Sonder Siesta 105 WiFi User manual

Siesta 1 05 WiFi
C h r o n o t h e r m o s t a t W i F i
Code: 29.101
Instructions Manual
Smart chronothermostat with WiFi communication
Heating / Cooling includes App Sonder Home
26.0
23.8
°
33.6

Cód: 8052VØ MAR20
Warnings
Safety instructions
- For any manipulation, either while installing or repairing,
the control must be disconnected from the mains.
- Assembly, electrical connection, commissioning and
maintenance should only be carried out by qualified
personnel.
- It is an independent control device for surface mounting
on a 60 mm diameter junction box.
- The electrical connections can only be those indicated in
this manual and on the device connection label.
- Before installing the control, make sure that the
environmental conditions are the necessary, working
temperature, humidity, pollution and emission of gases,
since any of these factors can affect its correct operation.
- This control is not a safety device, nor can it be used as
such, it is the responsibility of the installer to incorporate
the appropriate protection to each type of installation
(approved).
UNE-EN 60730-1 + A1: 2005 + A12: 2004 + A13: 2005
- In case of doubts about its operation or its correct
installation, do not connect the device to the mains and
consult a professional technician.
- Sonder Regulación S.A. reserves the right to make
changes related to the product, technical data, or
assembly and use instructions without prior notice.
- In case of visualizing possible defects in the device that
could cause damage or a malfunction in the
installation, do not connect the device.
Designed and manufactured according to:
UNE-EN 60730-2-1: 1998 + A11: 2005
Warranty conditions
We decline all responsibility for damaged devices, as a
result of mishandling, omission of the warnings in this
manual or technical ignorance of the installation's needs.
For any repair under warranty it is necessary to present
the documentation proving the purchase of the product
within the term of validity of this warranty and a
description as exact as possible of the defect or the
anomalous behavior of the product according to the user.
If the repair is out of warranty, the user will be informed
of the feasibility and cost of it. The valuation of our
technical department may involve an additional cost for
the user.
This device has a 3-year warranty, it is limited to the
replacement of the defective part and will be delivered in
the same material reception conditions, packaging,
batteries, instructions or any other accessory that
includes this product will not be replaced.
Appliances with natural wear or improper use of the
equipment.
The costs resulting from the shipment or receipt of the
material.
They are out of warranty:
Devices whose serial number has been damaged,
deleted or modified.
Modified devices without prior agreement with the
manufacturer.
Devices whose deterioration is the result of crashes or
liquid or gaseous emanations.
Compensation requirements due to loss of earnings,
compensation for use as well as indirect damages,
provided they are not mandatory under the law
Devices whose connection or use have not been
executed according to the instructions attached to the
device.
Directive 2012/19 / EU on waste electrical and
electronic equipment (WEEE) The product and its
packaging must be disposed of at the corresponding
recycling center
MADE IN
SPAIN
3
años RoHS
Compliant

Warnings
Presentation
Content
Characteristics
Functioning
Installation
Thermostat
Display
Keyboard
4
5
............................................................................................................ 6
............................................................................................................... 6
....................................................................................................... 6
............................................................................................................ 7
.................................................................................................................. 8
.................................................................................................................. 10
INDEX
Location
Connection and Examples
.............................................................................................................. 6
..................................................................................... 7
App
App Installation
IOS
Android
........................................................................................................................ 16
................................................................................................................. 18
Leds Receiver 12
Botón reset WiFi 12
Home
Registros (Logs)
Programación (Programming)
.................................................................................................................... 13
..................................................................................................... 13
............................................................................... 14
..........................................................................................15
Configuración (Setting)
App ...................................................................................................................... 12

