Sonance Landscape LSV10SUB User manual

Introduction
Thank you for purchasing a SLS Subwoofer. When properly installed,
this subwoofer will provide you with years of outdoor entertainment
pleasure. To get the most out of your new subwoofer, please read
this manual thoroughly before you begin installation.
Box Contents
SLS In-ground subwoofer boxes contain:
(1) In-ground subwoofer
(2) Silicon filled wire nuts
Subwoofer Location Selection
The SLS is designed to deliver a seamless, evenly dispersed sound
field in an ‘open air’ environment. An array of multiple Satellite
speakers and Subwoofers should be strategically placed to
minimize ‘hot spots’ and ‘nulls’ as you move around the outdoor
entertainment area.
AS A GENERAL GUIDELINE, (1) SUBWOOFER WILL COVER
ABOUT 2000 SQUARE FEET OF LISTENING AREA
Figure 1 Shows The SLS placed along the perimeter of the
entertainment area. See Figure 1.
Select a central location for the subwoofer if using only one
subwoofer (see Figure 1) if using multiple subwoofers, select
locations that are the same distance from the main listening area.
Figure 1
Sonamp DSP 2-750
Amplifier Power Planning
The maximum number of satellites and subwoofers that can
be used in a system will depend on the amplifier power,
refer to the SLS wattage calculator on the Sonance website
(www.sonance.com/outdoor/sonance-landscape-series/subwoofers).
In-Ground Subwoofer
Subwoofer
1
LSV10SUB IN-GROUND SUBWOOFER
INSTRUCTION MANUAL

Subwoofer Installation
70 volt audio systems allow for speakers to be daisy chained
together. In a typical system with one zone of audio you simply run a
stereo or 4 conductor wire from the amplifier to the closest speaker.
Once you have designated your first speaker as either left or right,
continue alternating the wires between the left and right channels
creating a daisy chain of stereo satellites. The Subwoofer can be
wired anywhere in the chain. See Figure 4.
NOTE: SONANCE STRONGLY RECOMMENDS THE USE OF 14
GAUGE, OR LARGER, DIRECT BURIAL GRADE WIRE.
CAUTION: THE AMPLIFIER SHOULD NOT BE CONNECTED
TO AC POWER UNTIL ALL CONNECTIONS ARE COMPLETED.
HIGH POWER 70VOLT AMPLIFIERS PRESENT A SERIOUS
SHOCK HAZARD. DO NOT CONNECT SPEAKER WIRES TO THE
AMPLIFIER UNTIL ALL OTHER CONNECTIONS ARE COMPLETED.
1. Locate the subwoofer in an area that will not flood with
standing water.
2. Dig the hole using the guide. See Figure 2
LSV10SUB: A=4” B=14” C=10”
4. Place the subwoofer into the ground.
5. Fine tune the enclosure depth as required so that the bottom of
the canopy will be 4” above the finished grade after backfill.
6. Dig a 4” – 5” deep trench to run the speaker wires in.
7. Run the wire through the trench from your amplifier to the first
speaker location.
8. Connect the direct burial wire to each speaker wire, connections
should be made with either silicone filled wire connectors or
appropriate junction boxes. See Figure 3.
3. Prepare a ‘bed’ for the subwoofer that is reasonably free of
voids and large rocks.
A
BB
C
A
C
B
Figure 2
Twist
Wires
Together
Waterproof
Wire Nuts
From Speaker To Amplifie
r
Positive
+Negative
-
IMPORTANT: BE SURE NOT TO LET ANY STRAY ‘+’ & ‘–’ STRANDS
TOUCH EACH OTHER. TOUCHING STRANDS CAN CAUSE A
SHORT-CIRCUIT THAT COULD DAMAGE YOUR AMPLIFIER.
NOTE: CONFIRM THAT YOU HAVE CONNECTED SPEAKER “+”
TO AMPLIFIER “+” AND SPEAKER “–” TO AMPLIFIER “–”.
9. After all the speaker connections are completed, connect the
wires to your amplifier. See Figure 4 for reference.
10. Turn your amplifier on and test the system with your favorite
music. If the speakers are operating properly, refill the wire
trench and enjoy your new speakers.
SLS Wiring Diagram 70V
ExpandableConfiguration: 4 SATs to 1 SUB or up to 8 SATs to 1 SUB
Sonamp DSP 2-750 Amplifier
LS48SATs/LS68SATs & LSV10SUB
LeftLeft RightRight LeftLeft RightRight



Figure 4
Note: The subwoofer can be
connected at any point in the
daisy chain.
Figure 3
2
SLS LSV10SUB IN-GROUND SUBWOOFER INSTRUCTION MANUAL

Specifications
LSV10SUB
Woofer: 10” (254mm) polypropylene cone with a
Santoprene rubber surround
Frequency Response: 35Hz – 100Hz ±3dB
Transformer: 70V/300W
Enclosure Material: 1/2” (LDPE) non-corrosive sealed enclosure
Finish: Black enclosure, dark brown textured canopy
Dimensions: Overall
Width: 17” (431mm)
Height: 23 21/32” (599mm)
Woofer Enclosure
Height: 15 3/4” (400mm)
Diameter: 12 3/16” (310mm)
Canopy
Height: 8 15/32” (215mm)
Diameter: 17” (431mm)
Shipping Weight: 46.3 lbs (21 kg)
3
SLS LSV10SUB IN-GROUND SUBWOOFER INSTRUCTION MANUAL
Canopy
Diameter
Woofer
Enclosure
Diameter
Overall
Width
Canopy
Height
Woofer
Enclosure
Height
Overall
Height
