7
Mounting 7
Connections 7
4.0 Operation 8
Input Section 8
Dynamics Section 9
Filter Section 10
Equaliser Section 11
Output Section 11
5.0 Signal Routing 12
Block Diagram 12
Signal Routing 13
Appendices:
A Internal Links and Fuses 14
B Connector Details 15
C Electronic Specification 16
D Calibration Information 21
E Physical Specification 24
F Environmental Specification 24
Page 1

XLogic Channel (front)
XLogic Channel (rear)
XLogic Channel Owner’s Manual
Page 2
RELEASE
4
DYN
S/C INPUT
LPF
IN
PAD 48VHI Z
EXP
HOLD
0
THRESHOLD
+10
0
30
FILTERS
35 3
KHz
25
9
4
15
KHz
.6
15
Q
Q
Hz
40 600
6 0400
KHz
.2 2.0
.3 1.6
HF
+
GAIN
LMF
+
GAIN
LF
+
GAIN HMF
BELL IN
EQ EDYN
S/C
2
15
0220 .6 1.0
COMPRESSOR
+10 1
20141063
RELEASE
14
0
-20
RATIO
1∞
DYN
IN
KEY LINK
PRE
EQ PK
FAST
ATT
dB 72
INP
BINST
GAIN
1260-12-24 2418
MTR
INPUT
7
KHz
1.5 22
215
+
GAIN
BELL
+20
-20
35
DYNAMICS
FAST
ATT
GATE
30
Hz
500
20
60 100
300
RANGE
040
HPF
IN
66
60
54
48
42
36
30
24 18
12 6
INPUT B - INSTRUMENT
INPUT GAIN OUTPUT
Ø
ADC LOCK
POWER
THRESHOLD
4
10
XL
SUPER ANALOGUE
C H A N N E L
Solid State Logic
ogic
INPUT A
DYN
LINK
KEY INOUTPUT
100V 120V 230V 240V
Blanking plate for
(optional) ADC card

1.0 Introduction
The XLogic Channel unit is a 1U rack mounting unit containing a complete set of signal processing from the
XL 9000 channel strip – Input, Compressor/Limiter, Expander/Gate, Hi and Lo pass filters and Equaliser. An
optional ADC card is available (SSL part number: 629945XT) to provide an additional digital audio output.
The object of this manual is to provide purchasers of the XLogic Channel unit with information in the following
areas:
• Safety considerations
• Installation requirement
• Electrical connections and cabling
• Connector pin outs
• Specifications and physical dimensions
Warranty
The warranty period for this unit is 12 months from date of purchase.
In Warranty Repairs
In the event of a fault during the warranty period the unit must be returned to your local distributor who will
arrange for it to be shipped to Solid State Logic for repair. All units should be shipped to Solid State Logic in their
original packaging. Solid State Logic can not be held responsible for any damage caused by shipping units in
other packaging. In such cases Solid State Logic will return the unit in a suitable box, which you will be charged
for. Please do not send manuals, power leads or any other cables - Solid State Logic can not guarantee to return
them to you. Please also note that warranty returns will only be accepted as such if accompanied by a copy of
the receipt or other proof of purchase.
Out of Warranty Repairs
In the event of a fault after the warranty period has expired, return the unit in its original packaging to your local
distributor for shipment to Solid State Logic. You will be charged for the time spent on the repair (at Solid State
Logic's current repair rate) plus the cost of parts and shipping.
Introduction
Page 3

