Soltech Sunlike 30W PRO User manual

01
SOLTECH offers Eco-friendly technology
to help users benefit clean energy.
SunLike
30W
User Manual

02 03
Sunlike 30W PRO
Contents
01 Introduction
02 Specification
03 Luminous Distribution
04 Battery Notes
05 Installation and Wiring Compliance
06 Mounting Accessories
07 Installation
08 Panel Angle
09 Remote Control Guide
04
05
06
07
08
09
010
012
014

04 05
Specification
Lumileds 5050 (215lm-CR>70)
Remote control and One-key Setting
40%–100% 25hrs
Night Owl 23hrs
100% 11hrs
70% 15hrs
40% 26hrs
20%–80% 50hrs
Early Bird 20hrs
Sunlike 30W PRO
30W
18V 52W
12.8V 25AH Superior Battery
47.1 lbs
6000
6.26
IP65
> 70
Aluminum
200 lm/W
7hrs
11hrs
9 to 20ft
-40 °F to 140 °F
-58 °F to 140 °F
LED Nominal Power
Solar Panel
LiFePO4Battery
Weight
Lumen Output@5000K
EPA
Waterproof Rate
CRI
Casting
Efficiency@5000K
LED Chip
* Charging Time
Run Time (@Full Power)
Maximum Autonomy
Motion Sensor Mode
Time Control Mode
Constant Mode
Operation Mode
Installation Height
* Operating Temperature
* Charging Temperature
01 Introduction 02 Specification
Thank you for purchasing Sunlike Pro Urban Lighting Products.
Introduction
The high-performance Sunlike 30 Pro is a municipal-grade solar outdoor
lighting system that provides bright off-grid light. This heavy-duty
commercial dedicated series is ideal for city streets, parking lots, area
lighting, and security lighting. It comes in a wide choice of configurations,
lighting outputs, and recommended pole heights. The Sunlike 30 pro
is optimized to provide years of bright, reliable light. Industry-leading
efficiency, dense batteries, and advanced controls to guarantee the highest
possible off-grid autonomy.
Important
In order to avoid deep discharge of the battery during storage, please
fully recharge your battery every 4 months. Please make sure that the
light is installed in an area with sufficient sunlight irradiance. A strict
minimum of 3.5 hours/day of sunshine on average is recommended.
Select the right operating mode according to the local legislation needs and
the local sunshine conditions. Keep it away from shadows. Self-cleaning
available when the light fixture have minimum angle of 15 degrees.
36.0 inches
17.0 inches
4.0 inches
Sunlike 30W PRO
Charging Point DC14.6V 3.75A
Indicator
Light Module
Please save these instructions. Read all of the instructions carefully
before attempting to carry out any installation or wiring. Do not open or
attempt to repair the product on your own, as it many cause serious
damage and would void the product warranty. Contact your local
distributor for any questions concerning the installation.
Range of the light module on the lighting fixture is 20–26 feet (6–8
meters). The ideal installation spacing is >16 feet(5 meters). When
installing two or more lighting fixtures on one pole, select desired
operating mode before installation. Interference can cause delay or
malfunction when using the remote control to change operating modes
after installation.
Precautions when working with solar panels
When the solar panel is exposed to sunlight, a voltage appears at the
output terminals of the solar panel turning it into a source of electricity.
To avoid a shock hazard, make sure the solar panel is covered with an
opaque (dark) layer such as paper or cloth during the installation. Do
not make contact with the terminals when the panel is exposed to sun-
light or any other light source.
* The temperature can impact the battery’s charging and normal operation. * The solar charge time data is base on 77 degree F ambient temperature with the panel
pointed directly at the solar radiation. The standard radiation value is 1000W/m2.

