Installation & Operation Manual | TEQUATIC™ PLUS
Installation & Operation Manual
TEQUATIC™ PLUS F-150, C-Series
Registered Patent

1
Installation & Operation Manual | TEQUATIC™ PLUS | Disclaimer
1
Disclaimer
Copyright © 2022 Amiad Water Systems Ltd. All rights reserved.
The contents of this document, including without limitaon all informaon and materials, images, illustraons,
data, drawings, names and any other such materials that appear in this document are the sole property of Amiad
Water Systems Ltd., including any intellectual property rights, whether registered or not, and all know-how
contained or embodied therein. Amiad may alter, remove or change the Content without any further noce. You
may not reproduce, copy, modify, create derivave works from, sell or parcipate in any sale of, or exploit in
any way, in whole or in part, any of this document or its content.
The condenal nature of and/or privilege in the le enclosed is not waived or lost as a result of a mistake or
error in this le. If you received this le in error, please nofy Amiad immediately at [email protected].
This document does not replace any cered drawing, procedure or informaon provided by Amiad in reference
to a specic customer, site or project.
Amiad assumes that all users understand risks involved within this le and/or its aached materials. This
document is given in good faith and is not intended to impose any obligaon to Amiad. While every eort has
been made to ensure the informaon in this manual is accurate and complete, we would appreciate if you can
bring any errors or omissions to the knowledge of Amiad or consult Amiad experts or its authorized
representaves if you have any quesons.
Amiad Water Systems Ltd. D.N. Galil Elyon 1, 1233500, Israel Tel: [phone] | Fax: [phone]
Email: [email protected]

Installation & Operation Manual | TEQUATIC™ PLUS | Table of Contents
2
Table of Contents
Disclaimer........................................................................................................................................................1
Table of Contents .............................................................................................Error! Bookmark not defined.
Introduction...................................................................................................... Error! Bookmark not defined.
System Overview .............................................................................................................................................6
Installation.......................................................................................................................................................7
Controls Overview ............................................................................................Error! Bookmark not defined.
Main Settings.................................................................................................................................................14
Admin Settings ..............................................................................................................................................18
Start-Up and Operation.................................................................................................................................23
Maintenance .................................................................................................................................................34
Troubleshooting ............................................................................................................................................38
Spare Parts.....................................................................................................................................................41
Amiad Limited Warranty ...............................................................................................................................47

3
Installation & Operation Manual | TEQUATIC™ PLUS | Introduction
3
Introducon
Safety Information
Symbols
It is important for you to read and understand the information in this manual prior to installation
and operation of TEQUATIC™ PLUS filter skids. This manual contains information designed to
facilitate operator safety and prevent problems. The symbols below are used to reinforce key
messages throughout.
Caution: Indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury.
Notice: Indicates a potential situation which, if not avoided, can result in
property damage or damage to the equipment.
Note: Indicates information, notes, or tips for improving your success using
the equipment.
Personnel Safety Messages
➢To avoid risk of personal injury or equipment damage, please read and understand all the
safety precauons and instrucons in this secon and throughout this manual before
servicing or operang this equipment.
➢Personnel responsible for system operaon and/or maintenance should aend all available
safety and operator training courses. Procedures, safeguards, and training should be
appropriate for the types of hazards present.
➢Always disconnect electrical power from the system prior to any service of the equipment,
including opening of any electrical panel.
➢Lockout/tagout procedures should be established and ulized as appropriate for servicing
the equipment.
➢Operators should be familiar with the locaon and use of all safety devices on the machine.
Do not use the machine if it is not in proper operang condion and report any damage or
operaon faults immediately.
➢Make sure that the oors in the work area are dry and non-slip. Keep the work area clean
to promote safety, and to avoid or idenfy working hazards.
➢Always wear appropriate personal protecve equipment (PPE), such as steel-toed shoes,
safety glasses, hard hats, and long sleeves during installaon, operaon, and maintenance
of the system. Addional PPE may be required depending on the applicaon environment
and materials being used.

