SOLOY AVIATION SOLUTIONS 700-1030-3 User manual

SERVICE
INSTRUCTION NO.: 764-08R1 Page 1 of 5
Issued Date: March 1, 2000
Revision 1: June 7, 2001
INSTALLATION OF 700-1030-3 FUEL FLOW INDICATOR
IN AIRCRAFT THAT PRESENTLY HAVE 700-1030-1
INDICATORS INSTALLED
(Wiring Kit P/N 700-1031-1)
Note: The technical aspects of this Service Instruction are FAA approved.
See FAA Approved Drawings: 764-1020 EO’s dated 2/29/2000
MODEL(S)
Soloy Turbine Cessna 207 Series
Flight Manual Data Required: NO
Note: If ownership of this aircraft has changed, please forward this document to the new owner.

SERVICE INSTRUCTION 764-08R1 Page 2 of 5
DESCRIPTION
Replacement of old style round electrical connector with D connector to match P/N 700-1030-3
fuel flow indicator.
MODIFICATION
1. Remove P/N 700-1030-1 indicator from instrument panel.
2. Pull connector through indicator mounting hole and remove connector from harness.
3. Locate wire number D100D22 and cut approximately 4 inches from instrument end.
4. Strip wires D100D22 and D107A22 and crimp into one end of 320559 splice.
5. Strip end of wire D111X20 and crimp into other end of splice.
6. Trim other end of wire D111X20 to match the length of existing wires.
7. Strip ends of wires and install pins onto (4 ea.) existing wires and wires D111X20 and
D115A20N.
8. Find suitable ground connection for D115A20N, trim to length and crimp terminal on wire.
Connect D115A20N to ground terminal.
9. Slide backshell over wire harness and insert pins into connector according to schematic on
Figure 2.
10. Secure backshell to connector and install spring clips on each end using screws and nuts
provided. Protect wires with tape then tighten backshell clamp.
ADJUSTMENT
1. Locate and record the K factor value, which may be found on the side of the fuel flow
transducer.
2. Find the K factor value for your transducer in Table 1. Working through the hole in the top
of indicator, adjust SW 1 and SW 2 switches to settings indicated. (See figure 1).
INSTALLATION
1. Connect plug to back of fuel flow indicator and secure with spring retainers.
2. Install indicator in instrument panel.
3. Program fuel flow indicator according to Digiflow Operation Manual.

SERVICE INSTRUCTION 764-08R1 Page 2 of 5
TABLE 1
K-FACTOR TABLE
SW 1
Page 3 of 5
0 1 2 3 4 5 6 7 8 9 A B C D E F
0 77.0 78.0 79.0 80.0 81.0 82.0 83.0 84.0 85.0 86.0 87.0 88.0 89.0 90.0 91.0 92.0
1 41.4 41.6 41.8 42.0 42.2 42.4 42.6 42.8 43.0 43.2 43.4 43.6 43.8 44.0 44.2 44.4
2 44.6 44.8 45.0 45.2 45.4 45.6 45.8 46.0 46.2 46.4 46.6 46.8 47.0 47.2 47.4 47.6
3 18.0 18.2 18.4 18.6 18.8 19.0 19.2 19.4 19.6 19.8 20.0 20.2 20.4 20.6 20.8 21.0
4 21.2 21.4 21.6 21.8 22.0 22.2 22.4 22.6 22.8 23.0 23.2 23.4 23.6 23.8 24.0 24.2
5 08.0 09.0 09.2 09.4 09.6 09.8 10.0 10.1 10.2 07.6 10.3 10.4 10.5 10.6 10.7 10.8
6 05.6 05.6 05.7 05.7 05.8 05.8 05.9 05.9 06.0 33.8 06.6 06.0 06.0 06.0 06.0 06.0
7 91.0 92.0 93.0 94.0 95.0 96.0 97.0 98.0 99.0 10.0 10.10 10.20 10.30 10.40 10.50 10.60
8 38.0 38.1 38.2 38.3 38.4 38.5 38.6 38.7 38.8 38.9 39.0 39.1 39.2 39.3 39.4 39.5
9 39.6 39.7 39.8 39.9 40.0 40.2 40.4 40.6 49.0 49.1 49.2 49.3 49.4 40.8 41.0 41.2
A 57.0 57.1 57.2 57.3 57.4 57.5 57.6 57.7 57.8 57.9 58.0 58.1 58.2 58.3 58.4 58.5
B 58.6 58.7 58.8 58.9 60.0 37.0 37.6 37.4 37.2 37.0 24.4 24.6 24.8 25.0 25.2 25.4
C 25.6 25.8 26.0 55.5 26.2 26.4 26.6 26.8 27.0 27.2 27.4 06.3 06.4 06.4 06.4 06.4
D 06.4 06.5 06.5 06.5 06.5 06.5 10.9 11.0 04.8 04.9 05.0 05.1 05.2 05.3 05.4 05.5
E 49.1 49.3 49.5 49.7 50.0 50.2 50.4 50.6 50.8 02.3 29.8 30.0 30.2 30.4 55.5 55.5
SW2
F 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5 55.5
K-factor values are divided by 1000. Example: Switch 1 set at 5, switch 2 set at 1 = K-factor value of 42, 400 (42.4)