2.0 Safety considerations
This section contains definitions and warnings, and practical information to ensure a safe working environment.
Please take time to read this section before undertaking any installation work.
2.1 Definitions
‘Maintenance’
All maintenance must be carried out by fully trained personnel. Note: it is advisable to observe suitable ESD
precautions when maintenance to any part is undertaken.
‘Non-User Adjustments’
Adjustments or alterations to the equipment may affect the performance such that safety and/or international
compliance standards may no longer be met. Any such adjustments must therefore only be carried out by fully
trained personnel.
‘Users’
This equipment is designed for use solely by engineers and competent operators skilled in the use of professional
audio equipment.
‘Environment’
This product is a Class A product intended to form an integrated component part of a professional audio
recording, mixing, dubbing, film, TV, radio broadcast or similar studio wherein it will perform to specification
providing that it is installed according to professional practice.
2.3 Installation
Voltage Selection and Fusing
All XLogic units have selectable voltage inlets. Always confirm that the input mains voltage range is set correctly
before applying power. Always isolate the mains supply before changing the input range setting.
If it is ever necessary to replace a blown mains-fuse, then always use the correct rating and type of replacement.
If a correctly rated fuse continues to blow, then a fault exists and the cause should be investigated or the unit
returned to Solid State Logic for repair/replacement as appropriate.
Details of mains settings and correct fuse ratings can be found in Section 3.1 and Appendix A of this manual.
Safety Earth Connection
Any mains powered item of Solid State Logic equipment that is supplied with a 3-core mains lead (whether
connectorised or not) should always have the earth wire connected to the mains supply ground. This is the safety
earth and grounds the exposed metal parts of the racks and cases and should not be removed for any reason.
2.2 Electrical Safety Warning
When installing or servicing any item of Solid State Logic equipment with power applied, when cover
panels are removed, HAZARDOUS CONDITIONS CAN EXIST.
These hazards include: High voltages
High energy stored in capacitors
High currents available from DC power busses
Hot component surfaces
Any metal jewellery (watches, bracelets, neck-chains and rings) that could inadvertently come into contact
with uninsulated parts should always be removed before reaching inside powered equipment.
XLogic Channel Owner’s Manual
Page 4

Mains Supply and Phases
Solid State Logic equipment is designed for connection to single phase supplies with the Neutral conductor at
earth potential – category TN – and is fitted with a protective fuse in the Live conductor only. It is not designed
for use with Phase (Live) and Neutral connections reversed or where the Neutral conductor is not at earth
potential (TT or IT supplies).
Mains cables will be coded with the following colour scheme:
LIVE: Brown
NEUTRAL: Blue
EARTH: Yellow/Green
Mains Isolation and Over-Current Protection
An external disconnect device is required for this equipment which must be installed according to current wiring
regulations. A detachable power cord, as fitted to this equipment, is a suitable disconnect device.
An external over-current protection device is required to protect the wiring to this equipment which must be
installed according to the current wiring regulations. The fusing or breaking-current are defined in the product
specification. In certain countries this function is supplied by use of a fused plug.
CE Certification
Note that the majority of cables supplied with SSL equipment are fitted with ferrite rings at each end. This is to
comply with current European CE regulations and these ferrites should not be removed.
If any of the unit metalwork is modified in any way this may the adversely affect the CE certification status of
the product.
FCC Certification
The XLogic unit has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
Page 5
Safety Considerations

XLogic Channel Owner’s Manual
Page 6
240
120
100
240
230
120
100
240
230
120
100
240
230
100
100V
120V
230V
240V
100V Setting
(Use for 90-105V)
120V Setting
(Use for 105-125V)
230V Setting
(Do not use)
240V Setting
(Use for 220-240V)
Mains Input Module
Mains Input Programming PCB
These diagrams show the PCB arrangements for the different voltage settings.
Note that where the mains voltage is a nominal 230V, the ‘240V Setting’ should be used – not the ‘230V Setting’!