Installation & Operation Manual | TEQUATIC™ PLUS | Introduction
4
Property and Equipment Messages
➢This equipment is not rated for hazardous locaons.
➢Avoid electrical hazards and damage to equipment. Install in an area where water leakage from
vessel or piping will not damage sensive equipment.
➢Never operate the system at pressures and temperatures in excess of the specied rang.
➢Verify all seals and internal components are properly installed.
➢To avoid damage to the system or facility, repair any leaks as soon as discovered.
➢Always open and close valves gradually. Auto-actuated valves should open and close in such a
way as to minimize water hammer.
➢Install proper safety devices in pipes and equipment carrying hot water to avoid thermal burns.
➢Verifying the lter assembly and cleaning assembly are properly installed before operang the
system.
➢To avoid damage or hammering, expel all air from the housing and piping before startup.
➢Do not start the system with ltrate line open. This will result in premature plugging of the
lter membrane.
➢Do not over-ghten the swing bolts when securing the housing cover. Do not exceed 80 -lb
of torque.
➢Avoid lateral loading in excess of 8 pounds to connecon on the lter housing.
➢Equipment is rated for indoor installaon only.
➢Ensure chemical compability of feedwater with materials and components of the system.
Feedwater must be compable with CPVC and shall not contain ozone, permanganate, or other
strong oxidizing or corrosive agents.
➢Always use a hoist for liing the lter housing lid. The lid weighs approximately 500 pounds.

5
Installation & Operation Manual | TEQUATIC™ PLUS | Introduction
5
Parameter
Value
Max Inlet Pressure
80 psi (5.5 bar)
Process Water Temperature
45 - 140˚F (7-60˚C)1,2
Ambient Temperature Range
32 - 100˚F (0 - 37.8˚C)
Maximum Altitude
6500 Ft (2000m)
Relative Humidity
95%, non-condensing
pH Range
5.0 - 9.0 continuous
Electrical, C-Series
380-480V, 50/60Hz, 3-phase, 25A
Recirculation Pump
10HP, VFD controlled
Primary Construction
Fiberglass, HDPE, Polycarbonate, SS
316, Viton O-rings, Schedule 80
CPVC, Acetal Copolymer, Powder
coated carbon steel frame
Dimensions
Length
92 in (234 cm)
Width
50 in (127 cm)
Height
85 5/8 in (217 cm)
Weight
Dry
2380 lb (1080 kg)
Wet
3050 lb (1385 kg)
Max. Particle Size
0.07 in (2mm)
Filter Element and Typical
Flow Rate4
SSC - 17 - 1
80 - 240 gpm (18.2 - 54.5 m3/hr)
SSC - 22 - 1
120 - 280 gpm (27.3 - 63.6 m3/hr)
SSC - 27 - 1
160 - 320 gpm (36.3 - 72.7 m3/hr)
Piping Size
Inlet
2.5 in Class 150 Flange (DN65-PN16)
Filtrate
2.5 in Class 150 Flange (DN65-PN16)
Concentrate Purge
2 in Class 150 Flange (DN50-PN16)
Service Drain
1 in Class 150 Flange (DN25-PN16)
CIP Inlet
1 in Class 150 Flange (DN25-PN16)
CIP Chemical Inlet
1/2” in FPT
1. Consult factory if operaonal temperatures are required above this range.
2. Actual operang temperature range may be narrower depending on feedwater
composion.
3. Consult factory if operaonal pH is required outside of this range.

Installation & Operation Manual | TEQUATIC™ PLUS | System Overview
6
4. Flow rate will vary depending on water quality.
System Overview
Control System
The controller provides the operator interface for the system and controls the operation of the
various valves, sensors, and pump. The PLC and VFD are located in the main enclosure with the
main disconnect and the HMI screen. The small side enclosure is for all field connections and only
has 24VDC present.

