SOLIS CREMA SL 70 User manual

Legend:
Removable water reservoir and cover
Storage plate for cups
Swivelling steam and hot-water nozzle
Hot-water/steam knob
Height-adjustable cup tray
Removable drip tray
Filter holder
Built-in grounds tamper
Filter set, containing: one-cup insert, two-cup insert
and portion-insert
Measuring spoon
Dear Customer,
Congratulations on acquiring this new Crema espresso machine, a
Swiss quality product. Please read these instructions carefully and
follow them. By doing so, you and your guests will truly enjoy your
SOLIS CREMA. Please keep these instructions in a safe place. If
you are not sure about anything or would like more information,
please ask us or your local dealer. We are always ready to help.
SOLIS LTD.
SOLIS CREMA SL 70 User’s manual
46
2
3
4
5
6
7
8
9
10
1
10
9
8
7
2
3
4
56
1
This espresso machine is partially registered and patented in
Europe and overseas.

1.0 Safety instructions Page 48
2.0 General comments Page 49
3.0 Starting up / Before using for first time Page 50
4.0 Making coffee with ground coffee Page 51-52
5.0 Making coffee with portions Page 52-53
6.0 Making hot water Page 53
7.0 Making steam Page 53-54
8.0 Pre-heating the cups Page 54
9.0 Care and cleaning Page 55
10.0 Decalcifying Page 56
11.0 Trouble-shooting Page 57
12.0 Useful tips for coffee Page 58
13.0 Recommended accessories Page 58
14.0 Technical data Page 59
Control panel:
Main switch On/Off
Pump switch
Steam switch
Coffee temperature indicator
Steam temperature indicator
ON
OFF
SOLIS CREMA SL 70
User’s manual
47
Table of contents:

1.0 Safety instructions
Children do not understand how dan-
gerous electrical appliances can be.
For that reason, children should never
be allowed around electrical applian-
ces without supervision.
Do not use the appliance without stu-
dying the user manual or being shown
how to operate it.
Never use an appliance with a faulty
cord. Since special tools are needed
to replace a damaged cord, this work
must be carried by a manufacturer-
designated repair station.
Do not immerse the appliance in
water. Do not use the appliance with
wet hands.
Do not remove the filter holder while
the coffee is pouring. As the appliance
is under pressure, wait until the coffee
has stopped pouring.
The socket to which the appliance is
connected must be earthed. For your
safety, we recommend the use of an
FI safety adapter (available from all
good electricians).
Place the appliance on a firm, level
surface. The surface must not be
warm or hot. Choose a position which
is out of reach of children or pets.
Be careful when touching the steam
nozzle and filter holder as they beco-
me hot when the appliance is in ope-
ration (DANGER OF SCALDING!).
SOLIS CREMA SL 70 User’s manual
48

Be sure to remove the plug before
cleaning the appliance. Do not allow
the cord to come into contact with hot
parts of the appliance.
Do not expose the appliance to clima-
tic conditions (rain, snow, frost, etc).
When you unpack the appliance, plea-
se check that the voltage indicated on
the plate on the base of the appliance
is the same as your own main supply.
2.0 General comments
Do not operate the appliance without
water and coffee.
Any work on the appliance must be
carried out by authorised technicians.
Otherwise, all guarantee claims and
warranties are invalidated.
The appliance is intended for the pre-
paration of hot water, steam and cof-
fee and must not be used for any
other purpose. The appliance is desi-
gned for domestic use. If it is used for
commercial purposes, warranty condi-
tions will change. Please observe the
guarantee conditions.
The original packaging has been made
specially strong so that the appliance
can be sent by post. Please retain
the packaging in case it should be
necessary to return the appliance.
The appliance may be damaged by
freezing. For this reason, it must be
protected against frost and should not
be left overnight in a car during winter.
SOLIS CREMA SL 70
User’s manual
49
SERVICE