06 07
03 Luminous Distribution
1. Super Capacitor battery powered Sunlike Pro lights are visibly brighter
than other outdoor solar lights, and their performance overall is
more reliable.
2. To charge the battery fully may take up 6 to 12 hours.
3. The rechargeable battery can work continuously for 10 hours at
full power.
4. Output will be reduced to 40% when the battery is below 40% of
its capacity.
5. Battery will stop charging when the ambient temperature is below
-58°F or above 140°F.
Battery Status is indicated by the red indicator on the lighting fixture
as follows:
> Slow red light flashing (Every 2.5s) = Working
> Slow red flashing (Every 5s) = Open circurt
> Red light continuously on = Non-working
> Quick red flashing (Every 0.5s) = Charge fault
> Quick red flashing (Every 0.1s) = Over current or Short circurt
Storage
To avoid over discharge of the battery during storage, please recharge
the lighting fixture every 4 months. Use the dedicated charger to charge,
reset the switch when done.
(IAP) Intelligent Adaptive Program Battery Control Technology
In order to extend the off-grid autonomy of the Sunlike Pro under
shady trees, heavy rain, and thick clouds, our controllers now
integrate an adaptive smart control feature to actively track battery
capacity and adjust light output accordingly. Before integrating this
feature, selecting a light output percentage on the remote would yield
an accurate percentage of max LED brightness. Now with (IAP), the
controller actively monitors the battery and regulates the electrical
current to the LEDs. The controller makes light output of the selected
percentage on the remote relative to battery capacity rather than max
LED output. This smart-control feature can increase our off-grid
performance by up to 40%.
ATTENTION
Battery cannot be replaced on your own. Please conntact SOLTECH
for any battery’s questions.
After opening the Sunlike 30W Pro, package, you will notice that
the solar panel is covered, and the indicator is flashing every 5 seconds.
It signifies that the fixture is in open circuit mode. Once the fixture
is taken out of the package, and the solar panel is no longer covered,
the Sunlike 30W Pro will automatically turn on, and the indicator
will begin flashing every 2.5 seconds. The light head will then turn
on for 1 minute and then shut off again. It means the fixture is
switching from open circuit mode to standard working mode.
If you wish to shut off the light, you must first cover the solar
panel. Then press the off button on the remote. You can also just
press the off button to turn off the lights during the night. When
the solar panel detects light, the fixture will activate and resume
normal operation again.
04 Battery Notes
Sunlike Pro 30W Type III

08 09
05 Installation and Wiring Compliance 06 Mounting Accessories
1. Installation and wiring must comply with the State and National
Electrical Codes.
2. The Sunlike 30W Pro model is intended for outdoor use only
and should not be installed in an unventilated area, and shall be
installed in an environment within the operational temperatures
defined for the product.
3. The average sunshine in the installation area should be above
3.5 hours/day in order to ensure full function of the lighting fixture.
Avoid areas with shades.
4. Before installation, if applicable, please ensure the light pole and its
foundation are solid enough to withstand the lighting fixture(s).
5. Before installation, please ensure that the battery is fully charged. Install
during sunny days if possible.
6. Before installation, please press the ON/OFF key in the remote
control and check whether it shows a red light on the indicator.
Please cover the panel and check if the light module turns on normally
within 1 minute.
After Installation
The lighting fixture will automatically turn on at night and turn off
during daylight.
Important
Always orient the solar panel facing the equator (e.g. facing south if in
northern hemisphere).
Always have a tilt angle of at least 15° to avoid dust accumulation
(0°=horizontal plane).
A. TRUNNION—Wall Mount
C. TRUNNION—Square
D. SLIP FITTER—Rotative AND STRAIGHT ARM
3.9 inches
6.7 inches
0.4 in
0.9 in
0.4 in
A-b. STLSTC-TRS-30W Pro (for Sunlike 30W Pro)
Pole Size For Slip Fitter And Straight Arm
1.8 inches 2.4 inches
3.9 inches
6.7 inches
0.4 in
0.9 in
0.4 in
B-b. STLSTC-TRR-30W Pro (for Sunlike 30W Pro)
works with 2.0 inches to 4.7 inches poles.
Pole Size
2.0 inches 4.7 inches
3.9 inch
6.7 inch
0.4 in
0.9 in
0.4 in
C-b. SLSTC-TRS-30W Pro (for Sunlike 30W Pro)
works with 2.0 inches to 4.0 inches poles.
Pole Size
2.0 inches 4.0 inches
Ordering Information Chart
Sample Number: STLSTC30XYYZZPRO
For example: STLSTC303TRSGYPRO
This means the customer wants a Sunlike Pro 30 watt, 3000K CCT,
wall mount installation, with a gray finish.
DO NOT send the sample number directly to our salers. Use the
information in the chart above to create a model number with
the correct series, wattage, temperature, mounting option, and finish
for the product that you want.
Series Wattage Color
Temperature
Mounting
Options Finish
STLSTC=Sunlike Pro 30=30W 6000 Lumens X=3=3000K
X=4=4000K
X=5=5000K
X=6=5700K
YY=WM=Wall Mount
YY=TRR=Trunnion Round
YY=TRS=Trunnion Square
YY=SF=Slip Fitter
YY=SA=Straight Arm
ZZ=GY=Gray
ZZ=BZ=Bronze