3.0 Installation
3.1 Voltage Selection
Before connecting the mains supply ensure that the voltage range selector next to the IEC socket on the rear of
the unit is correctly set. The input setting must be confirmed before applying power. The input module can be
configured to be one of 4 voltage settings. The setting is indicated by a plastic pin protruding through the
appropriate hole in the fuse panel.
The setting is altered by a small vertical PCB which can be fitted in 4 positions.
To change the setting:
Switch off and remove the IEC lead.
Using a small flat-bladed screwdriver, lever open the fuse panel to the right of the connector.
At the right hand side is a vertical PCB with a plastic key which indicates the setting. Using pliers, pull
out the PCB.
The PCB has to be rotated until the desired voltage is shown along the edge which plugs into the module.
The plastic key (and this bit is quite fiddly) must also be rotated so that it points out of the module and so
that the round pin aligns with the appropriate hole in the cover panel; (refer to the diagrams opposite).
Re-insert the PCB and replace the fuse panel. The plastic pin should project through the appropriate hole.
3.2 Mounting
The XLogic unit is designed to be rack-mounted. It is 1 RU (44.5mm/1.75 inch) high. Its depth is:
325 mm/12.8 inches not including heatsink.
365 mm/14.3 inches including heatsink
400 mm/15.75 inches including connectors
Please note that the rack ears of early XLogic Channel units are not capable of supporting the full weight of the
unit. Therefore if the unit is to be rack-mounted, it must either be mounted on suitable rack shelves or be fitted
with a pair of support brackets to reinforce the rack ears – do not rely on just the basic front panel for rack-mounting
the unit. Later XLogic Channel units incorporate reinforcement brackets into the chassis and so are suitable for
direct rack-mounting. Should your unit require them, pairs of support brackets (SSL Part No.: 629943XR) are
available from your local distributor.
A 1RU space should be left above each unit to ensure adequate ventilation.
3.3 Connection
There are four connectors on the rear panel and a single combined XLR and mono jack on the front panel.
The rear panel connections are:
Input A (female XLR)
Output (male XLR)
Key Input (female XLR)
Link Bus (TRS jack socket)
The front panel connections are:
Input B/Instrument (combined female XLR and mono jack)
Inputs A and B are can be used for either microphone or line level signals. The HI Z switch should be selected
when using line level signals as some devices may not be able to provide full output level in to the low (1.2kΩ)
impedance of the standard microphone input.
The mono jack provides a very high (1MΩ) impedance input, designed for use with guitar pickups, piezo electric
bugs etc.
Connect the output of the unit to your recorder, workstation or mixing desk. Connect the input to a suitable
source. If you have more than one unit the dynamics LINK jacks on the rear of the units should be connected
together using a mono or stereo jack–to–jack cable.
Installation
Page 7

4.0 Operation
The XLogic Channel unit is a 1U rack mounting unit containing a complete set of signal processing from the
XL 9000 channel strip – Input, Compressor/Limiter, Expander/Gate, Hi and Lo pass filters and Equaliser.
The signal processing order can be changed and the EQ and filter sections used in the dynamics side chain.
providing a wide range of signal processing options.
Obviously there are many different permutations of signal routing, allowing an enormous number of creative
possibilities. This section looks at each control on the XLogic Channel individually, with a brief summary of the
routing possibilities. See Section 5 for more on routing.
4.1 Channel Input Section
The channel input can pick up any one of three inputs:
INP A With the INP B and INST switches released
the input is fed by the INPUT A XLR on the rear of the
unit.
INP B – Selects the female XLR on the front of the
unit.
INST – Selects the mono jack instrument input on the
front of the unit. This is a very high impedance
unbalanced input intended to be used with guitar
pickups etc.
The stepped INPUT GAIN control has a gain range of +6dB to +72dB in 6dB steps.
HI-Z – Increases the input impedance of the microphone input (inputs A or B) from 1.2kΩ to 8.45kΩ. This
allows the connection of line level signals to the channel input if required, and provides an alternative
input impedance for some dynamic microphones.
PAD – This switch reduces the signal level by 18dB. Setting the gain to +18dB and selecting PAD sets the
input gain to 0dB for use with line level signals.
48V – When selected provides phantom power to the associated microphone.
Please note that connecting a microphone to the XLogic Channel unit with phantom power switched on is not advised
as it may cause damage to either the microphone or the input stage of the XLogic Channel unit. Also note that
phantom power should be switched off before changing the input source to avoid possible damage to connected devices
or to the input stage of the XLogic Channel unit. Take care not to use phantom power when connecting line level
sources (keyboards etc.) as this may damage the output stage of the connected unit.
Ø (Phase) – This reverses the phase of the selected channel input.
XLogic Channel Owner’s Manual
Page 8
PAD 48VHI Z
dB 72
INP
BINST
66
60
54
48
42
36
30
24
18
12 6
INPUT B - INSTRUMENT
INPUT GAIN
Ø