3.4 Vent the appliance.
To do this, place a large container
under the hot water/steam nozzle, turn
the rotary knob and activate the pump
switch until a steady stream of water
comes out of the nozzle. Let it run until
about 2 dl of water has been collected,
then close the rotary switch and turn off
the pump switch again. The applian-
ce has now been vented.
3.5 Rinse the appliance out. To do
this, fit the empty filter holder and place
a cup underneath. Turn the pump
switch on until the cup is full. Turn
the switch off again. The appliance
has now been rinsed out.
3.6 The appliance is ready to ope-
rate when the temperature light
shows green. We recommend leaving
the empty filter holder in place while the
appliance is heating up so that it is pre-
warmed.
3.0 Starting up
3.1 Fill the water container with
cold water up to a maximum of 3 lit-
res. Insert it into the rear of the appli-
ance and press home firmly so that the
base valve opens. Close the cover.
Note: Use only fresh cold water to fill
the container. Do not use mineral
water, milk or any other fluid.
3.2 Pull the required length of
cord out from the back of the
appliance. Leave the rest in the spe-
cial cable compartment. Connect the
appliance to an earthed socket.
3.3 Turn the main switch to ON.
The appliance must now be vented
and rinsed out.
Note: The best time to remove air from
the appliance is when it is cold. For
this reason, start the venting operation
as quickly as possible after switching
on.
SOLIS CREMA SL 70 User’s manual
50

IMPORTANT: Never operate the
appliance without water. For reasons
of hygiene, we would recommend you
to vent and rinse out the appliance
before it is used for the first time or
after any long period of non-use (e.g.
after the holidays).
4.0 Making coffee with ground
coffee
It is assumed that the appliance has
been started up in accordance with
Point 3 and is ready to operate, i.e.
the container has been filled with
water and the temperature light is
showing green.
4.1 With the appliance ready, fit
the appropriate filter (one-cup or
two-cup) into the filter holder.
Depending on the filter size, fill with
one or two level measuring spoons of
coffee and press down lightly with the
built-in tamper . Wipe the edge of the
filter holder to remove any coffee
grains.
4.2 Insert the filter holder into the
brewing unit by moving from left
to right and close tightly. Check that
the filter holder is fully tightened.
4.3 Place one or two cups on the
tray under the filter holder.
Note: The height of the tray can be
adjusted to take small espresso cups
simply by turning it.
4.4 Activate the pump switch
and coffee will be poured.
SOLIS CREMA SL 70
User’s manual
51

4.5 As soon as your cup is full,
turn off the pump switch .This will
stop the pouring.
4.6 Now remove the filter holder
from the brewing unit by moving it
from right to left. Holding the filter
firmly with the filter holder, knock out
the grounds.
Note: You can use a special SOLIS tray
for your grounds (see Section 13.0,
recommended accessories).
Rinse the filter under running water and
replace the filter holder in the brewing
unit. Once the filter has been refilled,
the next cup of coffee can be prepared.
5.0 Making coffee with portions
It is assumed that the appliance has
been started up in accordance with
Point 3 and is ready to operate, i.e.
the container has been filled with
water and the temperature light is
showing green.
5.1 The procedure is just the
same as for ground coffee, except
that the following points must be
observed.
Please prepare SOLIS coffee portions
(see adjacent illustration and section
13.0 «Recommended accessories»)
with the special portion-filter insert
only, and do not use the 1 or 2 cup fil-
ter. The portion filter is specially desi-
gned for the «hard» portion bags.
«Soft» SOLIS portions or other brand
name portions should be prepared in
the 1 or 2 cup filter as recommended
by the coffee producer.
SOLIS CREMA SL 70 User’s manual
52

Note: If the coffee comes out of the
sides of the filter holder, the portion is
either too big for the filter insert or the
filter holder has not been properly ins-
erted.
As all SOLIS CREMA espresso machi-
nes are fitted with both portion inserts
and one-cup and two-cup filters, you
will have no problem in using any ordi-
nary filter-paper portions, provided
that you take note of the points listed
above. However, please be sure to fol-
low the coffee manufacturer’s instruc-
tions.
6.0 Making hot water
For tea, broth, etc. It is assumed that
the appliance has been started up in
accordance with Point 3 and is ready
to operate, i.e. the container has been
filled with water and the temperature
light is showing green.
6.1 With the appliance ready,
place your glass or cup directly
under the hot water/steam nozzle
and turn the rotary knob and activate
the pump switch . The hot water
now runs automatically.
6.2 After pouring the water requi-
red, close the rotary switch and
turn off the pump switch
7.0 Making steam
For heating milk and for cappuccino or
other drinks.
It is assumed that the appliance has
been started up in accordance with
Point 3 and is ready to operate, i.e. the
container has been filled with water and
the temperature light is showing
green.
7.1 With the appliance ready,
activate the steam switch and
wait until the temperature light shows
green.
7.2 Turn the rotary knob slightly,
allowing the condensed water to run
out into the drip tray. Next, swing the
steam jet out and immerse it in the
liquid to be heated. Slowly open the
rotary switch and heat the liquid by
making circular movements from bot-
tom to top.
SOLIS CREMA SL 70
User’s manual
53