010 011
05
04
Square Trunnion
07 Installation
Trunnion Mount
01
02
03
B. On Round Pole
A. On Wall
C. On Square Pole
E. On Round Tapered Pole—Straight Arm
Slip Fitter and Straight Arm
D. On Round Tapered Pole—Slip Fitter
01
03
02
04
Straight Arm
01
02
03 04
05
06
Slip Fitter
05
04
Round Trunnion
04
Wall Mount

012 013
Alaska
25° N
0°– 13°
13°– 26°
26°– 37°
37°– 45°
19° N
21° N
26° N
20° N
27° N
28° N
29° N
30° N
31° N
32° N
23° N
34° N
35° N
36° N
37° N
38° N
39° N
40° N
41° N
42° N
43° N
44° N
45° N
46° N
47° N
48° N
60° N
49° N
Washington
Oregon
California
Nevada
Arizona
Utah
New Mexico
Kansas
Colorado
Oklahoma
Texas
North Dakota
South Dakota
Nebraska
Idaho
Montana
Wyoming
61° N
62° N
63° N
64° N
65° N
70° N
66° N
67° N
68° N
69° N
Hawaii
The Solar charge in a battery pack won’t last forever. The off–grid
system relies on stored solar energy for autonomy. Angling your
solar panels properly can boost the power intake of your solar lighting
system. You want to angle your solar panels at a tilt based on the
area’s latitude.
Tip
You can increase the tilt 15° in the winter or decrease 15° in the summer.
In this way you can get the maximum sunlight to recharge the battrey bank.
Strong sunlight Nromal sunlight Less sunlight
Key
The area will dictate the installation of the fixtures and will sometimes
prevent the lights from facing south. But that’s okay! Panels facing West
& East won’t get as much light as Southern facing panels, but will still
collect a good amount of sunlight. A North facing panel also works, but
it will take longer to charge than any other direction. This would mean that
the solar charge will be less optimal if installations are facing North.
0°– 13°
13°– 26°
13°– 26°
37°– 45°
45°
37°– 45°
Arkansas
Louisiana
Mississippi
Alabama Georgia
South
Carolina
North
Carolina
Virginia
West
Virginia
Kentucky
Illinois
Wisconsin
Minnesota
Iowa
Missouri
Michigan
Indiana
Ohio
Pennsylvania
New York Massachusetts
Rhode Island
Connecticut
New Jersey
Delaware
Maryland
Tennessee
Florida
World Wide Panel Angles
Best Facing Direction For The Solar Panel
Best
Worst
OKOK
New Hampshire
Vermont Maine
26°– 37°
26°– 37°
09 Panel Angle

