SOLIS S3-WIFI-ST User manual

User Manual
External WiFi Data Logger for
Remote System Monitoring
Version 1.3 Release Date: 01/12/2023
Model Number: S3-WIFI-ST

● This device should only be installed by professional personnel who are qualified to
operate Solis equipment.
● Product specifications are subject to change without notice. Every attempt has been
made to make this document complete, accurate and up-to-date. Individuals reviewing
this document and installers or service personnel are cautioned, however, that Solis
reserves the right to make changes without notice and shall not be responsible for any
damages, including indirect, incidental or consequential damages caused by reliance
on the material presented including, but not limited to, omissions, typographical errors,
arithmetical errors or listing errors in the material provided in this document.
● Solis accepts no liability for customers' failure to comply with the
instructions for correct installation and will not be held responsible for upstream or
downstream systems Solis equipment has supplied.
● The customer is fully liable for any modifications made to the system; therefore,
any hardware or software modification, manipulation, or alteration not expressly
approved by the manufacturer shall result in the immediate cancellation of the warranty.
● Solis will not be held liable for defects or malfunctions arising from:
● Improper use of the equipment.
● Deterioration resulting from transportation or particular environmental conditions.
● Performing maintenance incorrectly or not at all.
● Tampering or unsafe repairs.
● Use or installation by unqualified persons.
● This manual is to be used for the S3-WIFI-ST data logger only. It should not be used for
any other Solis device.
● For additional assistance with SolisCloud, please go to the Ginlong US website and
download the SolisCloud user manual: www.ginlong.com/us
Important Notes
Solis Support can be reached by calling [phone] or by
sending an email direclty to [e-mail]
Please provide the support team with the data logger serial number,
inverter serial number, and a detailed description of the issue that
you are having. The support team will assist you in a timely manner.
.
Contacting Solis Technical Support

This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including interference that may
cause undesired operation
FCC Warning:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures: (1) reorient or relocate the receiving antenna (2) increase the separation
between the equipment and the receiver (3) connect the equipment into an outlet on a
circuit different from that to which the receiver is connected or (4) consult the dealer or an
experienced radio/TV technician for help
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance
of 20 centimeters (7.87 inches) between the radiator and your body.
FCC Certification

6 Technical Specs
5 Decommissioning
4 Commissioning
3 Configuration
2 Installation
1 Introduction
Table of Contents

1
1
1
1.1 Data Logger Description ...................................................................
1. Introduction .........................................................................................
1.2 Compatible Solis US Inverter Models .................................................
2. Installation ...........................................................................................
3. Configuration ......................................................................................
Table of Contents
1.3 LED Indicator Lights .........................................................................
2.1 Pre-Installation Steps .......................................................................
2.2 Installation Steps ........ .....................................................................
2.3 Connecting Multiple Inverters to One Data Logger ...............................
4. Commissioning ...................................................................................
4.1 Download SolisCloud and Register an Account ...................................
4.2 Create a New Plant for the System .....................................................
4.3 Add the Data Logger to the Plant .......................................................
5. Decommissioning ...............................................................................
6. Technical Specifications .....................................................................
2
3
3
3
4
5
8
8
9
9
10
11

1.1 Data Logger Description
The Solis WiFi Data Logger is an external device which plugs directly into to a port on
the bottom of a Solis inverter. The logger relays information from the inverter to the
Solis monitoring platform, called SolisCloud. This logger connects to a local 2.4GHz
WiFi network, it is incompatible with 5GHz networks. Up to ten Solis inverters can be
daisy-chained together with RS485 to communicate through one WiFi logger. This
logger works with any Solis inverter that has a 4-pin COM port, please reference the
list below for all compatible Solis US inverter models.
Figure 1.1
Logger Parts
1
1. Introduction
Lock Ring
Antennae
LED Indicator Lights
4-pin Connector
Solis-1P(2.5-6)K2-4G-US
Solis-1P(6-10)K-4G-US
RHI-1P(5-10)K-HVES-5G-US
Solis-(25-40)K-US
Solis-(50-66)K-US
Solis-(75-100)K-5G-US
S5-GC(75-100)K-US
Solis-(125-255)K-EHV-5G-US-PLUS
1.2 Compatible Solis US Inverter Models
The S6-EH1P(3.8-11.4)K-H-US hybrid
inverter series does not support the
Solis S3-WIFI-ST WiFi data logger.
Note
Reset Button
Lock Ring

1.3 LED Indicator Lights
The Solis S3-WIFI-ST data logger has three LED indicator lights. These lights depict
the status of the logger. There are three lights: NET, COM, and PWR. The chart below
explains what the lights mean when they are flashing, solid, or off. lf the LED lights are
all off when the inverter is getting proper voltages, please contact Solis Support.
Figure 1.2 LED indicator lights and normal logger behavior
2
1. Introduction
LED Indicator
Description
LED
Status
Meaning
Internet
Connection
NET
Connection status
between the data
logger and the local
WiFI network
Flashing
Attempting to connect to the WiFi network
Solid
Successfully connected to the WiFi network
Off
Not connected to the WiFi network
Inverter
Communication
COM
Communication
status between the
logger and the
inverter
Flashing
Attempting to communicate with the inverter
Solid
Communicating with the inverter normally
Off
Not communicating with the inverter
Logger Power
PWR
Power from the
inverter to the
logger
Solid
Data logger is powered up normally
Off
Data logger is not getting enough power
Normal Operation:
Once the logger has been configured
properly, all three LED indicator lights should be solid.
Every Five Minutes:
The logger will transmit a data package to SolisCloud.
When this happens, the COM light will flash for a few
seconds. This is normal behavior and should not cause
any concern.

