Sonance Visible and Dual Visible IR Emitter VE1 User manual

DESCRIPTION
The VE1 Single and the VE2 Dual Visible Emitters each contain a small Infrared LED, housed in
a small plastic shell. Unlike other emitters, they emit visible red light in addition to IR (infrared)
control signals when activated by IR commands sent to them by IR receivers or other Sonance
controllers. They are designed to be installed directly on the IR sensor window of each
controlled device.
INSTALLATION INSTRUCTIONS
VE1 AND VE2
VISIBLE AND DUAL VISIBLE IR EMITTER
Pg 1
INSTALLATION
ATTACHING THE EMITTERS TO IR SENSOR WINDOWS
• Each emitter has a clear adhesive layer on the bottom flat surface of the shell. The
rounded side faces the user and emits visible red light when a command is sent.
• Simply peel off the protective cover and affix the emitter to the center of the IR sensor
window on the controlled component's front panel. Move the emitter back and forth in
front of the window while sending codes to find the best location. A foil-packed alcohol
swab has been included for your convenience. Use the swab to clean off the IR sensor
window before adhering the IR emitter(s) or to clean the IR emitter(s) after installation.
• In some cases it may be difficult to find the location of the IR sensor on the component.
Consult the owner's manual of the unit, or the manufacturer, for the exact IR
window location.
• Double-sided adhesive tape is included. If you move the emitter to a different component,
use this tape to replace the current adhesive layer.
• The shell is transparent to infrared light, allowing commands from a handheld remote
control to pass through the shell. This permits direct control of the equipment from a
handheld remote as well as with the VE1 or VE2.
7 FT 3 FT 5/8"
VE2 Dual Visible IR Emitter
5/16"
3.5 mm mono
mini plug VE1 Visible IR Emitter

SONANCE • 212 Avenida Fabricante • San Clemente, CA 92672
Tech Support [phone] www.sonance.com ©2002 All rights reserved.
Pg 2
33-1379 4.02
EQUIPMENT CABINET, CLOSET, ETC.
+12VDC
GND
GND
SIGNAL
120 V AC
(Unswitched)
IR Sensor
Window
CB1
Connecting Block
PS1
Power Supply
CR1
IR Receiver
VE1 Emitter
VE2 Dual Emitter
VE2 Dual Emitter
Satellite Receiver
Hand Held
Remote
AV Receiver
DVD
EMITTERS
PWR IR
RCVR
CB1 ONE ZONE CONNECTING BLOCK
CONNECTING THE EMITTERS
• Simply insert the mono mini plug of the VE1 and VE2 emitters into the "EMITTERS" or
"OUT" jacks on any of the Sonance Connecting Blocks or Controllers.
• CAUTION: DO NOT plug emitters into the IN/OUT or HIGH OUT jacks on the CB1 and
ACB1 Connecting Blocks. To do so will destroy the emitters!
• The following diagram illustrates a typical basic system using the VE1 and VE2 emitters.
• The VE2 is designed to control two devices. If only one is to be controlled, hide the extra
emitter behind the equipment. It may be used in the future if an extra device is added.
• DO NOT CUT the extra emitter wire in an attempt to remove it. The two emitters are wired
in series. Cutting or removing one emitter will prevent the other from working.
• These visible emitters may also indicate the presence of stray IR or RF interference by
randomly blinking when no IR control signal is being sent. Reposition the IR receiver or the
interfering source to eliminate or reduce the random blinking. The more the random
blinking is reduced, the better the system will function.
• If the emitter glows red constantly, the signal line is shorted to “+12VDC” or a constant
noise, like florescent lights are present near the IR receiver.