014 015
09 Remote Control Guide
1. On/Off 2. Connect/Test
4. 20%~80% Motion
Sensor Mode (Default)
6. Early Bird Mode
8. 70% Constant Mode
10. Timer Mode Disabled
12. Time Mode 8 Hours
3. 40%~100% Motion
Sensor Mode
5. Night Owl Mode
7. 100% Constant Mode
9. 40% Constant Mode
11. Timer Mode 4 Hours
1. On/Off
When off is selected, the light will stop working. The solar panel will not
charge the battery and the battery will not supply electricity to the light.
2. Connect/Test
Remote control device can be connected with any lighting fixture, one
at a time. To connect, press the button once. It also functions as a test
button. To test, press the “Test” button once, the red light will indicate
the fixture is charging, green light indicates that the fixture is operating.
Testing lasts for 10 seconds, and then it goes back to the mode previously
in use.
When using the remote for the first time, please remove the plastic
piece at the bottom to make the remote turn on.
3. 40%~100% Motion Sensor Mode
Constant 40% brightness (turns on at dusk, turns off at dawn);
100% brightness turns on for 2 minutes when motion is detected.
4. 20%~80% Motion Sensor Mode (Default)
Constant 20% brightness (turns on at dusk, turns off at dawn);
80% brightness turns on for 2 minutes when motionis detected.
5. Night Owl Mode
Changes as natural light decreases/increases (turns on at dusk); 70%
brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness
for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours
(turns off at Dawn).
6. Early Bird Mode
Changes as natural light decreases/increases with increased brightness
near dawn for early risers (turns on at dusk); 70% brightness for 0.5
hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50%
brightness for 1 hour, 20% brightness for 4 hours, 100% brightness
for 1 hour (turns off at Dawn).
Important
Dust and dawn time can vary for different locations and seasons.
The sensors in our products will monitor the light levels where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes.
16ft–33ft
The range of the remote control to the
indicator is 16ft (Day time) to 33ft (Night
time). Because the sunlight will impact
the signal of the remote control, we recom-
mend that users setup the mode before
they install the light.
(IAP) Intelligent Adaptive Program Battery Control Technology
In order to extend the off-grid autonomy of the SUNLIKE 50W under
shady trees, heavy rain, and thick clouds, our controllers now
integrate an adaptive smart control feature to actively track battery
capacity and adjust light output accordingly. Prior to including this
feature, selecting a light output percentage on the remote determined
the constant percentage of max LED brightness. Now with (IAP),
the controller actively monitors the battery and regulates the electrical
current to the LEDs. The controller now applies the selected percentage
output on the remote to the battery capacity, rather than the max LED
output. This smart-control feature can increase our off-grid performance
by up to 40%.

016 017
09 Remote Control Guide
8. 70% Constant Mode
70% brightness from dusk to dawn.
9. 40% Constant Mode
40% brightness from dusk to dawn.
10. Timer Mode Disabled
Press this button to turn off Timer Mode; settings revert back to before
Timer Mode was last activated.
7. 100% Constant Mode
100% brightness from dusk to dawn.
11. Timer Mode 4 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70%
Constant Mode. If the light turns on at 7pm at dusk, it will turn off at
11pm. It will repeat the same schedule hereafter until it is canceled
by pressing Timer Mode Disabled.
12. Time Mode 8 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70% Con-
stant Mode. If the light turns on at 7pm at dusk, it will turn off at 3am. It
will repeat the same schedule hereafter until it is canceled by pressing
Timer Mode Disabled.
Important
Dust and dawn time can vary for different locations and seasons.
The sensors in our products will monitor the light levels where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes.

018 019
Sunlike products are covered by a 5 year limited warranty.
Sunlike urban light warrants to the original purchaser that
this product is free from defects in materials and work-
manship for the period of 5 years from date of purchase. To
obtain warranty service please contact your local distributor
or sales rep for further instruction.
SOLTECH LLC reserves the right to update all
product data sheets at any time. Consult SOLTECH
marketing specialists for publication updates at
[email protected]
Copyright©2020–2021 SOLTECH LLC,
All Rights Reserved.
1460 Park Avenue.
Emeryville CA 94608 USA
www.soltechlighting.com

020
SOLTECH offers
Eco-friendly
technology to help
users benefit
clean energy.