4.2 Dynamics Section
The Dynamics section comprises a compressor/limiter and an expander/gate, both of which use the same
gain change element. Both sections work independently, but can be operational at the same time,
providing sophisticated control of signal levels. The Filter and/or the Equaliser section can be assigned to
the dynamics side chain allowing de-essing etc.
The Dynamics section has two routing buttons associated with it. Section 5 deals with Dynamics routing
in more detail, but briefly these button function as follows:
DYN IN – Switches the Dynamics section into the signal path pre the EQ.
PRE EQ – Switches the Dynamics section pre the EQ section (but post the Filter section if the Filter INPUT
switch is pressed).
KEY – Switches the Dynamics side chain to the ‘KEY’ input on the rear panel of the unit.
If you have more than one unit and have connected the ‘DYN LINK’ jacks on the rear of the units together
the side chain control signals of multiple units can be linked by pressing the LINK switch on those units
you wish to gang. When two Dynamics sections are linked, the control voltages of each section sum
together, so that whichever section has the most gain reduction will control the other section.
Don’t try to link two gates using the LINK button when you want the signal on one to open the other. If
you need to achieve this effect, take a keying signal from one section to trigger the other. The easiest way
to do this is by patching from the output of the ‘source’ channel into the Key input of the ‘destination’
channel, and selecting KEY (see above) on this channel.
4.3 Compressor/Limiter
RATIO – When turned to 1:1, the Compressor/Limiter section is inactive. Turning the control clockwise
increases the compression ratio to give a true limiter at the fully clockwise position.
The compressor normally has an ‘over-easy’ characteristic. Selecting PK changes this to peak sensing, and
replaces the ’over–easy’ characteristic with a hard knee, providing an alternative for some instruments.
THRESHOLD – Whenever a signal exceeds the level set by this control, the compressor will start to act
at the ratio set by the RATIO control. This control also provides automatic make-up gain, so as you lower
the threshold and introduce more compression, the output level is increased, maintaining a steady output
level regardless of the amount of compression.
RELEASE – Sets the time constant (speed) with which the compressor returns to normal gain settings once
the signal has passed its maximum.
FAST ATT – Provides a fast attack time (3mS for 20dB gain reduction). When off the attack time is
program dependent (3mS – 30mS).
The yellow and red LEDs, on the bottom of the LED display area, indicate the amount of gain reduction
(compression).
Operation
Page 9
RELEASE
4
EXP
HOLD
0
THRESHOLD
+10
0
3
0
COMPRESSOR
+10 1
20141063
RELEASE
14
0
-20
RATIO
1∞
DYN
IN
KEY LINK
PRE
EQ PK
FAST
ATT
DYNAMICS
FAST
ATT
GATE
RANGE
040
THRESHOLD
4