8.0 Pre-heating the cups
Apart from the type of blend and the
quality of the water, the most important
factor in making a good cup of coffee is
getting the right temperature.
8.1 Place your cups on the storage
plate to be kept warm (indirect hea-
ting by the radiation from the heating
system).
8.2 If you need to heat cups
quickly, you can rinse them out with
hot water from the hot water nozzle.
7.3 When no more steam is nee-
ded, turn the rotary switch off
again. Swing the steam nozzle back to
the cup tray or leave in an empty con-
tainer. Turn off the steam switch
7.4 With the steam switch off,
turn the rotary knob, activate the
pump switch again and allow the
appliance to vent/cool down until water
emerges from the nozzle in a steady
stream. Then, turn the rotary switch off
again.The appliance is now ready to
make coffee again.
IMPORTANT: After steam has been
used, the appliance must be vented
and allowed to cool (see also under
Point 3.4). The steam nozzle can beco-
me very hot. To prevent scalding, avoid
direct contact with the skin.
Note: We recommend that you clean
the steam nozzle immediately after use.
Otherwise, milk can leave residues
which are difficult to remove.
SOLIS CREMA SL 70 User’s manual
54

9.0 Care and cleaning
If you always keep your SOLIS CREMA
machine clean, you will be sure of
good quality coffee and will extend the
useful life of the appliance.
9.1 Daily and weekly care:
Regularly clean the water container,
the drip tray, the cup tray, the filter hol-
der and the filter inserts. Simply use
hot water and, when necessary, a non-
scouring detergent.
DO NOT place in the dishwasher!
Brewing unit: Remove coffee resi-
dues regularly and wipe with a clean
damp cloth. We recommend you to let
about half a litre of hot water run
through from time to time, as this
keeps the brewing unit clear of fat resi-
dues.
SOLIS CREMA SL 70
User’s manual
55
If the brewing filter becomes very stai-
ned , remove it with a screwdriver and
brush both sides thoroughly.
Filter inserts: Rinse the 1 and 2 cup
filter inserts from time to time to keep
them clean. To do so, place the filter
holder with empty filter inserts in the
SOLIS Crema, position a cup under the
filter holder and switch on the pump
until the cup is full. Switch off the
pump. The rinsing operation is now
complete.
Housing: Where necessary, the hou-
sing should be cleaned with a damp
cloth and then rubbed dry with a cloth.
IMPORTANT: The appliance must not
be immersed in water. Switch off the
appliance and remove the plug during
all cleaning and care operations.

SOLIS CREMA SL 70 User’s manual
56
10.0 Decalcifying
Even if a water filter is used, the appli-
ance should be decalcified regularly in
accordance with the hardness of your
local water and, in any event, at least
every four to six months.
10.1 For decalcification, it is best
to use SOLIPOL, a product specially
designed for this purpose.
10.2 With the appliance switched
off, fill the water container in proporti-
ons of one part water and one part
SOLIPOL (0.5 litres of water and 0,5
litres of SOLIPOL).
10.3 Turn on the hot water/steam
rotary knob, activate the pump
switch and place a container under
the steam jet. Now, turn the main
switch ON and let water run from the
jet for about 1 minute.
10.4 Turn the main switch OFF
and leave the decalcifying product to
take effect for about 10 minutes.
10.5 Repeat 10.3 and 10.4 twice.
Then, rinse out the water container
thoroughly and fill with fresh water.
10.6 Turn the main switch ON and
rinse the appliance out thoroughly by
allowing the fresh water (approx. 2 lit-
res) to run out through the hot water
nozzle. This will ensure that nothing
remains which might affect the taste
of the coffee. The SOLIS CREMA is
now ready for use again.
IMPORTANT: Regular decalcification
will protect your machine from the
need for expensive repairs. It should
be noted that damage caused by failu-
re to carry out the necessary decalcifi-
cation, by misuse or by not following
the above instructions IS NOT
COVERED BY THE WARRANTY.
Vinegar must not be used for decal-
cifying purposes as it will damage the
appliance.

