Power 1.0 DC Flush installation instructions
Please read this installation guide carefully so that you can ensure
that the product functions reliably.
Somfy shall not be liable for any defects or damages if these are
caused by use outside the field of application or the failure to observe
this installation guide (incorrect installation, incorrect commissioning,
incorrect operation, etc.).
The Power 1.0 DC Flush power supply is designed to supply power to 24 V DC motors. Due to its small
dimensions, it can be installed in a surface box or a flush-mounted box. The output voltage is 24 V DC regulated.
1 Safety instructions
To ensure the safety of individuals, it is important to follow these instructions.
Incorrect installation can lead to serious injury.
Attention: Keep these safety instructions.
• Only a qualified person may set up, test, commission and perform troubleshooting on the installation.
• Switch off the voltage to all of the connection lines which are to be installed before working on the installation.
Remove all lines that are not needed and take out of operation all equipment that is not required for actuation
with the motor.
• Follow the installation and operating instructions, particularly the safety instructions for the equipment to be
operated.
2 Technical data
Operating voltage: 230 V~ 50/60 Hz
Output voltage no-load: 24 V DC
Continuous current: Max. 1.0 A
Temporary current: 1.5 A
Overload switch-off: 100 ms > 1.6 A
Index protection rating: II
Safety level: IP 20
Number of motors that
can be connected:
1
Dimensions H x W X D
in mm:
51 X 49 X 25
Operating temperature: -25 °C to + 40 °C
Attention: Installation must take
place in a flush-mounted box/
pattress box (e.g. 55 mm).
www.somfy.com

3 Electrical connection
Only a qualified electrician (VDE 1000 -10 [Association of German Engineers]) may set up, test, commission and
perform troubleshooting on the installation.
Switch off the voltage to all of the connection lines which are to be installed.
Take safety precautions to prevent the installation from being switched on unintentionally.
Exposed power lines →Risk if contact is made, electric shock.
-Switch off the voltage to all of the connection lines which are to be installed.
-Take safety precautions to prevent the installation from being switched on unintentionally.
Somfy shall not be liable for any defects or damages caused by the failure to observe this installation guide.
Somfy hereby declares that this product conforms to the essential requirements and other relevant provisions of
Directive 2014/35/E. A declaration of conformity is available on the website www.somfy.com/CE.
230 V ~ 50/60 Hz
1,5 mm2
PE N L
0,75 mm2
0,75 mm2
1,5 mm2
Motor
DC RTS receiver
Centralis DC IB
S51 switch
Output line
24 V DC
(red = +
black = _)
black
red
24 V DC RTS motors are supplied directly from the power supply
Note: Observe the relevant installation guides
(e.g. relating to polarity) when connecting
the motors/control units.