4
Content
Thermostat
Link Box
Ø3,6x13 mm
Physical
Thermostat:................................... 105 x 105 x 25 mm
Link box:............................................ 76 x 76 x 30 mm
Placa TA Ø60 (oponal code 3.970):... 85 x 85 x 5 mm
Weight net:......................................................... 119 g
Weight gross:...................................................... 139 g
Display e-ink:......................................................... 2,7"
Techniques
Power Supply Link box:......................... 230V~ 50/60Hz
Setpoint temperature range:.............. from 5°C to 35°C
Reading room temperature:....................... 0°C to 40°C
Storage temperature:........................... maximum 50°C
Breaking power (contacts):...................... 5(1)A 250Vac
2
Maximum section of the cable to connect:...... 1,5mm
Wiring Type:..................................................... H-05V-K
Degree of protection:............................................. IP20
Pollution Degree:......................................................... 2
Software:........................................................... Clase A
Type of Action according to EN 60730:.................... 1.B
Approved:.................................................................. CE
Communicaon
Compable with: ........... Wi-Fi 802.11 b/g/r (2,4GHz)
Support Wi-Fi security: .................. Open/WEP/WFA/
WPA2-personal (TKIP y AES)
Distance between thermostat and receiver: .... 75 m
Presentaon
Optional accessory Code: 3.970
Placa TA (installaon plate + screews)
UP
router
Link Box
Boiler
App
CLOUD
Thermostat
Characteristics
Functioning
The Siesta 105 WiFi is a smart thermostat for heating or
cooling and App with WiFi communication. Through the
Sonder Home App, access the advanced settings.
First of all we thank you for the purchase and trust placed
in the equipment and we hope that it meets the needs of
your installation.
You can program the operation, configure the parameters,
you can even lock the thermostat keyboard so that it can
- Download App and install on mobile phone (page 7)
- Install junction box and thermostat without connecting the
power.
- Power the box and press ready in the App to synchronize
only be adjusted from the App. Steps to follow:
- Finish installing the App

Thermostat
Installaon
Before any manipulation make sure that the electric current is disconnected.
The connection cables between link box-thermostat / link bop-boiler must not exceed 75 meters, of type H-05V-K, flexible
2-wire.
1.50m
Location
Must be installed away from sources of heat, direct sunlight or drafts. Height 1.5m approximately to facilitate visibility .
before fixing it to the wall check the coverage between the thermostat and the wifi
3 - 7mm
UP
UP
click!!
UP
Link boxInstallaon plate (oponal)
Location
Keep at least 30 cm away from other electronic devices.
Max. 9mm
S. 1,5mm
2
5

6
Boiler combined acon All/Nothing 2-way zone valve powered at 230V ~ All/Nothing acon
Connecon and Examples
Boiler powered at 230V ~ All/Nothing acon Boiler Modulang acon
When there is a power failure, the receiver may take 1 minute to recover the synchronizaon with the thermostat,
but it saves all data and sengs.
T1
T2
LN
T2
T1
M2
M1
N
L
N L
230V~
230V~ 50/60Hz
N L
N
L
N L
T2T1
230V~
230V~ 50/60Hz
T1T2 M1M2
T1
T2
LN
T2
T1
M2
M1
N
L
N L
230V~
230V~ 50/60Hz
M1M2
N L
N
L
N L
T2T1
230V~
230V~ 50/60Hz
T1T2 M1M2
LN
T2
T1
N
L
230V~ 50/60Hz
!
The connecon between
thermostat and Link box
has polarity, if you see
this screen on the
thermostat it means that
you have to exchange
the posion of the wires.
NO C
43
Link box
2
1
Relay/Boiler
N
6
F
5
90...250V~
50/60Hz
5(1)A
21
Thermostat

Forgot password?
[email protected]
.........|
Sign In
Sign In
Choose Wi-Fi network
your device will use
Continue Ready
Power On your device and make sure that
indicator is breathing blue
Check your device
You don’t have any devices
connected yet
Click the button below to start adding
a new device
App Android
Download App
From the Google Play Store download the Sonder Home app and install.
Install
WiFi configuraon on the device to control
Add new device
14
Sonder Home
Wi-Fi setup
14
Choose Wi-Fi network
password
1 2 3 4 5 6 7 8 9 0
q w e r t y u i o p
a s d f g h j k l ñ
z x c v b n m
, .
Español (ES) Ir
!#1
x
GIF
Open App & create new account
to which devices will be associated
Add device to control
The App needs locaon
permission only to view
available WiFi networks
It asks you to connect the receiver
to the power, when the blue light
of the receiver turns on and off
slowly, press Ready
WiFi Password
7
Home
Sonder
Log In
Create New Account
Home
Sonder
It asks for mail and password to
create a user.
Remember the network for other devices
WiFi network (Invalid 5G)
WiFi data where the device
to be controlled will be connected

8
Choose your device
NAME DEVICE
Siesta 105 WiFi
Connecting to device
Cancel
Sending home WiFi data to the device to be controlled
Customize product
Add device
Configuring Wi-Fi
Configuring device
Configuring Wi-Fi
Waiting for the device
Configuring device
Configuring Wi-Fi
Waiting for the device
Final check
Configuring device
Siesta 105 WiFi
connected!
Continue
+ Add another device
Siesta 105 DE6B4
DEVICES
Siesta Device - DE6B4
OTHER NETWORKS
You can change the name and icon
Wait, or try resetting the device and set it up again
Your device couldn’t connected to the network
Retry
Connecting to device
Connecon error screen
Appears when the WiFi sengs on
the device fail
Check WiFi status and configuraon
data
WiFi synchronizaon with the device to be controlled