4.4 Expander/Gate
This section can act as a ∞:1 Gate or as a 2:1 Expander when the EXP switch is pressed.
RANGE – Determines the depth of gating or expansion. When turned fully anticlockwise (Range = 0), this
section is inactive. When turned fully clockwise, a range of 40dB can be obtained.
THRESHOLD – Variable hysteresis is incorporated in the threshold circuitry. For any given ‘open’ setting,
the Expander/Gate will have a lower ‘close’ threshold. The hysteresis value is increased as the threshold
is lowered. This is very useful in music recording as it allows instruments to decay below the open
threshold before gating or expansion takes place.
RELEASE – This determines the time constant (speed), variable from 0.1- 4 seconds, at which the
Gate/Expander reduces the signal level once it has passed below the threshold. Note that this control
interacts with the Range control.
FAST ATT – Provides a fast attack time (100µs per 40db). When off, a controlled linear attack time of 1.5ms
per 40dB is selected. The attack time is the time taken for the Expander/Gate to ‘recover’ once the signal
level is above the threshold. When gating signals with a steep rising edge, such as drums, a slow attack
may effectively mask the initial ‘THWACK’, so you should be aware of this when selecting the appropriate
attack time.
HOLD – Determines the time after the signal has decayed below the threshold before the gate closes.
Variable from 0 to 4 seconds.
The green LEDs in the display section indicate Expander/Gate activity (the amount of gain reduction).
Note that when the Dynamics section is not in circuit, its sidechain input is also bypassed.
4.5 Filters Section
This section comprises a four–band parametric equaliser plus high and low pass filters. The EQ and filters
can be routed separately to different audio paths within the module.
Routing Buttons
There are four routing buttons associated with this section of the
module. Section 5 describes the routing combinations in more detail
but, briefly, these buttons function as described below.
LPF IN, HPF IN – Switches the Lo and Hi pass filter section into
circuit. If no other buttons are pressed, the Filters are post the
Equaliser.
DYN SC – The Filters are switched into the sidechain of the Dynamics
section. The Equaliser can be switched into the sidechain
independently. Note that DYN SC overrides the INPUT function (see
below).
INPUT – Moves the Filters to put them in circuit immediately post the Channel Input section.
This allows the Filters to be used to clean up signals before compressing them. Selecting Dynamics ‘PRE
EQ’ will allow the compressed signal to be EQ’d.
The Filter section is completely bypassed when both Filter IN switches are not selected.
XLogic Channel Owner’s Manual
Page 10
DYN
S/C INPUT
LPF
IN
FILTERS
35 3
KHz
25
9
4
15
30
Hz
500
20
60 100
300
HPF
IN
RELEASE
4
EXP
HOLD
0
THRESHOLD
+10
0
3
0
COMPRESSOR
+10 1
20141063
RELEASE
14
0
-20
RATIO
1∞
DYN
IN
KEY LINK
PRE
EQ PK
FAST
ATT
DYNAMICS
FAST
ATT
GATE
RANGE
040
THRESHOLD
4