7
Installation & Operation Manual | TEQUATIC™ PLUS | Installation
7
Installaon
System Conguraons
The conguraon of the TEQUATIC™ PLUS F-150 C-Series skid will depend on the purpose of the
system as well as the scale. The system can be a single skid, or mulple parallel skids for larger
scale. The opmal conguraon will be site-specic, but should include some of the following
aspects:
Parallel Systems: When parallel systems are employed, it is recommended that valving be ulized
on all lines to permit isolaon of any single system for maintenance. Check valves should also be
ulized to prevent one system backfeeding into another system.
Precondioning: Precondioning may be required for process water that falls beyond the scope
of the system. This may include, but is not limited to, prescreening of large parculate material
greater than listed in the specicaons secon above.
Feedwater Supply: The feedwater is best supplied from a holding tank. The feed tank will buer
variaons of inuent ow with me, and if recommended, it also permits the concentrate to be
returned back to the tank for greater ltraon eciency. The feedwater supply to the skid needs
to be pressurized. This is typically accomplished with a pressure-controlled pump. The skid
controller has a pump control dry contact, as well as a feed-tank-low sensor input.
Filtrate Euent: The ltrate euent is the primary treated discharge from the system and should
not have appreciable back pressure. This line contains a system-controlled valve. This is typically
best served with a holding tank to accommodate variaons in ow. A tank-full sensor dry contact
input is available for monitoring the status of the ltrate tank.
Concentrate Purge: The concentrate purge is a system-controlled, pressurized discharge of the
primary ltraon concentrate. The discharge point should be open-air or other sump means for
disposal or further processing.
Service Drain: The service drain is manually controlled and must be non-pressurized and located
entirely below the height of the system. The discharge should be open-air or fully vented, and
capable of receiving (expelling) air pressure during a system bleed operation.

Installation & Operation Manual | TEQUATIC™ PLUS | Installation
8
Site Preparaon
Before the physical installaon of the system, it is important
to make sure the installaon area is properly congured for
accessing the system. The alloed space should include the
physical requirements of the equipment plus addional space
for working and maintenance clearance.
At a minimum, the area in front of the control panel should be
le open to permit the operator access for daily operaon.
Addional space may be required for local codes.
Maintenance clearance around the system is more subjecve
and may vary depending on the frequency of maintenance
tasks. When planning the space, consider having extra
clearance near the pump to facilitate removal or servicing.
Unpacking the Skid
Notice: Be careful when working around the
filter housing with tools to avoid damaging the
housing. Also, take care not to disturb the
pressure and speed sensors on the upper filter
housing.
Note: Shipping damage must be noted at the
time of receipt, and claims made to the freight
company.
➢Remove all packing materials from the skid and inspect the system for shipping damage.
➢Inspect all of the plumbing lines and ngs to ensure they are rmly ghtened and
undamaged.
➢Inspect the controller cabinet to ensure that all components are rmly in place and no wires
have loosened.
➢If the system was shipped on a pallet, remove any strapping and lag bolts, and li the system
o the pallet using the liing points shown in the following secon.

9
Installation & Operation Manual | TEQUATIC™ PLUS | Installation
9
Hoisng
Hoisng and transporng the skid must be completed in a manner that maintains stability and
does not cause damage to the components. The primary liing method is intended to be forkli
or pallet jack. Note the following for liing and transporng:
➢When liing from the side, make sure the forks are spread as far as possible for beer stability.
Make sure the forks are long enough to reach under the opposite frame rail.
➢Li under the skid frame. Do not li by any component or plumbing xture.
➢Do not lt the system beyond 10°
➢Liing from the end should not be aempted unless the forks are long enough to reach the
second internal frame member past the center of the skid.
➢For hoisng, use a liing frame to avoid the straps or chains from binding against system
components.
➢Remove any ngs or xtures that could become damaged from the hoist.
➢Li only from the frame of the skid, and do not secure straps or chains to any components or
plumbing xtures.
Placement
The skid should be placed on a level oor surface such that all four corners are even, to prevent
twisng of the frame and reduce stress on any internal plumbing xtures.
Plumbing
Plumbing into the TEQUATIC™ PLUS Filter skid system uses 1, 2, and 2.5 inch class 150 ANSI anges
that will allow the installaon of ngs to adapt into the facility plumbing. The actual plumbing
layout will depend on the complete system design.