9
MY Devices
Log out
ON
23.6°C
0 50
22.8°C
Auto
+
-
45.1%
HOME REGISTROS PROGRAMACIÓN CONFIGURACIÓN
Siesta 105 WiFi
Delete product
Device access menu*
i
Siesta 105 WiFi
Delete
Set up Device
DEVICE NAME
Siesta 105 WiFi
Device Info
FIRMWARE VERSION
0.6.1
Online since 07:02 Jul 24, 2019
Add new device
Comedor
Wasn’t online yet
Sonder Home
Main App screen
Comedor
TERMOSTATO
27.9
°C
Habitaciones
TERMOSTATO
--
Apartamento
TERMOSTATO
27.9
°C
WiFi
disconnected
device*
WiFi
connected
device
Informaon and
configuraon of
the devices.
- Last connecon
- Name
- Icon
- Add Device
If you press Log out
you leave the App
and can re-enter
with another user
and password
Click on the device to access the
configuraon menu.
Confirm changes
* If you click on you also enter
the device access menu
i
Disposivos
* Check the status of the WiFi and
if correct, turn off the power to the
receiver, wait 10 seconds and turn
on again

26.0
23.8
°
33.6
From the App you can set parameters, regulaon mode (heang or cooling), schedule a schedule and check records. The
regulaon of the room can be manually or automacally (it has me programming for independent heang and cooling).
The thermostat has a basic operaon, the setpoint temperature rises or falls (desired room temperature). If it is in
programmed (automac) regulaon mode, it will return to its programming in the following period. You can also turn off
(an-freeze setpoint).
From the App you can lock the keyboard of the thermostat so that it cannot be manipulated. Public spaces, schools,
shelters, public places.
Thermostat display
WiFi Failure
Setpoint
Temperature
Relave
Humidity
Environment
Regulaon mode*
Heang
Cooling
Fault or Failure
!
Room temperature
Keyboard
Increase the setpoint
temperature
Turn off the regulaonDecrease the setpoint
temperature
* Only the icon is displayed when it is running
10

11
Screen that appears 3 seconds when we try to
raise or lower the setpoint from the thermostat
and we have locked the keyboard from the App.
If we press the buon for 2 seconds, the
thermostat is turned off, it disables the regulaon
and keeps the anfreeze.
Off
Locked
23.8
°
OFF
Screen that appears when it detects that the
baery level is running low and does not
guarantee proper operaon.
Exhausted baeries

Screen that shows you all the devices linked in the applicaon.
- It allows to have several devices in the same house (thermostats by zones).
- Allows you to configure several devices in several houses (second residence,
tourist apartments, ...). You will have to configure on each device the WiFi
you will use.
- It allows to be installed in several mobiles (configuring in Log In the same
username and password) so several people can access to control the same
thermostat.
- From the menu you can access the configuraon / erase screen of devices
(page 9).
12
Sonder Home App
App Display
Sonder Home
Comedor
TERMOSTATO
27.9
°C
Leds
Disposivos
Blue to indicate WiFi status Green when powered at 230V ~
Red when the relay is acvated
Orange has no communicaon with
the thermostat (they are far away)
- Blinks fast when you do not have WiFi configured.
- Turn on and off slowly when you are waing to receive
WiFi sengs.
- Off when the connecon to the WiFi is correct.
Thermostat Link box (hidden under the cover)
Hole on the right side of the thermostat
Clear Wi-Fi settings on the device
- Press 10 seconds
- Disconnect from power
- Wait 10 seconds
- Connect to the power
WiFi reset buon

Regulaon mode Heang / Cooling (From Factory: Heang)
13
HOME REGISTROS PROGRAMACIÓN CONFIGURACIÓN
Datos registrados
Señal WiFi termostato
Señal radio termostato - receptor
89%
Graph with recorded temperature and humidity readings
WiFi signal strength received by the thermostat
RF signal strength between thermostat and receiver
Registros (Logs)
- It can show temperature, humidity or both at the same me.
- Pressing on humidity or hidden temperature / shows the values
- Clicking on the period shows the graph for that period
- Pressing ... lets you export a CSV format file or delete data
- Pressing shows you the record in full screen
HOME REGISTROS PROGRAMACIÓN CONFIGURACIÓN
23.6°C
0 50
22.8°C
Auto
+
-
45.1%
ON
Room temperature
Desired temperature (select setpoint - / +)(From Factory: 20°C)
Relave humidity in the environment
Baery charge status
ON / OFF thermostat buon
Main display for thermostat
Home
Manual / Automac Mode (Programmed)(From Factory: Manual)
62%