4.6 Equaliser Section
Routing Buttons
There are three buttons associated with this section of the unit. Section 5 describes the routing
combinations in more detail but, briefly, these buttons function as described below.
EQ IN – Switches the EQ section into circuit.
DYN SC – Switches the EQ section into the sidechain of the Dynamics section. The Filter section can be
switched independently of the EQ section. If both Filter and EQ sections are assigned to the dynamic
sidechain the Filter section precedes the EQ.
E – Switches the EQ from ‘G’ operation to ‘E’ operation – see below.
Operation
This is a 4-band equaliser that can be switched between two different sets of curves, one based on SSL’s G
Series EQ and the other based on the latest version of the classic E Series EQ.
HF Section: Frequency range 1.5kHz – 22kHz, gain ±20dB.
LF Section: Frequency range 40Hz – 600Hz, gain ±16.5dB.
The HF and LF sections provide shelving equalisers with variable turnover frequency. Normally the curve
has a degree of overshoot/undershoot (depending on whether you are boosting or cutting) below the
selected HF frequency (or above the selected LF frequency). Selecting the ‘E’ button removes the
overshoot/undershoot effect and provides a slightly gentler slope. Selecting BELL in either mode switches
the equaliser to a peaking curve.
HMF Section: Centre frequency 600Hz – 7kHz, gain ±20dB, continuously variable Q (0.7 – 2.5).
LMF Section: Centre frequency 200Hz to 2.5kHz, gain ±20dB, continuously variable Q (0.7 – 2.5).
Normally, at any Q setting, the bandwidth of the HMF and LMF sections varies with gain, whereby an
increase in boost or cut increases the selectivity of the EQ. This type of EQ can sound effective when used
at moderate settings; the gentle Q curve lends itself to the application of overall EQ on combined sources
and subtle corrective adjustments to instruments and vocals.
When the EQ is switched to ‘E’ operation, the bandwidth of the HMF and LMF sections remains constant
at all gains, so at lower gains the EQ curves are comparatively narrower for a given Q setting. This is
particularly useful for drums, since relatively high Q is available at low gain settings. However, it is not
so suitable for overall EQ or subtle corrections, as you need to adjust the Q to maintain the same effect
when the gain is changed.
4.7 Output Section
The Output section consists of a ±20dB output gain control, indented at
centre and a 7-segment LED meter. Normally the meter reads the output of
the channel, but selecting MTR INPUT will meter the signal immediately
post the input section.
The blue POWER LED indicates that the unit is powered (what else?).
The ADC LOCK LED indicates that the (optional) ADC card is locked to an
external clock.
Operation
Page 11
KHz
.6
15
Q
Q
Hz
40 600
60 400
KHz
.2 2.0
.3 1.6
HF
+
GAIN
LMF
+
GAIN
LF
+
GAIN HMF
BELL IN
EQ EDYN
S/C
2
150 220 .6 1.0
7
KHz
1.5 22
215
+
GAIN
BELL
35
10
GAIN
1260-12-24 2418
MTR
INPUT
+20
-20
OUTPUT
ADC LOCK
POWER

INPUT GAIN
+6 — +72dB
+48V
PHANTOM
POWER
+48V
HI Z
INPUT A
INPUT B
INSTRUMENT
Ø
KEY INPUT
DYN
S/C
EQ F EQ F
DYN SCH DYN
SCH
KEY
FDYN
S/C
INPUT
PRE
EQ
LINK
Stereo Jack
DYN LINK
INP
BOUTPUT GAIN
±20dB
OUTPUT
1260-12-24 2418
MTR
INPUT
INST
XLogic Channel Owner’s Manual
Page 12
XLogic Channel Block Diagram

5.0 Signal Routing
Channel Processing Order
There are two switches that control the order of the signal processing elements. These are Filters to INPUT and
Dynamics PRE EQ. The table below shows the effect of these:
Side Chain Processing Order (KEY switch released)
The EQ and filter sections can be assigned to the dynamics side chain using the DYN S/CH switches in the
respective sections. The table below shows the sidechain source and processing for the various combinations of
these:
Side Chain Processing Order (KEY switch in)
Finally the side chain can be fed from the KEY input on the rear of the unit by selecting KEY. The table below
shows the sidechain source and processing for the various combinations of DYN S/CH switches:
Switch 1 Switch 2
KEY Input
EQ to
'DYN S/C 'KEY Input Equaliser
Filters to
'DYN S/C 'KEY Input Filters
EQ to
'DYN S/C '
Filters to
'DYN S/C 'KEY Input Equaliser Filters
Side chain processing order
Switch 1 Switch 2 Side chain
source
Dynamics
Input
EQ to
'DYN S/C '
Dynamics
Input Equaliser
Filters to
'DYN S/C '
Dynamics
Input Filters
EQ to
'DYN S/C '
Filters to
'DYN S/C '
Dynamics
Input Equaliser Filters
Side chain processing order
Switch 1 Switch 2
Equaliser Filters Dynamics
Filters to
'INPUT' Filters Equaliser Dynamics
Dynamics
'PRE EQ' Dynamics Filters
Filters to
'INPUT'
Dynamics
'PRE EQ' Filters Dynamics Equaliser
Processing Order
Equaliser
Signal Routing
Page 13

