Solmetex NXT Hg5 mini User manual

NXT Hg5® mini Amalgam Separator
Installation and Operations Manual
TM

NXT Hg5®mini Amalgam Separator
The waste stream treated by the NXT Hg5® mini is discharge from a dental
vacuum system and as such may contain concentrations of solid and
soluble mercury and silver.
• Always wear protective gear when handling full NXT Hg5® mini
collection containers (latex gloves, safety glasses or face shield) and
dispose of per local regulations and codes.
• Full collection containers should be handled, stored and disposed
of according to regulations applying to hazardous waste containing
mercury.
• Any spills should be considered hazardous and should be handled in
accordance with standard hazardous materials handling procedures.
WARNING
!
2
Solmetex Warranty
Solmetex NXT Hg5® mini Air Water Separators are warrantied against
defects in material and workmanship for a period of two (2) years from
the date of purchase, established by proof of purchase or formal warranty
registration. During the warranty period, Solmetex will at its option repair or
replace products that prove to be defective.
Solmetex NXT Hg5® Collection Containers are warrantied against defects
in material and workmanship for a period of one (1) year from the date of
purchase, established by proof of purchase or formal warranty registration.
During the warranty period, Solmetex will at its option repair or replace
products that prove to be defective.
Labor, transportation and service charges are not included.
Limitations of Warranty
The warranty shall not apply to defects resulting from improper
installation, maintenance, abuse, unauthorized modification, or
operation outside of the environmental specifications for the product
or damages that occur due to improper repackaging of equipment for
return to Solmetex.
Use of third party collection containers or line cleaners having a
pH less than or equal to 6 or greater than 8 will void these warranties.
For recommended line cleaning solution, visit our website at
www.solmetex.com.
No other warranty is expressed or implied. Solmetex specifically
disclaims the implied warranties of merchantability and fitness for
particular purpose.
Thoroughly read and understand instructions prior
to installing, operating and servicing the NXT Hg5®
mini Amalgam Separator. These instructions are also
available on our website at www.solmetex.com.

www.solmetex.com
3
NXT Hg5®mini Amalgam
Separator Initial Set-Up
A. Engage slot on pin (see detail below).
Rotate assembly into place (keeping
slot engaged on pin).
B. Push Top Bracket
down over tabs
until unit is secured
in place.
Detail:
Slot must
fully engage
pin on Lower
Bracket.
C. Tighten Top
Bracket bolts
until snug.
3. ENGAGE SLOT ON PIN
Install (4) Captive Threaded
Inserts from rear of backplate
and secure firmly into place
using (4) hex nuts provided.
TOP BRACKET
Leave bolts loose
enough to adjust
bracket height.
BOTTOM BRACKET
Locate into fixed
position and tighten
until snug.
Hex Nuts
1. THREADED INSERTS
Attach collection
container to NXT
Hg5® mini. Lock
into place with
retaining pins.
To replace
collection
container, keep
vacuum running
remove retaining
pins and detach.
Always wear protective gear when
handling a full collection container.
4. COLLECTION CONTAINER
NOTE: The NXT Hg5® mini may be installed
in either a "right hand" or "left hand"
position. Install as best fits your application.
“Left Hand”
NXT Hg5® mini
“Right Hand”
NXT Hg5® mini
2. MOUNTING OPTIONS

NXT Hg5®mini Amalgam Separator
4
NXT Hg5®mini Installation Tips
Installation tips:
• Place in an easily accessible location for
replacement of collection container.
• Place between treatment rooms and vacuum source.
DO NOT connect to outlet of separating tank or water
ring pump.
• The NXT Hg5® mini should be installed so that the outlet is
higher than the tank or pump inlet.
• Use provided inlet and outlet couplings. DO NOT glue
plumbing to the NXT Hg5® mini inlet and outlet.
• Securely mount or support the baseplate.
• If mounting to a wall, use the mounting holes provided on
backplate.
• If attaching to the floor, use the mounting holes provided
on bottom of backplate.
• Write the installation date on the collection container.
• Complete the registration form and return to Solmetex.
The NXT Hg5® mini Amalgam Separator is a Type 2 device with a
maximum flow of 500 ml/min and maximum fillable volume of 950 ml.
Environmental Specifications:
• Overall Dimensions: 11" W x 25" H x 8" D
• One NXT Hg5® mini will serve up to 4 chairs.
• minimize water lift height.
• Maximum Temperature = 120o F (52o C)
• Maximum Vacuum = 15" Hg (51 kPa)
• For dental use ONLY.
Treatment Rooms
NXT Hg5®mini Inlet
NXT
Hg5®mini
Outlet
Tank
Inlet
Pump
Inlet
OR
DO NOT connect NXT
Hg5®mini to outlet
of tank.
DO NOT connect
NXT Hg5®mini to outlet
of the water ring pump.
Dry Vacuum Unit
Functional with 15, 30, or 50 Gallon Tank
And with Single or Dual Wet Ring Pumps.