14
Programación (Programming)
HOME REGISTROS PROGRAMACIÓN CONFIGURACIÓN
20.0°C
+
-
Clicking on the icon choose the regulaon mode
Set the regulaon mode and program it
Heang or Cooling
Calefacción
00:00 Change, has 8 changes for heang and 8 for cooling
22.8°C
+
-
13:00
Tue, Wed, Thu, Fri, Sat, Sun
Pressing icon acvates / deacvates that period without deleng it
Desired temperature (setpoint)
Clicking on the me sets the me of the change and the days to make it.
If no day is selected, the program considers that the change is made for
every day.
Program the operation of heating and cooling with total freedom, changes are configured where time, temperature and
applicable days are indicated. You can memorize up to 8 changes.
It can also work in manual mode, indicating only the temperature.
In future versions you will also have the intelligent GeoFence (geolocation) function that adapts the programming to your
life rhythm, detecting its location.
If we have the GeoFence function activated, when it detects that we enter the distance radius assigned to home, it
activates the regulation in the mode defined in the App, Manual or Automatic (with time programming).
When it detects that we leave the radio assigned to home, it passes the value of the temperature setpoint to that defined
in the GeoFence parameter of the configuration menu.
24.5°C
+
-
07:00
Everyday
17.0°C
+
-
21:00
Everyday
Programming example with two changes configured.
The heang would turn on at in the morning and maintain the 07:00
temperature of all day, unl the next change that would be the second 24.5°C
at , and would regulate about all night, unl the next change that 21:00 17.0°C
would be the first change again at in the morning. As the changes are set 07:00
for every day, I would have all week scheduled.

15
MAX
MIN
23.0
°
+
Scale: 5.0°C ... 35.0°C
Scale: -10.0°C ... 10.0°C
Scale: 5.0°C ... 35.0°C
From factory: 0.3°C
Scale: 4.0 ... 9.0°C
Scale: Activated ... Deactivated
Scale: 0.1°C ... 3.0°C
From factory: 35.0°C
From factory: 5.0°C
From factory: OFF
Scale: Enabled ... Locked From factory: Enabled
From factory: 0.0°C
From factory: 5.0°C
Configuración (Configuraon)
HOME REGISTROS PROGRAMACIÓN CONFIGURACIÓN Display to adjust thermostat operaon
Límite temperatura máxima para la consigna (Maximum temperature limit for the setpoint) - Limit
value at which the desired temperature can be raised. Ideal for public places and tourist apartments.
Calibración lectura sensor interno (Internal sensor reading calibration) - Adjusts the temperature
displayed on the screen
Límite temperatura mínima para la consigna (Minimum temperature limit for the setpoint) - Limit value
at which the desired temperature can be lowered. Ideal for public places and tourist apartments.
Diferencial de temperatura de activación (Activation temperature differential) - The temperature
difference you need between the ambient temperature and the desired temperature (setpoint) to start
the accumulator. Example: The setpoint is at 22°C, it will stop boiler when it reaches 22°C and turn on
again when it reaches 21.7°C.
Protección antihielo (Frost protection) - Prevents the ambient temperature from falling below the
defined value to protect against damage to the installation by freezing the pipes.
Protección de la bomba recirculadora (Recirculation pump protection) - The recirculation pump is
activated for 1 minute every 24 hours avoiding blockage during long periods of inactivity
Teclado del termostato (Thermostat keypad lock ) - Cancels the thermostat keypad to limit access, only
the temperature can be modified from the App. Ideal for public places and tourist apartments.
Página de ayuda (Help page) - Link to the online manual of the device.
Reset de valores y programación (Reset of values and programming) -
Deletes all the adjustments made in programming, configuration and
setpoint temperature, leaving all the values with the factory settings.
Página de ayuda
Pulsando borrará todos los
cambios realizados en la programación
y volverá a valores de fábrica
!
Restaurar valores de fábrica

Avenida la Llana N° 93
P.I. La Llana 08191 RUBÍ
(Barcelona) - España
Telf.: [phone]
Fax: [phone]
www.sonder.es
[e-mail]
SONDER REGULACIÓN S.A.