Appendix A – Internal Links and Fuses
Fuses (Mains Inlet)
The mains inlet contains a single 1 amp 1.25" time delay fuse (SSL Part No. 35FJJ310). To change it disconnect the
mains inlet, then using a small screwdriver prise open the mains selector cover. This contains the fuse. Test and
replace with the same type and value if necessary.
Internal Fuses
The internal power rails are also individually fused. These fuses should only be changed by suitably experienced
staff. They are listed below:
Fuses (629610X2 Power Regulator Card)
+48V FS1 - 500mA wire ended (SSL part No. 35F5E250)
Fuses (629601X1 Main Card)
–18V FS1 - 3 amp wire ended (SSL part No. 35F5E330)
–15V FS2 - 3 amp wire ended (SSL part No. 35F5E330)
+15V FS3 - 3 amp wire ended (SSL part No. 35F5E330)
+18V FS4 - 3 amp wire ended (SSL part No. 35F5E330)
+5V FS5 - 3 amp wire ended (SSL part No. 35F5E330)
Links
LK1 Solder link. Links digital and analogue 0V. Do not remove.
LK2 Links chassis and analogue 0V. Normally fitted. Remove to increase impedance to 10Ω.
XLogic Channel Owner’s Manual
Page 14

Appendix B – Connector Details
Appendix
Page 15
All XLR Inputs and Outputs
Location: Front and Rear Panels
Conn' Type: XLR Female
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve
Instrument Input
Location: Front Panel
Conn' Type: Mono 1/4" Jack Socket
Pin Description
Guitar Input
Chassis
Tip
Sleeve
Dynamics Link
Location: Rear Panel
Conn' Type: Stereo 1/4" Jack Socket
Pin Description
Link Bus*
Link Bus*
0V
Tip
Ring
Sleeve
*Note that tip and ring are linked to allow use of
mono jacks

Appendix C – Performance Specification
The following pages contain audio performance specification figures for the XLogic Channel unit. No other Solid
State Logic products are covered by this document and the performance of other Solid State Logic products can
not be inferred from the data contained herein.
Measurement Conditions
For each set of figures on the following pages, the specific unit and test setup will be stated at the beginning of
that section. Any changes to the specified setup for any particular figure(s) will be detailed beside the figures to
which that difference applies.
Measurement References
Unless otherwise specified the references used in this specification are as follows:
• Reference frequency: 1kHz
• Reference level: 0dBu, where 0dBu ≈ 0.775V into any load
• Source impedance of Test Set: 50Ω
• Input impedance of Test Set: 100kΩ
• All unweighted measurements are specified as 22Hz to 22kHz band limited RMS and are expressed in
units of dBu
• All distortion measurements are specified with a 36dB/Octave low pass filter at 80kHz and are expressed
as a percentage
• The onset of clipping (for headroom measurements) should be taken as 1% THD
• Unless otherwise quoted all figures have a tolerance of ±0.5dB or 5%
Channel Microphone Amplifier
Measurement Conditions
Signal applied to Channel Microphone Input (A or B) and measured at Output. Pad switched out and Input Gain
control set to +6dB.
Gain Variable from +6dB to +72dB in 6dB steps
Independently switchable 18dB Pad available
Input Impedance > 1.5kΩ (or 8.45kΩ with HI Z ‘IN’)
Output Headroom > +26dBu at onset of clipping
THD + Noise < 0.003% at 1kHz
(-10dBu applied, +30dB gain) < 0.005% at 10kHz
Frequency Response +0.05dB/-0.1dB from 20Hz to 20kHz
–3dB at 200kHz
Equivalent Input Noise < –127dBu at maximum gain (input terminated with 150Ω)
< –90dBu at 0dB gain (+18dB with Pad ‘IN’)
Common Mode Rejection > 75dB from 50Hz to 1kHz
(-10dBu applied, +30dB gain) > 70dB at 10kHz
XLogic Channel Owner’s Manual
Page 16