Installation & Operation Manual | TEQUATIC™ PLUS | Installation
10
Electrical
➢The system requires a 3-phase, grounded supply circuit.
➢Make sure the circuit is installed in accordance with all applicable electrical codes.
➢The main disconnect lugs are rated for stranded copper, up to 3/0 maximum conductor size.
All conductors must be rated for 75°C.
Note: The actual enclosure layout may vary slightly depending on system
voltage considerations.
External Controls and Sensors
The following are external controls and sensors for the system that are not included with the skid.
Feedwater Tank
To prevent the system from running dry, the system can incorporate a feedwater tank level switch.
The sensor selecon should be appropriate for the water condions present. The sensor should
supply an “open” or “closed” circuit, dry contact, to indicate the no-run condion. The control
system will send +24VDC to the sensor and look for the same signal to return to indicate a closed
circuit. Logic can be selected in the HMI sengs screen. Refer to “Tank Sengs” on page 18 for all
opons and setpoints for sensor.
Product Tank
To help prevent the tank overow, an output tank from the skid (euent or concentrate) can
incorporate a tank level switch. The sensor selecon should be appropriate for the water
condions present. The sensor should supply a dry contact to indicate the no-run condion. The
control system will send +24VDC to the sensor and look for the same signal to return to indicate a
closed circuit. Logic can be selected in the HMI sengs screen. Refer to “Tank Sengs” on page
18 for all opons and setpoints for sensor.
External Alarm
An external alarm may be connected to the system to alert an operator of a problem with the
system. The alarm may be audible, visual or both. This relay output is a normally-open contact
closure (dry contact).

11
Installation & Operation Manual | TEQUATIC™ PLUS | Installation
11
Feed Pump
The lter skid is designed to operate with a constant feed pressure between 30 and 80 psi that is
maintained as ow changes with minimal pressure variaon. In the case where this type of feed
water is not available a dedicated feed pump should be used. The feed pump should be pressure
controlled using a VFD with a pressure sensor and a closed loop, PID feedback system. The lter
skid will provide a dry contact to control the on/o funcon of the feed pump but the speed
control must be self-contained.
Below are the design consideraons that must be addressed when building a feed pump skid.
➢The pump selecon should be capable of delivering 130% of the desired ltrate ow rate while
maintaining a minimum of 30 psi inside the lter housing.
oPressure drop from the feed pump to the lter skid must be taken into account when sizing
the feed pump.
oIn the case of mulple lters fed by a single feed pump reduce the feed pump ow
requirement by 5% for each addional lter. It is recommended that a maximum of 2
lters be served by a single feed pump. The feed pump ow capacity cannot drop below
110% of the combined ltrate ow rates.
➢The feed pump VFD should have inputs for a remote on/o command. The command will be
given by a dry contact within the lter skid control system; closed = on, open = o.
➢The feed pump VFD should have adjustable ramp-up and ramp-down funcons. The
recommended inial values are Ramp-up = 30 seconds, and Ramp-down = 5 seconds. The
pump should build pressure slowly but, be able to drop pressure quickly if ow stops.
➢The feed pump VFD must have an analog input to reference a pressure sensor and associated
PID funcon to maintain a pressure set point.
oDepending on the VFD and pressure sensor combinaon, the VFD likely needs the ability
to invert and bias the output speed such that the pressure versus speed are inverse
funcons.
oThe proporonal gain should be set high enough to accurately reach the setpoint but set
low enough to prevent oscillaons (hunng) near the set point.
oThe pressure set point must be adjustable for tuning the desired pressure.
➢The feedback pressure sensor should be located as close to the pump outlet as possible to
provide accurate pressure control.
Any feed pump setup must be tested prior to installing a lter. The tesng should include
vericaon the VFD can maintain a setpoint, vericaon the pump speed can adjust as ow
requirements change, and vericaon the VFD can accept the on/o commands from the lter
skid.

Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
12
Controls Overview
The TEQUATIC™ PLUS F-150 C-Series
Skid system is operated with a PLC
controller and touch screen display. The
display provides status informaon
about the system and also the primary
operator interface. The funcons of the
operator interface are presented on
various screens, which are described in
the secons below.
Each screen contains a set of navigaon
buons (Home, Sengs, Clock, Alarms)
for moving to the various other screens. Touching any of these four buons will navigate the
display to the applicable screen. These screens and their purposes are described in subsequent
secons.
Home Screen
The home screen provides a visual snapshot of the system operaon and serves as the primary
Start and Stop funcon of the system. The home screen also provides manual control of the various
pumps and valves. The individual funcons are described below. Components will be displayed or
hidden depending on whether they are enabled or disabled.
A) CIP Kit Hot Water Valve Status
B) Housing Pressure (High Pressure)
C) Dierenal Pressure Across Filter Screen
D) Message Center
E) Cleaning Assembly RPM
F) Filtrate Valve Status
G) Filtrate Pressure (Low Pressure)
H) Feed Tank
I) Recirculaon Pump Speed (Percent Of Maximum)
J) System Start Buon
K) Manual Forward Spin Trigger Buon
L) Purge Valve Status
M) System Stop Buon
N) Time Unl Next Scheduled Purge Event
O) Drain and Air Bleed Buon
P) Product Tank
Note: Some items shown may not be present, depending on enabled options.

13
Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
13
Manual Controls
Individual pumps and valves may be manually operated from the home screen. This can be helpful
for tuning the system or for troubleshoong and tesng devices.
To manually operate a device, touch the icon represenng the pump or valve. A pop-up dialog will
be displayed. If the device is not available for manual operaon, it will be listed as Disabled at the
top of the dialog. The device needs to be enabled before it can be manually controlled.
If the device has speed or other rate of operaon, set that value by touching the dialog to open a
numeric keypad. Type in the desired value and press Enter.
The dialog will indicate whether the On buon is a momentary buon or a toggle buon. For a
momentary buon, the device will remain acve only for as long as you hold the buon. For a
toggle buon, the device will toggle on and o each me you touch the buon.
Message Center
The message center will communicate any acon that is being taken by the system. The message
will change while in an event, such as Startup, and will detail how much me is le and/or what
step in the event the system is in.

Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
14
Main Sengs Screen
The main sengs screen provides navigaon to each of the individual seng screens. The
individual seng screens are listed below and in the subsequent secons.
Startup Sengs, page 14
Valve Sengs, page 15
Tank Sengs, page 16
DP/Pressure Sengs, page 17
RPM Sengs, page 17
CIP, Clean In Place, page 18
Admin Sengs, page 18
PID, page 19
Networking, page 19
Scaling Sengs, page 19
Misc, page 20
User Admin, page 20
Clock Sengs, page 21
Alarm Sengs, page 21
Startup Sengs
This screen sets the parameters for system startup. Touch the General or Air Bleed tab to open the
appropriate sub-screen.
➢Startup Feed Pressure: This is the minimum pressure that must be reached in the housing for
startup event to connue.
➢Startup Feed Pressure Delay: This is the me allowed for the system to reach the pressure
setpoint. If the mer expires before the pressure is reached startup will be aborted.
➢Startup Speed: This is the minimum cleaning assembly speed that must be reached for the
startup event to connue.
➢Startup Speed Delay: This is the me allowed for the cleaning assembly to reach the minimum
speed requirement. If the mer expires before the RPM is reached startup will be aborted.
➢Startup Time: Once both minimum setpoints are reached the system will dwell for the me
specied. This will allow the system to clean and then purge any contaminates o the screen
before entering normal operaon.

15
Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
15
Valve Sengs
This screen sets the basic parameters for any installed valves. Touch the valve name to select which
of the installed valves to view the sengs for. This will be Filtrate Valve (Manual, DP, or Flow) and
Purge Valve.
➢Enable/Disable: Sets whether the valve is available to the system or not.
➢Feedback: Sets whether the valve is capable of feedback (open/closed/posion) and whether
this feedback is available to the system.
➢Fault Delay: Once a valve has been signaled to close, the PLC will look for feedback to conrm
complete cycling of the valve. If feedback is not received once the delay mer has expired a
fault will be triggered.
➢Percent Open: Changes the degree to which the valve is open.
➢Schedule: Sets whether the valve should funcon on a med schedule.
➢Frequency: Sets how oen (in minutes) the valve should be operated when Schedule is
enabled.
➢Duraon: Sets how long (in seconds) the valve should be operated when Schedule is
enabled.

Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
16
Tank Sengs
This screen sets the basic parameters for any installed tank level switch. The switches must be dry
contact (open or closed circuit) type switches. The logic for switch condion to run condion can
be set according to the switch setup.
➢Enable/Disable: Sets whether the tank sensor is available to the system or not and displays
tanks on the layout on the homescreen.
➢Stop Delay: The tank level switch must remain in the “no run condion” for the specied delay
me before the system will take acon from the input. This is intended to eliminate nuisance
shutdowns due to water turbulence.
➢Shutdown Delay: This value sets the me delay between when the product tank is full and
when the system shuts down. This provides an opportunity for the tank to catch up without a
premature shutdown.
➢Automac Restart: Sets whether the system will automacally restart aer the sensor
condion has cleared.
➢Restart Delay: With automac restart enabled and aer a tank switch shutdown, the switch
must remain in the run posion for the delay me before any acon is taken. This is intended
to stagger restart and prevent premature restart.
➢Switch for Run: This opon allows the circuit logic for the switch to be changed. For example,
if Open is selected the switch must provide an open circuit for a run condion.
Commented [LL1]: An adds tanks to the layout on the
homescreen

17
Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
17
DP/Pressure Sengs
The DP/Pressure sengs screen lists various parameters related to the lter operaon and
associated alarm thresholds.
➢High DP: This seng determines the dierenal pressure value necessary to trigger a cleaning
cycle. The dierenal pressure represents how much resistance to water ow is through the
lter. A high dierenal pressure indicates the lter is becoming clogged. (See page 22)
➢Max DP Events/Period: This sets the maximum number of High DP events permied per me
period (in minutes) before an alarm is triggered.
➢High Feed Pressure: This seng determines the upper alarm limit for the feed pressure sensor.
➢Low Feed Pressure: This seng determines the lower alarm limit for the feed pressure sensor.
RPM Sengs
➢Low Brush Speed: This seng determines the Cleaning Assembly brush speed (RPM) that
results in a low speed alarm. The Cleaning Assembly brush speed (RPM) represents the rate of
water ow through the lter housing. If the brush speed (RPM) is less than the setpoint, the
system will shut down.
➢Max RPM Events/Period: This sets the maximum number of RPM alarms for a given period,
before the system shuts down.

Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
18
Clean In Place, CIP
This screen allows all sengs for the CIP event to be set. This funcon requires an add-on kit that
includes addional valves, plumbing, and wiring. With the components installed the proper
funcon can be ulized.
➢Chem Duraon, Dwell Duraon, Pause Duraon, and Filtrate Bump will adjust the ming of the
acon taken during each Cycle of a CIP event. The valve acon diagram shown below describes
the interacons of these sengs.
➢Schedule: When enabled, this will trigger a CIP event based on the Frequency mer.
➢Cycles: This determines the number of CIP cycles that occur during a single CIP event.
➢Shutdown CIP: Enabling this will trigger a CIP event whenever the system is shut down at the
HMI screen. It is not recommended to be used in conjuncon with a tank level switch and
automac restart.
➢DP Event CIP: This will trigger a CIP event instead of a forward spin in the case of high
dierenal pressure event.
➢Max CIP Events/Period: If the maximum CIP Events per time frame is exceeded the system will
not perform the CIP but will continue running. This is intended to limit chemical usage and
system downtime.
Admin Sengs
This screen sets the general parameters of the system, which are described in the secons below.
Notice: Access to
this section is
restricted to only
administrator
access levels and
should only be
adjusted by an
Amiad technician.

19
Installation & Operation Manual | TEQUATIC™ PLUS | Controls Overview
19
PID
These three screens contain sengs that can adjust the response of the control loops. These
seng are intended for lab tesng to ne tune the response, and once the response has been
fully mapped out these set screens should not be accessed.
Networking
This screen allows network and IP sengs to be set. These
sengs will allow the unit to be linked into a facility SCADA
system. These sengs should only be changed by Amiad
technicians as each applicaon is unique.
Scaling Sengs
This screen is for seng system parameters in their nave
electrical units. With the excepon of ltrate ow, the values
on this screen should not be altered.
