NANOLUX LED PGF18 User manual

The fixture is suitable for indoor environment. Do not install your LED in wet or outdoor
environment. Do not operate the fixture close to combustible materials. The fixture will
get hot during operation. Do not touch the fixture during or right after operation. Make
sure the power cord does not touch any hot part of the fixture. Make sure the light bar
is clean and inserted correctly. The normal operating environment temperature should
be below 40°C (104°F). Exceeding the maximum environmental temperature will
stress electronic components, which will lead to shorter lifetime and decreased
reliability.
Our fixture comes with a heat sink and other cooling components, which enable it to
dissipate heat effectively and allow maximum heat conductivity during the operation.
● Comply with local installation regulations.
● Store the fixture in a dry and clean environment, with an ambient temperature of
-10°C ~ 50°C and ambient humidity of less than 90% RH. It is recommended that the
fixture shall not stay unused for more than six months. If it has stayed unused for
more than six months, please test to ensure fixture is functioning at 100%.
● Please keep products safe. Avoid mechanical pressure, excessive vibration and
dropping the unit during the process of assembly to protect the light bar.
● Keep away from water, oil and organic solvent, or it will reduce the efficacy and have
the potential risk of electric leakage.
● All equipment, devices and machines shall be effectively grounded.
● Regularly check and clean the dust from the protective cover.
● It is recommended that you contact a licensed electrician or an expert if any of the
following happens:
1. The cable or the plug has been damaged.
2. The unit has been exposed to rain.
3. Significant changes in the unit performance.
4. Fixture or light bar dropped and corner of its enclosure got bent.
● There are no serviceable parts inside the LED. Opening the LED will void its
warranty.
Nanolux warrants manufacturing defects of this product if it is used under normal
operating conditions for a period of five (5) years from the original date of purchase. If
the product shows manufacturing defects within this period and that defect is not
caused by user error or improper use, Nanolux shall, at its discretion, either replace or
repair the product by using applicable new or refurbished parts. For any service, return
the product to your shop along with the original sales receipt.
SCOPE OF USE AND MAINTENANCE
ALWAYS COMPLY WITH LOCAL
INSTALLATION REGULATIONS AND CODES
OPERATING
MANUAL
LED
Modular design
LED CLONE LIGHT 18W
WARRANTY
TROUBLE SHOOTING
Problem
One or more
fixtures are
completely off.
Disconnect from power source.
The power supply settings do
not match with local AC
voltage and frequency.
Make sure power is on and
cables are plugged in.
LED will not
come on.
Probable cause(s) Possible fixes or
corrective maintenance
Disconnect fixture from the
power supply. Check settings
and correct if necessary.
Designed by NANOLUX in California
Made in China
PATENTED PRODUCTS, COUNTERFEITING NOT ALLOWED.
Input
Max.
25
light
bars
in
series

Fixture Hanging:
1. Fix the clip to the position to be installed (Fig.a).
2. Fix the clip with screws (Fig.b).
3. Buckle the light bar into the mounting clip, and each light bar is equipped with 2 clips
(Fig.c).
4. Connect the reserved power line, and pay attention to keep the joint away from
water (Fig.d).
Series Combination Steps:
1. Fix the light bar to the position to be installed.
2. When the light bars are combined in series, the male and female connector shall be
butted and then the nut shall be tightened.
TECHNICAL SPECIFICATIONS
ASSEMBLY INSTRUCTIONS
LED PGF18
AC120V/208V/240V/277V
18W Each Bar
39µmol/s
Full Spectrum 6500K
48.4x1.3x1.3inch / 0.9lbs
1230x32x32mm / 0.4kgs
≧50,000hrs
No
120°
Lifetime
Model
Light Distribution
Dimming
Input Voltage
Input Power
PPF
Spectrum
Dimension
/ Weight
The number of light bars can be combined in series according to the actual
environment needs. The maximum number of series combination is 25pcs.It is
recommended that you keep a mounting height of 6”-12”(15.2cm-30.4cm) above
canopy for optimal light efficiency and uniformity. Growers should regularly monitor the
temperature at the canopy level to ensure the height of the fixture is appropriate, as
canopy temperature and ambient room temperature can differ.
PLEASE READ THESE INSTRUCTIONS
FIRST BEFORE INSTALLATION
Welcome to purchase and use this new LED luminaire. We have done everything to
ensure a product of long lifespan and safe operation, but the installation and use of the
product is at the responsibility of the user. Incorrect use or installation can lead to
failure and damage to the luminaire. Damage to the luminaire or electronic circuitry as
a result of incorrect installation or use will revoke your warranty. Read this manual
carefully before installing your luminaire.
CAUTION :
T8 integrated lamp can be installed on the special lamp clip. The light bar can be
combined in series with the maximum power of 450W.
-02-
*Subject to change without notice, Tolerance ±10%.
c
a
b
d
AC120-277V
NOTE:
One input cable supports 25 light bars at Maximum, the last end needs to cover for
safe.
Input
Max.
25
light
bars
in
series