11.0 Trouble-shooting
Before returning the appliance for repair, please read the following
points carefully. This will often solve the problem and save you a lot
of bother.
11.1 Coffee comes out of the sides of the filter holder
•the filter holder is not properly fitted
•the filter holder is not tight enough
•there are coffee residues on the edge of the filter
•the seal is damaged or worn. Return the appliance for repair.
11.2 Pump is noisy
•the water container is empty
•the water container is not properly fitted
•the pump is not producing enough pressure because the coffee
is old or too coarsely ground.
11.3 No coffee comes out
•there is no water in the container
•the water container is not properly fitted
•the coffee is too finely ground or has been pressed down too
hard
•the appliance is set for steam
•the filter or the brewing unit are blocked and needs cleaning
•the appliance needs decalcifying
•the appliance is not vented/cooled and needs venting.
11.4 The coffee has no foam, pours too quickly or too slowly
•the coffee blend is unsuitable
•the coffee is too finely or too coarsely ground
•the coffee is no longer fresh
•there is not enough coffee in the filter
•the coffee needs to be pressed down more
•the cups are too cold and need pre-heating
•the appliance is not reaching the correct operating temperature.
SOLIS CREMA SL 70
User’s manual
57
If the problem still cannot be solved after checking the above
points, please return the appliance in the original packaging to our
customer service department, stating the nature of the fault.
In Switzerland, send the appliance to:
SOLIS PRODUZIONE SA
Customer Service Department
Centro SOLIS
6850 Mendrisio
Tel. 091/ 646'16'65/ 646'81'36
Fax 091/ 646'03'62
For repairs in all other countries in which SOLIS products are
sold, send the appliance to the customer service centre of the
SOLIS branch indicated on the warranty card.

SOLIS CREMA SL 70 User’s manual
58
If your local water is very hard, use a
filter such as the SOLIS AQUA-
SELECT.
If you want to get consistently good
coffee without having to clean gro-
unds out of the filter holder all the
time, try using SOLIS portions. They
are practical, clean and always ready
to use.
12.0 Useful tips for coffee
12.1 Optimum conditions for good coffee
Good coffee depends not only on the appliance but also on the
water, the blend of coffee, the grinding, the temperature, etc. You
should keep the following tips in mind:
Always use fresh coffee and dark roasts, such as the SOLIS pro-
ducts specially blended for use with espresso machines.
Fresh coffee should always be stored in a cool place. It can be
deep frozen and may be used directly while still cold.
Always have coffee beans ground to espresso grade. If the result is
still not satisfactory, check Point 11.4.
13.0 Recommended accessories
To simplify the care and maintenance of your SOLIS CREMA, we
recommend:
SOLIS Aqua-Select water filter: helps to reduce water hardness
and so to avoid premature calcification.
SOLIS Solipol decalcifying agent: specially designed for easy
decalcifying of espresso machines.
SOLIS storage box: specially designed to store opened packets
of coffee and portions.
SOLIS grounds drawer: specially designed for knocking out the
grounds from the filter holder.
CAFÉ SOLIS coffee blends: a variety of exclusive blends special-
ly selected for espresso machines. They guarantee good coffee.
CAFÉ SOLIS portions: three blends - espresso, café crème and
decaffeinated coffee. They come in practical portions specially
made for filter holder espresso machines. They are practical, clean
and ready for use at any time!

SOLIS CREMA SL 70
User’s manual
59
In Switzerland, these accessories are obtainable from specialist
stores, supermarkets and department stores or directly from
SOLIS MAIL
6850 Mendrisio
Tel. [phone]
Fax [phone]
In all other countries in which SOLIS products are sold, these
accessories can be obtained through the trade or directly from the
SOLIS subsidiaries indicated on the warranty card.
14.0 Technical data
Voltage: 230 V / (USA: 115 V)
Watts: 1100 Watt
Water reservoir: 3 liters
Cable length: 1.1 m, with 3-pin plug
Weight: 7,5 kg
Dimensions: 310 x 270 x 235 mm
Approbations: SEV and international safety approvals
00260