2.1 Pre-Installation Steps
Prior to installing the S3-WIFI-ST logger, the following steps must first be taken to
ensure that the logger will function properly once it has been installed.
1. The Solis inverter is completely installed and commissioned
2. The inverter address is 1: Go to Settings, then to Address, verify the number is 1,
if the number is not one, use the down button to change it to 1 and then press enter
3. Turn the inverter on with both AC and DC power
4. Ensure the WiFi network is 2.4 GHz, the logger does not support 5 GHz
5. Verify that WiFi network password is correct - check it by connecting with your phone
6. Check the signal strength of the WiFi network you plan to connect the logger to by
performing a network speed test.
See section 2.3 for instructions on how to connect multiple inverters to one logger
3
2. Installation
2.2 Installation Steps
Figure 2.1
COM Port
The data logger plugs into the 4-pin COM port on the bottom of the inverter wire box.
This port is protected by a black cap that screws on. The first step is to unscrew the cap.
Figure 2.1 shows the Solis-1P10K-4G-US inverter wire box as an example.
Other Solis inverters will have a similar green COM port on the bottom of the wire box.
Step 1: Locate the COM port and remove the protective cap
The minimum WiFi signal strength for the
logger is -90 dBm (20% RSSI) which equates
to approximately 11 Mbps upload speed.
Distance from the router to the logger should
be no more than 300 feet with no obstructions.
If there are obstructions, this distance is
significantly less. Please install a WiFi range
extender if the upload speed is under 11 Mbps.
Note

4
2. Installation
Step 2: Attach the antenna and plug the logger into the COM port
A.Screw the antenna onto the logger. Then plug the logger into the COM port. Be sure
the LED indicator lights are facing forward. The logger will only plug in if the joint matches.
B.Twist the black lock ring at the top the logger clockwise until it feels snug against the
bottom of the inverter. Be careful not to rotate the silver casing during this step.
match the joint
2.3 Connecting Multiple Inverters to One Data Logger
First, the inverters must first be daisy-chained together with RS485. The logger can
support a maximum of ten inverters. If there are more than ten inverters on the same
system, then additional loggers must be installed. Please see the inverter manual for
instructions on how to complete the daisy chaining.
Step 1: Daisy chain the inverters together with RS485 communication cable.
Step 2: Plug the data logger into the first inverter in the daisy chain.
Step 3: Adjust the address for each inverter.
Note: The first inverter should be set to 01. Each of the other inverters in the chain must
be set to a number other than 1.To do this,follow the steps:
A. Go to the Settings menu of each inverter and then to the Address submenu.
B. Use the up/down buttons to change the address number
C. Press enter to save the new address of the inverter
For example:
Inverter 2 = address of 2, Inverter 3 = address of 3... Inverter 10 = address of 10
Step 4: Commission the logger like normal. Each inverter in the daisy chain will populate
into SolisCloud once the logger transmits the first data packet.
The logger will collect and transmit information from all of the inverters in the daisy chain
to SolisCloud. Only the logger gets added to the new plant on SolisCloud. The inverters
will automatically populate into the plant once the logger starts to report to SolisCloud.

5
Step 1: Connect your phone to the data logger’s access point network
3. Configuration
Open your phone WiFi settings and look for the WiFi network that starts with “Solis_”
followed by the data logger serial number. Tap that network to connect to it. Enter the
password and then tap Join. This is the logger access point (AP) network.123456789
If you get a message stating that the password is incorrect or if the logger WiFi network
does not appear in the list of nearby networks, press and hold the Reset button on the
back of the data logger for 15 seconds.
If the AP network still does not appear or if the password fails again, contact Solis Support.
Configuration and Commissioning Overview
Connect phone to logger
access point network
Go to logger configuration
page on a browser app
Select the desired WiFi
network & enter password
Wait ten seconds for the
logger to communicate
Download SolisCloud and then
register a new account
Create a new plant for
the system on SolisCloud
On the new plant, go to
add a device
Scan the sticker
on the logger
Wait five to ten minutes
for the logger to report
Once the logger reports, the inverter(s)
will auto-populate into the new plant The system has now been commissioned
Solis Support can be reached by calling [phone] or by
sending an email direclty to [e-mail]
Please provide the support team with the data logger serial number,
inverter serial number, and a detailed description of the issue that
you are having. The support team will assist you in a timely manner.
.
Contacting Solis Technical Support