www.solmetex.com
5
Collection Container
Your collection container must be changed once every twelve (12)
months or when the sediment level reaches the full line, whichever
occurs first. Check the sediment level of the collection container
weekly.
Maintenance
Line rinsing & vacuum line cleaners - cleaners should be deodorizing,
sanitizing & have a pH greater than 6 and less than or equal to 8.
Using line cleaners outside of this pH range will void the warranty.
For recommended line cleaning solution, visit our website at
www.solmetex.com.
With Dental Vacuum Systems: Follow manufacturer’s instructions.
Plan to rinse no more than 5 chairs every 10 minutes. Limit the total maximum
flow to the NXT Hg5® mini during rinsing to 1 liter per minute. Rinsing too much or
too rapidly can overfill the NXT Hg5® mini and could aect the unit’s eciency.
Exclusive Remedies
The remedies provided herein are the buyer's sole and exclusive remedies.
Solmetex shall not be liable for any direct, indirect, special, incidental or
consequential damages, whether based on contract, tort or any other legal theory.
Service & Troubleshooting
The NXT Hg5® mini is designed to provide years of trouble-free service, with
minimal attention. In the unlikely event of system related problems, please
review the following for product support.
Q: Solids reach full line of collection container:
A: Change the collection container.
Q: Solids are above full line of collection container:
A: Change the collection container. Inspect the top chamber for solids.
Q: Top chamber has some solids:
A: System is backed up.
• Turn on vacuum
• Remove pins
• Tilt container towards outlet pipe to allow air into top chamber
• Place container back on and insert pins
NOTICE
• Refer to NXT Hg5® Collection Container Replacement & Recycle Procedure manual
at www.solmetex.com for removal and replacement of container.
• Always wear protective gear when handling full NXT Hg5® collection containers.
• Keep the vacuum system running during the entire collection container replacement
procedure.
• These procedures should be performed only when no operatories are being used
as loss of chairside vacuum may occur.

NXT Hg5®mini Amalgam Separator
6
Q: Top chamber is full with solids:
A: System is in bypass.
• Reduction in suction
• Solids released into waste stream and environment
• Top chamber needs to be replaced
• Top chamber needs to be recycled
Q: Little or no vacuum at the hand piece.
A: Check sediment level of collection container, if full change the
collection container.
• If the vacuum gauge reads normal but there is little or no
vacuum to the hand piece, there is probably a clog or a leak
between the hand piece and the NXT Hg5®mini.
• If the vacuum gauge reads lower than normal these are the
possible causes:
Did you just replace the collection container?
Yes: Check installation of the new collection container. If the
vacuum is low there is a possibility that the O-rings on
the collection container did not seal into the receivers.
With the vacuum running, remove the collection container,
check the O-rings and re-install per the collection
container installation procedure.
No: If you have a solids collection cup (installed by others) -
check & clean or replace element/screen if necessary.
Check operation of the vacuum pump.
- Check all flexible hose for kinks, breaks, or loose clamps.
- Check all connections for breaks or cracks.
- Listen for vacuum leaks.
Q: Water in the upper chamber (Air Water Separator)
A: Check sediment level of collection container, if full change
collection container.
• Check the pH of vacuum line cleaner: if less than or equal to 6
or greater than 8 change collection container and line cleaner.
Visit www.solmetex.com for a recommended list of cleaners.
• Call or email your dental dealer for support if the problem
cannot be solved easily.
Q: The equipment/utility room has poor lighting:
A: Bring a flashlight to check the container. Using a flashlight
from the backside of the system and shining it forward will help
determine the level of sedimentation.
Service & Troubleshooting
(continued)

www.solmetex.com
Visual Inspection Log
7
Post this log by your NXT Hg5 mini Amalgam Separator
for weekly maintenance tracking.
Available to print online at:
www.solmetex.com/visualinspectionlog
_________________________________________________________________
Account Number: _____________________________________________________________
Visual Inspection Log
Date (MM/DD/YYYY) Signature
Solmetex recommends weekly inspection of your Hg5 series Amalgam
Separator. Use this log to ensure proper operation and maintenance. Visually
inspect the collection container weekly to determine the level of solid waste.
It is time to change the collection container when solids reach the full line or it has
been one year, whichever occurs first.
Oce Name:
To download a copy of this log, go to: www.solmetex.com/visualinspectionlog
www.solmetex.com | 800.216.5505

NXT Hg5 mini Install Ops Manual 03.2019
In 1999, Solmetex designed the Hg5 which quickly became the industry
standard in Amalgam Separation. We have extensive experience in
water chemistry, chemical separation science, process engineering,
high performance manufacturing, as well as federal, state and local
regulations governing water and hazardous wastes.
The Solmetex product line oers a truly green "Complete
Solution" to dental waste handling and recycling. The
Solmetex Hg5 series is the global leader and gold
standard in high performance amalgam separation.
